System air Topvex Series User manual

Topvex Series
Compact Air Handling Unit
HWC - Hot Water Coil
EPH - Electric Pre-Heater
Installation Instructions
Item#: 420353
2014-06-09

Contents
1 Warnings .....................................................................................................................................................1
2 Mounting of Water heating Coil...................................................................................................................1
2.1 hW Installation in Topvex FR800-3800 (Re-heat)...................................................................................1
2.2 hW Installation in Topvex TR800-4000 (Re-heat)...................................................................................3
2.3ConguringtheSoftwareforHW(Re-Heat) ............................................................................................5
2.4 hW Installation in Topvex FR800-3800 (Pre-heat)..................................................................................7
2.5 hW Installation in Topvex TR800-4000 (Pre-heat)..................................................................................9
2.6ConguringtheSoftwareforHW(Pre-Heat) .........................................................................................11
3 Mounting of EL Pre-heater........................................................................................................................14
3.1 EL Pre-heater Installation for Topvex FR800-3800 ...............................................................................14
3.2 EL Ptr-heater Installation for Topvex TR models..................................................................................15
3.3ConguringtheSoftwareforELPre-Heater ..........................................................................................16
3.3.1 Topvex FR Pre-heater Electrical Components .............................................................................19
3.3.2 Topvex TR Pre-heater Electrical Components .............................................................................20
3.3.3 Topvex FR hW Pre-heater Components......................................................................................21
3.3.4 Topvex TR hW Pre-heater Components......................................................................................22

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
1
1 Warning
The following statements will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out by an authorized installer and in accordance with local
rules and regulations.
Warning
• Although the Mains supply to the unit has been disconnected there is still risk for injury due to
rotating parts that have not come to a complete standstill.
• Beware of sharp edges during maintenance. Use protective clothing.
• This product is not intended to be used by children or people with reduced physical or mental ability
or lack of experience and knowledge, if no instruction concerning the use has been given by the
person responsible for their safety or that this person is supervising the operation. Children should
be supervised so that they can not play with the product.
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
2 Mounting of Water Heating Coil
It is possible to add a water heating coil to units without re-heater (None). A water heating coil can be
purchased as an accessory.
The following procedure describes how to mount and connect the water heating coil in the unit.
2.1 HW Installation in Topvex FR800-3800 (Re-Heat)
1
Open the inspection door at the supply/extract air
side of the unit.
2
Insert the water heating coil in front of the supply
air fan and push the connection tubes through the
prepared holes in the unit gable.
* Sealing grommets are required on outside of
unit only.
2
Remove supply air fan

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
2
3
Connect the water piping to the coil connections
(pos.1 and 2).
Thearrowsintheguresdisplayhowthehotwater
should be connected to the coil. Connect the hot
water inlet to the tube connection marked pos. 1 in
thegure,andthereturnwatertotheconnection
marked pos. 2.
Note:
The unit in the illustration is installed with the
inspection door facing downward, i.e. false ceiling
installation.
2
1
4
Connect the frost protection sensor (pos. 1) to the
prepared fast coupling (pos. 2) on the inside casing
wall (wires are polarity independent).
Note:
The frost protection sensor is placed on the return
water tube.
2
1
Caution
• Take care not to damage the water coil when
connecting water pipes to connectors.
• Water temperature should not exceed 194°F
(90°C).
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
5
Connect all necessary accessories such as water
valves and valve actuators. See enclosed wiring
diagram for more information.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
3
6
Use the control panel to program the unit for water
heating. See chapter 2.3 on how to do software
conguration.
1
Remove the cover plate by unscrewing 3 screws.
2.2 HW installation in Topvex TR800-4000 (Re-Heat)
2
Insert the water heating coil as illustrated in the
gure.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
4
5
Replace the cover plate and fasten it with 2 screws
(pos. 1).
3
Connect the water piping to the coil connections.
Coverplatesaroundthepipesarexedtotheunit
(reinforcement).
Thearrowsintheguredisplayhowthehotwater
should be connected to the coil. Connect the hot
water inlet to position 1 and the return water to
position 2.
Connect the frost protection sensor (pos. 3) to
terminals 44 and 40 in the electrical connection box.
Use the prepared internal lead through to draw the
wiring between the compartments.
4
Connect all necessary accessories such as water valves and valve actuators. See enclosed wiring diagram
for more information
Important
Take care not to damage the water coil when
connecting water pipes to connectors.
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
2 1

