System air SYSHRW 019 Manual

Water source heat pump
Installation and maintenance manual
1 250 â4 000 m3/h
5.3 â20.6kW
5.8 â22.6kW
019 / 27 / 27HE / 30 / 30HE / 36 / 36HE
42 / 42HE / 48 / 60 / 60HE / 72 / 72HE
SYSHRW

INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

English
2SYSHRW
CONTENTS
1. GENERAL RECOMMENDATIONS........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS ...................................................................................................................................................................................................................................................................3
1.2. WARNING .....................................................................................................................................................................................................................................................................................3
1.3. EQUIPMENT SAFETY DATA.........................................................................................................................................................................................................................................................4
2. INSPECTION AND STORAGE.............................................................................................................................................................. 5
3. WARRANTY...................................................................................................................................................................................... 5
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE ............................................................................................................. 5
5. PRESENTATION................................................................................................................................................................................. 5
6. CONTENTS OF PACKAGE ................................................................................................................................................................... 6
6.1. OPTIONAL ACCESSORIES............................................................................................................................................................................................................................................................6
7. DIMENSIONS .................................................................................................................................................................................... 6
8. HANDLING........................................................................................................................................................................................ 6
8.1. NET WEIGHT.................................................................................................................................................................................................................................................................................6
8.2. GENERAL HANDLING..................................................................................................................................................................................................................................................................6
8.2.1. HANDLING WITH A FORKLIFT ...................................................................................................................................................................................................................................6
9. TECHNICAL SPECIFICATIONS ............................................................................................................................................................. 7
9.1. MODELS DESIGNATION ..............................................................................................................................................................................................................................................................7
9.2. PHYSICAL CHARACTERISTICS.....................................................................................................................................................................................................................................................8
9.3. ELECTRIC SPECIFICATIONS....................................................................................................................................................................................................................................................... 10
9.4. OPERATING LIMITS................................................................................................................................................................................................................................................................... 10
9.4.1. ENVIRONMENT........................................................................................................................................................................................................................................................ 10
9.4.2. TEMPERATURE LIMITS ............................................................................................................................................................................................................................................ 10
9.4.3. FLOW LIMITS............................................................................................................................................................................................................................................................ 11
9.5. REFRIGERATION SPECIFICATIONS .......................................................................................................................................................................................................................................... 14
9.5.1. REFRIGERANT CIRCUIT DIAGRAM ......................................................................................................................................................................................................................... 14
9.5.2. REFRIGERANT CHARGE........................................................................................................................................................................................................................................... 14
9.5.3. FLUOROCARBON GAS REGULATIONS................................................................................................................................................................................................................... 14
10. INSTALLATION.............................................................................................................................................................................. 15
10.1. GENERALITIES......................................................................................................................................................................................................................................................................... 15
10.2. CLEARANCE ............................................................................................................................................................................................................................................................................ 15
10.3. UNIT LOCATION ...................................................................................................................................................................................................................................................................... 16
11. DUCTING AND NOISE LEVEL REDUCTION ...................................................................................................................................... 17
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME................................................................................................................................................................................................ 18
11.2. MODIFYING THE AIR BLOWING DIRECTION ....................................................................................................................................................................................................................... 18
11.3. FILTER ACCESS ........................................................................................................................................................................................................................................................................ 19
11.4. VENTILATION .......................................................................................................................................................................................................................................................................... 19
11.5. AERAULIC ADJUSTEMENT...................................................................................................................................................................................................................................................... 19
11.5.1. MODEL SYSHRW19 .............................................................................................................................................................................................................................................. 20
11.5.2. MODEL SYSHRW27 .............................................................................................................................................................................................................................................. 20
11.5.3. MODEL SYSHRW27HE.......................................................................................................................................................................................................................................... 20
11.5.4. MODEL SYSHRW30 .............................................................................................................................................................................................................................................. 20
11.5.5. MODEL SYSHRW30HE.......................................................................................................................................................................................................................................... 21
11.5.6. MODEL SYSHRW36 .............................................................................................................................................................................................................................................. 21
11.5.7. MODEL SYSHRW36HE.......................................................................................................................................................................................................................................... 21
11.5.8. MODEL SYSHRW42 .............................................................................................................................................................................................................................................. 21
11.5.9. MODEL SYSHRW42HE.......................................................................................................................................................................................................................................... 22
11.5.10. MODEL SYSHRW48............................................................................................................................................................................................................................................ 22
11.5.11. MODEL SYSHRW60............................................................................................................................................................................................................................................ 22
11.5.12. MODEL SYSHRW60HE ....................................................................................................................................................................................................................................... 22
11.5.13. MODEL SYSHRW72............................................................................................................................................................................................................................................ 23
11.5.14. MODEL SYSHRW72HE ....................................................................................................................................................................................................................................... 23
12. HYDRAULIC LINKS........................................................................................................................................................................ 24
12.1. WATER QUALITY..................................................................................................................................................................................................................................................................... 24
12.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS.................................................................................................................................................................................................... 25
12.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM..................................................................................................................................................................... 27
13. WIRING DIAGRAM AND LEGEND.................................................................................................................................................. 28
13.1. WIRING DIAGRAM.................................................................................................................................................................................................................................................................. 28
13.2. WIRING DIAGRAM KEY DESCRIPTIONS............................................................................................................................................................................................................................... 28
13.3. POWER SUPPLY...................................................................................................................................................................................................................................................................... 28
13.4. PRESSOSTATS SETTING ......................................................................................................................................................................................................................................................... 28
14. ELECTRICAL CONNECTIONS........................................................................................................................................................... 28
14.1. UNIT POWER SUPPLY............................................................................................................................................................................................................................................................. 29
14.2. ALARM INDICATORS.............................................................................................................................................................................................................................................................. 30
14.3. REMOTE CONTROLS............................................................................................................................................................................................................................................................... 30
14.4. COMMUNICATION.................................................................................................................................................................................................................................................................. 31
14.5. REMOTE CONTROL................................................................................................................................................................................................................................................................. 31
14.5.1. WALL MOUNTING ................................................................................................................................................................................................................................................. 31
14.5.2. ELECTRICAL CONNECTIONS................................................................................................................................................................................................................................. 32
15. REGULATION ................................................................................................................................................................................ 33
15.1. ORDER OF PRIORITY FOR CONTROL SYSTEMS.................................................................................................................................................................................................................. 33
15.2. WALL-MOUNTED CONTROL.................................................................................................................................................................................................................................................. 33
15.2.1. KEYPAD................................................................................................................................................................................................................................................................... 33
15.2.2. SCREEN................................................................................................................................................................................................................................................................... 34
15.2.3. TIME SETTINGS...................................................................................................................................................................................................................................................... 34
15.2.4. SCHEDULING.......................................................................................................................................................................................................................................................... 35
16. FINAL TASKS ................................................................................................................................................................................ 36
17. STARTING - RECOMMENDATIONS - SETTINGS.............................................................................................................................. 36
17.1. COMMISSIONING ................................................................................................................................................................................................................................................................... 37
17.1.1. DEMAND FOR COOLING....................................................................................................................................................................................................................................... 37
17.1.2. DEMAND FOR HEATING....................................................................................................................................................................................................................................... 37
17.1.3. FINAL CHECK.......................................................................................................................................................................................................................................................... 37
18. MAINTENANCE AND SERVICING................................................................................................................................................... 38
18.1. MAINTENANCE PROCEDURES.............................................................................................................................................................................................................................................. 38
18.1.1. GENERAL................................................................................................................................................................................................................................................................ 38
18.1.2. GENERAL INSPECTION.......................................................................................................................................................................................................................................... 38
18.1.3. REFRIGERATION CIRCUIT...................................................................................................................................................................................................................................... 38
18.1.4. ELECTRICAL SECTION............................................................................................................................................................................................................................................ 38
18.1.5. AIR FILTER .............................................................................................................................................................................................................................................................. 39
18.1.6. FAN MOTOR ASSEMBLY....................................................................................................................................................................................................................................... 39
18.2. FAULT FINDING....................................................................................................................................................................................................................................................................... 40
18.2.1. NEITHER THE FAN NOR THE COMPRESSOR OPERATE ..................................................................................................................................................................................... 40
18.2.2. VENTILATION (FAN) MODE OPERATES BUT THE COMPRESSOR DOES NOT OPERATE................................................................................................................................ 40
18.2.3. INSUFFICIENT COOLING OR HEATING PRODUCTION........................................................................................................................................................................................ 40
18.2.4. INSUFFICIENT WATER FLOW AT THE LEVEL OF THE COAXIAL EXCHANGER.................................................................................................................................................. 40
18.2.5. APPEARANCE OF WATER DROPLETS IN THE APPLIANCE................................................................................................................................................................................ 40
18.2.6. APPEARANCE OF ABNORMAL NOISES AND VIBRATIONS IN THE CASING................................................................................................................................................... 41
18.3. ALARM CODES........................................................................................................................................................................................................................................................................ 41
19. WARRANTY CLAIM - MATERIAL RETURN PROCEDURE................................................................................................................. 42
20. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 42
21. DISPOSAL..................................................................................................................................................................................... 42

