System air SYSLOOP 70 Manual

Installation and maintenance manual
Water source heat pump
1 727 â3 677m3/h
7.0 â13.3kW
8.1 â14.6kW
70 / 135
SYSLOOP 70-135

INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

English
2SYSLOOP 70-135
CONTENTS
1. GENERAL RECOMMENDATIONS........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS .......................................................................................................................................................................................................................3
1.2. WARNING.........................................................................................................................................................................................................................................3
1.3. EQUIPMENT SAFETY DATA.............................................................................................................................................................................................................4
2. INSPECTION AND STORAGE .............................................................................................................................................................. 5
3. WARRANTY...................................................................................................................................................................................... 5
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE ............................................................................................................. 5
5. PRESENTATION................................................................................................................................................................................. 5
6. CONTENTS OF PACKAGE ................................................................................................................................................................... 6
6.1. OPTIONAL ACCESSORIES................................................................................................................................................................................................................6
7. DIMENSIONS .................................................................................................................................................................................... 6
8. HANDLING........................................................................................................................................................................................ 6
8.1. NET WEIGHT.....................................................................................................................................................................................................................................6
8.2. GENERAL HANDLING......................................................................................................................................................................................................................6
8.2.1. HANDLING WITH A FORKLIFT ...................................................................................................................................................................................................................................6
9. TECHNICAL SPECIFICATIONS ............................................................................................................................................................. 7
9.1. MODELS DESIGNATION ..................................................................................................................................................................................................................7
9.2. PHYSICAL CHARACTERISTICS ........................................................................................................................................................................................................8
9.2.1. SYSLOOP - EC MOTOR...............................................................................................................................................................................................................................................8
9.3. ELECTRIC SPECIFICATIONS..............................................................................................................................................................................................................9
9.4. OPERATING LIMITS..........................................................................................................................................................................................................................9
9.4.1. TEMPERATURE LIMITS ...............................................................................................................................................................................................................................................9
9.4.2. FLOW LIMITS............................................................................................................................................................................................................................................................ 10
9.5. REFRIGERATION SPECIFICATIONS ...............................................................................................................................................................................................11
9.5.1. REFRIGERANT CIRCUIT DIAGRAM ......................................................................................................................................................................................................................... 11
9.5.2. REFRIGERANT CHARGE........................................................................................................................................................................................................................................... 11
9.5.3. FLUOROCARBON GAS REGULATIONS................................................................................................................................................................................................................... 11
10. INSTALLATION.............................................................................................................................................................................. 12
10.1. GENERALITIES..............................................................................................................................................................................................................................12
10.2. CLEARANCE .................................................................................................................................................................................................................................12
10.3. UNIT LOCATION...........................................................................................................................................................................................................................13
11. DUCTING AND NOISE LEVEL REDUCTION ...................................................................................................................................... 14
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME.....................................................................................................................................................15
11.2. MODIFYING THE AIR BLOWING DIRECTION ............................................................................................................................................................................15
11.3. FILTER ACCESS.............................................................................................................................................................................................................................16
11.4. VENTILATION ...............................................................................................................................................................................................................................16
11.5. AERAULIC ADJUSTEMENT...........................................................................................................................................................................................................16
11.5.1. SL70.EC / SL85.EC................................................................................................................................................................................................................................................ 17
11.5.2. SL100.EC / SL110.EC ........................................................................................................................................................................................................................................... 17
11.5.3. SL120.EC / SL135.EC ........................................................................................................................................................................................................................................... 18
12. HYDRAULIC LINKS........................................................................................................................................................................ 19
12.1. WATER QUALITY..........................................................................................................................................................................................................................19
12.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS ........................................................................................................................................................20
12.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM..........................................................................................................................22
13. WIRING DIAGRAM AND LEGEND.................................................................................................................................................. 23
13.1. WIRING DIAGRAM ......................................................................................................................................................................................................................23
13.2. WIRING DIAGRAM KEY DESCRIPTIONS....................................................................................................................................................................................23
13.3. POWER SUPPLY...........................................................................................................................................................................................................................23
13.4. PRESSOSTATS SETTING ..............................................................................................................................................................................................................23
14. ELECTRICAL CONNECTIONS........................................................................................................................................................... 23
14.1. UNIT POWER SUPPLY .................................................................................................................................................................................................................24
14.2. ALARM INDICATORS...................................................................................................................................................................................................................25
14.3. REMOTE CONTROLS ...................................................................................................................................................................................................................25
14.4. COMMUNICATION.......................................................................................................................................................................................................................26
14.5. REMOTE CONTROL......................................................................................................................................................................................................................26
14.5.1. WALL MOUNTING ................................................................................................................................................................................................................................................. 26
14.5.2. ELECTRICAL CONNECTIONS................................................................................................................................................................................................................................. 27
15. REGULATION ................................................................................................................................................................................ 28
15.1. ORDER OF PRIORITY FOR CONTROL SYSTEMS.......................................................................................................................................................................28
15.2. WALL-MOUNTED CONTROL.......................................................................................................................................................................................................28
15.2.1. KEYPAD................................................................................................................................................................................................................................................................... 28
15.2.2. SCREEN................................................................................................................................................................................................................................................................... 29
15.2.3. TIME SETTINGS...................................................................................................................................................................................................................................................... 29
15.2.4. SCHEDULING.......................................................................................................................................................................................................................................................... 30
16. FINAL TASKS ................................................................................................................................................................................ 31
17. STARTING - RECOMMENDATIONS - SETTINGS.............................................................................................................................. 31
17.1. COMMISSIONING ........................................................................................................................................................................................................................32
17.1.1. DEMAND FOR COOLING....................................................................................................................................................................................................................................... 32
17.1.2. DEMAND FOR HEATING....................................................................................................................................................................................................................................... 32
17.1.3. FINAL CHECK.......................................................................................................................................................................................................................................................... 32
18. MAINTENANCE AND SERVICING................................................................................................................................................... 33
18.1. MAINTENANCE PROCEDURES...................................................................................................................................................................................................33
18.1.1. GENERAL................................................................................................................................................................................................................................................................ 33
18.1.2. GENERAL INSPECTION.......................................................................................................................................................................................................................................... 33
18.1.3. REFRIGERATION CIRCUIT...................................................................................................................................................................................................................................... 33
18.1.4. ELECTRICAL SECTION............................................................................................................................................................................................................................................ 33
18.1.5. AIR FILTER .............................................................................................................................................................................................................................................................. 34
18.1.6. FAN MOTOR ASSEMBLY....................................................................................................................................................................................................................................... 34
18.2. FAULT FINDING............................................................................................................................................................................................................................35
18.2.1. NEITHER THE FAN NOR THE COMPRESSOR OPERATE ..................................................................................................................................................................................... 35
18.2.2. VENTILATION (FAN) MODE OPERATES BUT THE COMPRESSOR DOES NOT OPERATE................................................................................................................................ 35
18.2.3. INSUFFICIENT COOLING OR HEATING PRODUCTION........................................................................................................................................................................................ 35
18.2.4. INSUFFICIENT WATER FLOW AT THE LEVEL OF THE COAXIAL EXCHANGER.................................................................................................................................................. 35
18.2.5. APPEARANCE OF WATER DROPLETS IN THE APPLIANCE................................................................................................................................................................................ 35
18.2.6. APPEARANCE OF ABNORMAL NOISES AND VIBRATIONS IN THE CASING................................................................................................................................................... 36
18.3. ALARM CODES.............................................................................................................................................................................................................................36
19. WARRANTY CLAIM - MATERIAL RETURN PROCEDURE................................................................................................................. 37
20. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 37
21. DISPOSAL..................................................................................................................................................................................... 37

