Symmons Duro 3600-TRM Installation instructions

Duro®
Model Numbers
Duro Trim Series
Duro Trim Series with TA-10 Flow Control Spindle & T-12A Cap Assembly
Installation & Operation Instructions
TRIM ONLY
3600-TRM
Shower Valve Trim
3601-TRM
Shower Trim
3602-TRM
Tub/Shower Trim
3603-H321-V-TRM
Hand Shower Trim
3605-H321-V-TRM
Shower/Hand Shower Trim
3606-H321-V-TRM
Tub/Shower/Hand Shower Trim
3620-TRM
Shower Valve Trim
3621-TRM
Shower Trim
3622-TRM
Tub/Shower Trim
3630-TRM
Shower Valve Trim
3631-TRM
Shower Trim
3632-TRM
Tub/Shower Trim
Compliance
• ASME A112.18.1/CSA B125.1
Limited Lifetime - to the original end purchaser in consumer/residential installations.
5 Years - for industrial/commercial installations.
Refer to www.symmons.com/warranty for complete warranty information.
Go to www.symmons.com/register to register your Symmons product.
TRIM, TA-10, T-12A
3600TRMTC
Shower Valve Trim
3601TRMTC
Shower Trim
3602TRMTC
Tub/Shower Trim
3603H321TRMTC
Hand Shower Trim
3605H321TRMTC
Shower/Hand Shower Trim
3606H321TRMTC
Tub/Shower/Hand Shower Trim
3620TRMTC
Shower Valve Trim
3621TRMTC
Shower Trim
3622TRMTC
Tub/Shower Trim
3630TRMTC
Shower Valve Trim
3631TRMTC
Shower Trim
3632TRMTC
Tub/Shower Trim
Warranty
3600-TRM
3600TRMTC
3601-TRM
3601TRMTC
3602-TRM
3602TRMTC
3620-TRM
3620TRMTC
3621-TRM
3621TRMTC
3622-TRM
3622TRMTC
3630-TRM
3630TRMTC
3631-TRM
3631TRMTC
3632-TRM
3632TRMTC
3605-H321-V-TRM
3605H321TRMTC
3603-H321-V-TRM
3603H321TRMTC
3606-H321-V-TRM
3606H321TRMTC
TA-10T-12A

2
SS
TT VV
UU
WW
XX YY
ZZ
1. Recommended Tools
A
G
H
K
L
E
B
D
F
M
O
Q
RP
FLOOR
N
I
C
J
FIGURE 2 Measurements
A Ø 2-1/2", 64 mm
B 6", 152 mm
C 6", 152 mm
D
Male 1/2-14 NPT thread
must be recessed 1/4" (6 mm)
from finished wall
E Ref. 77", 1956 mm
F 3-1/2", 89 mm
G Sq. 5", 127 mm
H Sq. 7-1/2", 191 mm
I Ø 2-1/2", 64 mm
J Ref. 10", 254 mm
K
3600, 3601, 3603, 3605:
Ref. 42", 1067 mm
3602, 3606:
Ref. 32", 813 mm
L Ref. 12", 305 mm
M 3-1/8", 79 mm
N 3-1/2", 89 mm
ORough-in
2-3/8" ± 1/2", 60 mm ± 13 mm
P 5-1/4", 133 mm
Q 7", 178 mm
R
Male 1/2-14 NPT fitting
must protrude 5-1/4" (133 mm)
from finished wall
S 3-5/8", 92 mm
T 3-1/8", 79 mm
U 3-5/8", 92 mm
V 3-1/8", 79 mm
W Ø 2-1/2", 64 mm
X
Male 1/2-14 NPT thread must
protrude 5-1/2" (140 mm)
from finished wall
Y 5-1/2", 140 mm
Z 7", 178 mm
Notes:
1) Valve body and piping not included and shown as reference only.
2) Plaster shield (p/n T-176) for dry wall, plaster or other type walls 1/2" or greater.
3) All dimensions measured from nominal rough-in (see O as reference).
4) Dimensions subject to change without notice.
Phillips Screwdriver
Adjustable Wrench Safety Glasses Thread Seal TapeDrill Allen Wrench (2mm)
FIGURE 1
2. Dimensions