English
3SYSHRW
1. GENERAL RECOMMENDATIONS
POWER SUPPLY MUST BE
SWITCHED OFF BEFORE STARTING
WORK IN THE ELECTRIC CONTROL
BOX
The purpose of this Manual is to provide users with instructions for installing, commissioning, using and
maintaining the units. It also contains instructions on starting up the machine as well as recommendations
to avoid bodily injury and risks of damage to the device during its operation.
It does not contain the complete description of all the maintenance operations guaranteeing the unit’s long
life and reliability. Only the services of a qualied technician can guarantee the unit’s safe operation over a
long service life.
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cut off the power supply before starting work on the appliance.
When forming the hydraulic connections, ensure that no impurities are introduced into the pipe work.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are not
complied with.
If you encounter a problem, please call the Technical Department for your area.
If possible, assemble the compulsory or optional accessories before placing the appliance in its nal location
(see instructions provided with each accessory).
To familiarize yourself fully with the appliance, we recommend that you also read our Technical Instructions.
The information contained in these Instructions is subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in force when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel who have a good knowledge of standards and local regulations, as well as experience of this
type of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
The unit should be handled using lifting and handling equipment appropriate to the unit's size and weight.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
Work must not be carried out on the electrical components if water or high humidity is present at the
installation site.
SAFETY SYMBOLS
ELECTRIC
VOLTAGE ROTATING PART RISK OF ASPHYXIA
PRESSURIZED
EQUIPMENT
RISK OF
CUTTING
RISK OF BURNS