English
3SYSLOOP 70-135
1. GENERAL RECOMMENDATIONS
POWER SUPPLY MUST BE
SWITCHED OFF BEFORE STARTING
WORK IN THE ELECTRIC CONTROL
BOX
The purpose of this Manual is to provide users with instructions for installing, commissioning, using and
maintaining the units. It also contains instructions on starting up the machine as well as recommendations
to avoid bodily injury and risks of damage to the device during its operation.
It does not contain the complete description of all the maintenance operations guaranteeing the unit’s long
life and reliability. Only the services of a qualied technician can guarantee the unit’s safe operation over a
long service life.
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cut off the power supply before starting work on the appliance.
When forming the hydraulic connections, ensure that no impurities are introduced into the pipe work.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are not
complied with.
If you encounter a problem, please call the Technical Department for your area.
If possible, assemble the compulsory or optional accessories before placing the appliance in its nal location
(see instructions provided with each accessory).
To familiarize yourself fully with the appliance, we recommend that you also read our Technical Instructions.
The information contained in these Instructions is subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in force when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel who have a good knowledge of standards and local regulations, as well as experience of this
type of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
The unit should be handled using lifting and handling equipment appropriate to the unit's size and weight.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
Work must not be carried out on the electrical components if water or high humidity is present at the
installation site.
SAFETY SYMBOLS
ELECTRIC
VOLTAGE ROTATING PART RISK OF ASPHYXIA
PRESSURIZED
EQUIPMENT
RISK OF
CUTTING
RISK OF BURNS

