System air SysAqua 25 Manual

GB
3990726GB
IOM AQA 01-N-8GB
Air Cooled Water Chillers and Heat Pumps
Refroidisseurs de liquide à condensation par air et pompes à chaleur air/eau
Luftgekühlte Flüssigkeitskühler und Wärmpumpen
Refrigeratori d'Acqua e Pompe di Calore Raffreddati ad Aria
Enfriadores de Agua y Bomba de Calor Condensadas con Aire
Installation and maintenance manual
Manuel d’installation et de maintenance
Installations- und Wartungshandbuch
Manuale di installazione e di manutenzione
Manual de instalación y de mantenimiento
English Français EspañolDeutsch Italiano
IOM AQA 01-N-9
Part number / Code / Teil Nummer / Codice / Código : 3990726
Supersedes / Annule et remplace / Annulliert und ersetzt /
Annulla e sostituisce / Anula y sustituye : IOM AQA 01-N-8
25.3
Ü
128 kW
26.9
Ü
119.1 kW
SysAqua
25 ÷ 125

English
1SysAqua
INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

English
2SysAqua
CONTENTS
1. GENERAL RECOMMENDATIONS........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS .......................................................................................................................................................................................................................3
1.2. WARNING.........................................................................................................................................................................................................................................3
1.3. EQUIPMENT SAFETY DATA.............................................................................................................................................................................................................4
2. INSPECTION AND STORAGE.............................................................................................................................................................. 5
3. WARRANTY...................................................................................................................................................................................... 5
4. PRESENTATION................................................................................................................................................................................. 5
5. CONTENTS OF PACKAGE ................................................................................................................................................................... 6
5.1. OPTIONALS ACCESSORIES..............................................................................................................................................................................................................6
6. DIMENSIONS .................................................................................................................................................................................... 6
7. HANDLING........................................................................................................................................................................................ 6
7.1. NET WEIGHT.....................................................................................................................................................................................................................................6
7.2. GRAVITY CENTER POSITION...........................................................................................................................................................................................................6
7.2.1. WITHOUT BUFFER TANK............................................................................................................................................................................................................................................6
7.2.2. WITH BUFFER TANK ...................................................................................................................................................................................................................................................6
7.3. MANUTENTION GENERALITES ......................................................................................................................................................................................................7
7.3.1. HANDLING WITH A FORKLIFT ...................................................................................................................................................................................................................................7
7.3.2. HANDLING BY SLINGING...........................................................................................................................................................................................................................................8
8. TECHNICAL SPECIFICATIONS ............................................................................................................................................................. 9
8.1. PHYSICAL CHARACTERISTICS ........................................................................................................................................................................................................9
8.2. REFRIGERATION SPECIFICATIONS ...............................................................................................................................................................................................10
8.2.1. REFRIGERANT CIRCUIT DIAGRAM ......................................................................................................................................................................................................................... 10
8.2.2. REFRIGERANT CHARGE........................................................................................................................................................................................................................................... 10
8.2.3. FLUOROCARBON GAS REGULATIONS................................................................................................................................................................................................................... 10
8.3. ELECTRIC SPECIFICATIONS............................................................................................................................................................................................................10
8.3.1. SYSAQUA WITH STANDARD FAN.......................................................................................................................................................................................................................... 10
8.3.2. SYSAQUA WITH HIGH-PRESSURE FAN................................................................................................................................................................................................................. 11
8.4. OPERATING LIMITS........................................................................................................................................................................................................................11
8.4.1. SYSAQUAL/SYSAQUAH COOLING MODE ............................................................................................................................................................................................................ 11
8.4.2. SYSAQUAH HEATING MODE .................................................................................................................................................................................................................................. 11
9. INSTALLATION ................................................................................................................................................................................ 12
9.1. SITING THE INSTALLATION...........................................................................................................................................................................................................12
9.1.1. PREVAILING WIND................................................................................................................................................................................................................................................... 12
9.1.2. CONDENSATE WATER MANAGEMENT IN HEATING MODE................................................................................................................................................................................ 12
9.1.3. HOW TO REDUCE NOISE POLLUTION.................................................................................................................................................................................................................... 12
9.2. CLEARANCE....................................................................................................................................................................................................................................13
9.3. ATTACHMENT TO THE GROUND ..................................................................................................................................................................................................13
10. HYDRAULIC LINKS........................................................................................................................................................................ 14
10.1. MAIN HYDRAULIC CIRCUIT ........................................................................................................................................................................................................14
10.2. ANTI-CLOGGING PROTECTION..................................................................................................................................................................................................14
10.3. MINIMUM WATER VOLUME REQUIREMENTS..........................................................................................................................................................................15
10.3.1. SYSAQUA COOLING ONLY VERSION................................................................................................................................................................................................................... 15
10.4. MAXIMUM WATER VOLUME REQUIREMENTS ........................................................................................................................................................................15
10.5. RINSING THE CIRCUIT .................................................................................................................................................................................................................15
10.6. FROST PROTECTION ...................................................................................................................................................................................................................16
10.7. WATER QUALITY..........................................................................................................................................................................................................................17
10.8. HEAT INSULATION.......................................................................................................................................................................................................................18
10.9. FILLING THE SYSTEM WITH WATER..........................................................................................................................................................................................18
