System air Sysloop EVO Manual

Water source heat pump
Compressor of variable speed
Installation and maintenance manual
SYSLOOP EVO
290 â525 m3/h
1.69 â2.95kW
2.00 â3.77kW

INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

English
2SYSLOOP EVO
CONTENTS
1. GENERAL RECOMMENDATIONS........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS .......................................................................................................................................................................................................................3
1.2. WARNING.........................................................................................................................................................................................................................................3
1.3. EQUIPMENT SAFETY DATA.............................................................................................................................................................................................................4
2. INSPECTION AND STORAGE .............................................................................................................................................................. 5
3. WARRANTY...................................................................................................................................................................................... 5
4. CONTENTS OF PACKAGE ................................................................................................................................................................... 5
5. DIMENSIONS .................................................................................................................................................................................... 5
6. HANDLING........................................................................................................................................................................................ 5
6.1. NET WEIGHT.....................................................................................................................................................................................................................................5
7. REFRIGERATION SPECIFICATIONS..................................................................................................................................................... 6
7.1. REFRIGERANT CIRCUIT DIAGRAM .................................................................................................................................................................................................6
7.2. REFRIGERANT CHARGE...................................................................................................................................................................................................................6
7.3. FLUOROCARBON GAS REGULATIONS ..........................................................................................................................................................................................6
7.3.1. CALCULATING GREENHOUSE GAS QUANTITIES .....................................................................................................................................................................................................6
8. TECHNICAL SPECIFICATIONS ............................................................................................................................................................. 7
8.1. OPERATING LIMITS..........................................................................................................................................................................................................................7
8.1.1. ENVIRONMENT...........................................................................................................................................................................................................................................................7
8.1.2. TEMPERATURE LIMITS ...............................................................................................................................................................................................................................................7
8.1.3. FLOW LIMITS...............................................................................................................................................................................................................................................................7
9. ELECTRIC SPECIFICATIONS ................................................................................................................................................................ 8
9.1. ELECTRICAL POWER SUPPLY .........................................................................................................................................................................................................8
10. INSTALLATION................................................................................................................................................................................ 8
10.1. GENERALITIES................................................................................................................................................................................................................................8
10.2. CLEARANCE ...................................................................................................................................................................................................................................9
10.3. UNIT LOCATION.............................................................................................................................................................................................................................9
11. DUCTING AND NOISE LEVEL REDUCTION ...................................................................................................................................... 10
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME.....................................................................................................................................................11
11.2. AIR BLOWING PLENUM AND RETURN AIR INTAKE PLENUM................................................................................................................................................11
11.3. AIR DISCHARGE MODIFICATION................................................................................................................................................................................................12
11.4. FILTER ACCESS.............................................................................................................................................................................................................................12
11.5. VENTILATION ...............................................................................................................................................................................................................................12
11.6. AERAULIC ADJUSTEMENT...........................................................................................................................................................................................................13
11.6.1. MODEL SYSLOOP EVO.......................................................................................................................................................................................................................................... 13
12. UNCLAMPING THE COMPRESSOR................................................................................................................................................. 14
13. HYDRAULIC LINKS........................................................................................................................................................................ 15
13.1. WATER QUALITY..........................................................................................................................................................................................................................15
13.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS ........................................................................................................................................................16
13.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM..........................................................................................................................18
14. WIRING DIAGRAM AND LEGEND.................................................................................................................................................. 19
14.1. WIRING DIAGRAM ......................................................................................................................................................................................................................19
14.2. LEGEND ........................................................................................................................................................................................................................................19
14.2.1. POWER SUPPLY..................................................................................................................................................................................................................................................... 19
14.2.2. PRESSOSTATS SETTING ........................................................................................................................................................................................................................................ 19
15. ELECTRICAL CONNECTIONS........................................................................................................................................................... 19
15.1. GENERALITIES..............................................................................................................................................................................................................................20
15.2. REMOTE CONTROL......................................................................................................................................................................................................................20
15.2.1. WALL MOUNTING ................................................................................................................................................................................................................................................. 20
15.2.2. ELECTRICAL CONNECTIONS................................................................................................................................................................................................................................. 21
16. REGULATION ................................................................................................................................................................................ 22
16.1. ORDER OF PRIORITY FOR CONTROL SYSTEMS.......................................................................................................................................................................22
16.2. WALL-MOUNTED CONTROL.......................................................................................................................................................................................................22
16.2.1. KEYPAD................................................................................................................................................................................................................................................................... 22
16.2.2. SCREEN................................................................................................................................................................................................................................................................... 23
16.2.3. TIME SETTINGS...................................................................................................................................................................................................................................................... 23
16.2.4. SCHEDULING.......................................................................................................................................................................................................................................................... 24
17. FINAL TASKS ................................................................................................................................................................................ 25
18. STARTING - RECOMMENDATIONS - SETTINGS .............................................................................................................................. 25
18.1. COMMISSIONING ........................................................................................................................................................................................................................26
18.1.1. DEMAND FOR COOLING....................................................................................................................................................................................................................................... 26
18.1.2. DEMAND FOR HEATING ....................................................................................................................................................................................................................................... 26
19. MAINTENANCE AND SERVICING................................................................................................................................................... 27
19.1. FAULT FINDING............................................................................................................................................................................................................................27
19.1.1. NEITHER THE FAN NOR THE COMPRESSOR OPERATE ..................................................................................................................................................................................... 27
19.1.2. VENTILATION (FAN) MODE OPERATES BUT THE COMPRESSOR DOES NOT OPERATE................................................................................................................................ 27
19.1.3. INSUFFICIENT COOLING OR HEATING PRODUCTION........................................................................................................................................................................................ 28
19.1.4. INSUFFICIENT WATER FLOW AT THE LEVEL OF THE COAXIAL EXCHANGER.................................................................................................................................................. 28
19.1.5. APPEARANCE OF WATER DROPLETS IN THE APPLIANCE................................................................................................................................................................................ 28
19.1.6. APPEARANCE OF ABNORMAL NOISES AND VIBRATIONS IN THE CASING................................................................................................................................................... 28
19.2. ALARM CODES.............................................................................................................................................................................................................................29
20. IN CASE OF WARRANTY - MATERIAL RETURN PROCEDURE ......................................................................................................... 29
21. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 29