English
4SYSLOOP 70-135
1.3. EQUIPMENT SAFETY DATA
Safety data R513A
Toxicity level Low.
In contact with the skin Dermal contact with the rapidly evaporating liquid can cause frostbite to the tissue. In the event of contact with the liquid, warm the frozen tissue with water and notify a physician. Remove
contaminated clothing and shoes. Wash clothes before reuse
In case of eye contact Steam has no effect. Splashing or splashing liquid can cause burns. Clean immediately with eye drops
or clean water for at least 15 minutes. Seek medical attention urgently.
Ingestion Burns can occur if this happens. Do not induce vomiting. When the patient is conscious, wash the
mouth with water. Seek medical attention urgently.
Inhalation If inhaled, move to fresh air and give oxygen if necessary. Perform artificial respiration if the patient is no longer breathing or is short of air. In the event of cardiac arrest, perform external CPR. Seek
immediate medical attention.
Other medical advice Cardiac sensitivity may, in the presence of circulating catecholamines such as adrenaline, lead to
increased arrhythmias and subsequent cardiac arrest if exposed to high concentrations.
Occupational exposure limits R513A: Recommended limit: 1,000 ppm - 8 hours.
Stability Room temperature stable product
Conditions to avoid Pressure build-up due to high temperatures can cause the container to explode. Protect from sunlight
and do not expose to a temperature >50°C.
Dangerous reactions Possibility of dangerous reactions in case of fire due to the presence of F and/or CI radicals
General precautions Avoid inhaling high concentrations of vapors. Atmospheric concentrations should be minimized and kept as far as possible below the occupational exposure limit. Steam is heavier than air and
concentrates at a low level and in small places. Exhaust ventilation at the lowest levels.
Respiratory protection If there is any doubt about the air concentration, breathing apparatus approved by the health services
should be used. These devices will contain oxygen or allow better breathing.
Storage The containers must be placed in a dry and cold place away from any risk of fire, direct sunlight and
away from any heat source such as radiators. Temperatures should not exceed 50°C.
Protective clothing Wear coveralls, impermeable gloves and goggles or a face shield.
Procedure in case of spillage or
a leak
Make sure that everyone wears the appropriate protective clothing and respirators. If possible isolate
the source of the leak. Encourage evaporation of small spills provided there is adequate ventilation.
Large spills: ventilate the area. Contain spill with sand, earth or other suitable absorbent material.
Prevent liquid from entering drains, sewers, basements and manholes as the vapor can create a
suffocating atmosphere.
Waste disposal Preferably to be recovered and recycled. If this is not possible, ensure that they are destroyed in an
authorized area able to absorb and neutralize acids and other toxic manufacturing products.
Fire fighting data R513A: Non-flammable at ambient temperatures and atmospheric pressures.
Containers Containers exposed to fire must be kept cold by means of water jets. Containers may burst if
overheated.
Fire protection equipment In case of fire, wear self-contained breathing apparatus and protective clothing.

