System air SYSCW-AR 07R Manual

Water source heat pump
Installation and maintenance manual
250 â460 m3/h
1.7 â2.0kW
1.8 â2.6kW
07R / 09R
SYSCW-AR R513

INSTALLATION INSTRUCTION
NOTICE D’INSTALLATION
INSTALLATIONSHANDBUCH
ISTRUZIONI INSTALLAZIONE
INSTRUCCIONES DE INSTALACIÓN
English
Français
Español
Deutsch
Italiano

English
2SYSCW-AR R513A
CONTENTS
1. GENERAL RECOMMENDATIONS........................................................................................................................................................ 3
1.1. SAFETY DIRECTIONS .......................................................................................................................................................................................................................3
1.2. WARNING.........................................................................................................................................................................................................................................3
1.3. EQUIPMENT SAFETY DATA.............................................................................................................................................................................................................4
2. INSPECTION AND STORAGE .............................................................................................................................................................. 5
3. WARRANTY...................................................................................................................................................................................... 5
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE ............................................................................................................. 5
5. PRESENTATION................................................................................................................................................................................. 5
6. CONTENTS OF PACKAGE ................................................................................................................................................................... 6
6.1. OPTIONAL ACCESSORIES................................................................................................................................................................................................................6
7. DIMENSIONS .................................................................................................................................................................................... 6
8. HANDLING........................................................................................................................................................................................ 6
8.1. NET WEIGHT.....................................................................................................................................................................................................................................6
8.2. GENERAL HANDLING......................................................................................................................................................................................................................6
9. TECHNICAL SPECIFICATIONS ............................................................................................................................................................. 7
9.1. MODELS DESIGNATION ..................................................................................................................................................................................................................7
9.2. PHYSICAL CHARACTERISTICS ........................................................................................................................................................................................................8
9.2.1. SYSCW-AR - EC MOTOR............................................................................................................................................................................................................................................8
9.2.2. SYSCW-AR - AC MOTOR............................................................................................................................................................................................................................................9
9.3. ELECTRIC SPECIFICATIONS..............................................................................................................................................................................................................9
9.4. OPERATING LIMITS........................................................................................................................................................................................................................10
9.4.1. TEMPERATURE LIMITS ............................................................................................................................................................................................................................................ 10
9.4.2. FLOW LIMITS............................................................................................................................................................................................................................................................ 10
9.5. REFRIGERATION SPECIFICATIONS ...............................................................................................................................................................................................11
9.5.1. REFRIGERANT CIRCUIT DIAGRAM ......................................................................................................................................................................................................................... 11
9.5.2. REFRIGERANT CHARGE........................................................................................................................................................................................................................................... 11
9.5.3. FLUOROCARBON GAS REGULATIONS................................................................................................................................................................................................................... 11
10. INSTALLATION.............................................................................................................................................................................. 12
10.1. SITING THE INSTALLATION.........................................................................................................................................................................................................12
10.2. CLEARANCE .................................................................................................................................................................................................................................13
10.3. UNIT INSTALLATION....................................................................................................................................................................................................................13
10.3.1. CONNECTION POSITIONS..................................................................................................................................................................................................................................... 13
10.3.2. CABINET REMOVAL............................................................................................................................................................................................................................................... 14
10.3.3. ANCHORING TO THE GROUND ............................................................................................................................................................................................................................ 14
10.4. AERAULIC ADJUSTEMENT...........................................................................................................................................................................................................15
10.4.1. MODEL SYSCW-AR 07R - EC MOTOR ................................................................................................................................................................................................................ 15
10.4.2. MODEL SYSCW-AR 09R - EC MOTOR ................................................................................................................................................................................................................ 15
11. UNCLAMPING THE COMPRESSOR................................................................................................................................................. 15
12. HYDRAULIC LINKS........................................................................................................................................................................ 16
12.1. WATER QUALITY..........................................................................................................................................................................................................................16
12.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS ........................................................................................................................................................17
12.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM..........................................................................................................................18
13. WIRING DIAGRAM AND LEGEND.................................................................................................................................................. 19
13.1. WIRING DIAGRAM ......................................................................................................................................................................................................................19
13.1.1. POWER SUPPLY..................................................................................................................................................................................................................................................... 19
13.1.2. WIRING DIAGRAM KEY DESCRIPTIONS.............................................................................................................................................................................................................. 19
13.1.3. PRESSOSTATS SETTING ........................................................................................................................................................................................................................................ 19
14. ELECTRICAL CONNECTIONS........................................................................................................................................................... 19
14.1. UNIT POWER SUPPLY .................................................................................................................................................................................................................20
14.2. REMOTE CONTROL......................................................................................................................................................................................................................21
14.2.1. WALL MOUNTING ................................................................................................................................................................................................................................................. 21
14.2.2. ELECTRICAL CONNECTIONS................................................................................................................................................................................................................................. 21
15. REGULATION ................................................................................................................................................................................ 23
15.1. ORDER OF PRIORITY FOR CONTROL SYSTEMS.......................................................................................................................................................................23
15.2. WALL-MOUNTED CONTROL.......................................................................................................................................................................................................23
15.2.1. KEYPAD................................................................................................................................................................................................................................................................... 23
15.2.2. SCREEN................................................................................................................................................................................................................................................................... 24
15.2.3. TIME SETTINGS...................................................................................................................................................................................................................................................... 24
15.2.4. SCHEDULING.......................................................................................................................................................................................................................................................... 25
16. FINAL TASKS ................................................................................................................................................................................ 26
17. STARTING - RECOMMENDATIONS - SETTINGS .............................................................................................................................. 26
17.1. COMMISSIONING ........................................................................................................................................................................................................................27
17.1.1. DEMAND FOR COOLING....................................................................................................................................................................................................................................... 27
17.1.2. DEMAND FOR HEATING....................................................................................................................................................................................................................................... 27
17.1.3. FINAL CHECK.......................................................................................................................................................................................................................................................... 27
18. MAINTENANCE............................................................................................................................................................................. 28
18.1. MAINTENANCE PROCEDURES...................................................................................................................................................................................................28
18.1.1. GENERAL................................................................................................................................................................................................................................................................ 28
18.1.2. GENERAL INSPECTION.......................................................................................................................................................................................................................................... 28
18.1.3. REFRIGERATION CIRCUIT...................................................................................................................................................................................................................................... 28
18.1.4. ELECTRICAL SECTION............................................................................................................................................................................................................................................ 28
18.1.5. AIR FILTER .............................................................................................................................................................................................................................................................. 29
18.1.6. FAN MOTOR ASSEMBLY....................................................................................................................................................................................................................................... 29
18.2. FAULT FINDING............................................................................................................................................................................................................................30
18.2.1. NEITHER THE FAN NOR THE COMPRESSOR OPERATE ..................................................................................................................................................................................... 30
18.2.2. VENTILATION (FAN) MODE OPERATES BUT THE COMPRESSOR DOES NOT OPERATE................................................................................................................................ 30
18.2.3. INSUFFICIENT COOLING OR HEATING PRODUCTION........................................................................................................................................................................................ 30
18.2.4. INSUFFICIENT WATER FLOW AT THE LEVEL OF THE COAXIAL EXCHANGER.................................................................................................................................................. 30
18.2.5. APPEARANCE OF WATER DROPLETS IN THE APPLIANCE................................................................................................................................................................................ 30
18.2.6. APPEARANCE OF ABNORMAL NOISES AND VIBRATIONS IN THE CASING................................................................................................................................................... 31
18.3. ALARM CODES.............................................................................................................................................................................................................................31
19. WARRANTY CLAIM - MATERIAL RETURN PROCEDURE................................................................................................................. 32
20. ORDERING SERVICE AND SPARE PARTS ORDER ........................................................................................................................... 32
21. DISPOSAL..................................................................................................................................................................................... 32