English
3
SYSLOOP EVO
POWER SUPPLY MUST BE
SWITCHED OFF
BEFORE STARTING WORK IN THE
ELECTRIC CONTROL BOX
1. GENERAL RECOMMENDATIONS
The purpose of this Manual is to provide users with instructions for installing, commissioning, using and
maintaining the units. It also contains instructions on starting up the machine as well as recommendations
to avoid bodily injury and risks of damage to the device during its operation.
It does not contain the complete description of all the maintenance operations guaranteeing the unit’s long
life and reliability. Only the services of a qualied technician can guarantee the unit’s safe operation over a
long service life.
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cutoff power supply before starting to work on the appliance.
When making the hydraulic connections, ensure that no impurities are introduced into the pipe work.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are
not respected.
If you meet a problem, please call the Technical Department of your geographical area.
If possible, assemble the compulsory or optional accessories before placing the appliance on its nal location
(see instructions provided with each accessory).
In order to become fully familiar with the appliance, we suggest to read also our Technical Instructions.
The information contained in these Instructions are subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in forces when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel having a good knowledge of standards and local regulations, as well as experience of this type
of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
The unit should be handled using lifting and handling equipment appropriate to the unit's size and weight.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
It is forbidden to start any work on the electrical components if water or high humidity is present on the
installation site.

