Systec & Solutions CONTROL 217 PC User manual

CONTROL 217 PC
INDUSTRIAL PC
INSTRUCTIONS FOR USE
CONTROL
Read the instructions prior to performing any task!

©2013
Systec & Solutions GmbH
Emmy-Noether-Straße 17
D–76131 Karlsruhe
Telephone: [phone]
Fax: [phone]
email: [email protected]
Internet: www.systec-solutions.com
CONTROL, 1, en_US, 11.11.2015
CONTROL 217 PC - Industrial PC
2

Table of contents
1 General information................................................................................... 5
1.1 Information on the user guide........................................................ 5
1.2 Copyright notice................................................................................... 5
2 Safety................................................................................................................. 7
2.1 Designated use..................................................................................... 7
2.2 Safety notices........................................................................................ 7
2.3 Important safety notes....................................................................... 8
3 Product description................................................................................. 11
3.1 Übersicht............................................................................................... 11
3.2 Type plate............................................................................................. 12
3.3 Technical data for the device........................................................ 13
3.4 Dimensions.......................................................................................... 15
3.5 External connections........................................................................ 17
3.5.1 Overview of external connections........................................... 17
3.5.2 Description of the external connections............................... 17
3.6 Conformity........................................................................................... 20
4 Starting up................................................................................................... 23
4.1 Unpacking the device...................................................................... 23
4.2 Setting up the device....................................................................... 23
4.3 Mounting the device........................................................................ 24
5 Operation...................................................................................................... 27
5.1 Switching the device on.................................................................. 27
5.2 Switching the device off................................................................. 27
5.3 Operating the touchscreen............................................................ 27
5.4 Cleaning the device.......................................................................... 28
5.5 Using the optional USB connection............................................ 31
5.6 Setting up the WLAN (optional) .................................................. 31
5.7 Hard disk LED (optional)................................................................. 32
6 Repairs........................................................................................................... 33
7 Storage........................................................................................................... 35
7.1 Unmounting the device.................................................................. 35
7.2 Storing the device............................................................................. 36
8 Packaging and transport...................................................................... 37
8.1 Packaging the device....................................................................... 37
8.2 Transporting the device.................................................................. 37
9 Disposal......................................................................................................... 39
10 Site information......................................................................................... 41
Table of contents
CONTROL 217 PC - Industrial PC 3

Table of contents
CONTROL 217 PC - Industrial PC 4

1 General information
1.1 Information on the user guide
This translation of the original user guide is an integral part of the
CONTROL 217 PC and provides you with information on the set-up, use,
storage and disposal of the device.
Before beginning any work, read the user guide and always keep it in
an accessible place.
This user guide is aimed solely at authorized specialists. None of the
content of this user guide may be put to practice by anyone other than
trained specialists.
Our user guides are updated regularly. Please send us your suggested
improvements and other hints by e‑mail, phone or fax. This will help us
to ensure that our documentation is as intelligible and user-friendly as
possible.
You will find our contact information on the inside of the front cover or
under “Site information”. Ä Chapter 10 “Site information” on page 41
1.2 Copyright notice
This user guide is protected by copyright.
Other than for internal purposes, making this user guide available to
third parties, duplicating it in any form, in whole or in part, and utiliza-
tion or distribution of its contents are permitted only with the written
permission of the manufacturer.
Any violation of this requirement will render you liable for damages.
The right to make further claims is reserved.
General information
Copyright notice
CONTROL 217 PC - Industrial PC 5