English
3SYSCW-AR R513A
1. GENERAL RECOMMENDATIONS
POWER SUPPLY MUST BE
SWITCHED OFF BEFORE STARTING
WORK IN THE ELECTRIC CONTROL
BOX
The purpose of this Manual is to provide users with instructions for installing, commissioning, using and
maintaining the units. It also contains instructions on starting up the machine as well as recommendations
to avoid bodily injury and risks of damage to the device during its operation.
It does not contain the complete description of all the maintenance operations guaranteeing the unit’s long
life and reliability. Only the services of a qualied technician can guarantee the unit’s safe operation over a
long service life.
Please read the following safety precautions very carefully before installing the unit.
1.1. SAFETY DIRECTIONS
Cut off the power supply before starting work on the appliance.
When forming the hydraulic connections, ensure that no impurities are introduced into the pipe work.
The manufacturer declines any responsibility and the warranty becomes void if these instructions are not
complied with.
If you encounter a problem, please call the Technical Department for your area.
If possible, assemble the compulsory or optional accessories before placing the appliance in its nal location
(see instructions provided with each accessory).
To familiarize yourself fully with the appliance, we recommend that you also read our Technical Instructions.
The information contained in these Instructions is subject to modication without advance notice.
1.2. WARNING
Follow the safety rules in force when you are working on your appliance.
The installation, commissioning, use and maintenance of these units should be performed by qualied
personnel who have a good knowledge of standards and local regulations, as well as experience of this
type of equipment.
This appliance has not been designed for use by persons (including children) with reduced physical, sensorial
or mental faculties or by persons without any experience or knowledge of heating systems, unless they act
under the safety and supervision of a responsible person or have received prior training concerning the use
of the appliance.
The unit should be handled using lifting and handling equipment appropriate to the unit's size and weight.
Any wiring produced on site must comply with the corresponding national electrical regulations.
Make sure that the power supply and its frequency are adapted to the required electric current of operation,
taking into account specic conditions of the location and the current required for any other appliance
connected to the same circuit.
The unit must be EARTHED to avoid any risks caused by insulation defects.
Work must not be carried out on the electrical components if water or high humidity is present at the
installation site.
SAFETY SYMBOLS
ELECTRIC
VOLTAGE
ROTATING PART RISK OF
ASPHYXIA
PRESSURIZED
EQUIPMENT
RISK OF
CUTTING
RISK OF BURNS

