Systembuild Evolution 4888408COM User manual

4888408COM
2 Door Base Cabinet
B344888408COM0
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
Follow Ameriwood Home
Tube
You
Date of Purchase ___ / ___ / ___
Lot Number:
Do Not Return This Product!
Contact our customer service team for help first.
Call: 1-866-452-4081 (toll free)
Monday-Friday 9am - 5pm CST
Visit: www.systembuild.com
Assembly Difficulty Meter
Easy Tough
Secure Your Furniture
Keep your home and family safe
with the wall anchor kit that is
included with the product.
Serious or fatal crushing injuries can
occur from tipping furniture.
WARNING: Manufacturer assumes no liability
for improper installation or excessive loads
placed on screws or bracket. This wall anchor
is not a substitute for proper adult supervision.

Contact Us!
Helpful Hints
2
systembuild.com
Do NOT return this product!
Contact our friendly customer service team first for help.
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
Visit ameriwoodhome.com to view the
limited warranty valid in the U.S. and Canada.
Assembly Tips
- Open your item in the area you plan to keep it to avoid excessive heavy lifting.
- Identify, sort and count the parts before attempting assembly.
- Compression dowels are lightly tapped in with a hammer.
- Slides are labeled with a R (right) and L (left) for proper placement.
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge.
- Use all the nails provided for the back panel and spread them out equally.
- Back panel must be used to make sure your unit is sturdy.
- Do NOT use harsh chemicals or abrasive cleaners on this item.
- Never push, pull, or drag your furniture.
Tube
You
PEOPLE NEEDED FOR ASSEMBLY: 1-2

3
systembuild.com
Before You Start
P
Quick
Tip
Assembly
P
P
P
Cam Lock Fastening System
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Parts are labeled on the surface or edge of the part
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, #2 Phillips Head
Screwdriver and Hammer
Caution: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is tight.
Failure to do so may result in stripping the screw.
P
12
34
Press parts together so CAM BOLT inserts
into edge hole.
Press CAM BOLT into hole. Press CAM LOCK into hole.
End hole
Using a screwdriver, turn the CAM LOCK clockwise to
lock the CAM LOCK and CAM BOLT into their holes
and fastening parts together.
Arrow to point towards end
hole in edge of part.

4
systembuild.com
Before You Start
Quick
Assembly
Tip
Please Note:
You may need to lightly tap the wood dowels into the holes during
your assembly process.

5
systembuild.com
Board Identification
Not actual size
This part is made of paperboard
construction. It is not made
from wood, but is required for
the assembly of your unit.
Left Panel
34888408010 Right Panel
34888408020 Top
34888408030
Bottom
34888408040
Adjustable Shelf
34888408050 Left Door
34888408060 Right Door
34888408070 Back Panl
K488840800
AB
CD
E
FGH

6
systembuild.com
Board Identification
Not actual size
A
B
C
D
H
G
F
E

7
systembuild.com
Part List
Actual Size
(x20)
#A12105
7/16" pan head screw
12
34
11
(x4)
#A22700
cam lock
(x4)
#A22710
cam bolt
(x4)
#A21670
wood dowel
(x4)
#A23030
confirmat screw
(x4)
#A17400
7/8" bolt
(x30)
#A21110
nail
(x4)
#A80250
shelf support
(x2)
#A11170
5/8" pan head screw
(x2)
#A11210
3/4" pan head screw
(x10)
#A12810
1" pan head screw
(x2)
#A89020
plastic stop
(x1)
#A55410
slide bolt
5
610
7
13 14
9
15

8
systembuild.com
Part List
Not Actual Size
(x1)
#A84050
safety bracket
(x4)
#A65615
hinge
(x2)
#A51010
handle
(x5)
#A44710
foot
(x1)
#A55055
lock
16
17 18
8a
8b
8c
8d 12a
12b
12c
12d
12e
(x2)
#A92550
base plate kit
19
812

9
systembuild.com
STEP1
Proper orientation of CAM LOCK
Tip
Assembly
Quick
(x2)
13
(x2)
1
3
1
3
A

10
systembuild.com
STEP2
Proper orientation of CAM LOCK
Tip
Assembly
Quick
13
(x2) (x2)
1
3
B
1
3

11
systembuild.com
STEP3
8a
8b
2613
(x4) (x2) (x2)
(x1)
2
8a
8b
6
13
C
2
2
2
Finished Edge
Do not fully tighten screw.