English
4SYSLOOP EVO
Safety data R513A
Toxicity level Low.
In contact with the skin Dermal contact with the rapidly evaporating liquid can cause frostbite to the tissue. In the event of contact with the liquid, warm the frozen tissue with water and notify a physician. Remove
contaminated clothing and shoes. Wash clothes before reuse
In case of eye contact Steam has no effect. Splashing or splashing liquid can cause burns. Clean immediately with eye drops
or clean water for at least 15 minutes. Seek medical attention urgently.
Ingestion Burns can occur if this happens. Do not induce vomiting. When the patient is conscious, wash the
mouth with water. Seek medical attention urgently.
Inhalation If inhaled, move to fresh air and give oxygen if necessary. Perform artificial respiration if the patient is no longer breathing or is short of air. In the event of cardiac arrest, perform external CPR. Seek
immediate medical attention.
Other medical advice Cardiac sensitivity may, in the presence of circulating catecholamines such as adrenaline, lead to
increased arrhythmias and subsequent cardiac arrest if exposed to high concentrations.
Occupational exposure limits R513A: Recommended limit: 1,000 ppm - 8 hours.
Stability Room temperature stable product
Conditions to avoid Pressure build-up due to high temperatures can cause the container to explode. Protect from sunlight
and do not expose to a temperature >50°C.
Dangerous reactions Possibility of dangerous reactions in case of fire due to the presence of F and/or CI radicals
General precautions Avoid inhaling high concentrations of vapors. Atmospheric concentrations should be minimized and kept as far as possible below the occupational exposure limit. Steam is heavier than air and
concentrates at a low level and in small places. Exhaust ventilation at the lowest levels.
Respiratory protection If there is any doubt about the air concentration, breathing apparatus approved by the health services
should be used. These devices will contain oxygen or allow better breathing.
Storage The containers must be placed in a dry and cold place away from any risk of fire, direct sunlight and
away from any heat source such as radiators. Temperatures should not exceed 50°C.
Protective clothing Wear coveralls, impermeable gloves and goggles or a face shield.
Procedure in case of spillage or
a leak
Make sure that everyone wears the appropriate protective clothing and respirators. If possible isolate
the source of the leak. Encourage evaporation of small spills provided there is adequate ventilation.
Large spills: ventilate the area. Contain spill with sand, earth or other suitable absorbent material.
Prevent liquid from entering drains, sewers, basements and manholes as the vapor can create a
suffocating atmosphere.
Waste disposal Preferably to be recovered and recycled. If this is not possible, ensure that they are destroyed in an
authorized area able to absorb and neutralize acids and other toxic manufacturing products.
Fire fighting data R513A: Non-flammable at ambient temperatures and atmospheric pressures.
Containers Containers exposed to fire must be kept cold by means of water jets. Containers may burst if
overheated.
Fire protection equipment In case of fire, wear self-contained breathing apparatus and protective clothing.
1.3. EQUIPMENT SAFETY DATA

English
5
SYSLOOP EVO
2. INSPECTION AND STORAGE
The appliances are delivered fully assembled, factory tested and ready to operate.
Any modication to the units without the manufacturer’s prior approval, shall automatically render the
warranty null and void.
The following conditions must be respected in order to maintain the validity of the warranty:
²Commissioning shall be performed by specialised technicians from technical services approved by
the manufacturer.
²Maintenance shall be performed by technicians trained for this purpose.
²Only Original Equipment spare parts shall be used.
²All the operations listed in the present manual shall be performed within the required time limits.
THE WARRANTY SHALL BE NULL AND VOID IN THE EVENT
OF NON-COMPLIANCE WITH ANY OF THE ABOVE CONDITIONS.
3. WARRANTY
4. CONTENTS OF PACKAGE
On opening the carton, check that all the accessories required for installation are present.
At the time of receiving the equipment carefully cross check all the elements against the shipping documents
in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or
hidden damage.
In the event of shipping damage, write precise details of the damage on the shipper’s delivery note and
send immediately a registered letter to the shipper within 48 hours, clearly stating the damage caused.
Forward a copy of this letter to the manufacturer or his representative.
Never store or transport the unit upside down. It must be stored indoors, completely protected from
rain, snow etc. The unit must not be damaged by changes in the weather (high and low temperatures).
Excessively high temperatures (above 60 °C) can harm certain plastic materials and cause permanent
damage. Moreover, the performance of certain electrical or electronic components can be impaired.
Package contents:
1 appliance
1 suspension kit comprising:
²4 nuts
²4 locknuts
²4 shock mounts
²4 washers
1 installation manual
SEE APPENDIX
5. DIMENSIONS
6. HANDLING
6.1. NET WEIGHT
The appliance may be handled with a pallet truck or a forklift truck.
MODELS SYSLOOP EVO
WEIGTH WITH PLENUM Kg 55
WITHOUT PLENUM Kg 50