English
4SYSHRW
1.3. EQUIPMENT SAFETY DATA
Safety Data R407C
Toxicity Low
In contact with skin
Liquid splashes or sprays may cause freeze burns. Unlikely to be hazardous by skin absorption.
However, R407C may be slightly irritant and, if liquid, it has a strong degreasing effect. Flush contaminated skin
areas with running water. If it comes into contact with fabrics, the liquid refrigerant will cause them to freeze
and adhere to the skin. Carefully remove the contaminated clothing since it might adhere to the skin and cause
freeze burns. Contact a doctor if the affected skin areas are reddened or irritated.
In contact with eyes Vapours have no effect. Liquid splashes or sprays may cause freeze burns. In these cases rinse your eyes with
running water or with a solution for eye lavages for at least 10 minutes. Immediately contact a doctor.
Ingestion Very unlikely to occur. If this should be the case, it may cause freeze burns. Never induce vomiting. Keep the patient awake. Make him rinse his mouth with running water and make him drink about 1/4 of a litre.
Immediately contact a doctor.
Inhalation
R407C: High concentration levels of its vapours in the air can produce an anaesthetic effect, including the loss of
consciousness. Particularly severe exposures may cause heart arrhythmia and sometimes prove to be also fatal.
At high concentrations there is a danger of asphyxia due to a reduced oxygen content in the atmosphere.
In these cases take the patient to the open air, in a cool place and keep him at rest. Administer oxygen, if
required. Apply artificial respiration if breathing has ceased or if it has become irregular. In case of heart failure
immediately apply cardiac massage. Immediately contact a doctor.
Further Medical Advice
A symptomatic and supportive therapy is generally suitable. A heart sensitisation has been observed in some
cases, as a result of exposures to particularly high concentrations. In the presence of catecholamines (such
as for example adrenaline) in the blood flow, it has increased the irregularity of the cardiac rhythm and then
caused the heart failure.
Long-term exposure R407C: A lifetime study which has been conducted on the effects inhalation may have on rats at 50,000 ppm has shown the onset of benign tumours of the testicle. These remarks suggest that there is no danger for
human beings if they are exposed to concentrations below the occupational limits or equal to them.
Occupational exposure
limits R407C: Recommended limits: 1,000 ppm v/v 8 hours TWA.
Stability R407C: Not specified.
Conditions to avoid Use in the presence of exposed flames, red heat surfaces and high humidity levels.
Hazardous reactions Possibility of violent reactions with sodium, potassium, barium and other alkaline substances.
Incompatible materials: magnesium and all the alloys containing over 2% of magnesium.
Hazardous
decomposition
products R407 C: Halogen acids deriving from thermal decomposition and hydrolysis.
General precautions Avoid the inhalation of high concentrations of vapours. The concentration in the atmosphere shall be kept at the minimum value and anyway below the occupational limits. Since vapours are heavier than air and they tend to
stagnate and to build up in closed areas, any opening for ventilation shall be made at the lowest level.
Breathing protection In case of doubt about the actual concentration, wear breathing apparatus. It should be self-contained and
approved by the bodies for safety protection.
Storage Preservation Refrigerant containers shall be stored in a cool place, away from fire risk, direct sunlight and all heat sources,
such as radiators. The maximum temperature shall never exceed 45°C in the storage place.
Protection clothes Wear boots, safety gloves and glasses or masks for facial protection.
Behaviour in case of
leaks or escapes
Never forget to wear protection clothes and breathing apparatus. Isolate the source of the leakage, provided
that this operation may be performed in safety conditions. Any small quantity of refrigerant which may have
escaped in its liquid state may evaporate provided that the room is well ventilated.In case of a large leakage,
ventilate the room immediately. Stop the leakage with sand, earth or any suitable absorbing material. Prevent
the liquid refrigerant from flowing into drains, sewers, foundations or absorbing wells since its vapours may
create an asphyxiating atmosphere.
Disposal The best procedure involves recovery and recycle. If this is not possible, the refrigerant shall be given to a plant which is well equipped to destroy and neutralise any acid and toxic by-product which may derive from its
disposal.
Combustibility features R407C: Non flammable in the atmosphere.
Containers If they are exposed to the fire, they shall be constantly cooled down by water sprays.
Containers may explode if they are overheated.
Behaviour in case of
fire In case of fire wear protection clothes and self-contained breathing apparatus.

English
5SYSHRW
2. INSPECTION AND STORAGE
The appliances are delivered fully assembled, factory tested and ready to operate.
Any modication to the units without the manufacturer’s prior approval, shall automatically render the
warranty null and void.
The following conditions must be respected in order to maintain the validity of the warranty:
²Commissioning shall be performed by specialised technicians from technical services approved by
the manufacturer.
²Maintenance shall be performed by technicians trained for this purpose.
²Only Original Equipment spare parts shall be used.
²All the operations listed in the present manual shall be performed within the required time limits.
3. WARRANTY
At the time of receiving the equipment carefully cross check all the elements against the shipping documents
in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or
hidden damage.
In the event of shipping damage, write precise details of the damage on the shipper’s delivery note and
send immediately a registered letter to the shipper within 48 hours, clearly stating the damage caused.
Forward a copy of this letter to the manufacturer or his representative.
Never store or transport the unit upside down. It must be stored indoors, completely protected from
rain, snow etc. The unit must not be damaged by changes in the weather (high and low temperatures).
Excessively high temperatures (above 60 °C) can harm certain plastic materials and cause permanent
damage. Moreover, the performance of certain electrical or electronic components can be impaired.
THE WARRANTY SHALL BE NULL AND VOID IN THE EVENT
OF NON-COMPLIANCE WITH ANY OF THE ABOVE CONDITIONS.
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE
For technical questions, work under warranty, commissioning, a manufacturer’s visit or repair quotations.
Our technical support and after-sales service hotline can be reached on:
²(0)891 700 407 in France
²[e-mail] for export customers
5. PRESENTATION
Following assembly of the units in the factory:
1. the electrical circuits are tested.
2. refrigeration circuits receive their operational refrigerant charge and are subject to pressurized leak
detection tests.
3. The SYSHRW units are tested.
These tests are conducted to guarantee the correct operation and quality of our products.
The SYSHRW units are produced in compliance with state-of-the-art design and manufacturing standards.
This guarantees their high performance and reliability as well as their compatibility with all types of air
conditioning installations. The unit, designed for an indoor mounted application, is not suitable for any uses
other than those specied in this manual.

