System Build 8129408COM User manual

8129408COM
2 Door Wall Cabinet
- Unit can tip over causing severe injury or death.
- Anchor unit to stud in wall (if instructed to).
- Do Not allow children to climb on unit.
- Put heavy items on lower shelves or drawers.
B348129408COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
WARNING
For the latest information on SystemBuild products
follow us at Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-866-452-4081
Monday-Friday
9am - 5pm CST
Visit systembuild.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
1
3
2
4
Tube
You
P
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Parts are labeled on the surface or edge of the part
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
Press CAM BOLT into hole.
Press parts together so CAM BOLT inserts
into edge hole.
Using a screwdriver, turn the CAM LOCK clockwise to
lock the CAM LOCK and CAM BOLT into their holes
and fastening parts together.
Press CAM LOCK into hole.
End hole
Arrow to point towards end
hole in edge of part.

4
systembuild.com
Before You Start
Quick
Tip
Assembly
Tube
You
Please Note:
You may need to lightly tap the wood dowels into the holes during
your assembly process.

5
systembuild.com
Board Identification
Not actual size
Tube
You
Left Panel
38129408010 Right Panel
38129408020 Top
38129408030
Bottom
38129408040
Adjustable Shelf
38129408050
Cabinet Hanger
38129000060
Back Panel
K812940800
ABC
DE
GH
Lower Rail
38129000070
Wall Hanger
38129000080
I
K
This piece is paperboard construction.
It is not made from wood, but is
required for the assembly of your unit.
F
Left Door
38129408090
J
Right Door
38129408100

6
systembuild.com
Board Identification
Not actual size
Tube
You
F
H
B
D
K
A
G
C
E
I
J

7
systembuild.com
Part List
Actual Size
Tube
You
(x8)
#A22710
cam bolt
(x8)
#A22700
cam lock
(x8)
#A21670
wood dowel
(x7)
#A23030
confirmat screw
123
4
(x4)
#A80250
shelf support
(x3)
#A13800
#8 x 2-1/4" screw
(x4)
#A17400
7/8" truss bolt
8
12
10
(x2)
#A89370
door bumper
(x4)
#A13950
#8 X 3-1/2" screw
7
5
(x22)
#A12105
7/16" screw
9
6
(x2)
#A11210
3/4" pan head screw
13
(x1)
#A53595
L-bracket
11
(x1)
#A55410
slide bolt

8
systembuild.com
Part List
Not actual size
Tube
You
14
(x4)
#A65615
hinge
(x2)
#A51010
handle
(x2)
#A92550
base plate kit
17d
17e
17c
17b
17a
(x1)
#A55055
lock
15
16
17

9
systembuild.com
STEP1
Tube
You
2
2
(x4)
2
22
A

10
systembuild.com
STEP2
Tube
You
2
(x4)
2
2
2
2
B

11
systembuild.com
STEP3
Tube
You
1
1
3
13
(x4)
(x4)
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
1
C
3
3
3

12
systembuild.com
STEP4
Tube
You
13
1
3
Proper orientation of CAM LOCK
Tip
Assembly
Quick
1
1
1
(x4)
(x4)
G
F
3
3
3

13
systembuild.com
STEP5
Tube
You
C
A
F
G
UNLOCKLOCK

14
systembuild.com
STEP6
Tube
You
UNLOCKLOCK
C
F
G
B
CF
B
G

15
systembuild.com
STEP7
Tube
You
finished
surface
C
K
A
F
B

16
systembuild.com
STEP8
Tube
You
513
(x2) (x1)
D
13
5
5

17
systembuild.com
STEP9
Tube
You
finished edges face up
4
(x4)
D
A
B
C
4
4
4
4

18
systembuild.com
STEP10
Tube
You
(x3)
C
F
4
4
4
4

19
systembuild.com
STEP11
Tube
You
516
(x2)
(x20)
5
I
J
16
5
5

20
systembuild.com
STEP12
Tube
You
9
10
6
11
15
14
9
10
15
10
I
(x2) (x2)
(x2)
(x1) (x1)
(x1)
6
6
11
14
14