English
4SYSCW-AR R513A
1.3. EQUIPMENT SAFETY DATA
Safety data R513A
Toxicity level Low.
In contact with the skin Dermal contact with the rapidly evaporating liquid can cause frostbite to the tissue. In the event of contact with the liquid, warm the frozen tissue with water and notify a physician. Remove
contaminated clothing and shoes. Wash clothes before reuse
In case of eye contact Steam has no effect. Splashing or splashing liquid can cause burns. Clean immediately with eye drops
or clean water for at least 15 minutes. Seek medical attention urgently.
Ingestion Burns can occur if this happens. Do not induce vomiting. When the patient is conscious, wash the
mouth with water. Seek medical attention urgently.
Inhalation If inhaled, move to fresh air and give oxygen if necessary. Perform artificial respiration if the patient is no longer breathing or is short of air. In the event of cardiac arrest, perform external CPR. Seek
immediate medical attention.
Other medical advice Cardiac sensitivity may, in the presence of circulating catecholamines such as adrenaline, lead to
increased arrhythmias and subsequent cardiac arrest if exposed to high concentrations.
Occupational exposure limits R513A: Recommended limit: 1,000 ppm - 8 hours.
Stability Room temperature stable product
Conditions to avoid Pressure build-up due to high temperatures can cause the container to explode. Protect from sunlight
and do not expose to a temperature >50°C.
Dangerous reactions Possibility of dangerous reactions in case of fire due to the presence of F and/or CI radicals
General precautions Avoid inhaling high concentrations of vapors. Atmospheric concentrations should be minimized and kept as far as possible below the occupational exposure limit. Steam is heavier than air and
concentrates at a low level and in small places. Exhaust ventilation at the lowest levels.
Respiratory protection If there is any doubt about the air concentration, breathing apparatus approved by the health services
should be used. These devices will contain oxygen or allow better breathing.
Storage The containers must be placed in a dry and cold place away from any risk of fire, direct sunlight and
away from any heat source such as radiators. Temperatures should not exceed 50°C.
Protective clothing Wear coveralls, impermeable gloves and goggles or a face shield.
Procedure in case of spillage or
a leak
Make sure that everyone wears the appropriate protective clothing and respirators. If possible isolate
the source of the leak. Encourage evaporation of small spills provided there is adequate ventilation.
Large spills: ventilate the area. Contain spill with sand, earth or other suitable absorbent material.
Prevent liquid from entering drains, sewers, basements and manholes as the vapor can create a
suffocating atmosphere.
Waste disposal Preferably to be recovered and recycled. If this is not possible, ensure that they are destroyed in an
authorized area able to absorb and neutralize acids and other toxic manufacturing products.
Fire fighting data R513A: Non-flammable at ambient temperatures and atmospheric pressures.
Containers Containers exposed to fire must be kept cold by means of water jets. Containers may burst if
overheated.
Fire protection equipment In case of fire, wear self-contained breathing apparatus and protective clothing.

English
5SYSCW-AR R513A
2. INSPECTION AND STORAGE
The appliances are delivered fully assembled, factory tested and ready to operate.
Any modication to the units without the manufacturer’s prior approval, shall automatically render the
warranty null and void.
The following conditions must be respected in order to maintain the validity of the warranty:
²Commissioning shall be performed by specialised technicians from technical services approved by
the manufacturer.
²Maintenance shall be performed by technicians trained for this purpose.
²Only Original Equipment spare parts shall be used.
²All the operations listed in the present manual shall be performed within the required time limits.
3. WARRANTY
At the time of receiving the equipment carefully cross check all the elements against the shipping documents
in order to ensure that all the crates and boxes have been received. Inspect all the units for any visible or
hidden damage.
In the event of shipping damage, write precise details of the damage on the shipper’s delivery note and
send immediately a registered letter to the shipper within 48 hours, clearly stating the damage caused.
Forward a copy of this letter to the manufacturer or his representative.
Never store or transport the unit upside down. It must be stored indoors, completely protected from
rain, snow etc. The unit must not be damaged by changes in the weather (high and low temperatures).
Excessively high temperatures (above 60 °C) can harm certain plastic materials and cause permanent
damage. Moreover, the performance of certain electrical or electronic components can be impaired.
THE WARRANTY SHALL BE NULL AND VOID IN THE EVENT
OF NON-COMPLIANCE WITH ANY OF THE ABOVE CONDITIONS.
4. TECHNICAL SUPPORT AND AFTER-SALES SERVICE HOTLINE
For technical questions, work under warranty, commissioning, a manufacturer’s visit or repair quotations.
Our technical support and after-sales service hotline can be reached on:
²(0)891 700 407 in France
²[e-mail] for export customers
5. PRESENTATION
Following assembly of the units in the factory:
1. the electrical circuits are tested.
2. refrigeration circuits receive their operational refrigerant charge and are subject to pressurized leak
detection tests.
3. The SYSCW-AR units are tested.
These tests are conducted to guarantee the correct operation and quality of our products.
The SYSCW-AR units are produced in compliance with state-of-the-art design and manufacturing standards.
This guarantees their high performance and reliability as well as their compatibility with all types of air
conditioning installations. The unit, designed for an indoor mounted application, is not suitable for any uses
other than those specied in this manual.

