System air fantech RCS80L Manual

Installation, Operations, and Maintenance instruction EN
bathfan Recessed RCS80L
Ceiling Mount Exhaust Fan with Metal Casing

Table of contents
1 Introduction .............................................................1
1.1 Product Description ........................................1
1.2 Intended Use................................................. 1
1.3 Document Description .....................................1
1.4 Fantech Warranty........................................... 1
1.5 Product Overview........................................... 1
1.6 Type Designation ...........................................1
2 Safety ....................................................................2
2.1 Safety definitions............................................2
2.2 Safety Instructions.......................................... 2
2.3 Personal protective equipment .......................... 2
3 Installation ..............................................................3
3.1 To Mount the Product ...................................... 3
3.2 To Mount with Hanger Bars............................... 3
3.3 To Plan the Duct Run ......................................3
3.4 To Attach the Duct ..........................................4
3.5 To Manage the Duct Run.................................. 4
3.6 To Mount the Light ..........................................4
4 Electrical connection ................................................. 5
4.1 To do before the electrical connection ................. 5
4.2 To connect the product to the power
supply..........................................................5
4.3 Motor Protection ............................................ 5
4.4 Wiring Diagrams ............................................ 5
5 Operation................................................................7
5.1 To Start the Product ........................................7
5.1.1 To Stop the Product ............................7
6 Maintenance............................................................7
6.1 To Maintain the Product ................................... 7
7 Technical data.......................................................... 8
7.1 Technical Data Overview..................................8
7.2 Product Dimensions........................................ 8

1 Introduction
1.1 Product Description
This product is a ceiling mount exhaust fan with a metal casing.
This fan has rotating parts and personnel must exercise safety
precautions during installation, operations, and maintenance.
1.2 Intended Use
Use this product only in the manner intended by Fantech. If you
have any questions, please contact a Fantech representative.
1.3 Document Description
This document contains instructions for installation, operation
and maintenance of the product. The procedures must be done
by approved personnel only.
Speak to a Fantech representative for more information on how
to install the product in different installation locations.
1.4 Fantech Warranty
Make a scan of the code above to access Fantech’s warranty
in English, French, or Spanish. This product has a 5 year
warranty.
If additional support is needed to retrieve the warranty, visit fan-
tech.net; call (800) 747–1762 (US), (800) 565–3548 (Canada),
or [phone] (Latin America); email support@fantech.
net; or mail us at 10048 Industrial Blvd, Lenexa, KS 66215
United States or at 50 Kanfläkt Way, Bouctouche, NB E4S 3M5
Canada.
1.5 Product Overview
5
4
6
2
1
7
3
1. Casing, quantity 1
2. Duct Assembly, quantity 1
3. Casing Channel
4. B Screw, quantity 4 – Self-tapping 1 inch (25mm)
5. A Screw, quantity 2 – Self-tapping 1/2 inch (13mm)
6. Hanger Bars, quantity 4 – 13–3/8 inch (340mm)
7. Trim Ring
1.6 Type Designation
Product
Name
Model Name bathfan
Duct
Collar
Dimen-
sions in
inches
(mm)
bathfan Recessed
RCS80L, #484304
4 (102)
5 (127)
Motor
Type
AC: Alternating Current, 1–phase
1