11. WIRING DIAGRAM AND LEGEND.................................................................................................................................................. 19
11.1. WIRING DIAGRAM ......................................................................................................................................................................................................................19
11.2. LEGEND ........................................................................................................................................................................................................................................19
11.2.1. POWER SUPPLY..................................................................................................................................................................................................................................................... 19
11.2.2. WIRING DIAGRAM KEY DESCRIPTIONS.............................................................................................................................................................................................................. 20
11.2.3. RANGE AND SETTINGS OF THEMAL PROTECTION / NOMINAL INTENSITY OF THE CONTACTORS (CLASSE AC3).................................................................................. 21
12. ELECTRICAL CONNECTIONS........................................................................................................................................................... 22
12.1. SYSAQUA 25 - 30 - 35 - 40.....................................................................................................................................................................................................23
12.2. SYSAQUA 45 - 55 - 65 - 75 - 90 - 105 - 125......................................................................................................................................................................24
12.3. OPTION ALL SEASONS ...............................................................................................................................................................................................................24
13. REGULATION ................................................................................................................................................................................ 25
13.1. ILTC CONTROL..............................................................................................................................................................................................................................25
13.1.1. GENERAL INFORMATION..................................................................................................................................................................................................................................... 25
13.1.2. DIP SWITCH............................................................................................................................................................................................................................................................ 25
13.1.3. FUNCTION OF DSW1 DIP SWITCHES .................................................................................................................................................................................................................. 25
13.1.4. FUNCTION OF DSW2 DIP SWITCHES .................................................................................................................................................................................................................. 26
13.2. KEYBOARD...................................................................................................................................................................................................................................26
13.2.1. SWITCH SM1.......................................................................................................................................................................................................................................................... 26
13.3. DISPLAY........................................................................................................................................................................................................................................26
13.4. MENU............................................................................................................................................................................................................................................27
13.5. ALARMS MANAGEMENT AND DISPLAY ..................................................................................................................................................................................28
13.5.1. HIGH PRESSURE ALARM ...................................................................................................................................................................................................................................... 28
13.5.2. LOW PRESSURE ALARM....................................................................................................................................................................................................................................... 28
13.5.3. ANTIFREEZE ALARM (COOLING MODE)............................................................................................................................................................................................................. 28
13.5.4. MENUS ALAR AND LOG....................................................................................................................................................................................................................................... 28
13.6. SENS MENU - SENSORS READOUT ..........................................................................................................................................................................................29
13.7. PARAMETERS LEVEL...................................................................................................................................................................................................................29
13.7.1. PARA MENU - USER LEVEL.................................................................................................................................................................................................................................. 29
13.7.2. PARA MENU - SERVICE LEVEL............................................................................................................................................................................................................................. 29
14. COMMISSIONING.......................................................................................................................................................................... 30
14.1. PRE-START CHECK LIST ..............................................................................................................................................................................................................30
14.1.1. VISUAL CHECK ....................................................................................................................................................................................................................................................... 30
14.1.2. ELECTRICAL CHECK ............................................................................................................................................................................................................................................... 30
14.1.3. HYDRAULIC CHECK................................................................................................................................................................................................................................................ 30
14.2. OPERATING CHECK LIST .............................................................................................................................................................................................................31
14.2.1. GENERAL................................................................................................................................................................................................................................................................ 31
14.2.2. PHASE ROTATION PROTECTION.......................................................................................................................................................................................................................... 31
14.2.3. ELECTRICAL............................................................................................................................................................................................................................................................ 31
14.2.4. COMPRESSOR AND REFRIGERATION SYSTEM.................................................................................................................................................................................................. 31
14.2.5. HYDRAULIC CIRCUIT.............................................................................................................................................................................................................................................. 31
14.2.6. FINAL CHECK.......................................................................................................................................................................................................................................................... 32
15. IN CASE OF WARRANTY - MATERIAL RETURN PROCEDURE ......................................................................................................... 32
16. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 32
17. MAINTENANCE............................................................................................................................................................................. 33
17.1. WEEKLY CHECK............................................................................................................................................................................................................................33
17.2. PERIODIC TABLE OF SERVICE AND MAINTENANCE ...............................................................................................................................................................34
17.3. MAINTENANCE PROCEDURES...................................................................................................................................................................................................36
17.3.1. REFRIGERANT CIRCUIT.......................................................................................................................................................................................................................................... 36
17.3.2. HYDRAULIC CIRCUIT.............................................................................................................................................................................................................................................. 37
17.3.3. WINTER PROTECTION .......................................................................................................................................................................................................................................... 38
18. TROUBLE SHOOTING..................................................................................................................................................................... 39