English
6SYSCW-AR R513A
SEE APPENDIX
6. CONTENTS OF PACKAGE
6.1. OPTIONAL ACCESSORIES
7. DIMENSIONS
8. HANDLING
8.1. NET WEIGHT
²Take care to avoid any rough handling or impacts when unloading and moving the appliance.
²Before hoisting the appliance into position, perform a test lift to ensure stability and balance. Avoid
twisting or uneven lifting of the units.
²The units shall be carefully inspected before unit installation to make sure this has not happened.
²All of these sections are inspected before they leave the factory. Prior to commissioning, it is
therefore important to make sure that no bolts, screws or other fastening components are loosened
or missing.
To avoid irreversible damage, do not tilt the SYSCW-AR by more than 45° during handling.
Caution
Never subject the metal work (panels, posts) of the SYSCW-AR to handling constraints, as only its
base is designed for that purpose.
Caution
8.2. GENERAL HANDLING
On opening the box, check that all of the accessories required for installation are present.
A pallet truck or a forklift truck can be used to handle the SYSCW-AR units when palletized.
Package contents:
1 appliance
1 installation manual
MODELS 07R 09R
STANDARD LOW HEIGT STANDARD LOW HEIGT
WEIGTH WITH CASING kg 70 73
WITHOUT CASING kg 55 58
1 Remote control

English
7SYSCW-AR R513A
9. TECHNICAL SPECIFICATIONS
9.1. MODELS DESIGNATION
The product plate on the device shows the full model reference number and should be used to check that
the actual unit matches the model ordered. It also provides the following information:
²General information
serial number
year of manufacture
IP index
²Electrical information
supply voltage
maximum operating current
starting current
²Thermodynamic circuit information
type of refrigerant
refrigerant charge in each circuit
Service pressure of refrigeration circuit
refrigeration circuit service
temperatures
²Hydraulic circuit information
nominal water ow
maximum water pressure
REP. Description
1
Size
CW-AR07R: SYSCW-AR R513A size 07 CW-AR09R: SYSCW-AR R513A size 09
2
Version H: Heat pump
3
Cabinet VN : STD no cabinet
VC : Std cabinet
VNL : Low No Cabinet
VCL : Low cabinet with RF
4
Hydraulic HB : Hydraulic connection bottom
HBK : Hydraulic connection back
HR : Hydraulic connection right side
HL : Hydraulic connection left side
5
Electrical ER : Electrical connection right side EL : Electrical connection left side
6
Acoustic LN : Standard Low Noise XLN : Extra low noise
7
Brand SYS : Systemair
8
Fan type AC : Ventilateur moteur AC EC : Ventilateur moteur EC
9
Air lter BA : G2 lter - bottom - dessous (xed
feet) FA : G2 lter - front (adjustable feet)
10
Communication
protocol
MBRT : Modbus RTU
BNMS : Bacnet MSTP LON : LON
11
Protection Blank : Porte fusible CB : Circuit breaker
12
Remote
control
Blank : Without remote thermostat
RCSM : POL822 Siemens mounted RCS : POL822 Siemens (wall mounting)
13
Cabinet
option Blank : Without grille FTG : grille for cabinet (between feet - Filter BA)
CW-AR07R . H . VN . HB . ER . LN . SYS . EC . BA . MBRT . CB . RCSM . FTG
1
2
3
4
5
6
7
8
9
10
11
12
13

English
8SYSCW-AR R513A
9.2. PHYSICAL CHARACTERISTICS
9.2.1. SYSCW-AR - EC MOTOR
(1) Nominal cooling capacities based on : entering air temperature of 27 °C dry bulb, 19 °C wet bulb
with entering water temperature of 30 °C.
(2) Nominal heating capacities based on : entering air temperature of 20 °C dry bulb, 15 °C wet bulb
with entering water temperature of 20 °C.
(3) Absorbed power (compressor + fan) at nominal conditions.
(4) Nominal currents are given at +/- 5%.
(5) Starting currents are given at +/- 10%.
(6) Informative data, considering an hypothetical sound attenuation of the room and installation of 9dB.
Models 07R 09R
PV MV GV PV MV GV
Total cooling capacities (1) W 1618 1690 1700 2001 2040 2051
Sensible cooling capacities (1) W 1208 1410 1660 1440 1600 1833
Total absorbed power (3) W 326 345 362 463 480 502
EER according to EN14511 4.96 4.9 4.7 4.32 4.25 4.09
Total Heating capacities (2) W 1801 1790 1793 2638 2630 2632
Total absorbed power (3) W 436 395 385 640 610 597
COP according to EN14511 4.13 4.53 4.66 4.12 4.31 4.41
VENTILATION
Setpoint voltage V3.53 5.13 5.99 5.13 5.99 7.28
Air ow m3/h 250 340 400 340 400 460
Fan absorbed power W 10 15 20 15 20 28
Air lter - Number / Efciency 1/G2
Air lter (FA) - Dimensions / Thickness mm 660 x 205 / 6
Air lter (BA) - Dimensions / Thickness mm 595 x 187 / 6
HYDRAULIC CIRCUIT
Water exchanger Nbr 1
Water pressure max. bar 10
Cooling
mode
Nominal water ow l/h 336 351 355 425 434 439
Water pressure drop at nominal ow kPa 3.42 3.75 3.84 5.6 5.84 5.97
Minimum water ow l/h 168 180 180 213 217 220
Heating
mode
Nominal water ow l/h 395 405 410 578 586 593
Water pressure drop at nominal ow kPa 4.8 5.06 5.2 10.5 10.8 11.1
Minimum water ow l/h 198 203 205 289 293 297
Water connections Input/output pouces ISO G 1/2'' INT
Condensate outlet Ø mm 15 x 20
REFRIGERANT CIRCUIT
Number of circuit Nbr 1
Refrigerant R513A
Compressor type Rotary
Load g 500 490
ELECTRICAL DATA
Electrical power supply 230V / 1Ph / 50Hz ±10%
Max. current (4) A 4.6 5.7
starting current (5) A 16 16.5
ACOUSTICAL DATA
Sound power level (6) dB(A) 47.2 49.8 51.5 49.8 51.5 54.3
Sound pressure level (6) dB(A) 38.2 40.8 42.5 40.8 42.5 45.3
NR (6) dB(A) 32 34 36 34 36 40