General information
Copyright notice
CONTROL 217 PC - Industrial PC 6

2 Safety
2.1 Designated use
CONTROL 217 PC is an HMI PC system. CONTROL 217 PC is used to
implement control and operating concepts and to display and manipu-
late information in industrial and commercial environments.
It is nonetheless possible for improper use to introduce hazards. For
correct operation and safe use it is therefore important to comply with
the information and instructions in this document.
Have the following work carried out only by professionals:
nInstallation
nDeinstallation
nWiring
nImplementing
Have the following work carried out only by Systec & Solutions
GmbH :
nRepairs
nServicing
nMaintenance
nModifications
The device may not be used in the following areas:
nareas subject to explosion hazards
nareas subjected to harmful radiation
nareas and applications that are subject to vibration and impacts
nfor carrying out safety functions such as
– air traffic control / flight control systems
– monitoring / controlling nuclear reactions
– monitoring / controlling mass transportation facilities
– monitoring / controlling medical systems
– monitoring / controlling weapons systems
Contravening these instructions voids all warranties and manufac-
turer’s responsibilities.
2.2 Safety notices
Please read these instructions attentively right through. It constitutes a
part of the device it describes and must be held available at all times.
Use the device only in accordance with its designated use (see
Ä Chapter 2.1 “Designated use” on page 7).
For your own safety, always comply with the following safety instruc-
tions.
Warnings signal safety-related information.
You will find warnings within sequences of procedures prior to a step
that involves a hazard to people or material property.
Safety
Safety notices
CONTROL 217 PC - Industrial PC 7

Three levels of warnings appear depending on the seriousness of the
hazard:
DANGER!
This signals an unusually hazardous situation. Failure to
comply with these instructions will result in serious irre-
versible injuries or death.
WARNING!
This signals an unusually hazardous situation. Failure to
comply with these instructions may result in serious irre-
versible or fatal injuries.
CAUTION!
This signals a hazardous situation. Failure to comply with
these instructions may result in minor or moderate inju-
ries.
NOTICE!
This signals a hazard for material property. Failure to
comply with these instructions may cause material
damage.
This signals useful hints within a series of work processes.
2.3 Important safety notes
WARNING!
Risk of injury from electric shock!
Assembling and connecting plug connectors while
voltage is connected may lead to life-threatening injuries.
– All work on the device must be carried out when the
supply line is free of voltage.
– Never plug in or unplug the power supply plug when
live with voltage.
– The supply cable must not be supplied with voltage
until assembly has completely finished.
Safety
Important safety notes
CONTROL 217 PC - Industrial PC 8

WARNING!
Danger of injury from hot surfaces.
Power transmission and regulatory components become
hot in operation and may lead to injuries.
– Allow these components to cool down before you
begin dismounting the device.
WARNING!
Danger of injury due to excessive load.
Working on heavy equipment may lead to serious injuries.
– Always have two people when working with heavy
equipment.
DANGER!
Electric shock hazard if the device is connected to the
mains supply incorrectly.
Connecting the device incorrectly to the mains supply
may expose people to injuries from electric shocks.
– Before connecting up the device always disconnect
the line from the power supply.
– Before connecting up always check that the lines are
at zero voltage.
NOTICE!
Danger of material damage from improber use of the
mounted keyboard!
Handling the keyboard too strong like moving the entire
system may cause material damage.
– Only use immovable components to move the entire
system.
Safety
Important safety notes
CONTROL 217 PC - Industrial PC 9

Safety
Important safety notes
CONTROL 217 PC - Industrial PC 10

3 Product description
3.1 Übersicht
HMI systems from Systec & Solutions GmbH are user interfaces for man-
aging and observing ongoing production processes. All devices are
highly available units designed in stainless steel, particularly suited to
harsh conditions in the process industry and, in addition, they guar-
antee IP65 protection.
Fig. 1: CONTROL 217 PC
No. Designation Description
1 Display Used to display information.
2 On/Off button Switches the device on and off.
Optional USB connection Used to connect a USB stick.
Hard disk LED (optional) Flashes when accessing data on
the internal HDD disk.
Fig. 2: Rear view of PC
The button on the back of the monitor is used to switch the PC ON and
OFF.
HMI system CONTROL 217 PC
Device
Product description
Übersicht
CONTROL 217 PC - Industrial PC 11