English
5SYSLOOP 70-135
2. INSPECTION AND STORAGE
The appliances are delivered fully assembled, factory tested and ready to operate.
Any modication to the units without the manufacturer’s prior approval, shall automatically render the
warranty null and void.
The following conditions must be respected in order to maintain the validity of the warranty:
²Commissioning shall be performed by specialised technicians from technical services approved by
the manufacturer.
²Maintenance shall be performed by technicians trained for this purpose.
²Only Original Equipment spare parts shall be used.
²All the operations listed in the present manual shall be performed within the required time limits.
3. WARRANTY
At the time of receiving the equipment carefully cross check all the elements against the shipping documents
in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or
hidden damage.
In the event of shipping damage, write precise details of the damage on the shipper’s delivery note and
send immediately a registered letter to the shipper within 48 hours, clearly stating the damage caused.
Forward a copy of this letter to the manufacturer or his representative.
Never store or transport the unit upside down. It must be stored indoors, completely protected from
rain, snow etc. The unit must not be damaged by changes in the weather (high and low temperatures).
Excessively high temperatures (above 60 °C) can harm certain plastic materials and cause permanent
damage. Moreover, the performance of certain electrical or electronic components can be impaired.
THE WARRANTY SHALL BE NULL AND VOID IN THE EVENT
OF NON-COMPLIANCE WITH ANY OF THE ABOVE CONDITIONS.
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE
For technical questions, work under warranty, commissioning, a manufacturer’s visit or repair quotations.
Our technical support and after-sales service hotline can be reached on:
²(0)891 700 407 in France
²[e-mail] for export customers
5. PRESENTATION
Following assembly of the units in the factory:
1. the electrical circuits are tested.
2. refrigeration circuits receive their operational refrigerant charge and are subject to pressurized leak
detection tests.
3. The SYSLOOP units are tested.
These tests are conducted to guarantee the correct operation and quality of our products.
The SYSLOOP units are produced in compliance with state-of-the-art design and manufacturing standards.
This guarantees their high performance and reliability as well as their compatibility with all types of air
conditioning installations. The unit, designed for an indoor mounted application, is not suitable for any uses
other than those specied in this manual.

English
6SYSLOOP 70-135
SEE APPENDIX
6. CONTENTS OF PACKAGE
6.1. OPTIONAL ACCESSORIES
7. DIMENSIONS
8. HANDLING
8.1. NET WEIGHT
The handling method depends on the SYSLOOP model and its nal destination.
²Take care to avoid any rough handling or impacts when unloading and moving the appliance.
²Before hoisting the appliance into position, perform a test lift to ensure stability and balance. Avoid
twisting or uneven lifting of the units.
²The units shall be carefully inspected before unit installation to make sure this has not happened.
²All of these sections are inspected before they leave the factory. Prior to commissioning, it is
therefore important to make sure that no bolts, screws or other fastening components are loosened
or missing.
To avoid irreversible damage, do not tilt the SYSLOOP by more than 45° during handling.
Caution
Never subject the metal work (panels, posts) of the SYSLOOP to handling constraints, as only its
base is designed for that purpose.
Caution
8.2. GENERAL HANDLING
On opening the box, check that all of the accessories required for installation are present.
8.2.1. HANDLING WITH A FORKLIFT
A forklift can be used to handle the SYSLOOP units when palletized.
Place a safety wedge between the unit base and the fork lift truck to avoid damaging the unit’s structure
and casing.
Package contents:
1 appliance
1 suspension kit comprising:
1 RCS control module
²4 nuts
²4 locknuts
²4 shock mounts
²4 washers
1 installation manual
70 85 100 110 120 135
Weigth kg 134 134 153 153 160 160

English
7SYSLOOP 70-135
9. TECHNICAL SPECIFICATIONS
9.1. MODELS DESIGNATION
The product plate on the device shows the full model reference number and should be used to check that
the actual unit matches the model ordered. It also provides the following information:
²General information
serial number
year of manufacture
IP index
²Electrical information
supply voltage
maximum operating current
starting current
²Thermodynamic circuit information
type of refrigerant
refrigerant charge in each circuit
Service pressure of refrigeration circuit
refrigeration circuit service temperatures
²Hydraulic circuit information
nominal water ow
maximum water pressure
REP. Description
1
Size
SL70 : SYSLOOP size 70
SL85 : SYSLOOP size 85
SL100 : SYSLOOP size 100
SL110 : SYSLOOP size 110
SL120 : SYSLOOP size 120
SL135 : SYSLOOP size 135
2Version CO : Cooling only HP : Heat pump
3
Brand SYS : Systemair
4
Fan type EC : Fan with EC motor
5
Air lter Blank : Without lter G2M1 : G2M1 lter
6
Regulation POL423 : POL423 SIEMENS (Modbus RTU / Bacnet
MSTP) DISTECH : DISTECH (Bacnet IP)
7
Electric heater Blank : Without heater
EH3750 : Capacity 3750W
EH4500 : Capacity 4500W
EH5400 : Capacity 5400W
EH6500 : Capacity 6500W
EH7500 : Capacity 7500W
8
Communication
protocol Blank : Stand Alone MBRT : Modbus RTU BNMS : Bacnet MSTP
BNIP : Bacnet IP
9
Main switch Blank : Without main switch SECT : Main switch
10
Air outlet S1 : Frontal S2 : Lateral
11
Remote control Blank : Without remote control RCS : POL822
12
Water valve Blank : Without 2W : two-way valve
13
Option FS : Flow switch
14
Option RS : Room temperature sensor
15
Packaging IP : Individual Packaging GP : Grouped Packaging
SL70 . HP . SYS . EC . G2M1 . POL423 . EH3750 . MBRT . SECT . S1 . RCS . 2W . FS . RS . IP
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15

