Taiga Concept LOHKO BOX 3 User manual

LOHKO BOX 3
ASSEMBLY
GUIDE
www.taigaconcept.com
x2
3h

Take image of the damaged item
before opening the package for
later documentation, then
continue opening package
If you find damage please
take images before
opening the package
Check if there is any damage
to the package
Remove top cover and check that
there are no signs of damage before
unpacking.
If you find damage please take
images before unpacking the product
elements
If you damage elements while carrying,
take images of the damages
If you damage elements
while assembling the product,
take images of damages
Assemble the product
Take image of the damage,
check which element / part
is damaged and contact
the local Taiga dealer
Take image of the damage,
check which element / part
is damaged and contact
the local Taiga dealer
Take image of the damage,
check which element / part
is damaged and contact
the local Taiga dealer
If you find damage, document with
photos according instructions
Carry the elements
Note: Take extra care
when carrying glass

1. Take images where you can see
full package from 2 different angles
which show the damage
1. Take images where you can see
full package from 2 different angles
which show the damage
1. Take images where you can see
the whole element from 2 different angles
which show the damage
2. Take closer images of the damage
2. Take closer images of the damage
2. Take closer images of the damage and
check which element / glass is damaged.
3. Contact your local Taiga dealer
3. Contact your local Taiga dealer
3. Contact your local Taiga dealer
How to document if you cause damage while carry orassembling the product

www.taigaconcept.com
Installation
Open the packing carefully not to damage the
product.
Always follow assembly instruction when you
assemble your product.
When moving the glass elements make sure
you don’t place them on hard surfaces as they
will break easily.
When assembling the product make sure you
can support the wall element until they are
stable.
Taiga Concept recommend to use authorized
installation persons and will not take
responsibility for any harm to persons or
goods due to irresponsible actions.
Product may have some smell after assembling
but it will disappear in few weeks.
Before installation find out your country fire
regulation and contact your local Taiga dealer.
Do not carry out your own modifications to the
product, as it will automatically end warranty.
Check building / floor weight capacity before
assembling the products.
Maintenance
After assembling the product, wipe all surfaces
with clean damp cloth. Avoid using too much
water, as it will damage the product. Prolonged
direct sunlight may change the color of
wooden surfaces over time.
Check tightness of hinges and door position
every six month.
Choosing location
Always place the product inside the building.
Room temperature needs to be minimum 10°C.
Do not place the product to space that is wet
or where has high humidity.
Place the product so that the minimum space
between roof element and ceiling needs to be
at least 10 cm. Building ceiling height minimum
of 230 cm.
When placing the product make sure the door
will not block any walkway and that it does not
damage when open.
Maximum floor deflection ≤ 0,7° degree /
meter.
Warranty / Contact
Upon successful installation please inform the
local Taiga dealer to activate the warranty.
Warranty is not valid if assembly has been
carried out in contradiction to the installation
guide.
It is recommended to use Taiga Concept local
dealers authorized assembling person.
If you have any questions or problems during
installation, please contact your local Taiga
dealer.

1x CW010
1x CF004
1x CR004
1x CR005
1x CG003
2x CG004
3x CG005
2x CA2xx
1x SCA003
Width 700mm
Width 767 mm
1x CF005
1x SR005
1x CW007
1x CW008
1x CW009
Wall
Roof
GlassAcoustic panel & carpet
Floor
Elements &
Components
1x CD004
1x CD005
2x CD006
2x SR006
1x SR007
1x EP106
Width 2135 mm
Width 2335 mm
Frames & Joints
Cables & control panel
1x EC1xx
500cm
200cm
200cm
100cm
1x EC221
1x EP109
1x EC220

4x SS002
4x SS003
2x SS004
2x SS005
8x SF002
3x SM001
4x SC006 2x SR001
12x SC001 16x SC002
Doorframe &
acoustic panel
Wall connector
plate Hinges
Roof
Roof
2x SF006 38x SR003
8x SC003 4x SC005
1x SF001 1x SF003
Width 2100 mm
Width 700 mm
Width 2280 mm
6,3 x 80
3,5 X 20
4,5 X 30
4,5 X 30
Seals
Screws & Accessories
1x SH00x
Elements &
Components
Screw machine + bits
Gloves Safety glasses Safety shoes Safety helmet
Carpet knife Cleaning tools Protection material
for elements and glasses
Glass suction cup
min weight capacity 50 kg / pcs
2 x
+
Hex key set
Step ladder Rubber hammer
Spirit leveler
Equipments
& tools
Small adjustable
wrench

ATTENTION
Never put glass against hard surface, use always carton or carpet under the glass.
Use always 2 person and suction cups to lift glass
X

SR005
CF002
CF003
SR003
6X

SC007
4X

SR003
16X

CW010
x2

CG005
SS002
x2

CW009
x2

SS002
CG005
x2

SR006

CW007
x2

SR006

CW008
x2

SH001
SC003
2X
SR003
16X
Warning: Do not apply excessive force

CR005
x2
X
Do not scratch the element surfaces
and be careful with sharp edges
