Warnings |1
1 Warnings
The following admonitions will be presented in the different sections of the document:
Danger
Indicates a potentially or imminently hazardous situation which, if not avoided, could result in death or
serious injury.
Warning
Indicates a potentially hazardous situation that may result in minor or moderate injuries.
Caution
Indicates a risk of damaging the product or prevent optimal operation.
Important
• This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children
without supervision.
124455 | A003

2| Product description
2 Product description
2.1 Internal components Topvex SR 03-06
Fig. 1 Internal components with air connections symbols (Drawn as a right hand unit)
Position Description Symbol
AConnection supply air
BConnection exhaust air
CConnection outdoor air
D Connection extract air
1Fan supply air
2 Fan extract air
3Filter supply air
4Filter extract air
5Heat exchanger
6 Rotor motor
7Rotation guard (sensor)
8Extra driving belt
9Pressure sensor supply air/extract air filter
10 Pressure sensor extract air fan/supply air filter
11 Temp. sensor outdoor air
12 Temp. sensor extract air
13 Temp. sensor exhaust air
14 Electrical re-heater battery
1
15 Electrical connection box
1Only valid for units with electrical re-heater battery
124455 | A003

Product description | 3
2.2 Internal components Topvex TR 03-06
Fig. 2 Internal components with air connection symbols (Drawn as a left hand unit)
Position Description Symbol
AConnection supply air
BConnection exhaust air
CConnection outdoor air
D Connection extract air
1Fan supply air
2 Fan extract air
3Filter supply air
4Filter extract air
5Heat exchanger
6 Rotor motor
7Rotation guard
8Extra driving belt
9Pressure sensor supply air fan/extract air filter
10 Pressure sensor extract air fan/supply air filter
11 Temp. sensor extract air
12 Temp. sensor supply air
13 Temp. sensor outdoor air
14 Temp. sensor exhaust air
13 Electrical connection box
14 Electrical re-heater battery
1
1Only valid for units with electrical re-heater battery
124455 | A003

4| Product description
2.3 Description of internal components
2.3.1 Supply and extract air fans
The fans have external rotor motors of EC type which are steplessly controlled individually by setting the control signal
to a fixed value. It is possible to program the speed in 2 steps (normal/reduced) depending on the programming of the
week schedule. The motor bearings are life time lubricated and maintenance free. It is possible to remove the fans for
cleaning, see chapter 5 for more information.
2.3.2 Pressure sensor fans
2 pressure sensors maintain the airflow at a constant level by measuring the differential pressure over the inlet cone of
the fan impellers (pos.10 figure 1, pos.10 figure 2). The pressure sensors are installed from factory in all CAV units. VAV
control of the fans is available as an accessory. The VAV accessory kit includes two pressure sensors, tubes, electrical
cables and instruction on how to connect to the air handling unit and set-up the controller. See also “Installation instruc-
tions” for more information concerning VAV installations.
2.3.3 Supply and extract air filters
The filters are of bag filter type with filter quality F7 for the supply air filter and F5 for the extract air filter. The filters
need to be replaced when polluted. New sets of filters can be acquired from your installer or wholesaler.
2.3.4 Pressure guard for filters
A pressure guard measures the differential pressure over the supply and extract air filters (pos.9 figure 1,figure 2).
When the pressure drop reaches the set value an alarm is triggered in the main regulator. The differential pressure can
be set between 40 and 300 Pa. The pressure switch is preset from factory to 240 Pa.
2.3.5 Heat exchanger
Topvex SR/TR models are equipped with a highly efficient, belt driven, rotating aluminium heat exchanger. Required
supply air temperature is therefore normally maintained without adding additional heat. The operation of the heat ex-
changer is automatic and depends on the set temperature. An extra driving belt is included on the rotor on delivery
(pos. 8 figure 1 and figure 2).
The heat exchanger is removable for cleaning and maintenance, see chapter 5 for more information.
2.3.6 Rotor motor
The rotor motor drives the exchanger rotor with a variable rpm as long as there is a heat demand. The motor is con-
trolled by an analogue 0-10V control signal (figure 1 and figure 2).
2.3.7 Rotation guard
A sensor registers the rotation of the heat exchanger rotor. It’s connected by the rotor to the main regulator which
gives an alarm if the rotor stops while there is a heat demand (pos.7 figure 1 and figure 2).
2.3.8 Temperature sensors
4 temperature sensors (PT1000) are included in the unit from factory:
• Supply air sensor
• Extract air sensor
• Outdoor air sensor
• Exhaust air sensor
In Topvex TR 03-06 all temperature sensors are mounted and wired inside the unit. In Topvex SR 03-06 the supply air
sensor is loosely delivered with the unit and needs to be installed in the supply air duct externally from the unit. See In-
stallation instructions for more detailed information.
2.3.9 Water heating battery
In units with built in water heating battery the hot water coil is located next to the supply air connection. The hot water
coil can be either HWL (hot water coil, low power) or HWH (hot water coil, high power). The coil material is copper pip-
ing with a frame of galvanized sheet steel and aluminium fins. The coil is equipped with venting and immersion sensor
for frost protection.
124455 | A003