English
8SYSLOOP 70-135
9.2. PHYSICAL CHARACTERISTICS
9.2.1. SYSLOOP - EC MOTOR
Models 70 85 100 110 120 135
Total cooling capacities (1) W 7 011 8 407 10 290 11 183 12 105 13 301
Sensible cooling capacities (1) W 5 960 7 146 8 541 9 282 10 047 11 040
Total absorbed power (3) W 1 776 2 275 2 743 3 234 3 161 3 784
EER according to EN14511 3.95 3.7 3.75 3.46 3.83 3.52
Total Heating capacities (2) W 8 069 9 808 11 307 12 514 13 834 14 639
Total absorbed power (3) W 1 761 2 256 2 590 3 073 3 081 3 467
COP according to EN14511 4.58 4.35 4.37 4.07 4.49 4.22
VENTILATION
Setpoint voltage V3.80 5.50 7.80 8.80 7.60 8.60
Air ow m3/h 1 727 2 165 2 826 3 078 3 309 3 677
Available pressure Pa 100 100 100 100 100 100
Fan absorbed power W 328 393 552 631 617 737
Air lter - Number / Efciency 1/G2M1
HYDRAULIC CIRCUIT
Water exchanger Nbr 1
Exchanger type coaxial
Water pressure max. bar 10
Cooling
mode
Nominal water ow l/h 1 497 1 818 2 274 2 508 2 649 2 957
Water pressure drop at nominal ow kPa 35.9 49.8 39.6 46.6 30.6 38.3
Minimum water ow l/h 749 909 1 137 1 254 1 325 1 479
Heating
mode
Nominal water ow l/h 1 882 2 256 2 514 2 738 3 143 3 463
Water pressure drop at nominal ow kPa 52.7 71.3 46.8 53.9 43.4 53
Minimum water ow l/h 941 1 128 1 257 1 369 1 572 1 732
Water connections Input/output pouces 1” - Male gas thread
Condensate outlet Ø mm 19
REFRIGERANT CIRCUIT
Number of circuit Nbr 1
Compressor type Scroll
Refrigerant R513A
Load g 1 040 1 165 1 108 1 116 1 355 1 363
ELECTRICAL DATA
Electrical power supply 400V / 3~ N / 50Hz
Max. current (4) A 12.8 13.4 15.6 18.2 17.3 18.1
starting current (5) A 53.5 53.5 53.5 78.5 71.4 78.4
Electric heating - Power (6) W 3 750 4 500 5 400 6 500 7 500 7 500
ACOUSTICAL DATA
Sound power level (7) dB(A) 72.6 74.7 78.1 78.5 75.1 77.0
Sound pressure level (7) dB(A) 56.2 56.4 62.6 61.9 60.5 62.1
NR (7) dB(A) 51 51 58 59 58 60
(1) Nominal cooling capacities based on : entering air temperature of 27 °C dry bulb, 19 °C wet bulb
with entering water temperature of 30 °C.
(2) Nominal heating capacities based on : entering air temperature of 20 °C dry bulb, 15 °C wet bulb
with entering water temperature of 20 °C.
(3) Absorbed power (compressor + fan) at nominal conditions.
(4) Nominal currents are given at +/- 5%.
(5) Starting currents are given at +/- 10%.
(6) Electric heating coil is available optional.
(7) Informative data, considering an hypothetical sound attenuation of the room and installation of
21dB.