English
6SYSLOOP EVO
7. REFRIGERATION SPECIFICATIONS
7.1. REFRIGERANT CIRCUIT DIAGRAM
SEE APPENDIX
7.2. REFRIGERANT CHARGE
The type and quantity of refrigerating uid per circuit are indicated on the product plate.
The installer and end user will get informed on local environmental regulations for the installation, operation
and disposal of the equipment ; more particularly, for the collection of substances hazardous for the
environment (refrigerating uid, oil, antifreeze, etc.). A refrigerating uid, whatever it is, must not be vented.
Refrigerating uids must be handled by skilled personnel.
7.3. FLUOROCARBON GAS REGULATIONS
The EC No. 517/2014 regulation covering uorinated greenhouse gases requires of refrigeration equipment
operators to comply with the following ve obligations:
Greenhouse gas quantity (kg of CO2) = Quantity of gas (kg) x gas' GWP
Quantity of greenhouse gas expressed in weight
(kg) and CO2 equivalent
Quantity of gas: amount of gas contained in the
machine in kg (see ID plate)
GWP (GlobalWarming Potential) of the gas contained
in the machine (see ID plate)
²GWP for the R513A = 631
7.3.1. CALCULATING GREENHOUSE GAS QUANTITIES
1. Installation, servicing, maintenance as well as checking the sealing must be carried out by qualied
personnel.
2. The uorinated gas must be recovered during servicing and maintenance as well as the end of the
installation.
3. All the necessary measures must be taken to prevent the leakage of uorinated gases and any leaks
must be repaired as rapidly as possible.
4. Regular checks on any leaks must be performed according to the following conditions:
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 5 tonnes of CO2but less than the equivalent of 50 tonnes of CO2:
at least every twelve months or, if a leak detection system is installed, at least every twenty-
four months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 50 tonnes of CO2but less than the equivalent of 500 tonnes of CO2:
at least every six months or, if a leak detection system is installed, at least every twelve
months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 500 tonnes of CO2:
at least every three months or, if a leak detection system is installed, at least every six
months.
5. A document grouping a description of all the operations carried out on the cooling circuit must be
drafted and conserved.
This equipment contains uorinated gas with greenhouse gas effects covered by the Kyoto
agreement.
Caution
SYSLOOP EVO units use the R513A uoro-carbonated uid, belonging to group 2 as dened in
directive 2014/68/UE. Considering the maximum operating pressure of these units (18 bar g), they
integrate category 2 (or lower) components as dened in directive 2014/68/UE.
Caution
Non-compliance with one of these obligations constitutes an offense and can result in nancial
penalties.
Furthermore, compliance of the equipment with the uorinated gases regulation must be proven to
the insurance company.
Caution

English
10
15
20
25
30
35
40
45
50
16
20 21 22 23 24 25 26 27 28 29 30 31 32
33
Air inlet temperature (°C db)
Water inlet temperature (°C)
10
15
20
25
30
35
40
45
50
11
32
14 15 16 17 18 19 20 21 22 23 24 25 26
27
Air inlet temperature (°C)
Water inlet temperature (°C)
40
50
60
70
80
90
100
110
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32
33
Air inlet temperature (°C db)
Max nominal air flow (%)
14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
52
8 10 12
40
50
60
70
80
90
100
110
Water inlet temperature (°C)
Max nominal water flow (%)
7
SYSLOOP EVO
8. TECHNICAL SPECIFICATIONS
8.1. OPERATING LIMITS
This equipment is designed EXCLUSIVELY for INDOOR installation.
In general, sheltered locations such as garages, roof space, etc, do not provide sufcient protection against
extreme temperatures and/or humidity and may be harmful to the unit’s performance, reliability and service
life.
8.1.1. ENVIRONMENT
* Conditions in
accordance with the
standard: EN 14511-2
* Conditions in
accordance with the
standard: EN 14511-2
8.1.2. TEMPERATURE LIMITS
8.1.3. FLOW LIMITS
Operation within
the shaded ranges
requires special
attention to the
minimum water
ow rate.
Caution
THERMAL LOAD 50 % 100 %
Nominal air ow m3/h 290 525
THERMAL LOAD 50 % 100 %
Nominal water ow (cooling mode) l/h 354 662
Nominal water ow (heating mode) l/h 458 789
Maximum hydraulic pressure bar 10 10