12
systembuild.com
STEP4
4
(x4)
Finished Edges
Face Up
4
4
4
4
C
D
A
B
UNLOCKLOCK

13
systembuild.com
STEP5
14
(x30)
Finished Edges
Face Down
14
IMPORTANT! THE BACK PANEL IS A STRUCTURAL PART OF THIS UNIT AND MUST BE INSTALLED PROPERLY.
Carefully turn the unit over on its front side.
Position back panel as shown. Align squarely with all edges and nail straight into back edges as
shown.
Assure that our unit is square.
Distance from corner to corner
must be equal as shown.
Flush bottom edge of the back
panel with the bottom edge of
bottom (D).
Raw Surface Shown
B
D

14
systembuild.com
STEP6
17
7
D
B
17
7
7
(x10) (x5)
x5

15
systembuild.com
STEP7
519
(x20) (x2)
F
G
19
55
5
5
5

16
systembuild.com
STEP8
10
15
11
16 18
(x2)
(x2) (x1) (x2) (x1)
F
11
11
10
15
16
16
18

17
systembuild.com
STEP9
11
16 18
G
11
11
18
16
16
(x2) (x2) (x1)

18
systembuild.com
STEP10
12e
12d
12c
12b
12a
G
Insert the barrel of the lock (12a) into the hole as shown.
With the teeth of the lock nut (12c) facing the door
surface, tighten the lock nut (12c). Position lock bar (12b)
and attached the barrel of the lock (12a) with the lock
screw (12d). Lock bar (12b) will point straight left. When
you turn the lock with the key, lock bar will rotate
counter-clockwise pointing straight down.
Teeth of lock nut will tighten
against the surface of the
door.
12a
12b
12c
12d
12c
Keyway Vertical
Flat /smooth
surface of
lock barrel.

19
systembuild.com
STEP11
F
G
When mounting the right door (G),
be sure the lock bar (12b) is
pointing straight down.
When mounting the left door (F),
be sure the slide bolt (15) is
positioned in the up position.
15

20
systembuild.com
STEP12
For Masonry, Concrete, or other
wall materials:
Consult your local hardware store
for appropriate anchors to securely
attach the safety bracket.
IMPORTANT: THIS UNIT MUST BE SECURE TO THE WALL TO HELP PREVENT TIPOVER. FOLLOW
THESE INSTRUCTIONS TO INSTALL THE ANTI-TIPPING SAFETY BRACKET PROVIDED WITH THIS
PRODUCT.
WARNING
Serious or fatal crushing injuries can
occur from furniture tipover.
To prevent tipover:
* Install tipover restraint provided
* Place heaviest items in the lowest
drawers
* Unless specifically designed to
accommodate, do not set TVs or other
heavy objects on the top of this product
* Never allow children to climb or hang
on drawers, door, or shelves
* Never open more than one drawer at a
time
Use of tipover restraints may only
reduce, but not eliminate the risk of
tipover
OPTION 1: Attachment into a wall stud (preferred method)
Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety bracket aligned
in this location. To make driving the screw easier, you can drill a 1/8" diameter pilot hole (3mm) through the
safety bracket into the stud. Drive the screw through the safety bracket into the wall stud. Tighten the screw
that was not fully tightened in step 3.
OPTION 2: Attachment into drywall
Locate your unit where desired against a wall and mark the wall through the safety bracket, then move your
unit aside. Drill a 3/16" diameter hole (5mm) into the wallboard. Tap the wall anchor into the hole until it is
flush. Move your unit into location and fasten the wall bracket to the wall anchor with the screw. Tighten the
screw that was not fully tightened in step 3.
stud
wallboard
hole
8c
8d
8c
8d