English
10
15
20
25
30
35
40
45
50
55
15
20
25
30
35
40
45
50
55
60
100%
22
27
32
37
42
47
52
57
62
67
50%
15°C wb 24°C wb
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
Air inlet temperature (°C db)
Water inlet temperature (°C)
Water outlet temperature (°C)
Water flow
7
12
17
22
26
31
100%
5
10
15
20
25
30
35
40
45
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Air inlet temperature (°C)
Water inlet temperature (°C)
Water outlet temperature (°C)
Water flow
9SYSLOOP 70-135
9.3. ELECTRIC SPECIFICATIONS
9.4. OPERATING LIMITS
A variance of ±10% is acceptable in relation to the operating voltage marked on the appliance’s Maker’s
Plate. Phase imbalance on three phase units must not exceed 2%.
Operating voltages :
²400V / 3~ N / 50Hz (360 Volts mini ; 440 Volts maxi.)
Comments: the stated voltages represent the accepted range. However, certain components may be subject
to premature wear on appliances operating continuously, for extensive periods, on abnormally low or high
voltages.
9.4.1. TEMPERATURE LIMITS
MODELS 70 85 100 110 120 135
Supply voltage 400V / 3~ N / 50Hz
Full load current (max) A 12.8 13.4 15.6 18.2 17.3 18.1
Starting amperage A 53.5 53.5 53.5 78.5 71.4 78.4

English
40
50
60
70
80
90
100
110
15°C wb 24°C wb
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33
34
Air inlet temperature (°C db)
Nominal air flow (%)
14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
52
8 10 12
40
50
60
70
80
90
100
110
Water inlet temperature (°C)
Max nominal water flow (%)
10 SYSLOOP 70-135
The maximum authorized water ow is plus 30% of the nominal ow.
Caution
* Conditions in accordance with the standard: EN 14511-2
* Conditions in accordance with the standard: EN 14511-2
9.4.2. FLOW LIMITS
MODELS 70 85 100 110 120 135
Nominal air ow * m3/h 1 727 2 165 2 826 3 078 3 309 3 677
65% Nominal air ow m3/h 1 123 1 407 1 837 2 001 2 151 2 390
MODELS 70 85 100 110 120 135
Nominal water ow * l/h 1 882 2 256 2 514 2 738 3 143 3 463
50% Nominal water ow l/h 941 1 128 1 257 1 369 1 572 1 732
Maximum hydraulic pressure bar 10 10 10 10 10 10

English
11SYSLOOP 70-135
9.5. REFRIGERATION SPECIFICATIONS
9.5.1. REFRIGERANT CIRCUIT DIAGRAM
SEE APPENDIX
9.5.2. REFRIGERANT CHARGE
The type and quantity of refrigerating uid per circuit are indicated on the product plate.
The installer and end user will get informed on local environmental regulations for the installation, operation
and disposal of the equipment ; more particularly, for the collection of substances hazardous for the
environment (refrigerating uid, oil, antifreeze, etc.). A refrigerating uid, whatever it is, must not be vented.
Refrigerating uids must be handled by skilled personnel.
9.5.3. FLUOROCARBON GAS REGULATIONS
The EC No. 517/2014 regulation covering uorinated greenhouse gases requires of refrigeration equipment
operators to comply with the following ve obligations:
Greenhouse gas quantity (kg of CO2) = Quantity of gas (kg) x gas' GWP
Quantity of greenhouse gas expressed in weight
(kg) and CO2 equivalent
Quantity of gas: amount of gas contained in the
machine in kg (see ID plate)
GWP (GlobalWarming Potential) of the gas contained
in the machine (see ID plate)
²GWP for the R513A = 631
9.5.3.1. CALCULATING GREENHOUSE GAS QUANTITIES
1. Installation, servicing, maintenance as well as checking the sealing must be carried out by qualied
personnel.
2. The uorinated gas must be recovered during servicing and maintenance as well as the end of the
installation.
3. All the necessary measures must be taken to prevent the leakage of uorinated gases and any leaks
must be repaired as rapidly as possible.
4. Regular checks on any leaks must be performed according to the following conditions:
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 5 tonnes of CO2but less than the equivalent of 50 tonnes of CO2:
at least every twelve months or, if a leak detection system is installed, at least every twenty-
four months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 50 tonnes of CO2but less than the equivalent of 500 tonnes of CO2:
at least every six months or, if a leak detection system is installed, at least every twelve
months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 500 tonnes of CO2:
at least every three months or, if a leak detection system is installed, at least every six
months.
5. A document grouping a description of all the operations carried out on the cooling circuit must be
drafted and conserved.
This equipment contains uorinated gas with greenhouse gas effects covered by the Kyoto
agreement.
Caution
SYSLOOP 70-135 units use the R513A uoro-carbonated uid, belonging to group 2 as dened in
directive 2014/68/UE. Considering the maximum operating pressure of these units (18 bar g), they
integrate category 2 (or lower) components as dened in directive 2014/68/UE.
Caution
Non-compliance with one of these obligations constitutes an offense and can result in nancial
penalties.
Furthermore, compliance of the equipment with the uorinated gases regulation must be proven to
the insurance company.
Caution