English
3SysAqua
1. GENERAL RECOMMENDATIONS
POWER SUPPLY MUST BE
SWITCHED OFF BEFORE STARTING
WORK IN THE ELECTRIC CONTROL
BOX
The purpose of this Manual is to provide users with instructions for installing, commissioning, using and
maintaining the units. It also contains instructions on starting up the machine as well as recommendations
to avoid bodily injury and risks of damage to the device during its operation.
It does not contain the complete description of all the maintenance operations guaranteeing the unit’s long
life and reliability. Only the services of a qualied technician can guarantee the unit’s safe operation over a
long service life.
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cutoff power supply before starting to work on the appliance.
When making the hydraulic connections, ensure that no impurities are introduced into the pipe work.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are
not respected.
If you meet a problem, please call the Technical Department of your area.
If possible, assemble the compulsory or optional accessories before placing the appliance on its nal location.
(see instructions provided with each accessory).
In order to become fully familiar with the appliance, we suggest to read also our Technical Instructions.
The information contained in these Instructions are subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in forces when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel having a good knowledge of standards and local regulations, as well as experience of this type
of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
The unit should be handled using lifting and handling equipment appropriate to the unit's size and weight.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
It is forbidden to start any work on the electrical components if water or high humidity is present on the
installation site.

English
4SysAqua
1.3. EQUIPMENT SAFETY DATA
Safety Data R410A
Toxicity Low
In contact with skin Skin contact with the rapidly evaporating liquid may cause tissue chilblains. In case of skin contact with the liquid, warm the frozen tissue with water and call a doctor. Remove contaminated clothing and
footwear. Wash the clothing prior to re-use.
In contact with eyes Vapours have no effect. Liquid splashes or sprays may cause freeze burns. In these cases rinse your eyes with running water or with a solution for eye lavages for at least 10 minutes. Immediately contact a
doctor.
Ingestion In this case, burns may result. Do not attempt to make the patient vomit. If the patient is conscious, rinse
the mouth with water. Call a doctor immediately.
Inhalation In case of inhalation, move the patient to an area with fresh air and provide oxygen if necessary. Perform artificial respiration if the patient has stopped breathing or lacks air. In case of cardiac arrest, perform
external cardiac massage. Call a doctor immediately.
Further Medical Advice Exposure to high concentrations can be dangerous for individuals with cardiac problems, as the presence of catecholamines such as adrenalin in the bloodstream may lead to increased arrhythmia and possible
cardiac arrest.
Occupational exposure limits R410A: Recommended limits: 1,000 ppm v/v 8 hours TWA.
Stability Stable product
Conditions to avoid Increased pressure due to high temperatures may cause the container to explode. Keep out of the sun
and do not expose to a temperature >50°C.
Hazardous reactions Possibility of dangerous reactions in case of fire due to the presence of F and/or CI radicals
General precautions
Avoid the inhalation of high concentrations of vapours. The concentration in the atmosphere shall be kept
at the minimum value and anyway below the occupational limits. Since vapours are heavier than air and
they tend to stagnate and to build up in closed areas, any opening for ventilation shall be made at the
lowest level.
Breathing protection In case of doubt about the actual concentration, wear breathing apparatus. It should be self-contained
and approved by the bodies for safety protection.
Storage Preservation Refrigerant containers shall be stored in a cool place, away from fire risk, direct sunlight and all
heat sources, such as radiators. The maximum temperature shall never exceed 50°C in the storage
place.
Protection clothes Wear boots, safety gloves and glasses or masks for facial protection.
Behaviour in case of leaks or
escapes
Never forget to wear protection clothes and brething apparatus. Isolate the source of the leakage,
provided that this operation may be performed in safety conditions. Any small quantity of
refrigerant which may have escaped in its liquid state may evaporate provided that the room is
well ventilated.In case of a large leakage, ventilate the room immediately. Stop the leakage with
sand, earth or any suitable absorbing material. Prevent the liquid refrigerant from flowing into
drains, sewers, foundations or absorbing wells since its vapours may create an asphyxiating atmosphere.
Disposal The best procedure involves recovery and recycle. If this is not possible, the refrigerant shall be
given to a plant which is well equipped to destroy and neutralise any acid and toxic by-product
which may derive from its disposal.
Combustibility features R410A: Non-inflammable at ambient temperatures and atmospheric pressures.
Containers If they are exposed to the fire, they shall be constantly cooled down by water sprays.
Containers may explode if they are overheated.
Behaviour in case of fire In case of fire wear protection clothes and self-contained breathing apparatus.

English
5SysAqua
2. INSPECTION AND STORAGE
At the time of receiving the equipment carefully cross check all the elements against the shipping documents
in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or
hidden damage.
In the event of shipping damage, write precise details of the damage on the shipper’s delivery note and
send immediately a registered letter to the shipper within 48 hours, clearly stating the damage caused.
Forward a copy of this letter to the manufacturer or his representative.
Never store or transport the unit upside down. It must be stored indoors, completely protected from
rain, snow etc. The unit must not be damaged by changes in the weather (high and low temperatures).
Excessively high temperatures (above 60 °C) can harm certain plastic materials and cause permanent
damage. Moreover, the performance of certain electrical or electronic components can be impaired.
The appliances are delivered fully assembled, factory tested and ready to operate.
Any modication to the units without the manufacturer’s prior approval, shall automatically render the
warranty null and void.
The following conditions must be respected in order to maintain the validity of the warranty:
²Commissioning shall be performed by specialised technicians from technical services approved by
the manufacturer.
²Maintenance shall be performed by technicians trained for this purpose.
²Only Original Equipment spare parts shall be used.
²All the operations listed in the present manual shall be performed within the required time limits.
THE WARRANTY SHALL BE NULL AND VOID IN THE EVENT
OF NON-COMPLIANCE WITH ANY OF THE ABOVE CONDITIONS.
3. WARRANTY
All the models in the SysAqua liquid coolers range are produced to state-of-the-art design and manufacturing
standards. In this way, they offer guarantees of high performance and reliability as well as the capability of
adapting to all types of air conditioning installations operating with both chilled water and glycol solutions
(and with hot water for the Heat pump units). The unit, designed for an outdoor mounted application, is not
suitable for any use other than those specied in the present manual.
Improper usage of the unit or a use for purposes other than those originally intended, without the prior
approval by the manufacturer or its agents, could result in the unit functioning outside its safe operating
limits and could present risks to both personnel and property.
4. PRESENTATION
SysAqua are packaged units, optimized for air conditioning applications.
After the units are assembled, the refrigerating and electrical circuits are tested at the factory in order to
guarantee correct operation.
The are lled with an operational refrigerant uid charge and are subjected to pressure tightness tests.
The Cooling only models can produce chilled water at temperatures varying between +18°C to +5°C or
chilled water/glycol solution at temperatures varying between +5°C to +2°C.
The Heat pump models can produce hot water at temperatures varying between +25°C and +55°C.