Product description | 5
2.3.10 Electrical heater
In units with built in electrical heater the heating rods are located after the supply air fan in the airflow direction. The
material is stainless steel. The electric heating coil has both automatic and manual overheating protection. The manual
overheat protection is reset by pushing the red button on the side of the electrical heater frame by the use of a pointed
tool (figure 3). The power demand of the electric heating coil is controlled by the main regulator, which controls the
heat according to the desired supply/extract or room air temperature that is set in the control panel.
Danger
• Make sure that the mains to the unit is disconnected before performing any maintenance or electrical
work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Fig. 3 Reset of the manual over heat protection in Topvex SR 03-06.
2.4 Internal components electrical connection box
Danger
• Make sure that the mains to the unit is disconnected before performing any maintenance or electrical
work!
• All electrical connections must be carried out by an authorized installer and in accordance with local rules
and regulations.
Topvex SR/TR 03-06 are equipped with a built in regulator and internal wiring (figure 4).
The figure shows the electrical connection box for the Topvex TR 03-06 units. The connection box for the Topvex SR
03-06 has the same layout and components with the difference that the electrical heater is situated in a separate
compartment.
124455 | A003

6| Interface description
Fig. 4 Electric components
Position Description
1Regulator E-28 WEB
2Transformer 230/24V AC
3Terminals for internal and external components
4Terminals for internal wiring
5Terminals for mains supply to the unit
6Contactor (K2) Pump control water (HW units only, not present in EL-units)
7Automatic fuse
8Electric heater frame
9Automatic fuse for heater
10 Contactor (K3) for control of EL heater
11 Thermostat (EL units)
12 Manual over heat protection reset (EL units)
3 Interface description
3.1 Control panel
The SCP control panel is delivered with a 10 m cable (up to 100 m can be used) that is connected to the panel and with
a fast coupling contact, connected to the Topvex unit. The contact is connected to the Corrigo controller in the electrical
connection box. The cable can be unscrewed in the back of the control panel (figure 5).
124455 | A003

Commissioning |7
3.1.1 Operating the control panel
Fig. 5 The control panel
Position Explanation
1Alarm button: Gives access to the alarm list.
2Alarm LED: Indicates alarm by flashing red light.
3Write LED: Indicates by flashing yellow light that parameters can be set or changed.
4OK button: Press this button to be able to change or set parameters whenever possible. Also used to
move between changeable parameters in one dialogue window frame.
5Cancel button: Used to abort a change and return to the initial setting.
6Right/Left & Up/Down buttons: Used to move up, down, left & right in the menu tree. Up/Down buttons
are also used to increase or decrease values when setting or changing parameters.
7Mounting holes.
8Connection block.
9Connection to brown cable.
10 Connection to yellow cable.
11 Connection to white cable.
12 Connection to black cable.
3.1.2 Navigating the menus
The start display (the display normally shown) is at the root of the menu tree. Pressing DOWN will move you through
the menu options. UP will move you back through the options. To enter a higher menu level, use UP or DOWN to place
the cursor at the menu you wish to access and press RIGHT. If you have sufficient log on privileges the display will
change to the menu you have chosen.
At each level there may be several new menus which you move through using UP/DOWN. Sometimes there are further
sub menus linked to a menu or menu item. This is indicated by an arrow symbol at the right-hand side of the display. To
enter a menu, press RIGHT again. To step back to previous menu level, use LEFT.
4 Commissioning
4.1 Before starting the system
When the installation is finished, check that:
• The unit is installed in accordance with the installation instructions
• The unit is correctly wired
• Sound attenuators are installed and that the duct system is correctly connected to the unit
124455 | A003

