Symmons Winslet S-5104-TRM Manual

S-5104-TRM
Winslet®Tub/Hand Shower Trim
Operation & Maintenance Manual
Model Numbers Specifications
S-5104-TRM Tub/Hand Shower Trim Tub/hand shower trim with lever handle and secondary
integral diverter handle includes wall cradle for hand
shower mounting, non-diverter tub spout, in-line vacuum
breaker, exible metal hose and 1 mode hand shower
with 2.5 gpm (9.5 L/min) ow restrictor. Components
made from metal and nonmetallic materials plated in
standard polished chrome nish.
Modifications Compliance
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-462HSB 30" slide bar in place of wall cradle on
hand shower units
-STN Satin nickel finish
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Note: Append appropriate -sufx to model number.
CG

Dimensions
2
Measurements
A 2 1/8", 54 mm
B Ø 7 1/2", 191 mm
C 6", 152 mm right or left
D 40", 1,016 mm
EMale 1/2" IPS thread must
protrude 1/2" from nished wall
F 2 5/8", 67 mm
G 32", 813 mm
H 12", 305 mm
I 2 7/8", 73 mm
J 3 1/2", 89 mm
K 1/2" NPT
L 1/2", 13 mm
M(Rough in)
2 3/8" ± 1/2", 60 mm ± 13 mm
N 7 1/8", 181 mm
Notes:
1) All dimensions measured from nominal rough-in (see M as reference).
2) Dimensions are subject to change without notice.
AA
B
B
G
G
H
H
D
D
C
C
E
E
I
I
J
J
M
M
N
N
L
L
K
K
Floor
Floor
F
F

3
Parts Breakdown
Replacement Parts
Item Description Part Number
A
M
Vacuum Breaker
60" Hose EF-104
B Wall Cradle T-613
C Wall Cradle Flange T-606
D
J
Handle
Set Screw T-611
E Dome Cover T-608-PL
F
G
H
Shower Escutcheon
Mounting Screws
Mounting Plate
T-609A-NS-K001
I Hand Shower 462W
K Diverter Lever Handle T-610
L Tub Spout 512TS
Notes:
1) Append -STN for satin nickel nish.
2) Append -1.5 or -2.0 to hand shower for low ow.
Required for Installation
Adjustable wrench
Allen wrench (3/16")
Phillips head screwdriver
Plumber tape
JK
C
A
B
G
F
L
M
H
D
E
I

Installation
4
Note:
For valve body installation, please
see valve body installation guide.
1) Install mounting plate (H) onto
shower valve (S-46-2-BODY).
Secure with two screws (G).
2) Install diverter lever handle (K)
into escutcheon (F).
3) Attach escutcheon (F) onto
mounting plate (H).
4) Install dome cover (E) to valve by
turning clockwise.
5) Install handle (D) to valve.
Secure handle by tightening set
screw (J).
6) Install wall cradle ange (C) to
pipe tting by turning clockwise.
7) Attach wall cradle (B) to wall cradle
ange (C) turning clockwise to
tighten.
8) Attach large end of hand shower
hose (M) to hand shower (I). Attach
small end of hand shower hose
(M) and gasket to in-line vacuum
breaker (A). Connect in-line
vacuum breaker (A) to wall cradle
(B). Turn clockwise to tighten.
1
2
G
H
K
F
1
2
C
1
2
B
C
1
2
E
F
1
1
2
D
J
3
1
4
2
M
I
B
A
M
FH

1) Turn shower handle counter-
clockwise approximately 1/4 turn
to put valve in cold position.
2) Turn shower handle counter-
clockwise approximately 1/2 turn
to put valve in warm position.
3) Turn shower handle counter-
clockwise approximately 3/4 turn
to put valve in hot position.
1) Turn diverter left for tub spout
operation.
2) Turn diverter right for hand shower
operation.
1) Turn shower head to desired
mode of operation.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■Phone: [phone] ■ Fax: [phone]
Copyright © 2018 Symmons Industries, Inc. ■symmons.com ■[email protected] ■ZV-3078 REV A ■ 080118
Temperature Control Diverter Control Hand Shower Mode
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to
cause cancer, birth defects, or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