English
6SysAqua
SEE APPENDIX
5. CONTENTS OF PACKAGE
On opening the carton, check that all the accessories required for installation are present.
5.1. OPTIONALS ACCESSORIES
Anti-vibration rubber pads
Spring pads
Isolating valve
1 SysAqua
1 Water lter
1 Bag with the documentation
6. DIMENSIONS
7. HANDLING
7.1. NET WEIGHT
7.2. GRAVITY CENTER POSITION
7.2.1. WITHOUT BUFFER TANK
7.2.2. WITH BUFFER TANK
25 30 35 40 45 55 65 75 90 105 125
Without pump kg 270 300 310 310 510 510 580 580 760 870 890
1 pump kg 20 20 20 20 30 30 30 30 30 30 30
2 pumps kg / / / / 60 60 60 60 60 60 60
XLN kg / / / / 40 40 40 40 40 40 40
Buffer tank Kg 65 65 65 65 160 160 160 160 160 160 160
25 30 35 40
XGmm 470 470 470 470
YGmm 460 460 460 460
ZGmm 850 850 850 850
45 55 65 75 90 105 125
XGmm 940 940 1 000 1 000 1 000 1 000 1 000
YGmm 480 480 540 540 500 500 500
ZGmm 700 700 700 700 850 850 850
25 30 35 40
XGmm 480 480 480 480
YGmm 580 580 580 580
ZGmm 740 740 740 740
45 55 65 75 90 105 125
XGmm 1 250 1 250 1 270 1 270 1 100 1 100 1 100
YGmm 480 480 500 500 450 450 450
ZGmm 700 700 700 700 850 850 850

English
Do not tilt the SysAqua during handling, as it would be damaged irreversibly.
Caution
Never move the SysAqua on rollers.
Caution
When handling the SysAqua, beware not to damage the nned coil block. Protect it with cardboard
or particle panels.
Caution
Never submit the metal work (panels, posts) of the SysAqua to handling constraints, as only its base
is designed for that purpose.
Caution
7SysAqua
The good method of handling depends on the model of SysAqua and its nal destination.
²Take care to avoid any rough handling or impacts when unloading and moving the appliance.
²Before hoisting into position, test lift to insure stability and balance. Avoid twisting or uneven lifting
of the units.
²The units shall be carefully inspected before unit installation to make sure this has not happened.
²ll these sections have been inspected before leaving the factory. It is therefore important to insure
that no bolts, screws or other xing system are loosened or missing before the commissioning.
7.3. MANUTENTION GENERALITES
7.3.1. HANDLING WITH A FORKLIFT
A forklift can be used to handle the SysAqua 25/30/35/40 units
when palletized.
When a forklift is used to handle the
SysAqua 45/55/65/75/90/105/125 units,
lift them only along their width.
Place a safety wedge between the unit base and the fork
lift truck to avoid damaging the unit’s structure and casing.

English
Slings must never touch the unit casing of SysAqua.
Caution
8SysAqua
7.3.2. HANDLING BY SLINGING
Lifting is also possible by slinging.
Holes implemented at each end of the unit allow inserting slinging bars along the chassis width.
A spreader must be used to prevent damage to the machine edges.
25 30 35 40 45 55 65 75 90 105 125
Hole diameter mm 30 30 30 30 47 47 47 47 47 47 47
SysAqua 25/30/35/40
SysAqua 45/55/65/75/90/105/125 SysAqua 45/55/65/75/90/105/125
WITH BUFFER TANK
SysAqua 25/30/35/40
WITH BUFFER TANK

English
9SysAqua
8. TECHNICAL SPECIFICATIONS
8.1. PHYSICAL CHARACTERISTICS
(1) according to Eurovent.
25 30 35 40 45 55 65 75 90 105 125
Supply voltage 400V / 3 + N / 50Hz
Number of refrigerang circuit 1
REFRIGERANT
Type R410A
Factory charge SEE NAME PLATE
COMPRESSORS
Type Scroll
Number 22222222222
Startup type DIRECT
Part load steps % 0/50/100 0/43/
57/100 0/40/ 60/100 0/45/55/100 0/38/ 62/100 0/33/ 67/100
Crankcase heater W 2x40 2x49 2x49 2x49 2x66 2x66 2x66 2x66 66/82 66/95 66/95
EVAPORATOR
Type plates
Number 1
Water volume L1.78 2.55 2.55 2.55 4.1 4.1 6.1 6.1 10.8 10.8 10.8
water
ow
nominal
m3/h
4.3 4.8 6.1 6.6 8.0 9.3 11.2 12.8 15.3 17.6 20.9
minimum 2.7 3.0 3.8 4.1 5.0 5.8 7.0 8.0 9.6 11.0 13.1
maximum 7.2 8.0 10.2 11.0 13.7 15.5 18.7 21.3 25.5 29.3 34.8
Water pressure losses kPa 40 24 40 44 30 38 31 36 28 38 49
Antifreeze electric
heater W30 30 30 30 30 30 2x30 2x30 2x30 2x30 2x30
FANS
Type AXIAL
Number 11111122222
STD
Speed tr/mn 900 900 650 650 860 860 650 650 860 860 860
Air ow rate m3/h 13 000 13 000 16 000 16 000 22 500 22 500 15 000 15 000 21 000 21 000 21 000
Input power W 940 940 930 930 2 100 2 100 930 930 2 100 2 100 2 100
HPF
Speed tr/mn 870 870 870 870 890 890 870 870 890 890 890
Air ow rate m3/h 14 000 14 000 14 000 14 000 21 000 21 000 16 000 16 000 20 000 20 000 20 000
Input power W 1 950 1 950 1 950 1 950 1 950 1 950 1 950 1 950 1 950 1 950 1 950
Static Pressure Pa 140 140 140 140 100 100 130 130 100 90 90
COILS
Number 11111122222
Frontal surface m² 2.40 2.40 2.80 2.80 4.20 4.20 5.55 5.55 6.40 6.40 6.40
Number of rows 22222222233
HYDRAULIC LINKS
Type Male gas threaded
Inlet diameter pouce 1" 1/2 1" 1/2 1" 1/2 1" 1/2 2" 2" 2" 2" 2" 1/2 2" 1/2 2" 1/2
Outlet diameter pouce 1" 1/2 1" 1/2 1" 1/2 1" 1/2 2" 2" 2" 2" 2" 1/2 2" 1/2 2" 1/2
BUFFER TANK (OPTION)
Volume L 100 100 100 100 300 300 300 300 300 300 300
ACOUSTICAL DATA
Sound
power level
(1)
STD dB(A) 75 75 76 76 80 80 80 80 83 83 83
HPF dB(A) 79 79 80 80 81 81 82 82 84 84 84
XLN dB(A) / / / / 77 77 77 77 79 79 79