8|Commissioning
• Outdoor air intake is positioned with sufficient distance to pollution sources (kitchen ventilator exhaust, central vac-
uum system exhaust or similar)
• All external equipment are connected
• The following data is available:
• Intended configuration, for example temperature control functions, fan control, external control functions etc.
• How the unit is supposed to operate according to a weekly schedule (normal and reduced speed)
4.2 Initial setup of the unit
On the first start-up, the controller will start a special program for setting language, supply air temp set point, Time &
date and week schedule for normal speed. Use the “OK” button to move between changeable parameters and the UP/
DOWN arrows to see the displayed alternatives. Confirm by pressing “OK” once more. Move on down in the menu
structure by use of the UP/DOWN arrows.
The following will be displayed:
Choose Language
English
1 Select language by pressing “OK” and then move be-
tween the alternatives with the UP/DOWN buttons.
Confirm by pressing “OK”. Move to the next level by
pressing the “DOWN” button.
Extract air temp
Actual:.... ºC
Setp.: 18 ºC
2 Shows the actual extract air temperature
Set the supply air set point. Default is 18°C (logon to
service level needed, code 2222, to change default
setting)
Time: 12.46
Date: 2010–03–12
Weekday: Friday
3 Check and make sure that correct time and date is dis-
played, if not change the settings
Normal speed
Monday → Friday
Per 1: 07:00 – 16:00
Per 2: 00:00 – 00:00
4 Set the week schedule for how it’s intended for the
unit to operate at normal speed during Monday to Fri-
day. It’s possible to set 2 periods per day.
Normal speed
Saturday → Holiday
Per 1: 07:00 – 16:00
Per 2: 00:00 – 00:00
5 Set the week schedule for how it’s intended for the
unit to operate at normal speed during Saturdays and
holidays. It’s possible to set 2 periods per day.
Reduced speed
Monday → Friday
Per 1: 00:00 – 24:00
Per 2: 00:00 – 00:00
6 Set the week schedule for how it’s intended for the
unit to operate at reduced speed during Monday to
Friday. It’s possible to set 2 periods per day. Normal
speed inactivates reduced speed.
Reduced speed
Saturday → Holiday
Per 1: 00:00 – 24:00
Per 2: 00:00 – 00:00
7 Set the week schedule for how it’s intended for the
unit to operate at reduced speed during Saturdays
and holidays. It’s possible to set 2 periods per day.
End Wizard
No
8 Select “Yes” or “No”
After finishing the setup the menu system for “Operator level” will be available.
See below menu overviews that display the available menus in the Operator level followed by the “Service level”
manual.
To enter Service level use code 2222 in the “Access rights” menu. For operator level use code 1111.
To enter Administrator level use code 3333 in the “Configuration menu”.
124455 | A003

Commissioning |9
Note:
To perform more advanced settings please see the separate “General Commissioning Record” on www.
systemair.com, online catalogue
4.3 Menu overview
Below menu overview shows both the Operator, Service and Administrator level. The overview of the parts unique to
the levels in below table are marked with different background color.
To logon to Operator
level use code 1111
under Access
rights.
To logon to Service
level use code 2222
under Access
rights.
To logon to
Administrator level
use code 3333 under
Access rights.
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Topvex SR03 EL CAV
2016–09–13 09:00
System:Normal run
Sp:22.0 Act: ºC
Start screen headline
Can be set to 5 different layouts
(Changeable at “Administrator
level” under the Configuration
menu).
→ Running mode → Running mode Running mode
Auto↓
Set running mode to Auto,
Manual reduced run, Manual
normal run or Off.
Op time
SAF: 0.0 h
EAF: 0.0 h
The time in hours that the motors
have been operating
SAF = Supply air fan
EAF = Extract air fan
→Selected
functions
Control function
Cascade extract
ctrl
Fan control
Flow/Pressure/
Manual control↓
Type of air temperature control the
unit is configured for.
Type of fan speed control the unit
is configured for.
Heating: Water
Exchanger: Plate/
Rot.exc
Cooling: Not
connect↓
Type of heating selected.
Type of exchanger selected.
Type of cooling selected.
Free cool active:No
↓
Status of the free cooling function.
Support control
Active: No
CO2/VOC active
Never↓
Status of the support control
function.
Status of the demand ventilation
(CO2/VOC) function.
Fire damper
function
Not active
Operation when
alarm
Stopped↓
Status of the fire damper function
when fire alarm is active.
Frost protection
Active
Cooling recovery
Yes↓
Status of the frost protection
function.
Status of the cooling recovery
function.
External set point
Not active
Status of the external set point.
124455 | A003