English
8SYSLOOP EVO
9. ELECTRIC SPECIFICATIONS
A variance of ±10% is acceptable in relation to the operating voltage marked on the appliance’s Maker’s
Plate.
Operating voltages:
²230V / 1 ph / 50 Hz (207 Volts minimum; 253 Volts maximum.)
Comments: the stated voltages represent the accepted range. However, certain components may be subject
to premature wear on appliances operating continuously, for extensive periods, on abnormally low or high
voltages.
9.1. ELECTRICAL POWER SUPPLY
10. INSTALLATION
10.1. GENERALITIES
1. To avoid any damage, this equipment must not be used to supply heating or cooling during building
work.
2. Check that the voltage, the number of phases and the capacity of the unit comply with the
installation plans.
3. Check the size of the unit in relation to the plans to ensure that the unit will be installed in the right
location.
4. After having removed the packing box, take out the suspension kit that is to be found inside the fan
outlet frame.
5. Before installing the unit, check its height in relation to the available free ceiling height.
6. Take particular care over the location and routing of the water pipes and the condensate drainage
pipe as well as the electrical wiring. The location and routing of these items must be clearly indicated
on the plans.
7. It is always advisable for the heat pump installer to consult with all the various entrepreneurs
responsible for the pipe work, partitioning, ceiling and electrical installation on the site.
8. If necessary, change the direction of the airow inlet from the front to the side of the appliance,
or vice versa, prior to installing the unit in the ceiling. Refer to the instructions detailed in § AIR
DISCHARGE MODIFICATION, page 12.
9. We advise the installer to cover the appliances with a plastic sheet to protect it during the nal
building work.
This is particularly important if work such as spraying the joists with re retardant, sanding, spray
painting and plastering has not been completed.
MODEL
Fuse aM
(without heating) Full load current (max)
(without heating)
Fuse aM
(with heating) Full load current (max)
(with heating)
Starting
amperage
SYSLOOP EVO 10A aM 9.35A 16A aM 12.05A 34.50A
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work or
constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or a
collapse with dangerous consequences for personnel and property. In such an event, the warranty
shall be null and void.
Caution

English
M8 THREADED ROD
(NOT SUPPLIED)
SHOCK MOUNT
WASHER
NUT
LOCKNUT
600mm
600mm
600mm
600mm
200mm
827
37
26
26
37 457 37
26
917.5
547.5
26 37
9
SYSLOOP EVO
10.2. CLEARANCE
1. Install the unit in a location allowing easy removal of
the lter and the access panels to the electrical box/
compressor and fan by leaving sufcient free space
for servicing personnel to perform maintenance and
repairs. Leave sufcient space for the water, electricity
and duct connections.
2. The installer must ensure that access under the
suspended ceiling is provided, and that sufcient space
is provided for the suspension angle brackets, the
duct attachment collars and the water and electrical
connections.
3. Provide space under the unit for a siphon on the
condensates drainage pipe. Do not install the unit on
top of pipe work.
4. Each unit is suspended from the ceiling on four threaded
rods. The rods are attached through the shock mounts
to the corners of the unit by suspension angle brackets.
Warning! Do not use rods of a diameter smaller than
that stated below. The rods must be solidly anchored to
the ceiling and to the ceiling joists.
5. Each unit is supplied with a set of pre-tted suspension angle brackets and a tting kit contained in
the pouch with the technical manual. The kit comprises 4 shock mounts, 4 washers, 4 nuts and 4
locknuts.
6. Arrange the threaded rods in accordance with the dimensions stated below. The use of nuts and
locknuts is recommended for attaching the suspension rods to the unit as the unit’s vibrations may
loosen a single nut. The installer is liable for any damage in the event of this recommendation not
being followed.
7. To facilitate drainage, the unit must be angled in both
planes towards the condensates drainage pipe. (Slope
minimum: 2 %)
It is also possible to use a
cable suspension system.
10.3. UNIT LOCATION
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution

English
Internal cladding on both sides
with glass fibre sound insulation
Adapter part
Alignment elbow
Main duct
Spur with internal glass fibre
sound insulation cladding
Air distributor:
60 x 60 cm (example)
Canvas connection
Heat pump
SUPPLY AIR
OUTDOOR AIR
RETURN AIR
10 SYSLOOP EVO
Water circuit heat pumps are usually installed in conjunction with an air blowing duct. A return air duct may
also be required. All ductwork shall be compliant with best air conditioning engineering practices.
The air blowing duct system normally consists of a exible connector mounted on the unit, a bridging
section to link to the size of the main duct, a short section of straight duct, an elbow without a damper and
a main duct with spurs equipped with distribution grilles as illustrated in the drawing below. The sum total
of the bridging section angles must not be higher than 30°, otherwise there will be signicant performance
losses.
Do not connect the main duct directly to the unit without a bridging section to reduce the duct size to that of
the unit’s connection collar. In the event of using metal ducts, only the sides of the elbow section and all the
spur duct sections should be covered with breglass sound insulation for reducing the noise level. Fibreglass
duct panels are more sound absorbent and may enable the exible canvas connection to be eliminated.
The duct network must be laid out to avoid any rectilinear runs betweens the heat pump outlet and the air
distribution outlets.
The return air intake ducts can be connected to a grille/lter located at the base of a wall, then directed via
hollow partitions towards a ceiling mounted plenum or via ceiling mounted grilles. The ceiling grilles must
not be located directly below the air conditioning unit.
The return air intake duct can be connected directly to the standard lter bracket. (Lateral lter removal
advisable).
Do not drill panel screws directly into the unit’s casing for connecting the blowing and return air intake ducts,
especially on the air return side, as there is a risk of damaging the condensate recovery tray and the battery.
11. DUCTING AND NOISE LEVEL REDUCTION
Recommended layout diagram for installation
with several air distribution outlets

