System Build 7920403COM User manual

7920403COM
16" cabinet
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B347920403COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 1 HOUR

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
37360015011
Right Panel
37360015021
Top
37360015030
Bottom
37920015040
Shelf
37360015050
Adjustable Shelf (3)
37360015060
Door
37920403070
Back Panel
K73601500
This piece is paperboard construction.
It is not made from wood but is
required for the assembly of your unit.
H
G
F
E
D
C
B
A

5
systembuild.com
Board Identification
Not actual size
Tube
You
A
B
C
E
D
F
G
H
F
F
This piece is paperboard construction. It
is not made from wood but is required
for the assembly of your unit.

6
systembuild.com
Part List
Actual Size
Tube
You
Not Actual Size
(x8)
#A22620
cam lock
123
6
45
7
(x8)
#A22610
cam bolt
(x8)
#A12420
5/8" screw
(x4)
#A12930
1-1/8" screw
(x2)
#A17400
7/8" bolt
(x4)
#A13410
1-3/4" screw
(x33)
#A21110
nail
(x12)
#A80250
shelf support
(x2)
#A89210
door pad
(x1)
#A50395
handle
(x4)
#A44135
adjustable foot
89
(x1)
#A84050
safety bracket kit
10 11
13
12
12a
(x3)
#A65700
hinge
12b
12c
12d

7
systembuild.com
STEP1
Tube
You
NOTE: The hinges can be mounted on either the left panel or right panel, depending on which
way you want the door to open (right or left).
Shown is for the hinges to be mounted on the left panel.
Separate hinges by depressing end of hinge and removing the hinge plate
from the hinge arm.
2
(x4)
#A22610
13
(x3)
#A65700
press to release
hinge plate.
2
hinge plate
placa de la bisagra
plaque de charnière
hinge arm
brazo de la bisagra
bras de la charnière
A
2
2
2

8
systembuild.com
STEP2
Tube
You
2
(x4)
#A22610
B
2
2
2
2

9
systembuild.com
STEP3
Tube
You
1
(x8)
#A22620
Proper orientation of CAM LOCK
Tip
Assembly
Quick
E
C
1
1
1
1
1
1
12b
12a 12b
12a
(x1)
#A84050
Do not fully tighten
this screw in this
step.

10
systembuild.com
STEP4
Tube
You
EA
B
C
UNLOCKLOCK
finished edge
finished edge

11
systembuild.com
STEP5
Tube
You
3411
(x8)
#A12420
(x4)
#A12930
(x4)
#A44135
D
Unscrew the two piece foot as shown. After top part of foot is
attached to bottom shelf, screw on bottom part of foot. Be sure all
four feet are level with each other.
4
33
11

12
systembuild.com
STEP6
Tube
You
A
B
D
6
6
finished edge
6
6
6
(x4)
#A13410

13
systembuild.com
STEP7
Tube
You
(x33)
#A21110
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
* raw edges are shaded
Attached the back panel as shown nailing straight into
the raw edges.
Assure that the unit is square.
Distance from corner to corner must be equal as shown.
7
product collapse, and/or serious injury.
Por favor asegúrese que las Parte de atrás se atan
firmemente. Todos los clavos deben manejarse en las
partes recto y deben apretarse firmemente. El fracaso para
hacer para que podría causar inestabilidad, derrumbamiento
del producto, y/o la lesión seria.
S’il-vous-plaît assurez-vous que les PANNEAUX
ARRIÈRES sont attachés solidement. Tous les clous
doivent être enfoncés perpendiculairement et solidement
dans les parties. Sinon le meuble peut devenir instable,
s’effondrer subitement et/ou causer des blessures graves.
tightened firmly. Failure to do so could cause instability,
All nails must be driven into the parts straight and
Please make sure that the Backs are attached securely.
ADVERTENCIA
AVERTISSEMENT
WARNING
7
raw surface
Flush the edge of the back panel with the bottom edge of
the bottom shelf. Align squarely and nail straight through
into back edges.
Assure that the unit is square.
Distance from corner to corner
must be equal as shown.

14
systembuild.com
STEP8
Tube
You
8
12c
12d
(x12)
#A80250
(x1)
#A84050
8
8
8
F
F
F
8
stud
montante
planche
wallboard
muro
mur
hole
agujero
trou
12c
Option 1;
Securely screw (12C) into solid area of the
wall as shown.
Option 2:
Drill a 3/16" diameter hole (5mm) in the
wallboard. Tap the wall anchor(12d) into the
hole until it is flush. Fasten the wall bracket
(12a) to the wall anchor (12d) with the screw
(12c).
Now fully tighten screw (12b) from step 3.
12d
#1
#2

15
systembuild.com
STEP9
Tube
You
13
(x3)
#A65700
G
13

16
systembuild.com
STEP10
Tube
You
510
(x1)
#A50395
(x2)
#A17400
5
10
A
G
hook
gancho
crochet