Fig. 3: CONTROL 217 PC
Nr Designation Description
1 Camera/Microphone Used to record images and
sound.
2 Loudspeaker (behind the
display) Used to reproduce sounds.
3.2 Type plate
The product designation and identification will be found on the type
plate. This is always located on the rear of the device and contains the
following information:
Fig. 4: Position of type plate
Multimedia kit (optional)
Product description
Type plate
CONTROL 217 PC - Industrial PC 12

6
7
1
2
3
5
4
Fig. 5: Type plate
No. Description
1 Product name
2 Serial number
3 Power supply and consumption, charge current
and battery capacity (only for devices with an inte-
grated battery)
4 CE/FCC mark
5 Manufacturer’s logo
6 QR code (S/N + product name)
7 Manufacturer’s address
3.3 Technical data for the device
System
Model CONTROL 217
Variant Industrial PC
Housing material Front plate of stainless steel 1.4301
Surface Front surface sanded
IP protection factor IP65 on front
PC
CPU Intel ®Celeron™N2930 1.86 GHz/Burst 2.16 GHz, quad core
Intel ®Core™i3-4010U 1.7 GHz
Intel ®Core™i5-4300U 1.9 GHz/Turbo 2.9 GHz
Intel ®Core™i7-4650U 3.3 GHz
RAM 4 GB DDR3, max. 16 GB DDR3 (Celeron 8 GB)
Product description
Technical data for the device
CONTROL 217 PC - Industrial PC 13

PC
Storage capacity 120 GB SSD (optional HDD)
Operating system Windows®7 Professional 32 Bit/64 Bit
Display
Type of display 17.3" LCD display with LED backlight (Sunlight Readable optional)
Display area 382.08 x 214.92 mm
Native (maximum) resolution 1920 x 1080 (Full HD)
Page ratio 16:9
Colors 16.7 million
Brightness 400 cd/m2
Contrast 600:1
Response time 40 ms
Horizontal frequency (KHz)
Vertical Frequency (Hz)
30 ‒83 kHz
50 ‒76 Hz
Touchscreen (optional) mouse compatible, analog resistive or PCT (projected capacitive) multi-
touch
Interfaces
Standard interfaces 3x RS232, 2x USB 3.0, 2x USB 2.0 (Intel® Celeron® 1x USB 3.0, 5x USB 2.0),
1x Ethernet, additional interfaces (optional)
Power supply / consumption
(depending on the device variant)
Extra-low voltage power supply 12 ‒24 V DC, 10 ‒5 A
Protection of supply lead (Extra-low
voltage DC) max. 10 A, the supply lead should be specified.
Low voltage power supply 100 ‒240 V AC, 50 ‒60 Hz, 2,0 ‒0,9 A
Protection of supply lead (Low voltage
AC) max. 16 A, the supply lead should be specified.
Mean power consumption in oper-
ating mode 35 - 50 W (depending on configuration)
Product description
Technical data for the device
CONTROL 217 PC - Industrial PC 14

Environmental conditions
Storage -20 °C ‒+60 °C
Operation 0 °C ‒+40 °C (55 °C optional)
Humidity 10 % ‒90 %; non condensing
Dimensions (mm)
Display area W 382 / H 215
Mounting cutout See
Ä Chapter 3.4 “Dimensions” on page 15
D 40 (optional for DC)
Front panel W 504 / H 337 / D 5
Material of front panel Stainless steel 1.4301
Weight
Net weight ca. 9 kg
3.4 Dimensions
504
383(AA215)
337
216(AA215)
Fig. 6: Dimensions of front of device
Product description
Dimensions
CONTROL 217 PC - Industrial PC 15

72
0
132
192
432
153,5 153,5
237 237
138
min 28
min. 436 (cut-out)
min. 275 (cut-out)
Fig. 7: Dimensions of back of device
max60
Fig. 8: Dimensions in side view
Product description
Dimensions
CONTROL 217 PC - Industrial PC 16