English
6SYSHRW
SEE APPENDIX
6. CONTENTS OF PACKAGE
6.1. OPTIONAL ACCESSORIES
7. DIMENSIONS
8. HANDLING
8.1. NET WEIGHT
The handling method depends on the SYSHRW model and its nal destination.
²Take care to avoid any rough handling or impacts when unloading and moving the appliance.
²Before hoisting the appliance into position, perform a test lift to ensure stability and balance. Avoid
twisting or uneven lifting of the units.
²The units shall be carefully inspected before unit installation to make sure this has not happened.
²All of these sections are inspected before they leave the factory. Prior to commissioning, it is
therefore important to make sure that no bolts, screws or other fastening components are loosened
or missing.
To avoid irreversible damage, do not tilt the SYSHRW by more than 45° during handling.
Caution
Never subject the metal work (panels, posts) of the SYSHRW to handling constraints, as only its base
is designed for that purpose.
Caution
8.2. GENERAL HANDLING
On opening the box, check that all of the accessories required for installation are present.
8.2.1. HANDLING WITH A FORKLIFT
A forklift can be used to handle the SYSHRW units when palletized.
Place a safety wedge between the unit base and the fork lift truck to avoid damaging the unit’s structure
and casing.
Package contents:
1 appliance
1 suspension kit comprising:
1 RCS control module
²4 nuts
²4 locknuts
²4 shock mounts
²4 washers
1 installation manual
19 27 27HE 30 30HE 36 36HE 42 42HE 48 60 60HE 72 72HE
Weigth kg 80 100 112 100 100 112 133 133 135 140 144 149 149 253

English
7SYSHRW
9. TECHNICAL SPECIFICATIONS
9.1. MODELS DESIGNATION
The product plate on the device shows the full model reference number and should be used to check that
the actual unit matches the model ordered. It also provides the following information:
²General information
serial number
year of manufacture
IP index
²Electrical information
supply voltage
maximum operating current
starting current
²Thermodynamic circuit information
type of refrigerant
refrigerant charge in each circuit
Service pressure of refrigeration circuit
refrigeration circuit service temperatures
²Hydraulic circuit information
nominal water ow
maximum water pressure
REP. Description
1
Size
SYSHRW 19 : size 19
SYSHRW 27 : size 27
SYSHRW 27HE : size 27 High Efciency
SYSHRW 30 : size 30
SYSHRW 30HE : size 30 High Efciency
SYSHRW 36 : size 36
SYSHRW 36HE : size 36 High Efciency
SYSHRW 42 : size 42
SYSHRW 42HE : size 42 High Efciency
SYSHRW 48 : size 48
SYSHRW 60 : size 60
SYSHRW 60HE : size 60 High Efciency
SYSHRW 72 : size 72
SYSHRW 72HE : size 72 High Efciency
2
Version L: Cooling only H: Heat pump
3
Electric heater
Blank : Without heater
2250W : Capacity 2250W
3750W : Capacity 3750W
4500W : Capacity 4500W
5400W : Capacity 5400W
6500W : Capacity 6500W
7500W : Capacity 7500W
9000W : Capacity 9000W
4
Brand SYS : Systemair
5
Air outlet S1 : Frontal S2 : Lateral
6
Filter G2M1 : G2M1 lter G3M1 : G3M1 lter
7
Communication
protocol
Blank : Stand Alone
MBRT : Modbus RTU
BNMS : Bacnet MSTP
BNIP : Bacnet IP LON : Bacnet IP
8
Remote control Blank : Without remote control RCS : POL822
9
Main switch Blank : Without main switch SECT : Main switch
10
Option SOND : Room temperature sensor
SYSHRW 42 . H . 3750W . SYS . S1 . G2M1 . MBRT . RCS . SECT . SOND
1
2
3
4
5
6
7
8
9
10