English
9SYSCW-AR R513A
A variance of ±10% is acceptable in relation to the operating voltage marked on the appliance’s Maker’s
Plate.
Operating voltages:
²230V / 1 ph / 50 Hz ±10%
Comments: the stated voltages represent the accepted range. However, certain components may be subject
to premature wear on appliances operating continuously, for extensive periods, on abnormally low or high
voltages.
MODEL Fuse aM Full load current (max) Starting amperage
07R A 6 4.6 16
09R A6 5.7 16.5
9.2.2. SYSCW-AR - AC MOTOR
9.3. ELECTRIC SPECIFICATIONS
Models 07R 09R
PV MV GV PV MV GV
Total cooling capacities (1) W 1618 1690 1700 2001 2040 2051
Sensible cooling capacities (1) W 1208 1410 1660 1440 1600 1833
Total absorbed power (3) W 329 355 396 462 487 532
EER according to EN14511 4.92 4.75 4.29 4.33 4.19 3.86
Total Heating capacities (2) W 1801 1790 1793 2 638 2 630 2 632
Total absorbed power (3) W 439 405 419 639 617 627
COP according to EN14511 4.11 4.41 4.28 4.13 4.26 4.20
VENTILATION
Air ow m3/h 250 340 400 340 400 460
Fan absorbed power W 12 25 54 14 27 58
Air lter - Number / Efciency 1/G2
Air lter (FA) - Dimensions / Thickness mm 660 x 205 / 6
Air lter (BA) - Dimensions / Thickness mm 595 x 187 / 6
HYDRAULIC CIRCUIT
Water exchanger Nbr 1
Water pressure max. bar 10
Cooling
mode
Nominal water ow l/h 336 351 355 425 434 439
Water pressure drop at nominal ow kPa 3.42 3.75 3.84 5.6 5.84 5.97
Minimum water ow l/h 168 180 180 213 217 220
Heating
mode
Nominal water ow l/h 395 405 410 578 586 593
Water pressure drop at nominal ow kPa 4.8 5.06 5.2 10.5 10.8 11.1
Minimum water ow l/h 198 203 205 289 293 297
Water connections Input/output pouces ISO G 1/2'' INT
Condensate outlet Ø mm 15 x 20
REFRIGERANT CIRCUIT
Number of circuit Nbr 1
Refrigerant R513A
Compressor type Rotary
Load g 500 490
ELECTRICAL DATA
Electrical power supply 230V / 1Ph / 50Hz ±10%
Max. current (4) A 4.6 5.7
starting current (5) A 16 16.5
ACOUSTICAL DATA
Sound power level (6) dB(A) 47.2 49.7 52 49.7 52 54.4
Sound pressure level (6) dB(A) 38.2 40.7 43 40.7 43 45.4
NR (6) dB(A) 32 34 37 34 37 40
(1) Nominal cooling capacities based on : entering air temperature of 27 °C dry bulb, 19 °C wet bulb
with entering water temperature of 30 °C.
(2) Nominal heating capacities based on : entering air temperature of 20 °C dry bulb, 15 °C wet bulb
with entering water temperature of 20 °C.
(3) Absorbed power (compressor + fan) at nominal conditions.
(4) Nominal currents are given at +/- 5%.
(5) Starting currents are given at +/- 10%.
(6) Informative data, considering an hypothetical sound attenuation of the room and installation of 9dB.

English
15
20
25
30
35
40
45
50
23
20 21 22 23 24 25 26 27 28 29 30 31 32
33
Air inlet temperature (°C db)
Water inlet temperature (°C)
10
15
20
25
30
35
40
45
50
32
14 15 16 17 18 19 20 21 22 23 24 25 26
27
Air inlet temperature (°C)
Water inlet temperature (°C)
14 16 18 20 22 24 26 28 30 32 34 36 38 40 42 44 46 48 50
52
8 10 12
40
50
60
70
80
90
100
110
Water inlet temperature (°C)
Max nominal water flow (%)
10 SYSCW-AR R513A
9.4. OPERATING LIMITS
9.4.1. TEMPERATURE LIMITS
9.4.2. FLOW LIMITS
Operation within the shaded ranges requires special attention to the minimum water ow rate.
Caution
Conditions in
accordance with the
standard: EN 14511-2
* Conditions in accordance with the standard: EN 14511-2
MODELS 07R 09R
PV - Minimum air ow m3/h 250 340
MV - Nominal air ow * m3/h 340 400
GV - Maximum air ow m3/h 400 460
MODELS
07R 09R
Nominal water ow l/h 351 405 434 586
50% Nominal water ow l/h 180* 203 217 293
Maximum hydraulic pressure bar 10 10
* Cutoff water ow: 180l/h

