System One PB120B User manual
MODEL: PB120B
PORTABLE PARTY BOX SPEAKER
Introduction
Safety Precautions
Battery & Charging
Speaker Remote Control
Speaker Controls
Using your Party Box Speaker
Technical Specifications
.......................................................................................2
........................................................................2-4
...........................................................................5
..................................................................5
..............................................................................6
.........................................................7
...................................................................8
For safety reasons please read the following instructions and the enclosed Im-
portant Safety Precautions carefully before starting your Party Box speaker.
To reduce the risk of fire or electric shock, do not expose this appliance to rain
or moisture.
No user serviceable parts are included inside this product. Please refer all
servicing to a qualified engineer.
The lightning flash with the arrowhead symbol within an equilateral
triangle is intended to alert the user to the presence of uninsulated
’dangerous voltage’ within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to people.
The exclamation mark within an equilateral triangle is meant to alert
the user to the presence of important operating and maintenance
(servicing) instructions in writing accompanying the appliance.
Use of controls or adjustments or performance of procedures other than those
specified may result in hazardous radiation exposure.
Warning:
Caution:
Caution:
This product is covered by warranty, depending on the conditions in the
country where it is sold. If the speaker is returned for service, please include
the original dated receipt (or a copy) with the product.
Warranty and maintenance:
Items marked with the ”Crisscrossed wheeled bin” are not allowed to be disposed of together
with usual household waste. Electrical and electronic products should be disposed of in special
reception centers, equipped for recycling such products and components.
Thank you for purchasing this portable Party Box Speaker
from System One.
Before you start using the product, please read through this manual
and the safety instructions. Make sure that you follow each step
when using the product and follow the Important Safety Precausions.
This product has been granted with the CE certification mark to show that the product
follows the health, safety, and environmental protection standards for products sold within
the European Economic Area (EEA).
www.winnscandinavia.com
This products complies with the relevant proVisions of the RoHS Directive for the
European Union. In common with all Electrical and Electronic Equipment (EEE) the
product shouldn’t be disposed of as household waste.
Avoid direct sunlight - This product should not be used in direct sunlight, it
should be far away from heat sources such as a stove or heating radiators. The
speaker should be far away from dustiness, high temperature, hard light, strong
magnetism.
Placement - Do not place this product on an unstable surface, stand, bracket
or table. The product may fall, causing serious injury to child or adult, and
serious damage to the product. Use only a surface, stand bracket or table
recommended by the manufacturer, or sold with the product. Any mounting of
the product should follow the manufacturer’s instructions, and should use a
mounting accessory recommended by the manufacturer.
Damage Requiring Service - Unplug this product from the wall outlet and
refer servicing to qualified service personnel under the following conditions:
When the power-adaptor cord or plug is damaged
If liquid has been spilled, or objects have fallen onto the product.
If the product has been exposed to rain or water.
If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician
to restore the product to its normal operation.
If the product has been dropped or damaged in any way.
When the product exhibits a distinct change in performance
- this indicates a need for service.
a)
b)
c)
d)
e)
f)
Power-Cord Protection - Power supply cords should be routed so that they
are not likely to be walked on or pinched by items placed upon or against them,
paying particular attention to cords and plugs and where they exit from the
product. Please do not put any weight on the power cord. Do not pull the power
cord with excessive strength.
Lightning - For added protection for this product during a lightning storm, or
when it is left unattended and unused for long periods of time, unplug it from
the wall outlet. This will prevent damage to the product due to lightning and
power-line surges.
This product has a built-in battery. A fully charged battery lasts up to 5 hours
depending on product usage. While charging the battery the LED indicator in
the front panel shows a red light, when the battery is fully charged the LED
indicator switches to green. The PB120B Party Box Speaker supports
playing music while charging.
Battery & Charging
Speaker Remote Control
Make sure to charge the battery before using the Party Box Speaker without
the power cable. Charging time is 8 hours. More charging time may damage
the battery and can significantly reduce its lifetime.
There is a built-in intelligent power circuit that automaticly switches from
battery usage when connecting the product to an electrical outlet. The battery
will charge simultaneously and the same intelligent power circuit will switch the
power source back to the battery when the product is disconnected from the
electrical outlet.
When using the unit in battery mode, if the battery power runs low, turn the
product off with the front panel power switch before the battery fully runs out
and then charge the battery within 24 hours to avoid permanently damaging
the battery.
If the product is not in use during a long period of time, please make sure to
charge the battery every 6 months to prolong the battery life. The battery time
shortens due to excessive charging and over time. When a fully charged
battery life seems short or if the battery is no longer rechargeable, please
contact your local System One dealer to purchase a dedicated replacement
battery.