English
8SYSHRW
9.2. PHYSICAL CHARACTERISTICS
Models 19 27 27HE 30 30HE 36 36HE
Total cooling capacities (1) W 5 278 7 419 7 320 8 691 8 710 10 138 11 060
Sensible cooling capacities (1) W 4 257 5 824 5 600 6 315 6 676 7 278 9 070
Total absorbed power (3) W 1 557 2 118 1 981 2 658 2 357 3 044 2 909
EER according to EN14511 4.20 3.72 4.00 3.77 4.15 3.77 4.31
Total Heating capacities (2) W 5 826 8 342 9 252 9 759 9 960 11 036 12 200
Total absorbed power (3) W 1 611 2 332 2 382 2 983 2 475 3 460 3 203
COP according to EN14511 4.40 3.69 4.21 3.50 4.30 3.38 4.28
VENTILATION
Air ow m3/h 1 250 1 185 1 180 1 490 1 500 1 580 1 900
Available pressure Pa 90 90 90 150 150 190 190
Fan absorbed power W 450 450 450 950 950 950 950
Air lter - Number / Efciency 2/G2M1
HYDRAULIC CIRCUIT
Water exchanger Nbr 1
Exchanger type coaxial
Water pressure max. bar 16
Cooling
mode
Nominal water ow l/h 921 1 540 1 563 1 764 1 838 2 030 2 335
Water pressure drop at nominal ow kPa 13 17 15.7 23 21 25 27.6
Minimum water ow l/h 460 770 782 882 900 1 015 1 168
Heating
mode
Nominal water ow l/h 921 1 540 1 563 1 764 1 838 2030 2 335
Water pressure drop at nominal ow kPa 13 17 15.7 23 21 25 27.6
Minimum water ow l/h 460 770 782 882 919 1 015 1 168
Water connections Input/output pouces 3/4”
Female gas thread
Condensate outlet Ø mm 19
REFRIGERANT CIRCUIT
Number of circuit Nbr 1
Compressor type Rotary Scroll
Refrigerant R407C
Load g 1 160 1 483 2 534 1 594 1 950 1 950 3 200
ELECTRICAL DATA
Electrical power supply 230/1/ 50 400V / 3~ N / 50Hz
Max. current (4) A 12.3 8.5 8.5 12.3 12.3 13 13
starting current (5) A 35.4 35.4 35.4 46 46 52 52
Electric heating - Power (6) W 1 500+750 3 750 3 750 3 750 3 750 4 500 4 500
ACOUSTICAL DATA
Sound power level (7) (LS/MS/HS) dB(A) 51/54/58 54/56/57 54/56/57 53/54/57 53/54/57 53/56/58 53/56/58
Sound pressure level (7) dB(A) 30/33/37 33/35/36 33/35/36 32/33/36 32/33/36 32/35/37 32/35/37
NR (7) (LS/MS/HS) dB(A) 34/37/40 33/34/37 33/34/37 33/35/38 33/35/38 34/37/41 34/37/41
(1) Nominal cooling capacities based on : entering air temperature of 27 °C dry bulb, 19 °C wet bulb
with entering water temperature of 30 °C.
(2) Nominal heating capacities based on : entering air temperature of 20 °C dry bulb, 15 °C wet bulb
with entering water temperature of 20 °C.
(3) Absorbed power (compressor + fan) at nominal conditions.
(4) Nominal currents are given at +/- 5%.
(5) Starting currents are given at +/- 10%.
(6) Electric heating coil is available optional.
(7) Informative data, considering an hypothetical sound attenuation of the room and installation of
21dB.

English
9SYSHRW
Models 42 42HE 48 60 60HE 72 72HE
Total cooling capacities (1) W 11 366 12 500 12 965 14 344 16 700 17 174 20 600
Sensible cooling capacities (1) W 8 849 9 542 10 051 10 988 13 900 13 536 17 699
Total absorbed power (3) W 3 584 3 423 4 200 4 989 4 278 6 280 5 279
EER according to EN14511 3.44 4.00 4.03 3.23 4.44 3.26 4.74
Total Heating capacities (2) W 14 422 14 450 14 904 16 147 18 800 21 500 22 601
Total absorbed power (3) W 3 920 3 479 4 300 5 150 5 098 7 347 6 188
COP according to EN14511 3.84 4.36 4.25 3.33 4.20 3.15 4.23
VENTILATION
Air ow m3/h 2 040 2 040 2 750 2 840 3 050 3 570 4 000
Available pressure Pa 115 115 190 160 160 220 220
Fan absorbed power W 950 950 1 500 1 500 1 500 1 500 736
Air lter - Number / Efciency 2/G2M1
HYDRAULIC CIRCUIT
Water exchanger Nbr 1
Exchanger type coaxial
Water pressure max. bar 16
Cooling
mode
Nominal water ow l/h 2 592 2 641 2 822 3 348 3 458 3 924 4 319
Water pressure drop at nominal ow kPa 33 30 34 40 30 61 45
Minimum water ow l/h 1 296 1 321 1 411 1 692 1 729 1 944 2 160
Heating
mode
Nominal water ow l/h 2 592 2 641 2 822 3 348 3 458 3 924 4 319
Water pressure drop at nominal ow kPa 33 30 34 40 30 61 45
Minimum water ow l/h 1 296 1 321 1 411 1 692 1 729 1 944 2 160
Water connections Input/output pouces 3/4”
Female gas thread
1" 1/4
Male gas
thread
3/4”
Female gas
thread
1" 1/4
Male gas
thread
Condensate outlet Ø mm 19 22
REFRIGERANT CIRCUIT
Number of circuit Nbr 1
Compressor type Scroll
Refrigerant R407C
Load g 3 200 2 800 3 200 3 200 3 400 2 700 3 800
ELECTRICAL DATA
Electrical power supply 400V / 3~ N / 50Hz
Max. current (4) A 16 16 18 19 19 22.5 22.5
starting current (5) A 56 56 58 73.5 73.5 108.5 108.5
Electric heating - Power (6) W 5 400 5 400 6 500 7 500 7 500 9 000 9 000
ACOUSTICAL DATA
Sound power level (7) (LS/MS/HS) dB(A) 54/56/58 54/56/58 55/59/63 55/59/63 55/59/63 57/60/63 55/59/62
Sound pressure level (7) dB(A) 33/35/37 33/35/37 34/38/42 34/38/42 34/38/42 36/39/42 34/38/41
NR (7) (LS/MS/HS) dB(A) 36/40/43 36/40/43 39/43/46 39/43/46 39/43/46 36/39/44 36/39/44
(1) Nominal cooling capacities based on : entering air temperature of 27 °C dry bulb, 19 °C wet bulb
with entering water temperature of 30 °C.
(2) Nominal heating capacities based on : entering air temperature of 20 °C dry bulb, 15 °C wet bulb
with entering water temperature of 20 °C.
(3) Absorbed power (compressor + fan) at nominal conditions.
(4) Nominal currents are given at +/- 5%.
(5) Starting currents are given at +/- 10%.
(6) Electric heating coil is available optional.
(7) Informative data, considering an hypothetical sound attenuation of the room and installation of
21dB.