English
600mm
600mm
600mm
600mm
200mm
12 SYSLOOP 70-135
When installing the SYSLOOP, take care to
leave enough space for dismantling the
lter and access panels of the electrical
box/compressor, fan, leaving enough room
for maintenance personnel to conduct
maintenance and repair operations. Leave
enough room for water, electricity and
ductwork connections.
10. INSTALLATION
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work
or constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or
damage, which could prove hazardous to personnel and property. In such an event, the warranty
shall be voided.
Caution
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
10.1. GENERALITIES
1. To avoid any damage, this equipment must not be used to supply heating or cooling during building
work.
2. Check that the voltage, the number of phases and the capacity of the unit comply with the
installation plans.
3. Check the size of the unit in relation to the plans to ensure that the unit will be installed in the right
location.
4. After having removed the packing box, take out the suspension kit that is to be found inside the fan
outlet frame.
5. Before installing the unit, check its height in relation to the available free ceiling height.
6. Take particular care over the location and routing of the water pipes and the condensate drainage
pipe as well as the electrical wiring. The location and routing of these items must be clearly indicated
on the plans.
7. It is always advisable for the heat pump installer to consult with all the various entrepreneurs
responsible for the pipe work, partitioning, ceiling and electrical installation on the site.
8. If necessary, change the direction of the airow inlet from the front to the side of the appliance, or
vice versa, prior to installing the unit in the ceiling. Refer to the instructions detailed in § MODIFYING
THE AIR BLOWING DIRECTION, page 15.
9. We advise the installer to cover the appliances with a plastic sheet to protect it during the nal
building work.
This is particularly important if work such as spraying the joists with re retardant, sanding, spray
painting and plastering has not been completed.
10.2. CLEARANCE

English
M8 THREADED ROD
(NOT SUPPLIED)
SHOCK MOUNT
WASHER
NUT
LOCKNUT
13SYSLOOP 70-135
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
1. The installer must ensure that access under the suspended
ceiling is provided, and that sufcient space is provided for
the suspension angle brackets, the duct attachment collars
and the water and electrical connections.
2. Provide space under the unit for a siphon on the condensates
drainage pipe. Do not install the unit on top of pipe work.
3. Each unit is suspended from the ceiling on four threaded
rods. The rods are attached through the shock mounts to the
corners of the unit by suspension angle brackets.
Warning! Do not use rods of a diameter smaller than that
stated below. The rods must be solidly anchored to the ceiling
and to the ceiling joists.
4. Each unit is supplied with a set of pre-tted suspension
angle brackets and a tting kit contained in the pouch with
the technical manual. The kit comprises 4 shock mounts, 4
washers, 4 nuts and 4 locknuts.
5. Arrange the threaded rods in accordance with the dimensions
stated below. The use of nuts and locknuts is recommended
for attaching the suspension rods to the unit as the unit’s
vibrations may loosen a single nut. The installer is liable for
any damage in the event of this recommendation not being
followed.
6. To facilitate drainage, the unit must be angled in both planes
towards the condensates drainage pipe. (Slope minimum: 2
%)
10.3. UNIT LOCATION
1 054
722
564 5050
50 29
2929
SYSLOOP 70-135
70 - 85
1 245
779
619 4848
48 32
3232
SYSLOOP 70-135
100 - 110 - 120 - 135

