Symmons Symmetrix S-249 Series Quick guide

INSTALLATION:
Caution: Be sure to turn off hot and cold water supplies
before installing or servicing faucet.
1. Align flat edge of escutcheon showing logo with the back of sink.
Insert faucet supplies through holes in sink. Secure faucet to sink
by tightening flange nuts (KN-116) from underside. (If sink or
counter surface is uneven, use putty or sealant to make proper
seal under base.)
2. Connect hot supply to left tube and cold supply to right tube using
appropriate connectors.
3. It is very important to thoroughly flush the supply lines to
prevent foreign matter, i.e. copper chips, sand, stones, etc.
from damaging the sealing surfaces of cartridge. Remove
aerator (bar faucet) and turn cold valve handle on to full cold posi-
tion, open cold supply. Without closing, turn hot valve handle to
full hot position and open hot supply. Let water run in hot only and
cold only positions long enough to flush supply lines thoroughly.
Shut off faucet and replace aerator. Check for leaks.
Cartridge Replacement
Faucets with standard LCT handles
1. Remove plug button (T-33, T-33R or T-33B), loosen phillip head screw
(LN-121A) and remove handle (LN-140, LN-131 or LN-102).
Bar Sink and Lavatory Faucet, S-245 & 249 Series
Installation and Service Instructions
Symmetrix®
2. Place wrench on cartridge hex nut (KN-113, KN-114). Turn wrench
counter clockwise until cartridge is removed.
3. Install new cartridge. Turn cartridge with wrench until cartridge does
not turn easily then turn 1/4 or 1/2 turn further. Reassemble handle
in reverse fashion.
Faucets with optional LCF, LPO or LAM handles:
1. Loosen phillip oval head screw (LN-134) and remove handle (LN-152).
2. Remove collar (LN-112) by turning counter clockwise, do not use
wrench as this may damage the surface finish.
3. Place wrench on cartridge hex nut (KN-113, KN-114). Turn wrench
counter clockwise until cartridge is removed.
4. Install new cartridge. Turn cartridge with wrench until cartridge does
not turn easily then 1/4 or 1/2 turn further. Reassemble handle in
reverse fashion.
To lock spout:
1. See instructions in lock (BL-114) package.
4"
102mm
Dimensions Symmetrix®Bar Sink Faucet, S-245 and S-245-5
2"
51mm
12-3/8"
314mm
3-1/2"
89 mm
5-1/2"
140 mm
S-245-5
Long spout
S-245,
standard spout
Note: Dimensions subject to
change without notice.
3-3/8"
85mm
8"
203 mm 9-1/8"
232 mm
6-13/16"
174 mm
1-3/8" max
35 mm
2-13/16"
71 mm
5-15/16"
152 mm
1/2"-14 NPSM
2-1/8"
54 mm
hole size
min. 1" 25 mm
max. 1-1/4" 32 mm
S-245 with std LCT handles
WARNING: This product can expose you to chemicals including lead, which is known to the state of California to cause cancer, birth defects, or
other reproductive harm. For more information, go to www.P65Warnings.ca.gov.
S-249 with std LCT handles

Symmons Industries, Inc. ■31 Brooks Drive ■Braintree, MA 02184
Phone: [phone] ■Fax: [phone]
Website: symmons.com ■Email: [email protected]
Copyright © 2018 Symmons Industries, Inc. ■ZV-366 REV C ■ 060118
BL-102 Tubing assembly
BL-104* Escutcheon
BL-105* Nut, spout
BL-107* Spout (S-245 Series)
BL-106 Spout (S-249 Series)
BL-108 O-ring
BL-109 Adaptor, 3/4" hose (S-249 Series)
BL-113* Spout (S-245-5 Series)
BL-114 Spout lock
DF-30* Finial, lever, Handle (2)
KN-113 Valve cartridge, cold
KN-114 Valve cartridge, hot
KN-116 Flange nut (2)
LN-20 Gasket
LN-102 Acrylic handle (2)
LN-111* Lock ring (2)
LN-112* Collar (lever handle) (2)
LN-115 Bushing (2)
LN-121A Philips pan head screw (2)
LN-131 ADA handle (2)
LN-133A Temperature indicator (red)
LN-133B Temperature indicator (blue)
LN-134* Oval Philips head screw (2)
LN-140* Lever handle (2)
LN-147B Snap ring
LN-149 Clear, Lever, Handle (2)
LN-152* Handle lever
LN-153A White, Lever, Handle (2)
LN-153B Chrome, Lever, Handle (2)
J-21 O-ring
T-33* Plug Button (2)
T-33B Plug Button, Blue
T-33R Plug Button, Hot
*For Decorative Finish Faucets (S-245 Series
only) add sufx to parts marked with an asterisk
as follows:
Sufx -STN: Satin Nickel nish
Parts Assembly Symmetrix Lavatory / Bar Sink Faucet, S-245 & S-249
KN-114
J-21
LN-134
DF-30
LN-112
LN-152
LN-133A, LN-133B
LN-153A, LN-153B
LN-149
Handle option: LPO, LAM, LCF
Handle option: LCT
T-33, T-33B, T-33R
LN-121A
LN-102
KN-114
Cartridge used for
both hot and cold handles
BL-106
BL-109
* LN-111 not used with this handle
* LN-115 not used with this handle
BL-113
T-33
T-33B
T-33R
LN-121A
LN-140
BL-107
LN-115
KN-113
BL-105
LN-111
LN-147B
BL-108
BL-104
BL-114
BL-102
LN-20
KN-116
T-33, T-33B, T-33R
LN-121A
LN-131
Handle option: LWG
Flow Regulator
Part Number
Standard Aerator Vandal Resistant Laminar Stream Spray
(non-aerated)
2.2 gpm (8.3 L/min)
1.5 gpm (5.7 L/min)
1.0 gom (3.8 L/min)
0.5 gpm (1.9 L/min)
L-5
FLR-111-1.5
FLR-111-1.0
---
L-5VP
---
---
LL-60B
---
---
---
SWA-17-0.5-NA
---
---
---
LN-650
Removal tool part number (vandal resistant aerators), LL-60K
