Systembuild Evolution 3604408COM User manual

3604408COM
2 Door Tall Cabinet
B343604408COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Follow Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
Visit ameriwoodhome.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Parts are labeled on the surface or edge of the part
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P
12
34
Press parts together so CAM BOLT inserts
into edge hole.
Press CAM BOLT into hole. Press CAM LOCK into hole.
End hole
Using a screwdriver, turn the CAM LOCK clockwise to
lock the CAM LOCK and CAM BOLT into their holes
and fastening parts together.
Arrow to point towards end
hole in edge of part.

4
systembuild.com
Before You Start
Quick
Assembly
Tip
Please Note:
You may need to lightly tap the wood dowels into the holes during
your assembly process.

5
systembuild.com
Board Identification
Not actual size
This part is made of paperboard
construction. It is not made from
wood, but is required for the
assembly of your unit.
Left Panel
33604408010 Right Panel
343604408020
Top
33604408030
Bottom
33604408040
Left Door
33604408060
Right Door
33604408070 Back Panel
K360440800
AB
C
D
I
Shelf
33604408050
E
Adjustable Shelf (x2)
33604408060
F
G
H

6
systembuild.com
Board Identification
Not actual size
A
B
C
D
H
G
I
E
F
F

7
systembuild.com
Part List
Actual Size
(x40)
#A12105
7/16" pan head screw
12
34
10
(x8)
#A22700
cam lock
(x8)
#A22710
cam bolt
(x8)
#A21670
wood dowel
(x4)
#A23030
confirmat screw
(x4)
#A17400
7/8" bolt
(x50)
#A21110
nail
(x8)
#A80250
shelf support
(x2)
#A11210
3/4" pan head screw
(x10)
#A12810
1" pan head screw
5
9
68
13
(x2)
#A89370
door pad
12

8
systembuild.com
Part List
Not Actual Size
(x1)
#A84050
safety bracket
(x6)
#A65615
hinge
(x2)
#A55010
handle
(x5)
#A44710
foot
(x1)
#A55055
lock
15
16
17
7a
7b
7c
7d 11a
11b
11c
11d
11e
(x4)
#A92550
base plate kit
18
7
14
(x1)
#A55410
slide bolt
11

9
systembuild.com
STEP1
A
2
2
B
2
2
2
2
2
2
2
(x8)

10
systembuild.com
STEP2
Proper orientation of CAM LOCK
Tip
Assembly
Quick
13
(x4) (x4)
1
3
C
1
3
1
3
3
1

11
systembuild.com
STEP3
E
3
1
1
3
1
3
3
3
1
1
(x4) (x4)
Proper orientation of CAM LOCK
Tip
Assembly
Quick

12
systembuild.com
STEP4
Finished Edges
Face Up
UNLOCKLOCK
A
E
C
C
A

13
systembuild.com
STEP5
Finished Edges
Face Up
E
CB
UNLOCKLOCK

14
systembuild.com
STEP6
D
B
4
4
Finished Edges
Face Up
4
4
4
(x4)
A

15
systembuild.com
STEP7
D
16
6
(x10) (x5)
6
6
16
x5

16
systembuild.com
STEP8
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT
AND MUST BE INSTALLED PROPERLY.
Carefully turn the unit over on its front side.
Position back panel as shown. Align squarely with all edges and
nail straight into back edges as shown.
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
Flush bottom edge of the back
panel with the bottom edge of
bottom (D).
Raw Surface Shown
13
(x50)
13
I

17
systembuild.com
STEP9
For Masonry, Concrete, or other
wall materials:
Consult your local hardware store
for appropriate anchors to securely
attach the safety bracket.
IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW
THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS
PRODUCT.
WARNING
Serious or fatal crushing injuries can
occur from furniture tipover.
To prevent tipover:
* Install tipover restraint provided
* Place heaviest items in the lowest
drawers
* Unless specifically designed to
accommodate, do not set TVs or other
heavy objects on the top of this product
* Never allow children to climb or hang
on drawers, door, or shelves
* Never open more than one drawer at a
time
Use of tipover restraints may only
reduce, but not eliminate the risk of
tipover
OPTION 1: Attachment into a wall stud (preferred method)
Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety bracket aligned
in this location. To make driving the screw easier, you can drill a 1/8" diameter pilot hole (3mm) through the
safety bracket into the stud. Drive the screw through the safety bracket into the wall stud.
OPTION 2: Attachment into drywall
Locate your unit where desired against a wall and mark the wall through the safety bracket, then move your
unit aside. Drill a 3/16" diameter hole (5mm) into the wallboard. Tap the wall anchor into the hole until it is
flush. Move your unit into location and fasten the wall bracket to the wall anchor with the screw.
stud
wallboard
hole
7a
7b
7d
7c
7d
7c
7b
7a

18
systembuild.com
STEP10
518
(x40) (x4)
G
H
5
18
18
18

19
systembuild.com
STEP11
17
15
14
910
12
12
10
14
9
9
10
(x3) (x1)
(x1)
(x2)
(x1)
(x2)
G
17
15 15
15

20
systembuild.com
STEP12
10
12
15 17
(x2)
(x1) (x3)
(x1)
17 12
H
15 15
15
10
10