English
This equipment contains uorinated gas with greenhouse gas effects covered by the Kyoto
agreement.
Caution
SysAqua units use the R410A uoro-carbonated uid, belonging to group 2 as dened in directive
97/23/CE. Considering the maximum operating pressure of these units (42 bar g), they integrate
category 2 (or lower) components as dened in directive 97/23/CE.
Caution
10 SysAqua
8.2. REFRIGERATION SPECIFICATIONS
8.2.1. REFRIGERANT CIRCUIT DIAGRAM
SEE APPENDIX
8.2.2. REFRIGERANT CHARGE
The type and quantity of refrigerating uid per circuit are indicated on the product plate.
The installer and end user will get informed on local environmental regulations for the installation, operation
and disposal of the equipment ; more particularly, for the collection of substances hazardous for the
environment (refrigerating uid, oil, antifreeze, etc.). A refrigerating uid, whatever it is, must not be vented.
Refrigerating uids must be handled by skilled personnel.
8.2.3. FLUOROCARBON GAS REGULATIONS
The EC No. 842/2006 regulation covering uorinated greenhouse gases requires of refrigeration equipment
operators to comply with the following ve obligations:
Non-compliance with one of these obligations constitutes an offense and can result in nancial
penalties.
Furthermore, compliance of the equipment with the uorinated gases regulation must be proven to
the insurance company.
Caution
1. Installation, servicing, maintenance as well as checking the sealing must be carried out by qualied
personnel.
2. The uorinated gas must be recovered during servicing and maintenance as well as the end of the
installation.
3. All the necessary measures must be taken to prevent the leakage of uorinated gases and any leaks
must be repaired as rapidly as possible.
4. Regular checks on any leaks must be performed according to the following conditions:
load6 kg - at least once every 12 months
load30 kg - at least once every 6 months
5. A document grouping a description of all the operations carried out on the cooling circuit must be
drafted and conserved.
8.3. ELECTRIC SPECIFICATIONS
8.3.1. SYSAQUA WITH STANDARD FAN
25 30 35 40 45 55
Power supply 3N ~400 V - 50 Hz
Without
pump
Maximum current A 22.5 24.5 32 34 41 45
Fuse rating aM A 25 25 32 40 50 50
Total starting current (without soft starter) A 64 77 119 120 134 141
Total starting current (with soft starter) A 35 49 53 54 67 74
Standard
pump
Maximum current A 24.5 26.5 34.5 36.5 43.5 50
Fuse rating aM A 25 32 40 40 50 50
Total starting current (without softstarter) A 66 79 121 122 137 146
Total starting current (with softstarter) A 37 51 56 57 69 79
65 75 90 105 125
Power supply 3N ~400 V - 50 Hz
Without
pump
Maximum current A 59.5 64.5 79.5 87.5 103.5
Fuse rating aM A 63 80 80 100 125
Total starting current (without soft starter) A 202 207 266 313 351
Total starting current (with soft starter) A 101 106 129 147 184
Standard
pump
Maximum current A 64.5 69.5 84.5 92.5 108.5
Fuse rating aM A 80 80 100 100 125
Total starting current (without softstarter) A 207 212 271 318 356
Total starting current (with softstarter) A 106 111 134 152 189

English
-20
-15
-10
-5
0
5
10
15
20
25
15 20 25 30 35 40 45 50 55
60
Leaving water temperature (°C)
Air temperature (°C)
-15
-10
-5
0
5
10
15
20
25
30
35
40
45
50
55
-15 -10 -5 0 5 10 15
20
Leaving water temperature (°C)
Air temperature (°C)
BRINES or
WATER + GLYCOL
+ Fan speed controller
WATER + Fan
speed controller
BRINES or
WATER + GLYCOL WATER
11SysAqua
IMPORTANT
* These datas are given for guidance only. They must be checked aat commissioning according to prevailing
standards. They depend on the installation and the cables used.
A main fuse must mandatorily be provided on the power supply.
²Fuses not supplied
²Cables not supplied
8.3.2. SYSAQUA WITH HIGH-PRESSURE FAN
8.4. OPERATING LIMITS
8.4.1. SYSAQUAL/SYSAQUAH COOLING MODE
8.4.2. SYSAQUAH HEATING MODE
25 30 35 40 45 55
Power supply 3N ~400 V - 50 Hz
Without
pump
Maximum current A 24.5 26.5 34 36 41 45
Fuse rating aM A 25 32 40 40 50 50
Total starting current (without soft starter) A 66 80 120 121 134 141
Total starting current (with soft starter) A 38 51 55 56 67 74
Standard
pump
Maximum current A 26 28 36.5 38.5 43.5 49
Fuse rating aM A 32 32 40 40 50 50
Total starting current (without softstarter) A 68 82 123 124 137 146
Total starting current (with softstarter) A 40 53 57 58 69 79
65 75 90 105 125
Power supply 3N ~400 V - 50 Hz
Without
pump
Maximum current A 63 68 79.5 87.5 103.5
Fuse rating aM A 63 80 80 100 125
Total starting current (without soft starter) A 205 210 267 314 352
Total starting current (with soft starter) A 105 110 129 147 184
Standard
pump
Maximum current A 67.5 72 83.5 92 108
Fuse rating aM A 80 80 100 100 125
Total starting current (without softstarter) A 210 215 271 319 357
Total starting current (with softstarter) A 110 115 134 152 189