English
10 SYSHRW
DB: dry bulb WB:
bulbe humide
* Conditions in
accordance with the
standard:
EN 14511-2
9.3. ELECTRIC SPECIFICATIONS
A variance of ±10% is acceptable in relation to the operating voltage marked on the appliance’s Maker’s
Plate. Phase imbalance on three phase units must not exceed 2%.
Operating voltages :
²230V / 1 ph / 50 Hz (207 Volts minimum; 253 Volts maximum.)
²400V / 3ph / 50Hz + N (360 Volts mini ; 440 Volts maxi.)
Comments: the stated voltages represent the accepted range. However, certain components may be subject
to premature wear on appliances operating continuously, for extensive periods, on abnormally low or high
voltages.
9.4. OPERATING LIMITS
9.4.1. ENVIRONMENT
This equipment is designed EXCLUSIVELY for INDOOR installation.
In general, sheltered locations such as garages, roof space, etc, do not provide sufcient protection against
extreme temperatures and/or humidity and may be harmful to the unit’s performance, reliability and service
life.
9.4.2. TEMPERATURE LIMITS
Cooling Heating
Air inlet
temperature
Minimum 21 °C DB / 15 °C WB 15 °C
Normal * 27 °C DB / 19 °C WB 20 °C
Maximum 38 °C DB / 28 °C WB 27 °C
Water inlet
temperature
Minimum 18 °C 13 °C
Normal * 30 °C 20 °C
Maximum 44 °C 34 °C
Maximum hydraulic pressure 16 bar
MODELS 19 27 27HE 30 30HE 36 36HE
Supply voltage 230V 50Hz 400V / 3~ N / 50Hz
without
heating
Full load current (max) A 12.3 8.5 8.5 12.3 12.3 13 13
Starting amperage A 35.4 35.4 35.4 46 46 52 52
with heating Full load current (max) A 14.2 9.4 9.4 12.3 12.3 13.1 13.1
Starting amperage A 35.4 35.4 35.4 46 46 52 52
MODELS 42 42HE 48 60 60HE 72 72HE
Supply voltage 400V / 3~ N / 50Hz
without
heating
Full load current (max) A 16 16 18 19 19 22.5 23.2
Starting amperage A 56 56 58 73.5 73.5 108.5 109.2
with heating Full load current (max) A 16 16 18.3 19.9 19.9 22.5 23.2
Starting amperage A 56 56 58 73.5 73.5 108.5 109.2

English
Nominal air ow : 1 250 m3/h Nominal water ow : 921 l/h
600
700
800
900
1000
1100
1200
1300
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
450
500
550
600
650
700
750
800
850
900
950
1000
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 4410 46 48
50
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 185 m3/h Nominal water ow : 1 540 l/h
550
600
650
700
750
800
850
900
950
1000
1050
1100
1150
1200
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
400
500
600
700
800
900
1000
1100
1200
1300
1400
1500
1600
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 4410 46 48
50
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 180 m3/h Nominal water ow : 1 563 l/h
550
600
650
700
750
800
850
900
950
1000
1050
1100
1150
1200
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
400
500
600
700
800
900
1000
1100
1200
1300
1400
1500
1600
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 4410 46 48
50
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 490 m3/h Nominal water ow : 1 764 l/h
550
650
750
850
950
1050
1150
1250
1350
1450
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
680
780
880
980
1080
1180
1280
1380
1480
1580
1680
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
11SYSHRW
9.4.3. FLOW LIMITS
9.4.3.1. MODEL SYSHRW19
9.4.3.2. MODEL SYSHRW27
9.4.3.3. MODEL SYSHRW27HE
9.4.3.4. MODEL SYSHRW30

English
Nominal air ow : 2 040 m3/h Nominal water ow : 2 592 l/h
800
900
1000
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m
3
/h)
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
2100
2200
2300
2400
2500
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 2 040 m3/h Nominal water ow : 2 641 l/h
900
1000
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
2100
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m
3
/h)
1300
1400
1500
1600
1700
1800
1900
2000
2100
2200
2300
2400
2500
2600
2700
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 500 m3/h Nominal water ow : 1 838 l/h
600
700
800
900
1000
1100
1200
1300
1400
1500
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
800
1000
1200
1400
1600
1800
2000
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 580 m3/h Nominal water ow : 2 030 l/h
600
700
800
900
1000
1100
1200
1300
1400
1500
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
800
1000
1200
1400
1600
1800
2000
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 1 900 m3/h Nominal water ow : 2 335 l/h
800
900
1000
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m
3
/h)
1100
1200
1300
1400
1500
1600
1700
1800
1900
2000
2100
2200
2300
2400
2500
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
12 SYSHRW
9.4.3.5. MODEL SYSHRW30HE
9.4.3.6. MODEL SYSHRW36
9.4.3.7. MODEL SYSHRW36HE
9.4.3.8. MODEL SYSHRW42
9.4.3.9. MODEL SYSHRW42HE