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
5
2.3 Conguring the Software for HW (Re-heat)
After all the physical installations for water heating have been done the unit software needs to be setup
for water heating by the use of the control panel. This is done by activating the digital input where the frost
protection sensor has been connected and set the heating option to Water.
Follow procedure below.
1 Access rights
Go to Access Rights by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Temperature
Air Control
Time settings
→Access Rights
2 Log on
Choose Log on. Select by pressing the RIGHT
arrow button.
→Log on
Log off
Change password
3 Password
Enter password 1111 by pressing OK followed by
the UP/DOWN arrow buttons. Select next digit by
pressing the RIGHT arrow button. Press OK when
all 4 digits have been entered.
Go back 2 steps using the LEFT arrow button.
Log on
Enter password xxxx
Actual level: None
4 Conguration menu
Go to Conguration by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Man/auto
Settings
→Conguration
Access Rights
6
Use the control panel to program the unit for water
heating. See chapter 2.3 on how to do software
conguration.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
6
5 Inputs/Outputs
Go to Inputs/Outputs by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
→Inputs/Outputs
Control function
Fan control
Extra Sequence Y4
6 Universal input
Go to UI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AI
DI
→UI
AI
7. Frost Protection
Go to UI4 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SetAI sign to Not
used by using the UP/DOWN arrow buttons.
ConrmbypressingOK.
Set DI sign to External alarm by using
theUP/DOWNarrowbuttons.Conrmbypressing
OK.
Go back 2 steps using the LEFT arrow button.
UI:4
Choose AI or DI sign
AI sign: Not used
DI sign: External alarm
8 Heating
Go to Heating by using the UP/DOWN arrow
buttons. Select by pressing the RIGHT arrow
button.
Fan control
Extra Sequence Y4
→Heating
Exchanger
9 Water
Press OK. Select Water by using the UP/DOWN
arrowbuttons.ConrmbypressingOK.
Go back 2 step to the main menu using the LEFT
arrow button.
Heating
Water
The unit is now ready to be used with the installed water heating coil.
10 Complete setup
Press the UP arrow button repeatedly to return to
the unit status display.
TOPVEX #####
YYYY-MM-DD HH:MM
SYSTEM: STOPPED
SP: ACT: ºF ↓

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
7
2.4 HW Installation in Topvex FR800-3800 (Pre-Heat)
1
Open the inspection door at the supply/extract air
side of the unit.
2
Removebaglterandframe.
3
Insert the water heating coil in front of the outdoor
air connection and push the connection tubes
through the prepared holes in the unit gable.
4
Re-installthebaglterandframe.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
8
5
Connect the water piping to the coil connections
(pos.1 and 2).
Thearrowsintheguresdisplayhowthehotwater
should be connected to the coil. Connect the hot
water inlet to the tube connection marked pos. 1 in
thegure,andthereturnwatertotheconnection
marked pos. 2.
Note:
The unit in the illustration is installed with the
inspection door facing downward, i.e. false ceiling
installation.
Caution
• Take care not to damage the water coil when
connecting water pipes.
• Water temperature should not exceed 194°F
(90°C).
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
6
Connect the frost protection sensor (pos. 1) to the
prepared fast coupling (pos. 2) on the inside casing
wall (wires are polarity independent).
Note:
The frost protection sensor is placed on the return
water tube.
2
1
2 1
7
Connect all necessary accessories such as water
valves and valve actuators. See enclosed wiring
diagram for more information.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
9
8
Use the control panel to program the unit for water
heating. See chapter 2.5 on how to do software
conguration.
2.5 HW Installation in Topvex TR800-4000 (Pre-Heat)
1
Insert the water heating coil as illustrated in the
gure.
2
Connect plug and outdoor air sensor onto existing
bracket.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
10
5
Replace the cover plate and fasten it with 2 screws
(pos. 1).
3
Connect the water piping to the coil connections.
Coverplatesaroundthepipesarexedtotheunit
(reinforcement).
Thearrowsintheguredisplayhowthehotwater
should be connected to the coil. Connect the hot
water inlet to position 1 and the return water to
position 2.
Connect the frost protection sensor (pos. 3) to
terminals 44 and 40 in the electrical connection box.
Use the prepared internal lead through to draw the
wiring between the compartments.
4
Connect all necessary accessories such as water valves and valve actuators. See enclosed wiring diagram
for more information
Important
Take care not to damage the water coil when
connecting water pipes to connectors.
2 1