English
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work
or constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or
a degradation with dangerous consequences for personnel and property. In such an event, the
warranty shall be null and void.
Caution
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
Unit operation depends on air temperature. Any recycling of air extracted by the fan lowers the air
intake temperature across the exchanger ns and alters the standard operating conditions.
Caution
Do not expose the SysAqua to rejections from chimneys or vents. Fumes charged with soot or
grease as well as acid rejections are likely to clog or damage the condenser irreversibly. This would
cancel the warranty.
Caution
12 SysAqua
9. INSTALLATION
9.1. SITING THE INSTALLATION
The SysAqua must be installed outdoors with sufcient surrounding clearance to enable unobstructed air
circulation through the appliance and access for maintenance work.
In the case of the unit being sited in areas exposed to high winds, you must avoid the wind hitting the
fan blowing surface areas directly to avoid any risk of recycling cooled air. Exchanger fan operation can be
disrupted by strong winds, which can cause de-icing problems and fan malfunctions.
Depending on temperature and outdoor air humidity conditions, water vapour contained in the air can
condense on the nned heat exchanger and even form ice under low outdoor temperature conditions (around
< 5°C). This condensate water and defrosted water runs off via outlets provided under the exchanger. To aid
water run-off and avoid frozen water remaining in the appliance in winter, we recommend that it is mounted
at a height of around 10cm off the ground. In this way, condensate and defrosted water can run off freely
and be absorbed into the ground or channelled to a basin built under the appliance in order to protect the
environment.
In areas where outdoor temperatures fall below 1°C, the system can be equipped with a condensate anti-
freeze protection system (e.g. a heated pipe sheath, Not supplied).
In orderto contain noise levels,we equip our applianceswith quiet fans and encase the technical compartment
in sound-proofed panels. However, noise levels can be reduced even further by following a few installation
precautions:
²Do not install the appliance near a window.
²Do not install the unit in enclosed or conned yards, narrow locations where noise may be reected
on walls
²Avoid locating the appliance in a corner (increased reverberated noise).
²Install the rubber pads supplied or anti-vibration pads (available as an option) under the appliance.
²Do not join the concrete slab supporting the appliance to the structure of the dwelling (structure-
borne noise transmission).
²Electrical and hydraulic connections to the unit must be exible to avoid transmitting vibrations.
9.1.1. PREVAILING WIND
9.1.2. CONDENSATE WATER MANAGEMENT IN HEATING MODE
9.1.3. HOW TO REDUCE NOISE POLLUTION

English
When several SysAqua units are installed, ensure proper clearance is implemented around the
condensers specic to each machine.
Caution
956
1056
1927
968
1213.5
2427
968
1418
1056
13SysAqua
9.2. CLEARANCE
When choosing the location for the
SysAqua, take care to leave sufcient
free clearance on all sides to ensure
easy access for maintenance work. The
minimum free clearance dimensions indicated must
be observed to ensure both proper system operation
and allow access for maintenance and cleaning.
9.3. ATTACHMENT TO THE GROUND
The surface of the oor or structure located under the SysAqua must be at, and with sufcient strength
to withstand the unit's weight with its full liquid load, and occasional presence of maintenance equipment.
For normal applications,
rigidity of the SysAqua
and the positions of
supports allow for an
installation minimizing
vibrations. However, the
installers can use anti-
vibration rubber pads
(supplied in option).
The SysAqua does not require anchoring on the foundations, except in regions exposed to a high earthquake
risk or if the device is installed on a high level on a steel frame.
When tting anti-vibration pads, refer to the manual supplied with the kit.
SysAqua 25/30/35/40
SysAqua 45/55/65/75/90/105/125 SysAqua 45/55/65/75/90/105/125
WITH BUFFER TANK
SysAqua 25/30/35/40
WITH BUFFER TANK