10 |Commissioning
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
→Alarm events Alarm log list along with the time
and date they occurred.
Move down and up in the list by
pressing ↑↓.
→Input/Output →AI Status of the Analogue inputs.
→AI exp3 Status of the Analogue inputs for
expansion unit.
Only visible for counter-/crossflow
units with a connected pressure
module
→AI exp4
→DI Status of the Digital inputs.
→UI Status of Universal Analogue inputs
or Universal Digital inputs.
→UI exp3 Status of the Universal Analogue
inputs for expansion unit.
Only visible for counter-/crossflow
units with a connected pressure
module
→UI exp4
→AO Status of the Analogue outputs.
→DO Status of the Digital outputs.
→Temperature Extract air temp
Actual: ºC
Setp: 22.0ºC→↓
Configured temperature control
(default is Extract air temp).
Actual temperature in the chosen
control mode.
Set-point temperature for the
chosen control mode.
If cascade control
Max/min supply
setp.
Max: 30ºC
Min: 14.0ºC
Set the maximum and minimum
allowed supply air temperature in
case of cascade control.
Logon to service level needed to
change settings.
Outdoor temp: ºC
Supply air temp
Act.: ºC
Setp: 18ºC→↓
Neutral zone 0.0 °C Actual outdoor air temperature.
Actual supply air temperature.
Calculated supply air set point. The
extract air controller output signal
generates the supply air
controller’s set point value.
A neutral zone can be set around
the setpoint value.
Note:
See Corrigo manual-
Ventilation application for
more information.
Frost protection
Actual: ºC↓
Actual water temperature in the
water heating battery. (Only visible
for HW units).
124455 | A003

Commissioning |11
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Efficiency
exch.
Actual: %
Output exchanger
Actual: 100%↓
Actual heat recovery efficiency.
The function calculates the heat
exchangers temperature efficiency
in % when the output signal to the
exchanger is higher than 5% and
the outdoor temperature is lower
than 10° C.
For counter flow units, efficiency is
calculated from the Outdoor,
Extract and Supply air temperature.
For Topvex SR/TR efficiency is
calculated from Outdoor, Extract
and Exhaust air temperature.
Status of the exchanger output.
Extra unit
Actual: NaN °C
Setp: 18.0 °C↓
Setpoint temperature for extra unit.
Temp for
calculation
efficiency
Act: NaN °C
Presented temperature for supply
air efficiency calculation.
→Air Control This menu option becomes visible
if the unit is configured for “Flow
control”, “Manual frequency” or
“Pressure control”.
Frequency control
manual SAF
Output: %→↓
Frequency control manual.
Fans controlled by setting fixed
output signal.
This menu option becomes visible
if the unit is configured for
"Manual frequency”.
Frequency control
manual SAF
Output 1/1: 75%
Output 1/2: 50%↓
Outdoor comp.
output.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0 m³/h
Frequency control
manual EAF
Output: %→↓
Frequency control
manual EAF
Output 1/1: 75%
Output 1/2: 50%↓
Outdoor comp.
output.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0 m³/h
Flow control SAF
Actual: m³/h
Setp.: m³/h→↓
Airflow for the supply air fan
(constant airflow control).
Only visible if the unit is
configured for “Flow control”
(CAV).
Flow control SAF
Setp 1/1: 1100 m³/h
Setp 1/2: 550 m³/h↓
Set the normal (1/1) and reduced
(1/2) airflow for the supply air fan.
124455 | A003

