TAAG TIN KNOCKER Parts list manual

TIN KNOCKER
Pittsburgh Pistol Air Hammer
INSTRUCTIONS & PARTS DIAGRAM
TAAG MACHINERY CO.
(Master Distributor)
1257-B Activity Dr.
Vista, CA 92081
Tel: [phone] Fax: [phone]
Website: www.tinknocker.com * Email: [email protected]
June 2009
1

MAINTENANCE
Using pneumatic tool oil or machine oil of SAE No.5 or SAE No. 10, pour a few drops into the inlet each
day before using. Run the tool for a few seconds to distribute the oil within. If the tool is in constant use
over the course of a day, repeat the above every 3-4 hours.
SAFETY
1. Never operate this air tool without the forming tool in place.
2. Never disassemble the air tool with the air supply connected.
3. With heavy, constant use, you should tighten the barrel. Do so by loosening the socket screw in
the handle, providing access to the barrel every 3-4 hours or when the barrel begins to become
loose. Failure to keep the barrel tight will cause damage to the tool
OPERATION
The speed of the hammer will be regulated by how far the trigger is depressed. For maximum efficiency,
ensure the air pressure is around 90 psi.
DISASSEMBLY & ASSEMBLY
1. Disassembly
a. Place the barrel in the vise ensuring vise jaws contact at the flats in the barrel.
b. Loosen set screw
c. Unscrew the handle from the barrel. With the barrel pointing down, lift the handle off the
barrel.
d. Lift the back valve block P/N HAMMER006 wafer P/N HAMMER005, and front valve
block P/N HAMMER004 with pins, P/N HAMMER007 off the barrel.
e. Counter clockwise, unscrew the trigger assembly P/N HAMMER009.
2. Assembly
a. Thoroughly clean all parts prior to assembly
b. Replace any worn trigger washers.
c. Replace trigger assembly P/N HAMMER009, turning it clockwise until tight.
d. With the barrel pointing down, insert the two pins P/N HAMMER007 into the shallow
holes.
e. Replace front valve block P/N HAMMER004 on the pins P/N HAMMER007 with the
milled surface up.
f. Install the wafer P/N HAMMER005 in the large hole in the rear valve block
g. Replace the back valve block P/N HAMMER006 down on the pins P/N HAMMER007,
with the milled surface down.
h. Ensure lines on the side of the valve sections are aligned.
i. Screw barrel into the handle and tighten.
j. Tighten socket screw.
k. Lubricate and test as above described.
ORDERING PARTS: Ensure you have both the part nomenclature and part number.
2

Parts for TK PITTSBURGH PISTOL AIR HAMMER
Find No Part No Description No. REQ”D
1. HAMMER001 Handle 1
2. HAMMER002 Barrel 1
3. HAMMER003 Piston 1
4. HAMMER004 Front Valve Block 1
5. HAMMER005 Wa er 1
6. HAMMER006 Back Valve Block 1
7. HAMMER007 Pin 2
8. HAMMER008 Socket Set Screw 1
9. HAMMER009 Trigger Assembly 1
10. HAMMER010 Rubber Seal, Large 1
11. HAMMER011 Rubber Seal, Small 1
12. HAMMER012 Guide with Screw 1
13. HAMMER013 Hammer Form Tool 1
14. HAMMER014 Lock Seam Adapter 1
3

INSTRUCTIONS
1. Do not use without wearing protective eye and ear wear. Be safe!
2. Connect air hammer to an air source of approximately 90 psi for heavier gauge sheet metal.
Pressure can be reduced when working with lighter gauges.
3. Place the air hammer guide against the Pittsburgh lock as shown in Figure 1, below. Lightly
squeeze the trigger to begin hammer operation. Depress the trigger to achieve the desired
result in bending the flange.
4. Keep the piston/forming tool against the metal. Failure to do so will diminish the life of the
tool. Do not allow the forming tool to bounce off the flange.
5. Move the air hammer along the seam, hammering over the retainer flange. Note that the
position in figure 1 is about 45 degrees to achieve this initial bend.
6. Next, we will make another pass over the flange to close the Pittsburgh lock seam. Note the
position as indicated in Figure 2 below.
7. Bends in sheet metal may be removed by removing the aluminum guide and leaving the
forming tool in place.
WARRANTY
This air tool is warranted against factory defective parts for six months from date of purchase. TAAG
reserves the right to repair or replace, at TAAG’s option. Warranty claims require that the air tool be
delivered to TAAG, at the below address, for inspection and warranty evaluation.
4

OTHER TIN KNOCKER SHEET METAL ORKING MACHINES
Tin Knocker is a line o sheet metal working machinery exclusively designed to meet the needs and
budget o HVAC CONTRACTORS. It is the only line that produces all the machines necessary to
manu acture rectangular duct and ittings with high quality and a ordable prices. We have :
BRAKES ROLL FOMERS BENDERS SLITTERS SHEAR BEADER
4-10FT Pitts, ButtonLock Cleat 20 & 16 Ga. 52”x16Ga 5’x16 Ga.
22-16Ga. S&Drive Cleats Cheek
Bar Folder
NOTCHER TURRET PUNCH FLANGERS CRIMPER BEADERS ROLLS SPOTWELDER
5”X5”Corner 12 Station Manual Manual Deep Throat 3’x22Ga 15KVA
Attachments Throatless