English
The mains hydraulic circuit will provide a constant water ow on the refrigerating uid/water plate
exchanger and in case of load variation.
Caution
When choosing and installing water pipes, you must consult and observe all current local standards,
regulations and instructions.
Caution
The expansion tank must be dimensioned to be able to absorb an expansion corresponding to 2%
total volume of water contained in the installation (exchanger, piping, installations and buffer tank,
if present).
Caution
THE WARRANTY DOES NOT COVER DAMAGE DUE TO CORROSION RESULTING FROM ELECTROLYTIC
PHENOMENA.
Caution
To avoid anyrisk of foreign bodies entering the appliance and to guarantee operating performance,
IT IS IMPERATIVE TO INSTALL WATER FILTER on the SysAqua inlet pipe.
Caution
THE MANUFACTURER'S WARRANTY IS VOID IF THE FILTER SUPPLIED WITH
THE SysAqua IS NOT INSTALLED TO PROTECT THE APPLIANCE
Caution
14 SysAqua
10. HYDRAULIC LINKS
10.1. MAIN HYDRAULIC CIRCUIT
You must design the pipe network with the minimum number of bends and keep the number of changes in
height to the strict minimum. This will reduce installation costs and ensure optimum system performance.
The pipe network must include:
²A vibration elimination system (e.g.: link hoses available as an accessory) on all pipes connected to
the appliance in order to reduce vibrations and noise transmitted to the building fabric.
²A balancing valve on the water outlet pipe in order to control the water ow balance.
²Stop cocks to isolate the hydraulic circuit during maintenance.
²Manual or automatic bleed valves at the highest point on the water circuit.
²Draining connectors at all low points to allow complete circuit draining
²A circulation pump guaranteeing ow and manometric height necessary for the operation of the
SysAqua unit.
²A diaphragm expansion tank tted with a safety and draining valve must be visible.
²A low water pressure sensor to secure the water pump against cavitation if the water pressure in the
circuit decreases.
²The installation of thermometers and pressure gauges on the heat exchanger inlet and outlet to
facilitate day-to-day controls and system maintenance.
²An element ensuring ground continuity of all piping. An unbalance of grounding connection points
can cause corrosion problems due to electrolytic phenomena.
10.2. ANTI-CLOGGING PROTECTION
By default, the SysAqua plate exchanger
would be clogged soon after start-up.
Proper operation of the SysAqua would
be disturbed by the reduced water ow. In
case of insufcient water ow, the plate
exchanger would be damaged IRREVERSIBLY.
The mesh size of the lter must be lower than
800 µm.

English
Before lling the installation, check it and remove any contamination such as sand, stone, welding
chips and other materials likely to damage the SysAqua.
Caution
15SysAqua
For refrigeration only units, the total volume on the level of the primary water circuit must never below:
²application air conditioning
3.5 L/kW refrigeration power
²application process
10 L/kW refrigeration power
10.3. MINIMUM WATER VOLUME REQUIREMENTS
To ensure that the system operates correctly you must use suitably sized and properly routed pipes for the
hydraulic links between the SysAqua and the mains network. Proper operation of the regulation and safety
devices is ensured only when the water volume is sufcient.
10.3.1. SYSAQUA COOLING ONLY VERSION
For reversible units, a water volume equivalent to 12.5L/kW is recommended, which provides for a sufcient
energy reserve to ensure defrosting cycles without discomfort for the end user.
If the total volume of the primary hydraulic circuit does not allow to reach these recommendations, a buffer
tank must be added to the installation to increase the water volume up to the value required.
If the unit runs with a low volume of water (with air treatment plant…) or if it is used for industrial processes,
a buffer tank is compulsory to guarantee sufcient thermal inertia and satisfactory temperature stability.
10.4. MAXIMUM WATER VOLUME REQUIREMENTS
The maximum water volume is limited by the sizing of the unit's expansion tank and/or the expansion tank
present in the facility's hydraulic circuit. Expansion tanks must be sized according to the glycol percentage
in the hydraulic circuit.
Fully rinse all water pipes before nal connection to the SysAqua.
When using an off-the-shelf acid rinsing solution, implement a temporary branching around the SysAqua to
prevent damaging internal components (particularly the plate exchanger, ow switch, pump...).
10.5. RINSING THE CIRCUIT
Internal water tank :
²SysAqua 25-30-35-40  100L
²SysAqua 45-55-65-75-90-105-125 300L
The volume of the expansion tanks selected with Single pump and double pump options are :
The expansion tank should be installed at the pump suction, and the pressure inside will be adjusted by
taking into account the whole hydraulic circuit.
25 30 35 40 45 55 65 75 90 105 125
Minimum water volume in the system
application air conditioning L93 99 132 137 172 196 242 263 336 390 448
Minimum water volume in the system
application process L266 283 376 393 491 560 691 751 960 1115 1280
25 30 35 40 45 55 65 75 90 105 125
Minimum water volume in the system L 336 371 466 520 606 728 840 949 1101 1263 1489
25 30 35 40 45 55 65 75 90 105 125
volume of the expansion tank supplied
with hydraulic options L8 8 8 8 12 12 12 12 18 18 18

English
For Heatpump models, if the outdoor temperature is likely to fall below +1°C, provide a system to
prevent the condensates from freezing (e.g. heating cord).
Caution
THE USE OF A GLYCOL-BASED SOLUTION IS THE ONLY EFFECTIVE FROST-PROTECTION MEANS
Caution
Never ll the hydraulic circuit with pure glycol. Maximum glycol concentration is 30%. The water
and glycol mixture must be precisely prepared before lling the hydraulic circuit. If the mixture is
too much concentrated, the hydraulic could be damaged and the unit SysAqua should not perform
normally. In this case, unit guarantee will be cancelled.
Caution
The glycol percentage in the installation's hydraulic circuit must be entered in the ILTC regulation
upon start-up. This parameter setting changes the safety and alarm triggering threshold limits. An
incorrect value may cause malfunctions and a destruction of the unit's heat exchanger.
Caution
Avertissement
It is strongly recommended to post, on the electric box of the unit, glycol type and concentration in
the hydraulic circuit.
16 SysAqua
10.6. FROST PROTECTION
If the SysAqua is exposed to ambient temperatures between 0°C and -18°C, protect the water circuit
against frost.
Draining the water circuit is not recommended for frost protection, for the following reasons:
²The water circuit will rust, which will shorten its lifetime.
²Water will remain at the bottom of the plate exchangers and freezing may cause damage.
The glycol-based water solution must be sufciently concentrated to ensure appropriate protection and
prevent ice from forming at the minimum outdoortemperatures planned for the installation. Take precautions
when using non inert MEG antifreeze solutions (Mono Ethylene Glycol or MPG Mono Propylene Glycol). With
this type of antifreeze solution, corrosion may occur in the presence of oxygen.
Contact glycol resellers to ensure that its characteristics are compatible with environmental directive
applicable on site (this is not under manufacturer responsibility).
The glycol-based solution slightly modies the installation's performance, particularly in terms of load loss:
Minimum outdoor temp. °C 5 > T > 0 0 > T > -5 -5 > T > -10
Ethylene glycol concentration % 10 20 30
Correction
factor
load loss 1.070 1.129 1.181
water ow 1.013 1.040 1.074
thermodynamic power 0.991 0.982 0.972
Example for a solution with 20% glycol ethylene:
²load loss x 1.129
²water ow x 1.040
²thermodynamic power x 0.982
Minimum outdoor temp. °C 5 > T > 0 0 > T > -5 -5 > T > -10
Propylene glycol concentration % 10 20 30
Correction
factor
load loss 1.068 1.147 1.248
water ow 1.010 1.028 1.050
thermodynamic power 0.987 0.975 0.962