3
5. Installation - Adjust Packing Nut (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle over flow control spindle.
3) Tighten packing nut for positive frictional resistance as handle is rotated from shut-o position across adjustment range.
6. Installation - Setting Limit Stop Screw (Model Numbers Ending in TRMTC)
1) Turn hot and cold supplies on. Valve will not operate unless both hot and cold water supply pressures are on.
2) Place handle on flow control spindle and open valve to maximum desired temperature.
3) Turn limit stop screw clockwise until it seats.
WARNING: Failure to adjust limit stop screw properly may result in serious scalding.
The temperature limit stop screw limits valve handle from being turned to maximum position resulting in excessive hot
water discharge temperatures.
3. Parts Breakdown (Model Numbers Ending in TRMTC)
4. Installation - Remove Test Cap (Model Numbers Ending in TRMTC)
1) Check for leaks around the valve assembly and all pipe
fittings.
Flow control spindle (TA-10) and cap assembly (T-12A) will
come factory assembled for all model numbers ending in
TRMTC. When ready to remove Test Cap and install trim,
follow the instructions below:
2) Remove test cap from valve (FIGURE 4.1).
3) If system is dirty, flush valve.
4) Thread flow control spindle and cap assembly into valve
body. Turn clockwise to secure to valve (FIGURE 4.2).
FIGURE 4.1 FIGURE 4.2
LIMIT STOP
SCREW
2
1
PACKING
NUT
FIGURE 3
Replacement Parts
Item Description Part Number
1 Cap Assy. T-12A
2 Flow Control Spindle TA-10
IMPORTANT: Model numbers ending in TRMTC
coordinate with Temptrol pressure balancing valves
ordered with Test Cap. The Test Cap is used to
allow pressurization of system. Do not remove
test cap from valve during wall construction,
installation of valve or pressurization of system.
WARNINGS:
1. Do not expose valve with test cap to heat
for longer than 2 minutes when soldering
copper tubing. Doing so may damage the
internal components of the valve and will
void the product warranty.
2. Ensure test cap is tightened securely after
soldering valve body.

4
Replacement Parts
Item Description Part Number
A Showerhead 362SH
B
C
Shower Arm
Flange 300S
D Standard Handle T-617
D2 Metal Lever Handle RTS-092
D3
D4
D5
Metal Lever Handle
Handle Flange
O-ring
RTS-093
DF-6
DF-25
E Dome Cover RTS-037
F
G
H
Diverter Escutcheon
Screws
Mounting Plate
RTS-040
I
J
K
Shower Escutcheon
Screws
Mounting Plate
RTS-001
L
L1
Tub Spout
Diverter Tub Spout
067
352TS
M
N
O
Slide Bar
Assembly RA-009
P Hand Shower EF-100
Q Wall Elbow EF-105
R 60" Hose RTS-045
L
IJ
J
K
L1
D2
D3
R
P
Q
FIGURE 7
O
MN
A
B
C
D
E
D
E
FG
G
H
D4
D5
EF-109*
*Order in-line vacuum breaker (EF-109) for
hand shower systems without dual checks.
7. Parts Breakdown
Notes:
1) Append appropriate sux for premium finish.
2) Append appropriate flow rate to showerhead
or hand shower for low flow.
3) Apply a bead of silicone around the perimeter
of all shower trim installed flush to the
finished wall. Leave opening on bottom of
escutcheons for weep hole.
4) Apply plumber tape to threaded connections
as necessary. DO NOT use plumber tape on
fittings with face seal washers or o-rings.
5) DO NOT OVERTIGHTEN fittings with face seal
washers or o-rings.