English
Nominal air ow : 2 750 m3/h Nominal water ow : 2 822 l/h
1200
1400
1600
1800
2000
2200
2400
2600
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
1200
1400
1600
1800
2000
2200
2400
2600
2800
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 2 840 m3/h Nominal water ow : 3 348 l/h
1250
1450
1650
1850
2050
2250
2450
2650
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
1450
1650
1850
2050
2250
2450
2650
2850
3050
3250
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 3 570 m3/h Nominal water ow : 3 924 l/h
1600
1800
2000
2200
2400
2600
2800
3000
3200
3400
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
1750
1950
2150
2350
2550
2750
2950
3150
3350
3550
3750
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 3 050 m3/h Nominal water ow : 3 458 l/h
1400
1600
1800
2000
2200
2400
2600
2800
3000
3200
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38
39
Air inlet temperature (°C)
Air flow (m3/h)
1400
1600
1800
2000
2200
2400
2600
2800
3000
3200
3400
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44
Water inlet temperature (°C)
Water flow (l/h)
Nominal air ow : 4 000 m3/h Nominal water ow : 4 319 l/h
1800
2000
2200
2700
2600
2800
3000
3200
3400
3600
3800
4000
14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33
39
34 35 36 37 38
Air inlet temperature (°C)
Air flow (m3/h)
2000
2200
2400
2600
2800
3000
3200
3400
3600
3800
4000
4200
4400
4600
12 14 16 18 20 22 24 26 28 30 32 34 36 38 40 4842 44 46
Water inlet temperature (°C)
Water flow (l/h)
13SYSHRW
9.4.3.10. MODEL SYSHRW48
9.4.3.11. MODEL SYSHRW60
9.4.3.12. MODEL SYSHRW60HE
9.4.3.13. MODEL SYSHRW72
9.4.3.14. MODEL SYSHRW72HE

English
This equipment contains uorinated gas with greenhouse gas effects covered by the Kyoto
agreement.
Caution
SYSHRW units use the R407C uoro-carbonated uid, belonging to group 2 as dened in directive
2014/68/UE. Considering the maximum operating pressure of these units (42 bar g), they integrate
category 2 (or lower) components as dened in directive 2014/68/UE.
Caution
Non-compliance with one of these obligations constitutes an offense and can result in nancial
penalties.
Furthermore, compliance of the equipment with the uorinated gases regulation must be proven to
the insurance company.
Caution
14 SYSHRW
9.5. REFRIGERATION SPECIFICATIONS
9.5.1. REFRIGERANT CIRCUIT DIAGRAM
SEE APPENDIX
9.5.2. REFRIGERANT CHARGE
The type and quantity of refrigerating uid per circuit are indicated on the product plate.
The installer and end user will get informed on local environmental regulations for the installation, operation
and disposal of the equipment ; more particularly, for the collection of substances hazardous for the
environment (refrigerating uid, oil, antifreeze, etc.). A refrigerating uid, whatever it is, must not be vented.
Refrigerating uids must be handled by skilled personnel.
9.5.3. FLUOROCARBON GAS REGULATIONS
The EC No. 517/2014 regulation covering uorinated greenhouse gases requires of refrigeration equipment
operators to comply with the following ve obligations:
Greenhouse gas quantity (kg of CO2) = Quantity of gas (kg) x gas' GWP
Quantity of greenhouse gas expressed in weight
(kg) and CO2 equivalent
Quantity of gas: amount of gas contained in the
machine in kg (see ID plate)
GWP (Global Warming Potential) of the gas contained
in the machine (see ID plate)
²GWP for the R407C = 1774
9.5.3.1. CALCULATING GREENHOUSE GAS QUANTITIES
1. Installation, servicing, maintenance as well as checking the sealing must be carried out by qualied
personnel.
2. The uorinated gas must be recovered during servicing and maintenance as well as the end of the
installation.
3. All the necessary measures must be taken to prevent the leakage of uorinated gases and any leaks
must be repaired as rapidly as possible.
4. Regular checks on any leaks must be performed according to the following conditions:
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 5 tonnes of CO2but less than the equivalent of 50 tonnes of CO2:
at least every twelve months or, if a leak detection system is installed, at least every twenty-
four months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 50 tonnes of CO2but less than the equivalent of 500 tonnes of CO2:
at least every six months or, if a leak detection system is installed, at least every twelve
months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 500 tonnes of CO2:
at least every three months or, if a leak detection system is installed, at least every six
months.
5. A document grouping a description of all the operations carried out on the cooling circuit must be
drafted and conserved.