English
The SysAqua must not run on a network with open loops, likely to cause incidents related to
oxygenation, or with non treated table water.
Caution
If the water circuit is to be drained for a time exceeding one month, the circuit must be fully
charged with nitrogen to prevent any risk of corrosion by differential venting.
Caution
The manufacturer is not liable for recommendations in terms of water treatment (call a specialized
company).
However, this matter has a critical nature, and particular care must be given to ensure that the type
of treatment applied is effective.
The liability of the manufacturer or its representative will not be sought when non treated water
or non compliant quality water is used.
Caution
17SysAqua
10.7. WATER QUALITY
The water must be analyzed; the hydraulic network system installed must include all elements necessary
for water treatment: lters, additives, intermediate exchangers, drain valves, vents, check valves, etc.,
according to the results of the analysis.
Using improperly treated or non treated water in the SysAqua may cause scaling, erosion, corrosion or
algae or sludge deposits in the exchangers. Refer to a specialist skilled in water treatment to determine
any treatment to apply. The manufacturer will not be held liable for damages caused when non treated or
improperly treated water, demineralized water, salty water or sea water are used.
Apply the following guidelines :
²No NH4+ ammonium ions in the water, highly detrimental to copper. <10mg/l
²Cl- chloride ions are detrimental to copper with a risk of puncture by picking corrosion. <10mg/l.
²SO42- sulphate ions may cause perforating corrosion. < 30mg/l.
²No uoride ions (<0.1 mg/l)
²No Fe2+ and Fe3+ ions, particularly in case of dissolved oxygen. Fe< 5mg/l with dissolved oxygen
< 5mg/l. The presence of these ions with dissolved oxygen indicates corrosion of steel parts, likely
to generate corrosion of copper parts under Fe deposits, particularly in the case of multitubular
exchangers.
²Dissolved silica: silica is an acid element of water and may also cause corrosion. Content < 1mg/l.
²Water hardness: TH > 2.8K. Values between 10 and 25 may be recommended. This facilitates scaling
deposits likely to limit copper corrosion. Excess TH values may lead to clogging the pipes.
²TAC<100
²Dissolved oxygen: Prevent any sudden change in the water's oxygenation conditions. Also, avoid
deoxygenating water by sparging inert gas as well as overoxygenating it by pure oxygen sparging.
Disturbing oxygenation conditions destabilizes copper hydroxides and particle salting-out.
²Electrical Resistivity - Conductivity: The higher the resistivity, the slower the corrosion. Values above
3000 ohm/cm are preferred. A neutral environment favours maximum resistivity. For electrical
conductivity, values around 200-600 S/cm can be recommended.
²pH: neutral pH at 20°C (7 < pH < 8)

English
The water inlets and outlets must be connected as described on the labels afxed near the
connections.
Caution
FILLING OR DRAINING THE WATER CIRCUIT MUST BE PERFORMED BY SKILLED PERSONS USING THE
APPROPRIATE DEVICES ON THE EXTERNAL HYDRAULIC CIRCUIT BY THE INSTALLER.
Caution
VV VR
VV VR
UNIT 1
UNIT 2
V : Isolating valves VR : Balancing valves
18 SysAqua
When two or three units are connected in parallel, it is recommended that the return circuit connections are
reversed (Tickelman loop system) in order to reduce the pressure loss in each unit’s circuit.
Always check that the manual or automatic air drains are installed at all the high points of the hydraulic
network.
Install a balancing valve on the water outlet pipe to control the water ow balance.
To guarantee proper energy efciency and compliance with current standards, water pipes passing through
uninhabited zones should be properly lagged to retain heat.
To achieve correct insulation with conductivity of 0.04 W/mK, lag the pipes with insulating material with a
radial thickness between 25mm and 30 mm.
10.8. HEAT INSULATION
10.9. FILLING THE SYSTEM WITH WATER
It is important to ensure that the mains water supply pressure is sufficient to fill the installation.
Once the installation is complete and after having clean and rinsed out the circuit network, you must ll
the water circuit in accordance with current professional standards until you obtain the service pressure
which will be:
0.5 bar < Service Pressure < 2.5 bars.
When the hydraulic pump option is selected, a
safety valve is mounted (factory assembled) at the
Aqualogic water inlet to prevent from over pressure in
the circuit. The installer has to put a pipe at the safety
valve outlet for water evacuation.
A 3,5 bars safety valve is mounted in the unit when hydraulic options are selected (single or double pump).
