Symmons Naru S-4104-TRM Manual

S-4104-TRM
Naru™Tub/Hand Shower Trim
Operation & Maintenance Manual
Model Numbers Specifications
S-4104-TRM Tub/Hand Shower Trim Tub/hand shower trim with lever handle and secondary
integral diverter handle includes wall connection, cradle
for hand shower mounting, non-diverter tub spout, in-
line vacuum breaker, exible metal hose and 3 mode
hand shower with 2.5 gpm (9.5 L/min) ow restrictor.
Components made from metal and nonmetallic materials
plated in standard polished chrome nish.
Modifications Compliance
-1.5 1.5 gpm (5.7 L/min) flow restrictor
-2.0 2.0 gpm (7.6 L/min) flow restrictor
-412HSB 30" slide bar in place of wall cradle on
hand shower units
-PNL Polished nickel finish
-STN Satin nickel finish
-ASME A112.18.1; CSA B125.1
Warranty
Limited Lifetime - to the original end purchaser in
consumer installations.
5 Years - for commercial installations.
Refer to www.symmons.com/warranty for complete
warranty information.
Note: Append appropriate -sufx to model number.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
c

2
Dimensions
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
Measurements
A Ø 2 1/4", 57 mm
B
Female 1/2" IPS thread must
be recessed 7/8" from nished
wall
C Ø 7 1/2", 191 mm
D 2 1/8", 54
E 32", 813 mm
F 12", 305 mm
G 2 1/4", 57 mm
H 3", 76 mm
I(Rough in)
2 3/8" ± 1/2", 60 mm ± 13 mm
J 1/2" NPT
K 1/2", 13 mm
L 7 1/8", 181 mm
Notes:
1) All dimensions measured from nominal rough-in (see I as reference).
2) Dimensions are subject to change without notice.
AA
E
E
F
F
B
B
C
C
I
I
L
L
K
K
J
J
Floor
Floor
D
D
G
G
H
H

3
Parts Breakdown
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
Replacement Parts
Item Description Part Number
A
R
Vacuum Breaker
60" Hose EF-104
B
C
Wall Elbow
Wall Elbow Flange T-444-KIT
D
E
Handle
Set Screw T-567
F Dome Cover T-544
G Diverter Handle T-566
H
I
J
Shower Escutcheon
Mounting Screws
Mounting Plate
T-273A-NS-K002
K Hand Shower 412W
L
M
N
O
P
Cradle Mount
Cradle Mounting Screws
Washer
Cradle Arm
Set Screw
T-545
Q Tub Spout 412TS
Notes:
1) Append -PNL to part number for polished nickel
nish; -STN for satin nickel.
2) Append -1.5 or -2.0 to hand shower for low ow.
Required for Installation
Adjustable wrench
Phillips head screwdriver
Allen wrench (1/8")
Plumber tape
C
K
H
A
B
I
R
M
L
O
J
F
D
P
N
Q
G
E

4
Installation
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
Note:
For valve body installation, please
see valve body installation guide.
1) Install plastic mounting plate (J)
to shower valve (S-4002-BODY).
Secure with two screws (I).
2) Attach secondary integral
diverter (G) to shower
escutcheon (H).
3) Attach shower escutcheon (H) to
plastic mounting plate (J).
Note: Tabs should snap into place.
4) Install shower dome cover (F)
to shower valve by turning
clockwise.
5) Install shower handle (D) to
valve. Secure handle by
tightening set screw (E).
Note: Handle should be facing the
12 o'clock position.
6) Install tub spout (Q) to pipe tting.
Turn clockwise to secure.
7) Install wall elbow (B) and
ange (C) to recessed pipe tting.
Turn elbow clockwise to tighten.
8) Press tab to remove mounting
plate (L2) from cradle mount
cover (L1).
Note: Mounting plate (L2) center
tabs must be horizontal for removal.
1
1
2
I
J
HJ
1
2
F
1
2
D
E
1
2
Q
1
2
B
C
2
1
L1
L2
GH

5
Installation
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
9) Place mounting plate (L2) in
position, mark and drill 1/8" pilot
holes into stud.
Option: Place mounting plate (L2) in
position, mark and drill 3/16" holes
into wall. Install anchors.
10) Install mounting plate (L2) .
Secure with two screws (M) .
Replace cradle mount cover (L1).
Note: Mounting plate (L2) center
tabs must be horizontal for
installation.
11) Attach cradle arm (O) and washer
(N) to cradle mount (L). Secure
with set screw (P).
12) Attach large end of hand
shower hose (R) to hand
shower (K). Attach small end of
hand shower hose (R) and gas-
ket to in-line vacuum breaker
(A). Connect in-line vacuum
breaker to wall elbow (B). Turn
clockwise to tighten.
1
3
2
L2
1
3
2
M
L2
L2
L1
3
1
4
2
R
K
A
R
B
1
2
L2
1
2
L
P
N
O

6
Care and Cleaning
1) Clean nished trim area with a soft cloth using mild soap and water or a non-abrasive cleaner and then quickly rinse
with water.
Troubleshooting Chart
Problem Cause Solution
Finish is spotting. Elements in water supply may cause
water staining on nish.
Clean nished trim area with a soft
cloth using mild soap and water or a
non-abrasive cleaner and then
quickly rinse with water.
Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184 ■[phone] ■ Fax: [phone]
©2014 Symmons Industries, Inc. ■ www.symmons.com ■ [email protected] ■ ZV-3070 REV 0 09/25/14
1) Turn shower handle counterclockwise approximately
1/4 turn to put valve in cold position.
2) Turn shower handle counterclockwise approximately
1/2 turn to put valve in warm position.
3) Turn shower handle counterclockwise approximately
3/4 turn to put valve in hot position.
1) Turn diverter left for tub spout operation.
2) Turn diverter right for hand shower operation.
Operation
Temperature Control Diverter Control