English
11SYSCW-AR R513A
9.5. REFRIGERATION SPECIFICATIONS
9.5.1. REFRIGERANT CIRCUIT DIAGRAM
SEE APPENDIX
9.5.2. REFRIGERANT CHARGE
The type and quantity of refrigerating uid per circuit are indicated on the product plate.
The installer and end user will get informed on local environmental regulations for the installation, operation
and disposal of the equipment ; more particularly, for the collection of substances hazardous for the
environment (refrigerating uid, oil, antifreeze, etc.). A refrigerating uid, whatever it is, must not be vented.
Refrigerating uids must be handled by skilled personnel.
9.5.3. FLUOROCARBON GAS REGULATIONS
The EC No. 517/2014 regulation covering uorinated greenhouse gases requires of refrigeration equipment
operators to comply with the following ve obligations:
Greenhouse gas quantity (kg of CO2) = Quantity of gas (kg) x gas' GWP
Quantity of greenhouse gas expressed in weight
(kg) and CO2 equivalent
Quantity of gas: amount of gas contained in the
machine in kg (see ID plate)
GWP (GlobalWarming Potential) of the gas contained
in the machine (see ID plate)
²GWP for the R513A = 631
9.5.3.1. CALCULATING GREENHOUSE GAS QUANTITIES
1. Installation, servicing, maintenance as well as checking the sealing must be carried out by qualied
personnel.
2. The uorinated gas must be recovered during servicing and maintenance as well as the end of the
installation.
3. All the necessary measures must be taken to prevent the leakage of uorinated gases and any leaks
must be repaired as rapidly as possible.
4. Regular checks on any leaks must be performed according to the following conditions:
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 5 tonnes of CO2but less than the equivalent of 50 tonnes of CO2:
at least every twelve months or, if a leak detection system is installed, at least every twenty-
four months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 50 tonnes of CO2but less than the equivalent of 500 tonnes of CO2:
at least every six months or, if a leak detection system is installed, at least every twelve
months
for equipment containing uorinated greenhouse gases in quantities greater than or equal to
the equivalent of 500 tonnes of CO2:
at least every three months or, if a leak detection system is installed, at least every six
months.
5. A document grouping a description of all the operations carried out on the cooling circuit must be
drafted and conserved.
This equipment contains uorinated gas with greenhouse gas effects covered by the Kyoto
agreement.
Caution
SYSCW-AR units use the R513A uoro-carbonated uid, belonging to group 2 as dened in directive
2014/68/UE. Considering the maximum operating pressure of these units (18 bar g), they integrate
category 2 (or lower) components as dened in directive 2014/68/UE.
Caution
Non-compliance with one of these obligations constitutes an offense and can result in nancial
penalties.
Furthermore, compliance of the equipment with the uorinated gases regulation must be proven to
the insurance company.
Caution

English
12 SYSCW-AR R513A
10. INSTALLATION
10.1. SITING THE INSTALLATION
The unit is not designed to withstand weights or stresses from adjacent equipment, pipe work
or constructions. Any foreign weight or stress on the unit structure could lead to a malfunction or
damage, which could prove hazardous to personnel and property. In such an event, the warranty
shall be voided.
Caution
The unit base shall be arranged as indicated in the manual. There could be a risk of personal injury
or damage to property in the event of the unit being incorrectly supported.
Caution
This equipment is designed EXCLUSIVELY for INDOOR installation.
In general, sheltered locations such as garages, roof space, etc, do not provide sufcient protection against
extreme temperatures and/or humidity and may be harmful to the unit’s performance, reliability and service
life.
1. To avoid any damage, this equipment must not be used to supply heating or cooling during building
work.
2. Check that the voltage, the number of phases and the capacity of the unit comply with the
installation plans.
3. Check the size of the unit in relation to the plans to ensure that the unit will be installed in the right
location.
4. Take particular care over the location and routing of the water pipes and the condensate drainage
pipe as well as the electrical wiring. The location and routing of these items must be clearly indicated
on the plans.
5. It is always advisable for the heat pump installer to consult with all the various entrepreneurs
responsible for the pipe work and electrical installation on the site.
6. We advise the installer to cover the appliances with a plastic sheet to protect it during the nal
building work.
This is particularly important if work such as spraying the joists with re retardant, sanding, spray
painting and plastering has not been completed.
The unit must be installed on a rm level foundation, of adequate strength to support its full operating
weight.
1. Install the unit in a location allowing easy removal of the lter and the access panels to the
electrical box/compressor and fan by leaving sufcient free space for servicing personnel to
perform maintenance and repairs. Leave sufcient space for the water and electricity connections.
2. The unit must be pitched slightly towards condensate drain outlet to provide positive drainage of
condensates.
3. We recommend the installation of a siphon on the condensate outow to avoid unpleasant odours
travelling back up the pipe.
4. All electrical and ductwork connections to the unit must be made via exible connections to prevent
transmission of vibration.
5. In addition to the service clearances noted on the dimension sheet it is essential that provision is
made for adequate and safe service access.
The units are designed to be installed in a controlled environment. Each unit should be located on the
installation plans. Inspect the carton for specic tagging numbers and references (models, size, left hand
or right hand). The supply, return and condensation piping should be located accordingly making sure the
piping will t into the connes of the fan coil chassis and cabinet.

