Symmons Elm 553RH Manual

1
553RH, 553TB-18, 553TB-24, 553TP, 553TR
Elm™Accessories
Operation & Maintenance Manual
Model Numbers Specifications
553RH Robe Hook
553TB-18 18" Towel Bar
553TB-24 24" Towel Bar
553TP Toilet Paper Holder
553TR Towel Ring
All premium accessories made from brass plated in
standard polished chrome nish.
Modifications Warranty
-SBZ Seasoned bronze finish
-STN Satin nickel finish
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information
Note: Append appropriate -sufx to model number.

2
Note: Dimensions are subject to change without notice.
Dimensions
Measurements
A2 3/8”, 60 mm
B3 5/8”, 92 mm
C3”, 76 mm
D7”, 178 mm
E7 7/8”, 200 mm
F3 1/4”, 83 mm
G7 3/8”, 187 mm
H2 1/8”, 55 mm
I9 1/2”, 241 mm
J3 1/4”, 83 mm
K17 3/8”, 441 mm
L19 1/2”, 495 mm
M22 5/8”, 575 mm
N24 3/4”, 629 mm
Required for Installation
Phillips head
screwdriver
Allen wrench (3/16")
AA
B
B
HH
H
H
H
H
K
K
L
L
M
M
N
N
G
G
D
D
E
E
F
F
I
I
J
J
J
J
C
C
J
J
553RH
553TB-18
553TB-24
553TP
553TR
Replacement Parts
Description Part Number
Mounting
Hardware Kit HW-03141

3Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3025 REV A 05/13/2015
Installation
1) Measure and mark centerlines
for mounting bracket installation
using dimensions on page 2.
Notes: 553TB-18 and 553TB-24 only.
Make sure both centerline marks are
level.
2a) Dry Wall Option: Place mounting
brackets into desired position.
Using brackets as a guide,
carefully drill 5/16" holes into
wall. Remove brackets and
install anchors.
2b) Stud Option: Place mounting
brackets into desired position.
Using brackets as a guide,
carefully drill 3/16" holes into
wall.
3) With mounting brackets in
position, secure to wall using
screws.
4) Hang top of accessory on
mounting bracket. Lower into
position.
5) Secure with set screw.
1
3
3
2
1
2
1
2
1
2
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Note: For plaster walls 1/2” thick or
less, insert toggle tool into toggle to
secure behind wall prior to installing
accessory trim.