12 |Commissioning
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Outdoor comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0
Set the SAF airflow compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual airflow
compensation.
Flow control EAF
Actual: xxx m³/h
Setp.:xxx m³/h→↓
Airflow for the extract air fan
(constant airflow control).
Only visible if the unit is
configured for “Flow control”
(CAV).
Flow control EAF
Setp 1/1: 1100 m³/h
Setp 1/2: 550 m³/h↓
Set the normal (1/1) and reduced
(1/2) airflow for the extract air fan.
Outdoor comp.Setp.
–20°C = 0 m³/h
0°C = 0 m³/h
Act. Comp: 0
Set the EAF airflow compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual airflow
compensation.
Pressure control
SAF
Actual: Pa
Setp.: Pa→↓
The actual external pressure and
set point for the supply air fan.
Only visible if the unit is
configured for "Pressure control"
(VAV)
Pressure control
SAF
Setp 1/1: 200 Pa
Setp 1/2: 100 Pa↓
Set the external pressure set point
for normal speed (1/1) and
reduced speed (1/2) for the supply
air fan.
Outdoor comp.Setp.
1
—20°C = 0 Pa
10°C = 0 Pa
Act. Comp: 0 Pa
Set the SAF pressure compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual pressure
compensation.
Pressure control
EAF
Actual: Pa
Setp.: Pa→↓
The actual external pressure and
set point for the extract air fan.
Only visible if the unit is
configured for "Pressure control"
(VAV).
Pressure control
EAF
Setp 1/1: 200 Pa
Setp 1/2: 100 Pa↓
Set the external pressure set point
for normal speed (1/1) and
reduced speed (1/2) for the supply
air fan.
124455 | A003

Commissioning |13
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Outdoor comp.Setp.
1
—20°C = 0 Pa
10°C = 0 Pa
Act. Comp: 0 Pa
Set the EAF pressure compensation
for the settable outdoor
temperature. The outdoor
compensation is linear and is set
using two parameter pairs which
give the value of the compensation
at two different outdoor
temperatures. The compensation
can be positive or negative.
Shows the actual pressure
compensation.
Extra flow EAF
Actual: m³/h
Shows the extract air flow
→Time settings →Time/Date Set correct time and date.
Set 00:00 - 24:00 for continuous
running. Setting 00:00 - 00:00
inactivates the period (stops the
unit). Normal speed overrides
Reduced speed i.e. Normal speed
07:00 - 16:00 and Reduced speed
00:00 - 24:00 runs the unit on
Normal speed 07:00 - 16:00 and
Reduced speed the rest of the day.
→Timer normal
speed
Normal speed
Monday
Per 1: 07:00–16:00
Per 2: 00:00–00:00→
Normal speed
Monday-Friday
Per 1: 07:00–16:00
Per 2: 00:00–00:00↓
Set week schedule Monday to
Sunday, Monday-Friday+ Holiday
for normal speed. Possible to set 2
periods per day.
Note the settings in the
commissioning record.
→Timer reduced
speed
Reduced speed
Monday
Per 1: 00:00–24:00
Per 2: 00:00–00:00→
Reduced Speed
Monday-Friday
Per 1: 00:00–24:00
Per 2: 00:00–00:00↓
Set week schedule Monday to
Sunday, Monday-Friday + Holiday
for reduced speed. Possible to set 2
periods per day.
Note the settings in the
commissioning record.
→Extended
running
Extended running
60 min
Time in ext. running
0 min↓
Set the time for extended running.
Use digital input to force the unit to
start or increase to normal running
even if the actual mode is Off or
Reduced.
If the running time is set to 0 the
unit only runs as long as the digital
input is closed.
The time the extended running is
active is monitored in "Time in ext.
Running".
It's also possible to set a time here
as well in order to shorten the
initial set period.
124455 | A003

14 |Commissioning
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
→Holidays Holidays (mm:dd)
1:01–01 — 01–02
2:01–01 — 01–01
3:01–01 — 01–01↓
Set up to 24 separate possible
holiday periods for a full year.
A holiday period can be any
number of consecutive days from
one and upwards.
The dates are in the format: MM:
DD.
When the current date falls within
a holiday period, the scheduler will
use the settings for the weekday
“Holiday”.
→Manual/Auto In this menu the running mode of
all the configured output signals
and a number of control functions
can be manually controlled.
The supply air controller's output
signal can be manually set
(Manual/Auto) to any value
between 0 and 100%. The
temperature output signals will
change accordingly if they are in
Auto mode. It is also possible to
manually control each of the
temperature output signals
individually.
Since leaving any of the outputs in
manual control will disrupt the
normal control, an alarm will be
generated as soon as any output
is set to a manual mode.
Supply temp.
contr.
Auto
Manual set: 0.0↓
Set the supply air temperature
controller to Auto,Manual or Off.
Set the output signal between 0-
100%.
The outputs Y1, Y2 and Y3, if in
Auto-mode, will follow the signal
according to the set split values.
SAF: Auto
Manual set: 0.0↓Set the output signal for SAF
(supply air fan) to:Auto,
Manual,1/2–speed or 1/1–
speed.
EAF: Auto
Manual set: 0.0↓Set the output signal for EAF
(extract air fan) to:Auto,
Manual,1/2–speed or 1/1–
speed.
Heating
Auto
Manual set:
100.0↓
Set the heating to Auto,Manual
or Off.
Set the manual output 0-100%.
Exchanger
Auto
Manual set: 0.0↓
Set the exchanger rotor control to
Auto,Manual or Off
Set the manual output 0-100%
Cooling
Auto
Manual set: 0.0
Set the cooling to Auto,Manual or
Off
Set the manual output 0-100%
Note:
Needs to be activated in
order to be visible here
124455 | A003