17
systembuild.com
STEP11
Tube
You
To adjust the doors, remove the cover on the back of the hinge arm to expose the two adjusting
screws.
To adjust the doors up and down, loosen the hinge plate screws. Move the door the direction
needed and retighten the screws on the hinge plates.
To adjust the doors sideways, turn the large adjustment screw on the hinge arm clockwise or
counter clockwise, depending on the sideway direction needed. The small adjustment screw needs
to be loosend or tightened in conjunction with the larger screw.
Loosen screw C
Adjust door.
Tighten screw C
*side view
Suelte el tornillo C
Acomode la puerta.
Ajuste el tornillo C
*la vista lateral
Défaites le vis C
Ajustez la porte.
Serrez le vis C
*le côté envisagent
Loosen screw C
Turn screw B to
move door.
Tighten screw C
Suelte el tornillo C
Dé vuelta el tornillo B
para mover la puerta.
Ajuste el tornillo C
Défaites le vis C
Le vis du tour B
déplacer la porte.
Serrez le vis C
Loosen screw A
Adjust door.
Tighten screw A
Suelte el tornillo A
Acomode la puerta.
Ajuste el tornillo A
Défaites le vis A
Ajustez la porte.
Serrez le vis A
A
C
B
A

18
systembuild.com
Tube
You
Maximum Loads
Warning: Risk of injury to persons - do not place a television on this furniture. This furniture is
not approved for use with a television.
Certificate of Conformity
1. This certificate applies to the Dorel Home Furnishings, Inc. product identified by this instruction manual.
2. This certificate applies to compliance of this product with the CPSC Ban on Lead-Containing Paint (16 CFR 1303).
3. This product is distributed by: Dorel Home Furnishings, Inc.
410 East First Street South
Wright City, MO 63390
636-745-3351
4. Site of Manufacture: Tiffin OH
5. See front page of instruction manual for date of manufacture.
This unit has been designed to support the maximum loads shown. Exceeding these load limits
could cause sagging, instability, product collapse, and/or serious injury.
0 lbs.
0 kg.
40 lbs.
18.1 kg.
35 lbs.
15.8 kg.
50 lbs.
22.7 kg.
9
(x2)
#A89210
9

19
systembuild.com
Register your product to receive the following:
* New trend details - sneak peek on what's new
* Surveys - have a voice within our community
* Exclusive deals and discount codes
* Quick and easy replacement part service
To register your product, visit systembuild.com
Visit your local retailer's website, rate your purchased
product and leave us some feedback!
We would like to extend a big "Thank You" to all of
our customers for taking the time to assemble this
Systembuild product, and to give us your valuable
feedback.
Tube
You

20
systembuild.com
Tube
You
Cubierta Delantera
Este libro de instrucciones contiene información IMPORTANTE de seguridad. Por favor lea y manténgalo
para referencia en el futuro.
No Regrese este producto! Comuniquese con nuestro amistoso equipo de servicio al cliente para obtener
ayuda.
Llamenos al: 1-866-452-4081 (Gratis) Lunes - Viernes 9am - 5pm CST
Visitar: www.systembuild.com
PRECAUCION
Este mueble puede volcarse y causar graves heridas y/o muerte.
Anclar el mueble a un poste de madera en la pared (si esto se requiere).
No Permita que los niños monten el mueble.
Mantenga los artículos más pesados en los cajones de abajo.
Consejos Útiles (página 2)
- Abra su artículo en el área donde usted planea utilizarlo para evitar levantar y moverlo menos
- Identificar, ordenar y contar las piezas antes de intentar ensamblar
- Las clavijas de compresión se golpean con un martillo
- Las diapositivas están marcadas con una R (derecha) y L (izquierda) para la colocación correcta
- Asegúrese de que siempre este el punto locaizado en la parte superior de bloqueador de leva
este volteadohacia borde exterior
- Utilizar todos los clavos para el panel de atras y distribuirlos por igual
- El panel de atras debe utilizarse para asegurarse de que la unidad quede fija y firme
- No use quimicas fuertes ni limpiadores abrasivos en este articulo
- Nunca empuje, tire ni arrastre los muebles
Antes de Que Empieces (página 3)
-Lea cuidadosamente cada paso y siga el orden correcto
-Separar y contar todas sus piezas y hardware
-Dése suficiente espacio para el proceso de ensamble
-Tenga las siguientes herramientas: destornillador de cabeza plana, #2 cabeza Phillips
Destornillador y martillo
-Precaución: Si usa un taladro electrónico o un destornillador eléctrico para atornillar, por favor asegúrese
que deje de atornillar cuando el tonillos este apretado. Fallar hacer esto puede causar barrer el tornillo.
Sistema de fijar el bloqueo de leva (página 3)
Esta sistema de fijar el bloqueo de leva sera usado en todo el proceso ensamble.
Español