5
8. Installation - Shower Valve Trim
1) Secure large mounting plate to Temptrol
pressure balancing valve using mounting screws
(FIGURE 8.1).
2) Secure large shower escutcheon to mounting plate.
Tabs should snap in place (FIGURE 8.2).
3) Install dome cover by turning clockwise (FIGURE 8.3).
4) Install handle to shower valve. Secure with set screw
(FIGURE 8.4).
FIGURE 8.1 FIGURE 8.2
FIGURE 8.3 FIGURE 8.4
9. Installation - Diverter Valve Trim
2) Secure small diverter escutcheon to mounting plate.
Tabs should snap in place (FIGURE 9.2).
1) Secure small mounting plate to Symmons diverter valve
using mounting screws (FIGURE 9.1).
FIGURE 9.1 FIGURE 9.2
4) Install handle to diverter valve. Secure with set screw
(FIGURE 9.4).
FIGURE 9.3
3) Install dome cover by turning clockwise (FIGURE 9.3).
FIGURE 9.3
1) Attach arm and flange to shower pipe. Turn clockwise
to tighten (FIGURE 10.1).
2) Install showerhead to shower arm. Turn clockwise to
tighten (FIGURE 10.2).
3) Install tub spout to stub out pipe. Turn clockwise to
tighten (FIGURE 10.3).
FIGURE 10.1 FIGURE 10.2
FIGURE 10.3
10. Installation - Showerhead & Tub Spout

6
1a) Dry Wall Option: Remove upper and lower caps
from slide bar brackets. Place slide bar into desired
position. Using brackets as a guide, carefully drill 3/16"
holes into wall. Remove slide bar and install anchors.
Note: Slide bar holes and bracket holes must be
aligned before drilling. Before drilling bottom hole,
make sure slide bar is plumb (FIGURE 11.1A).
1b) Stud Option: Remove upper and lower caps
from slide bar brackets. Place slide bar into
desired position. Using brackets as a guide,
carefully drill 1/8" pilot holes into stud.
Note: Slide bar holes and bracket holes must be
aligned before drilling. Before drilling bottom hole,
make sure slide bar is plumb (FIGURE 11.1B).
2) With slide bar in position, secure to wall using screws.
Replace upper and lower caps onto slide bar brackets
(FIGURE 11.2).
3) Install wall elbow to stub out pipe. Tighten set screw to
secure (FIGURE 11.3).
4) Attach small end of hand shower hose to wall elbow.
Turn clockwise to tighten (FIGURE 11.4).
1
2
3
FIGURE 11.1A
FIGURE 11.3
FIGURE 11.4
FIGURE 11.1B
1
2
1 3
2
FIGURE 11.2
11. Installation - Slide Bar Assembly
5) Attach large end of hand shower hose to hand shower
wand. Turn clockwise to tighten (FIGURE 11.5).
FIGURE 11.5

7
12. Operation (Temperature Control)
1) Turn shower handle counter-clockwise
approximately 1/4 turn to put valve in
cold position (FIGURE 12.1).
2) Turn shower handle counter- clockwise
approximately 1/2 turn to put valve in
warm position (FIGURE 12.2).
3) Turn shower handle counter- clockwise
approximately 3/4 turn to put valve in
hot position (FIGURE 12.3).
FIGURE 12.1 FIGURE 12.2 FIGURE 12.3
13. Operation (Dual Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 13.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 13.2).
3) Turn handle to position 3 to share
functions 1 and 2 (FIGURE 13.3).
FIGURE 13.1 FIGURE 13.2 FIGURE 13.3
14. Operation (Triple Outlet Diverter Control)
1) Cartridge is factory set to divert to
function 1 (FIGURE 14.1).
2) Turn handle to position 2 to divert to
function 2 (FIGURE 14.2).
3) Turn handle to position 3 to divert to
function 3 (FIGURE 14.3).
FIGURE 14.1 FIGURE 14.2 FIGURE 14.3
4) Turn handle to position 4 to share
functions 2 and 3 (FIGURE 14.4).
5) Turn handle to position 5 to share
functions 1 and 3 (FIGURE 14.5).
6) Turn handle to position 6 to share
functions 1 and 2 (FIGURE 14.6).
FIGURE 14.4 FIGURE 14.5 FIGURE 14.6
Note: Additional handle positions for
same output are illustrated.

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2019 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3281 REV A ■ 062419
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth
defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
15. Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then quickly
rinse with water.