Commissioning |15
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
P1 heating
Auto
Set the pump control for the
heating coil to Auto,On or Off
P1 exchanger
Auto
P1 cooling
Auto
Set the pump control for the
cooling coil to Auto,On or Off
Fire damper
Auto
Set the Fire damper to Auto,Open
or Close
Note:
Needs to be activated in
order to be visible here
Configuration of fire
damper functions are made
at Administrator level
Outdoor air
damper
Auto
Set the Outdoor air damper to
Auto,Open or Close
Exhaust air
damper
Auto
Set the Exhaust air damper to
Auto,Open or Close
Extra ctrl unit
Auto
Manual set: 0.0
Set the extra control unit to Auto,
Manual or Off.
Extra sequence Y4
Auto
Manual set: 0.0
Set the Extra sequence to Auto,
Manual or Off
Only visible for Topvex SC units
Extra sequence Y5
Auto
Manual set: 0.0
Set the Extra sequence to Auto,
Manual or Off
Not used in default setting.
→Settings In this menu group the settings for
the activated functions are
available. Depending on which
choices have been made in the
configuration menu some of the
possible alternatives may not be
displayed.
→Control temp Supply air control
P-band: 33.0°C
I-time: 100.0 sec
Set P-band and I-time for the
Supply air control function
Note:
See Corrigo manual-
Ventilation application for
more information.
Extract air control
P-band: 100.0°C
I-time: 300.0 sec
Set P-band and I-time for the
Extract air control function
Note:
See Corrigo manual-
Ventilation application for
more information.
124455 | A003

16 |Commissioning
Main menu item Sub-menu item 1 Sub-menu item 2 Explanations
Shutdown mode
P-band: 100.0°C
I-time: 100.0 sec
Set P-band and I-time for the
Shutdown function
Note:
See Corrigo manual-
Ventilation application for
more information.
→Frost protection
Active
Setp shutdown:
25.0°C
P-band active: 5.0°
C
Status for frost protection.
When running mode switched to
"Off".
Shutdown controller will control the
heating output to maintain a
constant settable temperature at
the frost protection sensor for the
hot water coil.
If frost protection temperature falls
below Frost protection Alarm
level + settable P-Band for frost
protection, it will rise the internal
signal and force the heating valve
to open to avoid freeze-up of hot
water coil.
Fast stop at frost
protection alarm
Yes
Set the fast stop of the unit in case
of frost protection alarm to Yes or
No.
Sequency with frost
protection
Y1 heating
Frost protection control.
Is available for Y1 heating, Y4
extra sequenceor on both Y1
and Y4.
→Control flow or
Control pressure
Only shown if Fan control selected
to these alternatives.
Flow control SAF
P-band: 2160.0 m³/h
I-time: 40.0 sec
Min. output: 0%
Set P-band, I-time and Min. output
for the supply air fan when the unit
comes configured as Flow
control from factory.
Alternatively Pressure control
if that configuration is chosen
Flow control EAF
P-band: 2160.0 m³/h
I-time: 40.0 sec
Min. output: 0%
Set P-band, I-time and Min. output
for the Extract air fan when the unit
comes configured as Flow
control from factory.
Alternatively Pressure control
if that configuration is chosen
Control extra
unit
Control: extra unit
P-band: 33.0 °C
I-time: 100.0 s
Set P-band and I-time for the Extra
Unit control function
Note:
See Corrigo manual-
Ventilation application for
more information.
→Alarm settings →Alarm limits Set the alarm limits and allowed
deviations for the different
functions
→Alarm delays Set the alarm delays and allowed
deviation delays for the different
functions
124455 | A003