504
440
R
2
6
2
337
280
237 237
153,5 153,5
28
72
0
132
192
432
Fig. 9: Image of the wall template
3.5 External connections
3.5.1 Overview of external connections
The following illustration shows the connectors that are located on the
underside of the CONTROL 217 PC.
Fig. 10: Overview of the interfaces on the underside
3.5.2 Description of the external connections
Your device will not incorporate all of the following connectors (see
Ä Chapter 3.3 “Technical data for the device” on page 13).
Product description
External connections > Description of the external connections
CONTROL 217 PC - Industrial PC 17

= 9-pole Sub-D socket for connecting serial devices
Fig. 11: Serial connection (RS ‑ 232)
= 24-pole DVI socket for connecting to the basic computer
Fig. 12: DVI socket with pinout
= 19-pole HDMI socket for connecting to the basic computer
Fig. 13: HDMI socket with pinout
= 15-pole HD-D "VGA" socket for connecting basic computer
Fig. 14: VGA socket with pinout
= 4-pole USB socket (type A) for connecting components:
nVoIP hardware components and/or
ntouchscreen and/or
nkeyboard
Fig. 15: USB socket with pinout
Serial connection (RS‑232)
DVI port
HDMI port
VGA port
USB connection
Product description
External connections > Description of the external connections
CONTROL 217 PC - Industrial PC 18

= 8-pole Ethernet socket for connecting to a network
Fig. 16: Ethernet socket with pinout
3.5.2.1 Power supply
NOTICE!
Risk of material damage if the device is connected to
an incorrect power supply.
Connecting the device to an incorrect power supply may
cause material damage.
– Check the power rating of your device.
Power is supplied via a 2-pole Phoenix socket of type DFK-PC /2-
GF-7,62. The corresponding plug carries the designation Phoenix Con-
tact PC 4/ 2-ST-7,62.
Fig. 17: 2-pole Phoenix Contact socket for the power supply
Pin Designation Significance
1-Ground (GND) 0V
2 + Power supply +
Ethernet (RJ45)
Power supply in the extra low voltage
range (12‑24V DC)
Product description
External connections > Description of the external connections
CONTROL 217 PC - Industrial PC 19

Power is supplied via a 3-pole Phoenix socket of type DFK-PC /3-
GF-7,62. The corresponding plug carries the designation Phoenix Con-
tact PC 4/ 3-ST-7,62.
Fig. 18: 3-pole Phoenix Contact socket for the power supply
Pin Designation Significance
1 PE Surge protectors
2 L Phase
3 N Neutral conductor
3.6 Conformity
Systec & Solutions GmbH
CONTROL 217-218-219-221-224-232
Industrial PC/Monitor
nPURPOSE
For the above product, in the version with a 12 – 24 V DC power
supply, we hereby confirm that it complies with the essential pro-
tection requirements of the EMC Directive 2014/30/EU (formerly
2004/108/EC) (electromagnetic compatibility).
The above product, in the version with a 100 – 240 V AC power
supply, also complies with the requirements of the EC Low Voltage
Directive 2014/35/EU (formerly 2006/95/EC).
nSCOPE
The product listed above fulfills the requirements of the EMC Direc-
tive 2014/30/EU (formerly 2004/108/EC) on the basis of the fol-
lowing standards:
– EN 61000-6-2:2005
– EN 61000-4-2:2007
The product listed above fulfills the requirements of the Directive
2006/95/EC on the basis of the following standard:
– EN 60950-1:2006
nCERTIFICATE
Compliance with protection requirements was established with the
housing closed on all sides.
Systec & Solutions GmbH
Emmy-Noether-Straße 17
D–76131 Karlsruhe
Power supply in the low-voltage
range (100 – 240 V AC, 50 – 60 Hz)
Declaration of Conformity
Product description
Conformity
CONTROL 217 PC - Industrial PC 20