2 Safety
2.1 Safety definitions
Warnings, cautions and notes are used to point out specially
important parts of the manual.
Warning
If you do not obey these instructions, there
is a risk of death or injury.
Caution
If you do not obey these instructions, there
is a risk of damage to the product, other
materials or the adjacent area.
Note:
Information that is necessary in a given situation.
2.2 Safety Instructions
Warning
This product is intended for general ventila-
tion use only. If you have questions, contact
Fantech. To decrease the risk of fire, elec-
tric shock, or injury, read and obey the fol-
lowing warning instructions before you do
work on the product:
• The ventilation contractor and the operator are responsible
for correctly installing the product.
• When installing the product, obey all applicable local condi-
tions and laws, and fire-rated construction codes and
standards.
• Because the product has rotating parts, exercise safety pre-
cautions when installing, operating, and maintaining the
product.
• Before installing, servicing, or cleaning, set the product’s
electrical power supply source in the OFF position, and lock
the service disconnecting means. If the service disconnect-
ing means cannot be locked, tightly attach a large warning
device to the service panel.
• To prevent the product from backdrafting, obey the heating
equipment manufacturer’s guidelines and safety standards
such as those published by the National Fire Protection As-
sociation (NFPA), the American Society for Heating, Refrig-
eration & Air Conditioning Engineers (ASHRAE), and the
local code authorities.
• When cutting or drilling into walls or ceilings, watch for elec-
trical wiring and other hidden utilities to prevent damage.
• Ducted exhaust fans must always be released to the
outdoors
• When installing the product over a tub or shower, identify as
appropriate for the application and connect to a GFCI
(Ground Fault Circuit Interrupter) – protected branch circuit
(ceiling installation only).
• Make sure the product is correctly grounded.
• Never place a switch where it can be reached from a tub or
shower.
• Do not block the air intakes or exhaust.
• Do not mount this product in an outdoor location.
• Install the product at least 7 feet (2.1 meters) above the floor.
• Do not start and stop the product quickly.
• Do not clean the product with chemicals that can cause cor-
rosion or water more than 60° Celsius (140° Fahrenheit).
• Do not let unwanted objects enter the product.
• Do not use this product to remove hazardous or explosive
material and vapours.
• Do not mount this product vertically.
• This product is designed for installation in ceilings up to a
12/12 pitch (45 degree angle)
• Do not mount this product in kitchens.
• Do not release air into spaces within walls or into attics,
crawl spaces, or garages.
• Do not install this product in a ceiling with a thermal insula-
tion value more than R40.
Note:
Ducting has a strong effect on the air flow, noise and energy
use of the fan. Use the shortest, straightest duct routing pos-
sible for best performance, and avoid installing the fan with
smaller ducts than recommended. Insulation around the
ducts can reduce energy loss and inhibit mold growth. Fans
installed with existing ducts may not achieve their rated air
flow.
2.3 Personal protective equipment
Use personal protective equipment during all work on the
product.
• Approved eye protection
• Approved protective helmet
• Approved hearing protection
• Approved protective gloves
• Approved protective shoes
• Approved work clothing
2

3 Installation
3.1 To Mount the Product
Caution
Do not mount this product in a wall.
Note:
This product is designed for installation in ceilings up to a 12/
12 pitch (45 degree angle).
Note:
To make sure the product can be set correctly anywhere be-
tween the framing, hanger bars have been supplied.
Note:
The hanger bars can be used on all types of framing, such
as: I-joists, standard joists, and truss construction.
1Before installation, move hanger bars onto casing.
1
1
A
1. Hanger Bars
3.2 To Mount with Hanger Bars
1Adjust hanger bars as necessary to mount the product be-
tween the framing.
2Align the hanger bar tabs with the bottom edge of the
framing.
3Using (4) B screws, attach both ends of each hanger bar to
the framing.
4Using (2) A screws, attach each hanger bar onto the prod-
uct’s casing.
2
3
1
1
1. Hanger Bars
2. A Screw
3. B Screw
3.3 To Plan the Duct Run
Warning
Do not install the product above or inside
the area within 45 degrees on either side of
any kind of cooking equipment. Refer to
Figure 2.
Caution
Duct connector must be in a horizontal po-
sition when mounted.
1
2
3
4
2
1. Floor
2. Cooking Equipment
3. Ceiling
4. Cooking Area
3

3.4 To Attach the Duct
Caution
To keep pressure losses to a minimum, and
promote sufficient airflow, observe the
following:
• Where possible, use short and straight
duct run lengths.
• Do not install the product with existing
duct.
• Do not install smaller than recommen-
ded duct on the product.
Note:
For quiet operation, and to maximize performance, Fantech
recommends the following:
• Use insulated flexible duct for quiet operation
• If rigid duct is used, use 1–3 feet (0.3–0.91 meters) of in-
sulated flexible duct.
• Insulate the duct to minimize energy losses.
• If installing in an unconditioned space, attach insulation to
the product to prevent condensation
1Using duct tape, attach the duct to the duct connector.
2Examine the duct around the duct connector to make sure
the seal is air tight.
3
3.5 To Manage the Duct Run
1Using duct tape, attach additional ducts to the product to
make sure air is released to the outdoors.
2Depending on the shortest & straightest direction to the
outdoors, place the duct run either through the roof or
through the wall.
3If the duct was installed through the roof, attach an applica-
ble roof cap to the end of the duct run.
4If the duct was installed through the wall, attach an applica-
ble wall cap to the end of the duct run.
5Place insulation around the product’s casing.
6With sealant, close all gaps between the framing and the
product’s casing.
1
2
3
4
5
6
7
8
9
10
4
1. Insulation
2. Product Casing
3. Roof Cap
4. Vertical Duct Run
5. Wall Cap
6. Round Elbows
7. Duct Tape Attached to Duct Joints
8. Horizontal Duct Run
9. Sealed Gaps
10. Power Cable
3.6 To Mount the Light
Note:
Dimensions are given in inches (mm).
Note:
The lamp base can adjust up or down to move the lamp into
the casing.
1Measure a diameter of 6–1/2 inches (165mm) on the ceil-
ing, and make an applicable mark.
2Identify the marking and cut a hole with a diameter of 6–1/
2 inches (165mm) on the marking.
3With sealant, close any gap between the hole in the ceiling
and the product.
4Position the fluorescent lamp in the hole.
5Using the wing nut, attach the lamp inside of the lamp base.
6Once the lamp has been attached to the lamp base, close
the gap between the hanger bar flange and the ceiling with
caulk or another sealant to prevent air leakage.
4

