Symmons SRT-4172 Quick guide

Step 7
Connect handspray
to hose
Step 5
Connect supply lines
Step 2
Attach faucet handles
Step 6
Connect handspray hose
Step 8
Flush water supply lines
and check for leaks
Step 3
Attach faucet spout
Step 4
Attach handspray holder
Step 1
Attach supply valves
finished deck, front view
Hot supply Cold supply
3-mode
handspray
Quick Install Guide Naru Roman Tub Faucet, SRT-4172
Plumbers
Putty
Pipe
Sealant
3/32"
1 2 3 4
Model Numbers
SRT-4172 Faucet with handspray
Alternate Finish Options
-STN Satin nickel
-PNL Polished nickel nish
- Chrome (standard)
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth defects,
or other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
Compliance
ASME A112.18.1/CSA B125.1
Roman Tub Faucet SRT-4172
Installation and Service Instructions
Tools & Materials Need Help?
Symmons customer service:
Phone: [phone]
Email: [email protected]
Monday - Friday 7:30 am - 6:00 pm EST
www.symmons.com/service


Step 1 Attach supply valves to the deck
Step 2 Attach faucet handles
3/32" Allen
wrench
OFF OFF
OFF
nished deck
front view
Step 3 Attach spout
Step 4 Attach handspray holder
Caution: If replacing an older faucet ensure water supply is
turned OFF before removing and then turn faucet handles
ON to relieve water pressure.
screw mounting retainer
down until threads stop
HOT
(red label)
COLD
(blue label)
nished deck
front view
gasket
metal washer
brass nut
washer
1
2
CAUTION
Use care while
inserting to avoid
damaging O-rings
on sharp edges
O-rings
Do not loosen or
remove set screw
rear view
Factory
assembly
remove
Installation Instructions
Page 2

Step 5 Connect Supply lines
Step 6 Connect handspray hose
Step 7 Connect handspray to hose
Step 8 Run faucet and check for leaks
Care of faucet finish
Clean finish area by using mild soap and water or non-
abrasive cleaner and then rinse immediately. A non-
abrasive wax may be used to preserve finish area.
Valve cartridge replacement
Note: Turn on
water supply
Important: Flush supply
lines clean before attaching
to control valves.
HOT supply
COLD supply
supply hoses
not included
hoses are
included
3/32" Allen
wrench
OFF
position
OFF
position
Attaching handles
17 mm deep
socket wrench
3 mm" Allen
wrench
3/32" Allen
wrench
OFF OFF
washer
washer
washer
Page 3

Finished deck thickness
1-3/8" (35 mm) max
8" (203mm) min
16" (406 mm) max
9-1/4" (235 mm)
2-1/4"
(57 mm)
2" (51 mm) dia
Hole size
1-1/16" (27 mm) min
1-1/2" (38 mm) max
Note: Dimensions subject to change without notice
Hole size
1-3/8" (35 mm) min
1-3/4" (44 mm) max
3-1/4"
(84 mm)
3-7/8"
(98 mm)
4-7/8"
(124 mm)
2-1/4"
(57 mm)
7-1/4"
(184 mm)
2" (51 mm) dia
2-1/2" (64 mm)
4" (102 mm) min
1-7/8"
(48 mm)
1-1/8" (29 mm) dia
1/2" - 14 NPSM
exible hose
handspray hose
supply outlet
8-1/2" (214 mm)
handspray hose
supply inlet
Hole size
1-1/4" (32 mm) min
1-5/8" (41 mm) max
Dimensions Naru Roman Tub Faucet, SRT-4172
handle used in
either hot or cold
location
KN-113-EXT-KIT
(Cold cartridge kit)
KN-114-EXT-KIT
(Hot cartridge kit)
(2) Note: screw requires
3mm Allen wrench
(1) Note: screw requires
3/32" Allen wrench
Hot, KN-114
(OFF=CW)
Cold, KN-113
(ON=CCW)
handle
(1)
screw
collar
KN-113
identified
by groove
handle assy.
1 ea. / kit
RT-273-KIT*
Replacement Parts
Part Number Item
(2)
screw
extension
handle kit
assembly*
(ref. table)
handspray,
3-mode
washer
elbow mount
washer
connector
washer
hose
connection
base
gasket
metal washer
nut
Cartridge
(ref. table)
Handspray Assy.
412W-41*
spout, centerbody diverter
assembly RT-280
*
Ordering replacement parts:
Call Symmons customer service at [phone], M-F 7:30 am - 6:00 pm EST or check our
website at www.symmons.com for a list of Symmons distributors.
Note: For decorative nish faucets add three letter nish sufx code to parts marked with an asterisk
*
.
mounting
retainer
gasket
1/2" hose
with 1/2-14
NPSM female
connectors
1/2" hose
with 1/2-14
NPSM female
connectors
nut, M28 x 1.5
(used when
attaching piping)
handspray hose,
0.20mm x 5 feet
ange nut
washer
metal washer
brass nut
ow
regulator
Parts Assembly Naru Roman Tub Faucet, SRT-4172
Symmons Industries, Inc. ■31 Brooks Drive ■ Braintree, MA 02184
Phone: [phone] ■Fax: [phone]
Website: symmons.com ■ Email: [email protected]
Copyright © 2018 Symmons Industries, Inc. ■ZV-590 REV C ■121018