1. Mute key
2. Prev folder key
3. EQ mode key
4. FM ch- / previous key
5. Record key
6. Standby key
7. Next folder key
8. Folder repeat key
9. Repeat key
10. Volume increase key
11. Play / pause key
12. FM ch+ / next key
13. Volume decrease key
14. Tracks select key
15. Mode key
(input signal source)
6
PB120B Portable Party Box Speaker controls
1. Mode key (input signal source)
2. Previous & FM channel -
3. Recording
4. Play/Pause & True Wireless Stereo
5. Microphone priority
6. Next & FM channel +
7. Display screen
8. EQ adjustment panel
9. Volume control
10. Guitar input
11. Microphone input
12. Aux in (3,5mm)
13. USB jack
14. Micro SD/TF card jack
15. Guitar volume control
16. Microphone volume control
17. Microphone Echo
18. Charge display
19. External power adapter connector
(only use the original adapter)
20. Sound controlled LED switch
21. Power switch
Using the REC function:
While a USB memory stick is connected you can record sound from the AUX,
the wireless microphone and the FM radio. To record press and hold the ”REC”
button a few seconds, to stop recording just press the ”REC” button once.
Using the wireless microphone:
Turning the wireless microphone on while the speaker is active will automati-
cally connect it to the Party Box Speaker. Enabling the Microphone Priority
function automatically lowers the music when speaking in to the microphone,
the volume automatically recovers when you stop talking in the microphone.
Using the FM tuner:
Turn the Portable Party Box Speaker ON and press ”MODE” to switch to FM
mode. Use ”SCAN” to search for a requested radio station.
True Wireless Stereo (TWS) Technology:
The TWS technology allows you to connect a pair of System One PB120B
Party Box Speakers and use them in stereo (Right + Left channel). Changing
volume, play, pause and other functions simultaneously affect both speakers.
Using the TWS Technology:
Turn both Party Box Speakers ON and press ”MODE” to switch to Bluetooth
mode.
1.
2. Press and hold the TWS button on one of the speakers until you hear a
BEEP, this will become the main speaker (left channel), it will automatically
start searching for the second speaker (right channel). When a connection is
established this will be confirmed with a notification tone.
2.
Connect your Bluetooth enabled device accordingly.3.
To disconnect the second speaker, press and hold ”TWS” on any of the
PB120B Portable Party Box Speakers.
Using a USB memory stick or Micro SD/TF card:
Turn the Party Box Speaker ON. Plug in the USB stick or Micro SD/TF card,
music playback will start automatically. Use the remote control to select folder.
Using the AUX input:
Turn the Party Box Speaker ON and press ”MODE” to switch to AUX mode.
Connect any compatible device to the 3,5mm AUX connection located on the
front panel. To avoid damaging the product, please make dure that the volume
is turned down at the moment of connection with an external source.
Re-connecting your Bluetooth device:
Turn the Party Box Speaker ON and press ”MODE” to switch to Bluetooth
mode. If Bluetooth is enabled on your previously connected device the units
will connect automatically and confirm the connection with a notification tone.
Connecting your Bluetooth device to the Portable Party Box Speaker:
Make sure that Bluetooth is enabled on your mobile device. Turn the Party
Box Speaker ON and press ”MODE” to switch to Bluetooth mode, the BEEP
indicates searching.
1.
2. Scan for local Bluetooth devices with your mobile device and select the
”PB120B”. The Portable Party Box Speaker indicates a successful Bluetooth
connection with a notification tone.
2.
Select your favourite music service on your Bluetooth device and enjoy!3.
1x Portable Party Box Speaker
1x Power Adaptor
1x Wireless Microphone
1x Remote Control
1x User Manual
2x AA Batteries
2x AAA Batteries
Package includes:
Portable Party Box Speaker
80W
4Ω
92±3dB
50-18KHz
≥71dB
≤0.7% (1W)
1” + 12”
PB120B
261.8 MHz
87.50-108.00 MHz
PB120BModel
Type
RMS Power Output
Impedance
Sensitivity
Frequency Response
S/N Ratio
Distortion
Drive Unit
Bluetooth Name
Wireless Mic. Freq.
FM Frequency
355x320x555mm
8,2kg
9V/3A, 100V-240V,
50/60Hz
7.4V/4000MAH
Lithium battery
2xAAA
2xAA
8 hours
4h (50% volume)
5h (50% volume)
Size (H x W x D) mm
Gross Weight
Power Adaptor
Power Battery
Remote Battery
Mic Battery
Battery Charging Time
Battery Playtime (+ LED)
Battery Playtime (- LED)