English
RETURN AIR INTAKE
(IN LINE)
RETURN AIR INTAKE
(REAR) IN LINE BLOWING
(STANDARD CONFIGURATION)
AIR FILTER
225X366X23
RETURN AIR INTAKE
(IN LINE)
RETURN AIR INTAKE
(REAR)
IN LINE BLOWING
(STANDARD CONFIGURATION)
AIR FILTER
366X225X23
REAR BLOWING
FRESH AIR INTAKE
Ø100 or Ø125
(option)
11
SYSLOOP EVO
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME
11.2. AIR BLOWING PLENUM AND RETURN AIR INTAKE PLENUM

English
12
1
2
12
1 2
2
1
12 SYSLOOP EVO
11.3. AIR DISCHARGE MODIFICATION
11.4. FILTER ACCESS
The lter can be removed either from the side 1or from the top 2without having to dismantle the connection
duct.
The units can be delivered congured either for frontal air return, known as "In LINE" or for side air return. It
is also possible to modify the return air conguration onsite by proceeding as follows:
An outdoor air intake (new air) may be required for ventilation. The blown air temperature must be
controlled in order to avoid the temperature of the mixture of outdoor air and return air at the heat pump
inlet exceeding the appliance’s operating limits. It is also common practice to shut down ventilation during
periods of inoccupation (night time setting of the set temperature).
Each appliance’s ventilation system is generally a sub-system within the building, with its own distribution
duct network. The simple introduction of outdoor air into each return air plenum, quite close to the unit’s
return air intake is sufcient and recommended. New air should not be introduced directly into the appliance.
Provide for a sufcient distance to ensure effective mixing of the outdoor air with the return air. (Refer to
the § OPERATING LIMITS, page 7).
11.5. VENTILATION
1. Remove the access panel 1.
2. Remove the air return panel 2.
3. Fit the return air panel 2in the location
previously occupied by the access panel 1.
4. Ret the access panel 1.

English
AIR FLOW
AIR FLOW
P
1
P
2
SLE
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V 10V
Air flow (m3/h)
Available pressure (Pa)
HS
MS
LS
Ductwork
curve
SLE
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V 10V
Air flow (m3/h)
Available pressure (Pa)
HS
MS
LS
Ductwork
curve
SLE
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m
3
/h)
Available pressure (Pa)
HS
MS
LS
Ductwork
curve
SLE
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V 10V
Air flow (m3/h)
Available pressure (Pa)
HS
MS
LS
Ductwork
curve
13
SYSLOOP EVO
11.6. AERAULIC ADJUSTEMENT
11.6.1. MODEL SYSLOOP EVO
P1 : External static pressure at the air intake
P2 : External static pressure at blowing
EXTERNAL STATIC PRESSURE = P2-P1
BASIC FILTER - WITHOUT PLENUN BASIC FILTER - WITH PLENUM
G3 FILTER - WITHOUT PLENUN G3 FILTER - WITH PLENUM
LS : low speed
MS : medium speed
HS : high speed
External static pressure at the air intake above -100Pa
External static pressure at blowing less than 100Pa
Caution

English
14 SYSLOOP EVO
It is not necessary to open the panels to unlock the compressor. This can be achieved by removing the
locking screws accessible on the underside.
12. UNCLAMPING THE COMPRESSOR
Before the rst start-up the compressor transport clamping be removed. Failure to do this could
result in vibrations, high noise and could lead to the refrigerant tubes breaking.
Caution