English
70mm
70mm
70mm
70mm
Water outlet
Water inlet Condensates outlet
Water outlet
Water inlet Condensates outlet
Water outlet
Water inlet
Condensates outlet
Water outletWater inlet
Condensates outlet
13SYSCW-AR R513A
10.2. CLEARANCE
10.3. UNIT INSTALLATION
10.3.1. CONNECTION POSITIONS
Factory-congured water connections are available in 4 different positions:
²right side ²left side
²rear panel ²underneath (option not available when the air
lter is tted underneath the appliance)

English
2
1
14 SYSCW-AR R513A
Models with a frontal air intake are equipped with four
height-adjustable feet to facilitate levelling the appliance.
We recommend that the appliances are installed at a
slight angle to favour condensate run-off.
We recommend the use of an angle bracket to attach the appliance to the wall.
When removing cabinet do not pull or lift it up by the discharge grilles, to avoid any damages on
articulated fasteners of the access doors.
Caution
10.3.2. CABINET REMOVAL
No tools are required to remove the casing. You just have to lift it
up slightly to release the olive-shaped attachment studs from the
buttonholes. Then pull the casing towards the front.
10.3.3. ANCHORING TO THE GROUND
SEE APPENDIX

English
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m
3
/h)
Available pressure (Pa)
HSMSLS
0 100 200 300 400 500 600 700
800
0
20
40
60
80
100
120
140
2V
3V
4V
5V
6V
7V
8V
9V
10V
Air flow (m3/h)
Available pressure (Pa)
HSMSLS
15SYSCW-AR R513A
10.4. AERAULIC ADJUSTEMENT
10.4.1. MODEL SYSCW-AR 07R - EC MOTOR
10.4.2. MODEL SYSCW-AR 09R - EC MOTOR
Before the rst start-up
the compressor transport
clamping be removed.
Failure to do this could
result in vibrations, high
noise and could lead to
the refrigerant tubes
breaking.
Caution
11. UNCLAMPING THE COMPRESSOR
Unclamping the compressor
requires removing the body. It is
done by removing the clamping
tab accessible from the front of
the SYSCW-AR unit.

English
16 SYSCW-AR R513A
Correct water treatment is critical, and particular care must be taken to ensure that the type of
treatment utilized is appropriate.
The recommendations of a company specializing in such matters must be sought and applied.
The manufacturer or their representative cannot be held liable in the event of the use of water
that is untreated or of nonconforming quality.
Caution
If the water circuit is to be drained for a time exceeding one month, the circuit must be fully
charged with nitrogen to prevent any risk of corrosion by differential venting.
Caution
THE WARRANTY DOES NOT COVER DAMAGE DUE TO CORROSION RESULTING FROM ELECTROLYTIC
PHENOMENA.
Caution
The SYSCW-AR must not run on a network with open loops, likely to cause incidents related to
oxygenation, or with non treated table water.
Caution
12. HYDRAULIC LINKS
12.1. WATER QUALITY
The water must be analyzed; the hydraulic network system installed must include all elements necessary
for water treatment: lters, additives, intermediate exchangers, drain valves, vents, check valves, etc.,
according to the results of the analysis.
Using improperly treated or non treated water in the SYSCW-AR may cause scaling, erosion, corrosion or
algae or sludge deposits in the exchangers. Refer to a specialist skilled in water treatment to determine
any treatment to apply. The manufacturer will not be held liable for damages caused when non treated or
improperly treated water, demineralized water, salty water or sea water are used.
Apply the following guidelines :
²No NH4+ammonium ions in the water, highly detrimental to copper. <10mg/l
²Cl- chloride ions are detrimental to copper with a risk of puncture by picking corrosion. <10mg/l.
²SO42- sulphate ions may cause perforating corrosion. < 30mg/l.
²No uoride ions (<0.1 mg/l)
²No Fe2+ and Fe3+ ions, particularly in case of dissolved oxygen. Fe< 5mg/l with dissolved oxygen <
5mg/l. The presence of these ions with dissolved oxygen indicates corrosion of steel parts, likely
to generate corrosion of copper parts under Fe deposits, particularly in the case of multitubular
exchangers.
²Dissolved silica: silica is an acid element of water and may also cause corrosion. Content < 1mg/l.
²Water hardness: Values between 10°fH and 30°fH may be recommended. This facilitates scaling
deposits likely to limit copper corrosion. Excess TH values may lead to clogging the pipes.
²TAC<100
²Dissolved oxygen: Prevent any sudden change in the water's oxygenation conditions. Also, avoid
deoxygenating water by sparging inert gas as well as overoxygenating it by pure oxygen sparging.
Disturbing oxygenation conditions destabilizes copper hydroxides and particle salting-out.
²Electrical Resistivity - Conductivity: The higher the resistivity, the slower the corrosion. Values above
3000 ohm/cm are preferred. A neutral environment favours maximum resistivity. For electrical
conductivity, values around 200-600 S/cm can be recommended.
²pH: neutral pH at 20°C (7 < pH < 9)