23
4
5
6
7
1
8
5 5a
5b
1. Fluorescent Lamp
2. 6–1/2 (165)
3. Lamp Base
4. Wing Nut
5. Joist
6. Hanger Bar
7. Ceiling
8. 1/2 (3.2)
4 Electrical connection
4.1 To do before the electrical
connection
• Make sure that the electrical connection agrees with the
product specification on the motor name plate.
• Make sure that the environment for electrical connection is
clean and dry.
• Make sure that the wiring diagram that is included with the
supply of the product agrees with the terminals in the con-
nection box.
4.2 To connect the product to the
power supply
• Complete the electrical connection for the motor. Refer to
the motor wiring diagram that is included with the product.
• Make sure that the cross section of the protective grounding
is equal to or larger than the cross section of the phase
conductor.
4.3 Motor Protection
This product has integrated motor thermal overload protection.
Reset the motor protection by disconnecting the fan from power
supply for 60 seconds.
4.4 Wiring Diagrams
Caution
Do not place the power or light switch
where it can be touched from a shower or
tub.
Note:
To connect power to this product, use a minimum of 14
American Wire Gauge (AWG) conductor with temperature
rating of at least 90° Celsius (190° Fahrenheit).
Note:
Refer to the following wiring diagrams to attach the wires of
the product to the wires of the house.
5

Legend for Diagram
English Terminology Meaning
LIGHT SWITCH Light Switch
FAN SWITCH Fan Switch
LINE IN Line In
SWITCH BOX Switch Box
UNIT Unit
FAN Fan
LIGHT Light
POWER SUPPLY 120V AC 120 Voltage Alternating Current Power Supply
FAN RECEPTACLE Fan Receptacle
LIGHT RECEPTACLE Light Receptacle
WIRE PANEL Wire Panel
BLUE (BLU) (Line) Blue (Line)
BLACK (BLK) (Line) Black (Line)
WHITE (WHT) (Neutral) White (Neutral)
GROUND (GRD) Ground
1Take 120 Volt Alternate Current (AC) housing wires to the
location of the product.
2Using UL-approved connectors only, attach the wires of
the product to the wires of the house.
RCS80L
LINE
IN
FAN
BLK
BLK
BLU
LIGHT
SWITCH LIGHT
SWITCH BOX
WHT WHT
UNIT
WHT
GRD
6

RCS80L
UNIT
BLACK (BLK)
SWITCH BOX
POWER SUPPLY 120V AC
GROUND (GRD)
WHITE (WHT)
WIRE
PANEL
LIGHT
SWITCH
BLUE (BLU)
FAN
SWITCH
LIGHT
RECEPTACLE
FAN
RECEPTACLE
FAN
RECEPTACLE
5 Operation
5.1 To Start the Product
1Make sure that 120 volts of Alternate Current (AC) wiring
are attached to the product.
2Set the switch to the ON position.
3After a soft start (5–10 seconds), make sure that the prod-
uct works as intended.
5.1.1 To Stop the Product
1Set the switch to the OFF position.
6 Maintenance
Warning
Set the installed switch(es) in the OFF
position before you do the maintenance
unless the instructions tell you differently.
Make sure that the switch(es) is not
accidentally set in the ON position.
6.1 To Maintain the Product
Caution
If the product suddenly starts to make loud
noises, or starts to vibrate in an unusual
way, stop the product immediately. Contact
a Fantech representative as the product
will need to be replaced.
Note:
For quiet operation, long life, and to maximize performance,
observe the following:
• Remove grille before carefully cleaning interior of product
with a vacuum with a soft brush attachment or a soft cloth.
• No other maintenance is required.
7

7 Technical data
7.1 Technical Data Overview
Voltage, Motor Power, Frequency Refer to the mo-
tor nameplate on
the blower
assembly.
Motor data Refer to the mo-
tor nameplate or
the technical
documentation
from the motor
manufacturer.
7.2 Product Dimensions
B
A
C
D
E
Note:
Dimensions are given in inches (mm).
A B C D E
bathfan Recessed
RCS80L, #484304 4 (102) 6–1/2 (165) 8 (203) 7–1/4 (184) 12–5/8 (321)
8

9

Document in original language 2023-04-24
484285 - 001
© Copyright Fantech
All rights reserved
Fantech reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it
does not affect the previously agreed specifications.
USA
[phone]
[email protected]
Canada
[phone]
[email protected]
Latin America
[phone]
[email protected]
last page