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
11
2.5 Conguring the Software for HW (Pre-Heat)
After all the physical installations for water heating have been done the unit software needs to be setup
for water heating by the use of the control panel. This is done by activating the digital input where the frost
protection sensor has been connected and set the heating option to Water.
Follow procedure below.
1 Access rights
Go to Access Rights using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Temperature
Air Control
Time settings
→Access Rights
2 Log on
Choose Log on. Select by pressing the RIGHT
arrow button.
→Log on
Log off
Change password
3 Password
Enter password 1111 by pressing OK followed by
the UP/DOWN arrow buttons. Select next digit by
pressing the RIGHT arrow button. Press OK when
all 4 digits have been entered.
Go back 2 steps using the LEFT arrow button.
Log on
Enter password xxxx
Actual level: None
4 Conguration menu
Go to Conguration by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Man/auto
Settings
→Conguration
Access Rights
8
Use the control panel to program the unit for water
heating. See chapter 2.5 on how to do software
conguration.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
12
9 Frost Protection
Go to DI2 by using the UP/DOWN buttons.
ConrmbypressingOK.Set signal to Frost
protection by using the UP/DOWN arrow
buttons.ConrmbypressingOK.
Set NO/NC to NC by using the UP/DOWN arrow
buttons.ConrmbypressingOK.
Go back 1 step using the LEFT arrow button.
DI2
NO/NC: NC Signal:
Frost protection
Status: on
7 Outdoor temp
Go to AI3 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SelectOutdoor temp.
byusingtheUP/DOWNbuttons.Conrmby
pressing OK twice.
Go back 1 step using the LEFT arrow button.
AI3:
Sign: Outdoor temp.
Raw value
Compensation
8 Digital input
Go to DI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AO
→DI
UI
AO
10 Universal input
Go to UI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AO
DI
→UI
AO
5 Inputs/Outputs
Go to Inputs/Outputs by using the UP/DOWN
buttons. Select by pressing the RIGHT arrow
button.
→Inputs/Outputs
Control function
Fan control
Extra Sequence Y4
6 Analog input
Go to AI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
→AI
DI
UI
AO

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
13
11 Extra unit temp
Go to UI3 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SetAI sign to Extra
unit temp by using the UP/DOWN arrow
buttons. ConrmbypressingOK.
Set DI sign to Not used by using the UP/
DOWN arrow buttons. ConrmbypressingOK.
Go back 1 step using the LEFT arrow button
UI:3
Choose AI or DI sign
AI sign: Extra unit temp
DI sign: Not used
12 Analogue outputs
Go to AO by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AO
DI
UI
→AO
16 Control mode extra
Use the DOWN arrow button to select Control
mode extra and press OK.
Select Heating by using the UP/DOWN buttons.
ConrmbypressingOK.
Go back 1 step using the LEFT arrow button.
Control mode extra
Unit: Heating
15 Mode extra unit
Press OK. Select Running if unit runs by
usingtheUP/DOWNarrowbuttons.Conrmby
pressing OK.
Mode Extra unit
Running if unit runs
13 Extra unit CtrlVa
Go to AO5 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SelectExtra unit
CtrlVa by using the UP/DOWN arrow buttons
ConrmbypressingOKtwice.
Select Auto by using the UP/DOWN arrow
buttons.ConrmbypressingOK.
Go back 2 steps using the LEFT arrow button
14 Extra control unit
Go to Extra control unit by using the UP/
DOWN arrow buttons and press RIGHT.
Inputs/Outputs
Control functions
Fan control
→Extra control unit
AO5
Sign: Extra unit CtrlVa
Auto
Value:

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
14
3.1 EL Pre-Heater Installation for Topvex FR800-4000
3 Mounting of EL Pre-Heater
1
Remove the plate covering the electrical
connections.
2
Slide the Pre-Heater into place. Tighten mounting
screws.
Warning
Ensure Automatic fuse (AS3) is OFF when
connecting pre-heater.
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
18 Water
Press OK. Select Water by using the UP/DOWN
arrowbutton.ConrmbypressingOK.
Go back 2 step by pressing the LEFT arrow button
to the main menu.
Heating
Water
The unit is now ready to be used with the installed water pre-heating coil.
17 Heating
Go to Heating by using the UP/DOWN arrow
buttons. Select by pressing the RIGHT arrow
button.
Fan control
Extra Sequence Y4
→Heating
Exchanger
17 Complete setup
Press the UP arrow button repeatedly to return to
the unit status display.
TOPVEX #####
YYYY-MM-DD HH:MM
SYSTEM: STOPPED
SP: ACT: ºF ↓