English
Internal cladding on both sides
with glass fibre sound insulation
Adapter part
Alignment elbow
Main duct
Spur with internal glass fibre
sound insulation cladding
Air distributor:
60 x 60 cm (example)
Canvas connection
Heat pump
SUPPLY AIR
OUTDOOR AIR
RETURN AIR
14 SYSLOOP 70-135
Water circuit heat pumps are usually installed in conjunction with an air blowing duct. A return air duct may
also be required. All ductwork shall be compliant with best air conditioning engineering practices.
The air blowing duct system normally consists of a exible connector mounted on the unit, a bridging
section to link to the size of the main duct, a short section of straight duct, an elbow without a damper and
a main duct with spurs equipped with distribution grilles as illustrated in the drawing below. The sum total
of the bridging section angles must not be higher than 30°, otherwise there will be signicant performance
losses.
Do not connect the main duct directly to the unit without a bridging section to reduce the duct size to that of
the unit’s connection collar. In the event of using metal ducts, only the sides of the elbow section and all the
spur duct sections should be covered with breglass sound insulation for reducing the noise level. Fibreglass
duct panels are more sound absorbent and may enable the exible canvas connection to be eliminated.
The duct network must be laid out to avoid any rectilinear runs betweens the heat pump outlet and the air
distribution outlets.
The return air intake ducts can be connected to a grille/lter located at the base of a wall, then directed via
hollow partitions towards a ceiling mounted plenum or via ceiling mounted grilles. The ceiling grilles must
not be located directly below the air conditioning unit.
The return air intake duct can be connected directly to the standard lter bracket. (Lateral lter removal
advisable).
Do not drill panel screws directly into the unit’s casing for connecting the blowing and return air intake ducts,
especially on the air return side, as there is a risk of damaging the condensate recovery tray and the battery.
11. DUCTING AND NOISE LEVEL REDUCTION
Recommended layout diagram for installation
with several air distribution outlets

English
RETURN AIR INTAKE
(IN LINE)
IN LINE BLOWING (S1)
(STANDARD CONFIGURATION)
AIR FILTER
REAR BLOWING (S2)
3
2
1
32
3
23
2
1
15SYSLOOP 70-135
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME
11.2. MODIFYING THE AIR BLOWING DIRECTION
The unit SYSLOOP can be supplied congured for either frontal air blowing, known as "IN LINE", or for side air
blowing, known as "REAR". It is also possible to modify the air-blowing conguration on site. To achieve this:
1. Remove the top panel 1.2. Remove the fan motor access panel 2 and
release a small length of motor cable.
3. Remove the fan blower panel 3.
4. Fit the fan blower panel 3in the same location
as the access panel 2.
5. Ret the fan access panel 2.
6. Ret the top panel 1.

English
AIR FLOW
AIR FLOW
P1
P2
16 SYSLOOP 70-135
11.3. FILTER ACCESS
Each unit is supplied with a connection frame also serving as the lter support. This enables to lter to be
removed from the side without having to dismantle the duct or the connection frame.
An outdoor air intake (new air) may be required for ventilation. The blown air temperature must be
controlled in order to avoid the temperature of the mixture of outdoor air and return air at the heat pump
inlet exceeding the appliance’s operating limits. It is also common practice to shut down ventilation during
periods of inoccupation (night time setting of the set temperature).
Each appliance’s ventilation system is generally a sub-system within the building, with its own distribution
duct network. The simple introduction of outdoor air into each return air plenum, quite close to the unit’s
return air intake is sufcient and recommended. New air should not be introduced directly into the appliance.
Provide for a sufcient distance to ensure effective mixing of the outdoor air with the return air. (Refer to
the § OPERATING LIMITS, page 9).
11.4. VENTILATION
External static pressure at the air intake above -100Pa
External static pressure at blowing less than 100Pa
Caution
11.5. AERAULIC ADJUSTEMENT
P1 : External static pressure at the air intake
P2 : External static pressure at blowing
EXTERNAL STATIC PRESSURE = P2-P1

English
80
70
0 500 1000 1500 2000 2500 3000 3500
4000
0
50
100
150
200
250
300
350
2V 3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m
3
/h)
Available pressure (Pa)
LS
MS
HS HS
MS
LS
Ductwork
curve
110
100
0 500 1000 1500 2000 2500 3000 3500
4000
0
50
100
150
200
250
300
350
2V
3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m
3
/h)
Available pressure (Pa)
LS
MS
HS
HS
MS
LS
Ductwork
curve
17SYSLOOP 70-135
LS : low speed
MS : medium speed
HS : high speed
LS : low speed
MS : medium speed
HS : high speed
11.5.1. SL70.EC / SL85.EC
11.5.2. SL100.EC / SL110.EC

English
130
120
0 500 1000 1500 2000 2500 3000 3500
4000
0
50
100
150
200
250
300
350
2V
3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m
3
/h)
Available pressure (Pa)
LS
MS
HS
HS
MS
LS
Ductwork
curve
18 SYSLOOP 70-135
LS : low speed
MS : medium speed
HS : high speed
11.5.3. SL120.EC / SL135.EC