English
15
SYSLOOP EVO
13. HYDRAULIC LINKS
13.1. WATER QUALITY
The water must be analyzed; the hydraulic network system installed must include all elements necessary
for water treatment: lters, additives, intermediate exchangers, drain valves, vents, check valves, etc.,
according to the results of the analysis.
Using improperly treated or non treated water in the SYSLOOP EVO may cause scaling, erosion, corrosion
or algae or sludge deposits in the exchangers. Refer to a specialist skilled in water treatment to determine
any treatment to apply. The manufacturer will not be held liable for damages caused when non treated or
improperly treated water, demineralized water, salty water or sea water are used.
Apply the following guidelines :
²No NH4+ammonium ions in the water, highly detrimental to copper. <10mg/l
²Cl- chloride ions are detrimental to copper with a risk of puncture by picking corrosion. <10mg/l.
²SO42- sulphate ions may cause perforating corrosion. < 30mg/l.
²No uoride ions (<0.1 mg/l)
²No Fe2+ and Fe3+ ions, particularly in case of dissolved oxygen. Fe< 5mg/l with dissolved oxygen <
5mg/l. The presence of these ions with dissolved oxygen indicates corrosion of steel parts, likely
to generate corrosion of copper parts under Fe deposits, particularly in the case of multitubular
exchangers.
²Dissolved silica: silica is an acid element of water and may also cause corrosion. Content < 1mg/l.
²Water hardness: Values between 10°fH and 30°fH may be recommended. This facilitates scaling
deposits likely to limit copper corrosion. Excess TH values may lead to clogging the pipes.
²TAC<100
²Dissolved oxygen: Prevent any sudden change in the water's oxygenation conditions. Also, avoid
deoxygenating water by sparging inert gas as well as overoxygenating it by pure oxygen sparging.
Disturbing oxygenation conditions destabilizes copper hydroxides and particle salting-out.
²Electrical Resistivity - Conductivity: The higher the resistivity, the slower the corrosion. Values above
3000 ohm/cm are preferred. A neutral environment favours maximum resistivity. For electrical
conductivity, values around 200-600 S/cm can be recommended.
²pH: neutral pH at 20°C (7 < pH < 9)
THE WARRANTY DOES NOT COVER DAMAGE DUE TO CORROSION RESULTING FROM ELECTROLYTIC
PHENOMENA.
Caution
The SYSLOOP EVO must not run on a network with open loops, likely to cause incidents related to
oxygenation, or with non treated table water.
Caution
If the water circuit is to be drained for a time exceeding one month, the circuit must be fully
charged with nitrogen to prevent any risk of corrosion by differential venting.
Caution
The manufacturer is not liable for recommendations in terms of water treatment (call a specialized
company).
However, this matter has a critical nature, and particular care must be given to ensure that the type
of treatment applied is effective.
The liability of the manufacturer or its representative will not be sought when non treated water
or non compliant quality water is used.
Caution

English
1
0
0
Main return pipe work
Main water supply pipe work
Main condensate drainage
pipe work
Siphon
Spherical
dome valve
Hoses
16 SYSLOOP EVO
13.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS
1. It is recommended that all units are connected to a water supply and return pipe system of
the Tickelman Loop type. The Tickelman Loop system is self-balancing and thus only requires
manual balancing if a large number of units with different ow and pressure loss characteristics
are connected to a single hydraulic loop. A very simple way of checking the hydraulic balance
is to measure the temperature difference between the water connections. To ensure a correct
water ow, the difference must be in the region of 3 to 7 °C in Cooling mode and 2 to 5°C in
Heating mode.
A system with two parallel pipes can also operate in a perfectly adequate manner, but it is more
difcult to achieve, and to maintain, balance.
2. Never connect a unit to the water supply and return lines without completely
cleaning and flushing out the hydraulic loop beforehand. After performing these
operations, the units must be connected, with all valves completely open, ready for the
system to be lled with water.
3. Water exchanger clogging reduces efcient appliance operation. We recommend the installation
of a strainer lter (Ø 0.8mm) on the appliance's water inlet pipe. The lter must be installed if
the water circuit cannot be cleaned. This lter should be installed between two cut-off valves
and it must remain easily accessible for the user so that it can be checked at regular intervals.
4. Steel, copper or P.V.C. pressure pipes may be used.
5. It is advisable to make the unit’s water supply and return conveyance lines with short lengths
of high-pressure hose, as they form excellent shock absorbers for unit operating noise and
hydraulic pressure surges.
One of the hose ends must be tted with a rotating connector to facilitate removal for
maintenance. Rigid pipes can be connected directly to the unit, but this is not recommended
due to their inability to absorb vibrations and noise.
Rigid pipes must be equipped with removable connectors to facilitate future removal of the unit
from its location.