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
15
3
Remove the Pre-Heater electrical box cover and
connect power and control cables to the Topvex
unit.
4
Replace the electrical box cover and tighten screws.
3.2 EL Pre-Heater Installation for Topvex TR Models
1
Slidepre-heaterontorailswithlters
(pos.7.gure1)
2
Connectpre-heater(pos.8gure1)byremoving
both protective caps
7
8
Fig. 1 Mounting of Pre-heater
Warning
Ensure Automatic fuse (AS3) is OFF when
connecting pre-heater.
1 Warnings
The following admonitions will be presented in the different sections of the document.
Danger
• Make sure that the Mains supply to the unit is disconnected before performing any maintenance or
electrical work!
• All electrical connections must be carried out in accordance with local rules and regulations.
Warning
• In order for the unit to be considered safely installed the doors if equipped with handles have to be
locked with a key to prevent unauthorized or accidental opening
• The unit must be duct connected or in some other way provided with protection so that it is not
possible to come in contact with the fans through the duct connections
• The unit is heavy. Be careful during transport and mounting. Risk of injury through pinching. Use
protective clothing.
• Beware of sharp edges during mounting and maintenance. Make sure that a proper lifting device is
used. Use protective clothing.
Caution
• If the unit is installed in a cold place make sure that all joints are covered with insulation, and tape well
• Duct connections/duct ends should be covered during storage and installation
• Do not connect tumble dryers to the ventilation system
• Take care not to damage the water battery when connecting water pipes to connectors. Use a
spanner to tighten the connection.
Topvex FR03, FR06, FR08, and FR11 Installation instructions
206638 1Systemair AB
5
Use the control panel to program the unit for electric
pre-heating. See chapter 3.3 on how to do software
conguration.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
16
3.3 Conguring the Software for EL Pre-Heater
After all the physical installations for pre-heating are complete the unit software needs to be setup using the
control panel.
Follow procedure below.
1 Access rights
Go to Access Rights by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Temperature
Air Control
Time settings
→Access Rights
2 Log on
Choose Log on. Select by pressing the RIGHT
arrow button.
→Log on
Log off
Change password
3 Password
Enter password 1111 by pressing OK followed by
the UP/DOWN arrow buttons. Select next digit by
pressing the RIGHT arrow button. Press OK when
all 4 digits have been entered.
Go back 2 steps using the LEFT arrow button.
Log on
Enter password xxxx
Actual level: None
4 Conguration menu
Go to Conguration by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
Man/auto
Settings
→Conguration
Access Rights
3
Use the control panel to program the unit for electric
pre-heating. See chapter 3.3 on how to do software
conguration.

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
17
6 Analogue input
Go to AI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
→AI
DI
UI
AO
5 Inputs/Outputs
Go to Inputs/Outputs by using the UP/DOWN
arrow buttons. Select by pressing the RIGHT arrow
button.
→Inputs/Outputs
Control function
Fan control
Extra Sequence Y4
10 Universal Inputs
Go to UI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AI
DI
→UI
AO
7 Outdoor temp
Go to AI3 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SelectOutdoor temp
byusingtheUP/DOWNarrowbuttons.Conrmby
pressing OK twice.
Go back 1 step using the LEFT arrow button.
AI3:
Sign: Outdoor temp.
Raw value
Compensation
9 Pre-Heat Alarm
Go to DI2 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SelectOverheat
protection by using the UP/DOWN arrow
buttons.ConrmbypressingOK.
Set NO/NC to NO by using the UP/DOWN arrow
buttons.ConrmbypressingOK.
Go back 1 step using the LEFT arrow button.
DI2
NO/NC: NO Signal:
Overheat protection
Status: ON
8 Digital input
Go to DI by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AO
→DI
UI
AO

Topvex Series HWC - Hot Water Coil,
ELP - Electric Pre-Heater installation instructions
Systemair Inc.
18
13 Extra unit CtrlVa
Go to AO5 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SelectExtra unit
CtrlVa by using the UP/DOWN arrow buttons.
ConrmbypressingOKtwice.
Select Auto using UP/DOWN arrow button.
ConrmbypressingOK.
Go back 2 steps using the LEFT arrow button
AO5
Sign: Extra unit CtrlVa
Auto
Value:
15 Mode extra unit
Press OK. Select Running if unit runs by
usingtheUP/DOWNarrowbuttons.Conrmby
pressing OK.
Mode Extra unit
Running if unit runs
14 Extra control unit
Go to Extra control unit by using the UP/
DOWN arrow buttons. Select by pressing the
RIGHT arrow button.
Inputs/Outputs
Control functions
Fan control
→Extra control unit
11 Extra unit temp
Go to UI3 by using the UP/DOWN arrow buttons.
ConrmbypressingOK.SetAI sign to Extra
unit temp by using the UP/DOWN arrow
buttons. ConrmbypressingOK.
Set DI sign to Not used using the UP/DOWN
arrow buttons. ConrmbypressingOK.
Go back 1 step using the LEFT arrow button
UI:3
Choose AI or DI sign
AI sign: Extra unit temp
DI sign: Not used
12 Analogue outputs
Go to AO by using the UP/DOWN arrow buttons.
Select by pressing the RIGHT arrow button.
AO
DI
UI
→AO