English
600mm
600mm
600mm
600mm
200mm
15SYSHRW
When installing the SYSHRW, take care to leave
enough space for dismantling the lter and access
panels of the electrical box/compressor, fan,
leaving enough room for maintenance personnel to
conduct maintenance and repair operations. Leave
enough room for water, electricity and ductwork
connections.
10. INSTALLATION
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work
or constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or
damage, which could prove hazardous to personnel and property. In such an event, the warranty
shall be voided.
Caution
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
10.1. GENERALITIES
1. To avoid any damage, this equipment must not be used to supply heating or cooling during building
work.
2. Check that the voltage, the number of phases and the capacity of the unit comply with the
installation plans.
3. Check the size of the unit in relation to the plans to ensure that the unit will be installed in the right
location.
4. After having removed the packing box, take out the suspension kit that is to be found inside the fan
outlet frame.
5. Before installing the unit, check its height in relation to the available free ceiling height.
6. Take particular care over the location and routing of the water pipes and the condensate drainage
pipe as well as the electrical wiring. The location and routing of these items must be clearly indicated
on the plans.
7. It is always advisable for the heat pump installer to consult with all the various entrepreneurs
responsible for the pipe work, partitioning, ceiling and electrical installation on the site.
8. If necessary, change the direction of the airow inlet from the front to the side of the appliance, or
vice versa, prior to installing the unit in the ceiling. Refer to the instructions detailed in § MODIFYING
THE AIR BLOWING DIRECTION, page 18.
9. We advise the installer to cover the appliances with a plastic sheet to protect it during the nal
building work.
This is particularly important if work such as spraying the joists with re retardant, sanding, spray
painting and plastering has not been completed.
10.2. CLEARANCE

English
M8 THREADED ROD
(NOT SUPPLIED)
SHOCK MOUNT
WASHER
NUT
LOCKNUT
843
662
51037 50
87
32
32 32
B
A
C48 60
65 32
32 32
1 640
1 025
37 37
19
19
16 SYSHRW
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
1. The installer must ensure that access under the suspended ceiling is provided, and that sufcient
space is provided for the suspension angle brackets, the duct attachment collars and the water and
electrical connections.
2. Provide space under the unit for a siphon on the condensates drainage pipe. Do not install the unit
on top of pipe work.
3. Each unit is suspended from the ceiling on four threaded rods. The rods are attached through the
shock mounts to the corners of the unit by suspension angle brackets.
Warning! Do not use rods of a diameter smaller than that stated below. The rods must be solidly
anchored to the ceiling and to the ceiling joists.
4. Each unit is supplied with a set of pre-tted suspension angle brackets and a tting kit contained in
the pouch with the technical manual. The kit comprises 4 shock mounts, 4 washers, 4 nuts and 4
locknuts.
5. Arrange the threaded rods in accordance with the dimensions stated below. The use of nuts and
locknuts is recommended for attaching the suspension rods to the unit as the unit’s vibrations may
loosen a single nut. The installer is liable for any damage in the event of this recommendation not
being followed.
6. To facilitate drainage, the unit must be angled in both planes towards the condensates drainage pipe.
(Slope minimum: 2 %)
10.3. UNIT LOCATION
A B C
27-27HE-30-30HE-36 722 1 015 551
36HE-42-42HE-48-60-60HE-72 769 1 215 596
SYSHRW 19 SYSHRW 27 / 27HE / 30 / 30HE /36
SYSHRW 36HE / 42 / 42HE /48
SYSHRW 60 / 60HE / 72
SYSHRW 72HE

English
Internal cladding on both sides
with glass fibre sound insulation
Adapter part
Alignment elbow
Main duct
Spur with internal glass fibre
sound insulation cladding
Air distributor:
60 x 60 cm (example)
Canvas connection
Heat pump
SUPPLY AIR
OUTDOOR AIR
RETURN AIR
17SYSHRW
Water circuit heat pumps are usually installed in conjunction with an air blowing duct. A return air duct may
also be required. All ductwork shall be compliant with best air conditioning engineering practices.
The air blowing duct system normally consists of a exible connector mounted on the unit, a bridging
section to link to the size of the main duct, a short section of straight duct, an elbow without a damper and
a main duct with spurs equipped with distribution grilles as illustrated in the drawing below. The sum total
of the bridging section angles must not be higher than 30°, otherwise there will be signicant performance
losses.
Do not connect the main duct directly to the unit without a bridging section to reduce the duct size to that of
the unit’s connection collar. In the event of using metal ducts, only the sides of the elbow section and all the
spur duct sections should be covered with breglass sound insulation for reducing the noise level. Fibreglass
duct panels are more sound absorbent and may enable the exible canvas connection to be eliminated.
The duct network must be laid out to avoid any rectilinear runs betweens the heat pump outlet and the air
distribution outlets.
The return air intake ducts can be connected to a grille/lter located at the base of a wall, then directed via
hollow partitions towards a ceiling mounted plenum or via ceiling mounted grilles. The ceiling grilles must
not be located directly below the air conditioning unit.
The return air intake duct can be connected directly to the standard lter bracket. (Lateral lter removal
advisable).
Do not drill panel screws directly into the unit’s casing for connecting the blowing and return air intake ducts,
especially on the air return side, as there is a risk of damaging the condensate recovery tray and the battery.
11. DUCTING AND NOISE LEVEL REDUCTION
Recommended layout diagram for installation
with several air distribution outlets

English
3
2
1
3
2
3
23
2
1
LATERAL BLOWING (S2)
RETURN AIR INTAKE FRONTAL BLOWING (S1)
(STANDARD CONFIGURATION)
RETURN AIR INTAKE
18 SYSHRW
11.1. AIR BLOWING FRAME AND RETURN AIR INTAKE FRAME
11.2. MODIFYING THE AIR BLOWING DIRECTION
The unit SYSHRW (except SYSHRW72HE) can be supplied congured for either frontal air blowing or for
lateral air blowing. It is also possible to modify the air-blowing conguration on site. To achieve this:
1. Remove the top panel 1.2. Remove the fan motor access panel 2 and
release a small length of motor cable.
3. Remove the fan blower panel 3.
4. Fit the fan blower panel 3in the same location
as the access panel 2.
5. Ret the fan access panel 2.
6. Ret the top panel 1.
