System Build 7924403COM User manual

7924403COM
54" WALL CABINET
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B347924403COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2
ESTIMATED ASSEMBLY TIME: 2 HOURS

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P

4
systembuild.com
Board Identification
Not actual size
Tube
You
This piece is paperboard
construction.
it is not made from wood,
but is
required for the assembly
of your unit.
end panel
37365015012
left partition
37365015020
bottom
37365015051
top
37365015041
back rail
37365000090
2 adjustable shelves
37365015060
3 doors
37924403080
back panel
K73651500
wall hanger
37365000110
AB
DE
F
I
GH
right partition
37365015030
C
center adjustable shelf
37365015070
JK
bottom support rail
37365000101
L

5
systembuild.com
Part List
Not Actual Size
Tube
You
(x12)
#A22620
cam lock
1
(x12)
#A22610
cam bolt
2
(x16)
#A13430
1-3/4"
flat head
(x6)
#A17400
machine
screw
(x12)
#A80250
shelf
support
4
8
(x6)
#A89210
rubber bumper
(x3)
#A50395
pull (x6)
#A65700
hinge
(x4)
#A21500
steel pin
(x4)
#A13800
2-1/4" screw
56
9
7
10
3

6
systembuild.com
STEP1
Tube
You
* raw edges are shaded
Separate hinges by depressing end of hinge and removing the hinge plate from the hinge arm.
(x6)
#A65700
hinge arm
brazo de la bisagra
bras de la charniére
hinge plate
placa de la bisagra
plaque de charnière
Press to release hinge plate.
Presione para lanzar la placa
de la bisagra.
Pressez pour dégager la
plaque de charmière
10

7
systembuild.com
STEP2
Tube
You
* raw edges are shaded
2
(x12)
#A22610
(x6)
#A65700
2
NOTE: CAM BOLT LOCATIONS.
Orientation of hinge plate
on parts A and B.
A
A
B
finished edge
10
10
2
left side
right side
10

8
systembuild.com
STEP3
Tube
You
1
(x8)
#A22620
1
1
D
E
Proper orientation of CAM LOCK
Tip
Assembly
Quick

9
systembuild.com
STEP4
Tube
You
5
1
(x4)
#A22620
(x4)
#A21500
I
J
1
1
5
5
Proper orientation of CAM LOCK
Tip
Assembly
Quick

10
systembuild.com
STEP5
* raw edges are shaded
UNLOCKLOCK
left side
A
E
Tube
You

11
systembuild.com
STEP6
* raw edges are shaded
(x4)
#A13430
3
3
E
A
B
C
left side
Tube
You

12
systembuild.com
STEP7
Tube
You
UNLOCKLOCK
* raw edges are shaded
A
E
B
C J
I

13
systembuild.com
STEP8
Tube
You
D
UNLOCKLOCK
A
BE
CJ
I
* raw edges are shaded
3
(x4)
#A13430
3
left side

14
systembuild.com
STEP9
Tube
You
Be sure the back panel inserts into the grooves.
back panel
A
D
E
I
J
A
right side
raw surface
L
UNLOCKLOCK

15
systembuild.com
STEP10
(x5)
#A13430
3
3
3
1st
2nd
A
D
I
J
Tube
You

16
systembuild.com
STEP11
D
E
E
D
F
F
G
3
7
(x3)
#A13430
(x12)
#A80250
7
3
Tube
You

17
systembuild.com
STEP12
10
(x6)
#A89210
8
8
(x6)
#A65700
1) Position hinges onto hinge plates.
2) Be sure the front hooks catch the
hinge plates first.
3) Press hinges against hinge plates
until they snap together.
1st
2nd
10
Hx3
HA
A
D
E
B
C
x3
Tube
You

18
systembuild.com
STEP13
9
4
(x3)
#A50395
(x6)
#A17400
9
9
9
4
4
4
4
4
4
D
E
H
H
H
Tube
You

19
systembuild.com
STEP14
With the assistance of another person, locate and mark the studs in the wall that
the cabinet will be mounted to. Mark the location of the studs
with a pencil. Position the wall hanger (K) on the wall and mark the locations of the
studs on the back rail. Drill four 3/16" diameter holes in the wall
hanger (K) at the stud locations. Using a level, attach the wall hanger (K) to the wall
with four screws (7) as shown. It is important that the wall
hanger is mounted to a minimum of at least two studs. With the help of another
person, place the assembled component onto the wall hanger (K)
so the two beveled edges on the back rail (I) and wall hanger (K) mate together.
Wall to be
mounted to.
6
6
6
6
6
(x4)
#A13800
K
D
I
K
D
Tube
You

20
systembuild.com
STEP15
Loosen screw C
Adjust door.
Tighten screw C
*side view
Suelte el tornillo C
Acomode la puerta.
Ajuste el tornillo C
*la vista lateral
Défaites le vis C
Ajustez la porte.
Serrez le vis C
*le côté envisagent
Loosen screw C
Turn screw B to
move door.
Tighten screw C
Suelte el tornillo C
Dé vuelta el tornillo B
para mover la puerta.
Ajuste el tornillo C
Défaites le vis C
Le vis du tour B
déplacer la porte.
Serrez le vis C
Loosen screw A
Adjust door.
Tighten screw A
Suelte el tornillo A
Acomode la puerta.
Ajuste el tornillo A
Défaites le vis A
Ajustez la porte.
Serrez le vis A
To adjust the doors, remove the cover on the
back of the hinge arm to expose the two
adjusting screws.
To adjust the doors up and down, loosen the
hinge plate screws. Move the door the direction
needed and retighten the screws on the hinge
plates.
To adjust the doors sideways, turn the large
adjustment screw on the hinge arm clockwise or
counter clockwise, depending on the sideway
direction needed. The small adjustment screw
needs to be loosen or tightened in conjunction
with the larger screw
.
hinge cover
pry off / press on
A
B
C
Tube
You
A