English
Main return pipe work
Main water supply pipe work
Spherical
dome valve
Hoses
17SYSCW-AR R513A
12.2. RECOMMENDATIONS FOR HYDRAULIC CONNECTIONS
1. It is recommended that all units are connected to a water supply and return pipe system of
the Tickelman Loop type. The Tickelman Loop system is self-balancing and thus only requires
manual balancing if a large number of units with different ow and pressure loss characteristics
are connected to a single hydraulic loop. A very simple way of checking the hydraulic balance
is to measure the temperature difference between the water connections. To ensure a correct
water ow, the difference must be in the region of 3 to 7 °C in Cooling mode and 2 to 5°C in
Heating mode.
A system with two parallel pipes can also operate in a perfectly adequate manner, but it is more
difcult to achieve, and to maintain, balance.
2. Never connect a unit to the water supply and return lines without completely cleaning
and flushing out the hydraulic loop beforehand. After performing these operations, the
units must be connected, with all valves completely open, ready for the system to be lled with
water.
3. Water exchanger clogging reduces efcient appliance operation. We recommend the installation
of a strainer lter (Ø 0.8mm) on the appliance's water inlet pipe. The lter must be installed if
the water circuit cannot be cleaned. This lter should be installed between two cut-off valves
and it must remain easily accessible for the user so that it can be checked at regular intervals.
4. Steel, copper or P.V.C. pressure pipes may be used.
5. It is advisable to make the unit’s water supply and return conveyance lines with short lengths
of high-pressure hose, as they form excellent shock absorbers for unit operating noise and
hydraulic pressure surges.
One of the hose ends must be tted with a rotating connector to facilitate removal for
maintenance. Rigid pipes can be connected directly to the unit, but this is not recommended
due to their inability to absorb vibrations and noise.
Rigid pipes must be equipped with removable connectors to facilitate future removal of the unit
from its location.
6. Certain exible hose threaded connectors are supplied with sealing paste. If this is not the case,
use Teon tape to create a tight seal.
7. Each unit must be equipped with isolation valves on the water inlet and outlet pipes. The return
isolation valve is used for both cutting off the water supply and balancing the installation’s
water ow. As it is used to establish the balance of the ows, it must be equipped with a
lockable position end stop. This end stop ensures that, after the valve is closed, it can only be
re-opened as far as the position required to maintain a balanced water ow.

English
INTERCONNECTED CONVEYANCES
Rubber hose
Main return pipe work
Main water supply pipe work
Spherical
dome valve
18 SYSCW-AR R513A
8. Use steel, copper or P.V.C. pipes for the condensates drainage pipe. Each unit is supplied with a
connector for condensates drainage.
9. No point of the condensates drainage pipe work should be located above the level of one of
the units’ condensate drainage outlet connection.
10. The circuits’ high points must be bled of air.
11. Comply with current regulations in terms of dielectric isolation of the connectors and the pipe
work.
1. Before commissioning an appliance for the rst time, the water loop must be cleaned and rinsed out
to remove any dirt and manufacturing debris.
If the appliances are equipped with isolation valves (either electric or pressostatic), the water
supply and return conveyance circuits to and from each machine must be connected to each other.
This will avoid any dirt being introduced into the units.
Flushing water through the units is acceptable if they are not
equipped with water ow control devices.
2. The system must be lled from the mains water supply. All air
bleeds must be open during lling. Close the air bleeds once
the system is lled.
The installer must start the main circulation pump with the
water top-up tap on the pressure reduction valve in the open
position. Check the air bleeds by increasing order of height to
ensure water ows freely throughout the entire system.
Power supply to the cooling tower must be shut down, and the
water loop temperature regulation thermostat must be set at
27 °C.
As the water circulates through the system, the installer must
seek out and repair any possible pipe work leaks. The drain
cocks, on the lowest points on the circuit, must be open for
ushing out and chasing out any impurities. Ensure that the
mains water valves are adjusted to allow water to enter at the
same speed as it exits. Check the pump inlet pressure gauge
and manually adjust the compensating valve to maintain the
same pressure before and after the opening of the drain taps. Flushing must be performed for at
least two hours, or longer if necessary, until clear and clean water is obtained at the drain taps.
3. Stop the additional heating and the water circulation pump. Open all the bleed points and the drain
taps to empty the system completely. The short-circuited water supplies and returns must now be
connected to the units’ inlet and outlet connections. It is recommended to use Teon tape on the
pipe connector threads. Do not use sealing paste on the hoses’ rotating connecters.
4. Formerly, sodium tri-phosphate used to be recommended as a cleaning agent for ushing.
However, nowadays numerous countries forbid the introduction of phosphates into their wastewater
networks. Therefore, it is now recommended that the system is ushed out with hot water (30 °C).
5. Fill the system again with clean water. Test the water acidity level (litmus paper), and treat as
required to obtain a slightly alkaline water quality.
At this stage, the recommended percentage of anti-freeze can be added. Use commercial quality
anti-freeze specically intended for air conditioning systems. Do not use automobile radiator anti-
freeze.
6. On the main electrical cabinet, adjust the heater set temperature point at 20 °C and the cooling
tower set temperature at 30 °C. Connect the power supply to all motors and start the circulation
pumps.
When the normal ow level has been reached through all components, including the cooler (irrespective
of the season) and when the air is bled form the system and the loop temperature has stabilised, each
appliance is ready to be checked, tested and started for balancing the air and water ows.
12.3. RECOMMENDATIONS FOR CLEANING AND FLUSHING OUT THE SYSTEM