English
2%mini
40mm
Ø16mm
2%mini
40mm 40mm
Ø16mm
17
SYSLOOP EVO
6. Certain exible hose threaded connectors are supplied with sealing paste. If this is not the case,
use Teon tape to create a tight seal.
7. Each unit must be equipped with isolation valves on the water inlet and outlet pipes. The return
isolation valve is used for both cutting off the water supply and balancing the installation’s water
ow. As it is used to establish the balance of the ows, it must be equipped with a lockable
position end stop. This end stop ensures that, after the valve is closed, it can only be re-opened
as far as the position required to maintain a balanced water ow.
8. Use steel, copper or P.V.C. pipes for the condensates drainage pipe. Each unit is supplied with a
connector for condensates drainage.
9. The condensates drainage line must comprise a siphon and run from the unit on a downward
slope of at least 2%. Generally, the siphon is connected directly to the unit’s condensates
drainage outlet. A length of plastic pipe can be used between the siphon and the condensates
drainage line.
A complete condensates drainage system with copper or P.V.C. pipe can also be used.
Screw-on connectors shall be tted to facilitate drainage pipe removal if copper pipe is used for
the drainage pipe work.
10. No point of the condensates drainage pipe work should be located above the level of one of
the units’ condensate drainage outlet connection.
11. The circuits’ high points must be bled of air.
12. Comply with current regulations in terms of dielectric isolation of the connectors and the pipe
work.
Coil at the unit blowing
(standard)
Coil at the return air intake
(on request)

English
Main return pipe work
Main water supply pipe work
Spherical
dome valve
INTERCONNECTED CONVEYANCES
Rubber hose
18 SYSLOOP EVO
1. Before commissioning an appliance for the rst time, the water loop must be cleaned and rinsed out
to remove any dirt and manufacturing debris.
If the appliances are equipped with isolation valves (either electric or pressostatic), the water
supply and return conveyance circuits to and from
each machine must be connected to each other. This
will avoid any dirt being introduced into the units.
Flushing water through the units is acceptable if they
are not equipped with water ow control devices.
2. The system must be lled from the mains water
supply. All air bleeds must be open during lling. Close
the air bleeds once the system is lled.
The installer must start the main circulation pump
with the water top-up tap on the pressure reduction
valve in the open position. Check the air bleeds by
increasing order of height to ensure water ows freely
throughout the entire system.
Power supply to the cooling tower must be shut down,
and the water loop temperature regulation thermostat
must be set at 27 °C.
As the water circulates through the system, the
installer must seek out and repair any possible pipe
work leaks. The drain cocks, on the lowest points
on the circuit, must be open for ushing out and chasing out any impurities. Ensure that the mains
water valves are adjusted to allow water to enter at the same speed as it exits. Check the pump inlet
pressure gauge and manually adjust the compensating valve to maintain the same pressure before
and after the opening of the drain taps. Flushing must be performed for at least two hours, or longer
if necessary, until clear and clean water is obtained at the drain taps.
3. Stop the additional heating and the water circulation pump. Open all the bleed points and the drain
taps to empty the system completely. The short-circuited water supplies and returns must now be
connected to the units’ inlet and outlet connections. It is recommended to use Teon tape on the
pipe connector threads. Do not use sealing paste on the hoses’ rotating connecters.
4. Formerly, sodium tri-phosphate used to be recommended as a cleaning agent for ushing.
However, nowadays numerous countries forbid the introduction of phosphates into their wastewater
networks. Therefore, it is now recommended that the system is ushed out with hot water (30 °C).
5. Fill the system again with clean water. Test the water acidity level (litmus paper), and treat as
required to obtain a slightly alkaline water quality.
At this stage, the recommended percentage of anti-freeze can be added. Use commercial quality
anti-freeze specically intended for air conditioning systems. Do not use automobile radiator anti-
freeze.
6. On the main electrical cabinet, adjust the heater set temperature point at 20 °C and the cooling
tower set temperature at 30 °C. Connect the power supply to all motors and start the circulation
pumps.
When the normal ow level has been reached through all components, including the cooler (irrespective
of the season) and when the air is bled form the system and the loop temperature has stabilised, each
appliance is ready to be checked, tested and started for balancing the air and water ows.
13.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM
