TP9300/TP9400/TP9500/TP9600
TP3350
Portable Radios
Bluetooth® Device Acceptance Test
TN-2817c-AN
August 2021

TN-2817c-AN www.taitradio.com Page 2 of 14
Contents
Contents..............................................................................................................................................................2
Purpose...............................................................................................................................................................2
1.1 Hardware Requirements...........................................................................................................................3
1.2 Software Requirements.............................................................................................................................3
1.3 License Requirements ..............................................................................................................................3
1.4 Radio Configurations.................................................................................................................................3
1.4.1 TP9300/9400/9500/9600 .................................................................................................................................... 3
1.4.2 TP3350...............................................................................................................................................................4
1.5 Test Suite..................................................................................................................................................5
1.5.1 Device Pair and Connect.................................................................................................................................... 5
1.5.2 Device Disconnect.............................................................................................................................................. 6
1.5.3 Volume Control (if applicable).............................................................................................................................7
1.5.4 Audio Quality and PTT Audio Path(s) Switching.................................................................................................8
1.5.5 Recovery after Power Cycle ............................................................................................................................. 10
Further Reference Information..........................................................................................................................13
Additional Notes................................................................................................................................................13
Copyright and Trademarks................................................................................................................................13
Contact Information...........................................................................................................................................13
Publication Information......................................................................................................................................14
Purpose
This document describes a set of simple acceptance tests, which should be performed when selecting a
Bluetooth® device to be used as an accessory on a Tait Portable product.
The tests described here allow the user to make an informed choice of the suitability of the Bluetooth®
device under test in the desired modes of operations.

TN-2817c-AN www.taitradio.com Page 3 of 14
1.1 Hardware Requirements
The following hardware is required to do this testing:
•2 x Tait TP9300, TP9400, TP9500, TP9600 and/or TP3350 with suitable batteries and antennas
•Candidate Bluetooth® device under test
•1x wired PTT (optional)
•1x Tait Programming Cable to program the portable radios via a PC
1.2 Software Requirements
The following software is required for the following portable radio models:
•TP9300 –firmware v2.20.04 or later
•TP9400 –firmware v2.14.03 or later
•TP9500 –firmware v2.25.00 or later
•TP9600 –firmware v2.17.00or later
•TP3350 –firmware v1.04.00 or later
Refer to the Bluetooth® Functionality document TD-0016-xx for more details.
1.3 License Requirements
TPAS082 (SFE key - Bluetooth) must be enabled on the Tait TP9000 portable radios.
1.4 Radio Configurations
Two radio databases will be needed, one for each radio defined in this testing as “Radio A” and “Radio B”.
In addition to the normal configurations specific to your test setup e.g., Conventional Channel Profile; the
following specific settings are required to enable Bluetooth® functionalities on the radios.
1.4.1 TP9300/9400/9500/9600
On Radio A only:
•Global > PTT > Programmable/Bluetooth® PTT or VOX > Advanced > Audio Source as
‘Bluetooth® Mic’
•Function Key 2 (F2) Primary Action as ‘Programmable PTT’
•Function Key 4 (F4) Primary Action as ‘Bluetooth Devices Connect’
•Function Key 4 (F4) Long Press as “Bluetooth Devices Disconnect”
•Conventional > Conventional Menu > Bluetooth items enabled
On Radio B only:

TN-2817c-AN www.taitradio.com Page 4 of 14
•Global > PTT > Programmable/Bluetooth® PTT or VOX > Audio Source as ‘Bluetooth® Mic’
•Function Key 2 (F2) Primary Action as ‘Programmable PTT’
•Function Key 4 (F4) Primary Action as ‘Bluetooth Devices Connect’
•Function Key 4 (F4) Long Press as “Bluetooth Devices Disconnect’
•Conventional > Conventional Menu > Bluetooth items enabled
•In Global > Bluetooth® enable ‘Use Multi-Device UI’
•In Global > Bluetooth® > Power-On Action select ‘Reconnect to Last BT Devices’
•In Global > Bluetooth® enable ‘Attempt Automatic Reconnection’
1.4.2 TP3350
On Radio A and B:
•Edit > Specifications > Accessories > BT as ‘Selected’
•Function Key 3 (F3) as ‘Bluetooth Headset Audio Switch’
Please note different manufacturers may choose to operate their Bluetooth® headsets with PTT and
function key buttons with different commands. For some Bluetooth® devices, additional settings may
be required on the radio to enable the PTT and functional buttons to work. These radio configurations
can be found at Global > Bluetooth® > Button Profiles.
The Button Profile table lists the incoming Bluetooth® messages and associated them with functions
on the radio e.g., if the radio receives a Bluetooth string “+PTT=P”, it will understand this as a PTT
press. We expect this message from Savox and Aina Bluetooth® devices.

TN-2817c-AN www.taitradio.com Page 5 of 14
1.5 Test Suite
1.5.1 Device Pair and Connect
Purpose: Evaluate the functionality and reliability of pairing and connecting the Bluetooth®
device under test with Tait portable radio.
Pair Single Device
TP9300/9400/9500/9600
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® Device into pair mode (as per manufacturer’s instructions)
with Radio A.
3. Press F4 on Radio A.
4. Follow the radio UI prompts until the device is connected.
5. Press and Hold F2 Programmable PTT (or the wired EPTT1 depending on configuration)
and verify Radio A transmitted audio is received on Radio B.
Release the F2 Programmable PTT and verify Radio B stops receiving audio.
TP3350
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® device into pair mode (as per manufacturer’s instructions).
3. On Radio A, search devices (Menu > Accessories > Bluetooth > My devices > Search
devices).
4. Follow the radio UI prompts until the device is connected.
5. Press and Hold PTT and verify Radio A transmitted audio is received on Radio B.
Release PTT and verify Radio B stops receiving audio.
Pair Multiple Devices
Purpose: Ease of changing between Bluetooth® devices under test with Tait portable radio.
TP9300/9400/9500/9600
1. Power-on all Bluetooth® devices and ensure that they are in paired mode (as per
manufacturer’s instructions).
2. Press F4 on Radio B.
3. Follow the radio UI prompts until one device is connected.
4. Long press F4 to disconnect the device.
5. Navigate to ‘Bluetooth’and select ‘Find new devices’.

TN-2817c-AN www.taitradio.com Page 6 of 14
6. Select a second device and follow the radio UI prompts until it is also connected
(Add to my headsets).
7. Navigate to ‘Bluetooth’and select ‘Manage devices’. There should now be two devices
in the list. If they happen to use the same name add a ‘1’ and ‘2’ to each device name
respectively.
8. Press and Hold F2 Programmable PTT and verify Radio B transmitted audio is
received on Radio A. Release the F2 Programmable PTT and verify Radio A stopped
receiving audio.
9. Navigate to ‘Bluetooth’ and select ‘Manage devices’ and select a different Bluetooth®
device then repeat steps 8 and 9.
TP3350
1. Power-on all Bluetooth® devices and ensure they are in pairing mode (as per
manufacturer’s instructions).
2. On Radio B, search devices (Menu > Accessories > Bluetooth > My devices > Search
devices).
3. Follow the radio UI prompts until one device is connected.
4. Disconnect the device (Menu > Accessories > Bluetooth > My devices > [Connected
device name] > Disconnect).
5. Search for the new device (Menu > Accessories > Bluetooth > My devices > Search
devices).
6. Select a second device and follow the radio UI prompts until it is also connected.
7. Navigate to ‘My devices’ (Menu > Accessories > Bluetooth > My devices). There
should now be the two devices in the list.
8. Press and Hold PTT and verify Radio B transmitted audio is received on Radio A.
Release PTT on Radio B and verify Radio A stops receiving audio.
9. Navigate to ‘My devices’ and select a different Bluetooth® device then repeat Step 8.
1.5.2 Device Disconnect
Purpose: Verify Bluetooth® device(s) can be disconnected but remain paired with Tait
portable radio.
TP9300/9400/9500/9600
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® Device into pair mode (as per manufacturer’s instructions)
with Radio A.
3. Press F4 on Radio A.
4. Follow the radio UI prompts until the device is connected.

TN-2817c-AN www.taitradio.com Page 7 of 14
5. Press and Hold F2 Programmable PTT and verify Radio A transmitted audio is received on
Radio B. Release the F2 Programmable PTT and verify Radio B stops receiving audio.
6. Long press F4 on Radio A.
7. Press and Hold F2 Programmable PTT and verify Radio A transmitted audio is not received
on Radio B. Release the F2 Programmable PTT.
8. Press and Hold radio PTT and verify Radio A transmitted audio is received on Radio B.
Release the radio PTT and verify Radio B mutes.
9. Navigate to ‘Bluetooth’ and select ‘Find new devices’. From the list, verify the list of devices
include the device that has just been disconnected.
TP3350
1. Power-on all Bluetooth® devices and ensure they are in pair mode (as per manufacturer’s
instructions).
2. On Radio B, search devices (Menu > Accessories > Bluetooth > My devices > Search
devices).
3. Follow the radio UI prompts until one device is connected.
4. Disconnect the device (Menu > Accessories > Bluetooth > My devices > [Connected device
name] > Disconnect).
5. Hold radio PTT and verify Radio A transmitted audio is received on Radio B through the
internal speaker but not the Bluetooth® device.
6. Navigate to ‘My devices’ (Menu > Accessories > Bluetooth > My devices > [Connected
device name]), verify the option changed to ‘Connect’.
1.5.3 Volume Control (if applicable)
Purpose: Verify the Bluetooth® device speaker volume can be adjusted, and speaker volume
matches the adjusted level (if applicable for the Bluetooth® device under test).
TP9500/9600
1. Power-on both Radio A and Radio B.
2. Put an unpaired Bluetooth® Device into pair mode (as per manufacturer’s instructions) with
Radio A.
3. Press F4 on Radio A.
4. Follow the radio UI prompts until the device is connected.
5. Press and Hold Radio B F2 Programmable PTT and verify Radio B transmitted audio is
received on Radio A. Release the F2 Programmable PTT and verify Radio A stopped
receiving audio. Note the volume level on device connected to Radio A.
6. Adjust the volume to be louder on the device connected to Radio A.
7. Press and Hold Radio B F2 Programmable PTT and verify Radio B transmitted audio is
received on Radio A. Release the F2 Programmable PTT and verify Radio A stops
receiving audio. Note the volume level on device connected to Radio A is louder.

TN-2817c-AN www.taitradio.com Page 8 of 14
8. Press and Hold Radio A F2 Programmable PTT and verify Radio A transmitted audio is
received on Radio B. Release the F2 Programmable PTT and verify Radio B stops
receiving audio. Note the volume level on device connected to Radio B.
9. Adjust the volume to be quieter on the device connected to Radio A.
10. Press and Hold Radio B F2 Programmable PTT and verify Radio B transmitted audio is
received on Radio A. Release the F2 Programmable PTT and verify Radio A stops
receiving audio. Note the volume level on device connected to Radio A is quieter.
11. Press and Hold Radio A F2 Programmable PTT and verify Radio A transmitted audio is
received on Radio B. Release the F2 Programmable PTT and verify Radio B stops
receiving audio.
TP9300/9400
Suggest these models are programmed with Global > UI Preferences > Audio > Minimum
Volume Level set to at least ‘10’.
1.5.4 Audio Quality and PTT Audio Path(s) Switching
Purpose: Verify the audio quality and PTT audio path switching between the Bluetooth® device
under test, wired audio accessory and Tait portable radio.
NB: It is recommended to test the Bluetooth® devices with the Tait portables in the hardware
band and mode of operations that will be used by the end users to assess the adequacy of audio
quality for both the listener and speaker, especially in TDMA mode of operations.
When a wired audio accessory is not connected to the portable radio
TP9300/9400/9500/9600
1. Pair Bluetooth® device(s) to Radio A and/or Radio B depending on configuration and test.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Press and Hold Radio A F2 Programmable PTT and verify Radio B device unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio B device mutes.
5. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
6. Press and Hold Radio A radio PTT and verify Radio B device unmutes and audio is heard.
Release the PTT and verify Radio B device mutes.
7. Press and Hold Radio B radio PTT and verify Radio A speaker unmutes and audio is heard.
Release the radio PTT and verify Radio A speaker mutes.
8. Press and Hold Radio B F2 Programmable PTT and verify Radio A speaker unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio A speaker mutes.

TN-2817c-AN www.taitradio.com Page 9 of 14
9. Repeat the steps above in any other user-specific environments to ensure the audio volume
and clarity is suitable.
TP3350
1. Pair Bluetooth® device (s) to Radio A and/or Radio B depending on the test.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Press and Hold Radio A PTT, speak into Radio A Bluetooth®device and verify Radio B device
unmutes and audio is heard. Release the PTT and verify the Radio B device mutes.
5. Press Radio A F3 to switch audio source/destination.
6. Press and Hold Radio A PTT, speak into Radio A and verify Radio B device unmutes and
audio is heard. Release the PTT and verify the Radio B device mutes.
7. Press and Hold Radio B PTT, speak into Radio B Bluetooth® device and verify Radio A device
unmutes and audio is heard. Release the PTT and verify Radio A device mutes.
8. Press Radio B F3 to switch audio source/destination.
9. Press and Hold Radio B PTT, speak into Radio B and verify Radio A device unmutes and
audio is heard. Release the PTT and verify Radio A device mutes.
10. Repeat these steps in any other user-specific environments to ensure the audio volume and
clarity is suitable.
When a wired audio accessory is connected to the portable radio (optional)
NB: When a wired audio accessory is connected to the radio accessory connector, the radio speaker
is disabled.
TP9300/9400/9500/9600
1. Pair Bluetooth® device(s) to Radio A and/or Radio B depending on configuration and test.
2. Ensure both radios are on the same channel.
3. Connect the wired audio accessory to Radio A. NB: Ensure the radio is configured for wired
audio accessory usage via Global > PTT > External PTT (1) > Advance EPTT1 > Audio Source
= Aux Mic.
4. Wear the paired and connected Bluetooth® device for Radio A.
5. Press and Hold Radio A F2 Programmable PTT and verify Radio B device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio B device mutes.
6. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
7. Press and Hold Radio A wired audio accessory PTT and verify Radio B device unmutes and
audio is heard. Release the PTT and verify Radio B device mutes.

TN-2817c-AN www.taitradio.com Page 10 of 14
8. Press and Hold Radio B radio PTT and verify Radio A wired audio accessory speaker unmutes
and audio is heard. Release the radio PTT and verify Radio A audio accessory speaker mutes.
9. Press and Hold Radio B F2 Programmable PTT and verify Radio A wired audio accessory
speaker unmutes and audio is heard. Release the F2 Programmable PTT and verify Radio A
wired audio accessory speaker mutes.
10. Repeat the steps above in any other user-specific environments to ensure the audio volume
and clarity is suitable.
1.5.5 Recovery after Power Cycle
Purpose: Recovery after power cycle of the portable radio and/or Bluetooth® device.
Power-Cycle Radio without Automatic Reconnection
TP9300/9400/9500/9600
1. Pair Bluetooth® device(s) to Radio A and/or Radio B depending on configuration and test.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Press and Hold Radio A F2 Programmable PTT and verify Radio B unmutes and audio is
heard on the expected speaker (radio speaker or device speaker). Release F2
Programmable PTT and verify Radio B speaker mutes.
5. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
6. Radio A performs a ‘hard’power-cycle by disconnecting and reconnecting the battery.
7. Press and Hold Radio A F2 Programmable PTT and verify Radio B does not unmute.
Release the F2 Programmable PTT.
8. Press and Hold Radio B F2 Programmable PTT and verify Radio A speaker unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio A speaker mutes.
9. Press and Hold Radio A radio PTT and verify Radio B unmutes and audio is heard on the
expected speaker
10. Press F4 on Radio A.
11. Follow the radio UI prompts until the device is connected.
12. Press and Hold Radio A F2 Programmable PTT and verify Radio B device unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio B device mutes.
13. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and
audio is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
TP3350
Not applicable

TN-2817c-AN www.taitradio.com Page 11 of 14
Power-Cycle Radio with Automatic Reconnection
TP9300/9400/9500/9600
1. Pair Bluetooth® device(s) to Radio A and/or Radio B depending on configuration and test.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Press and Hold Radio A F2 Programmable PTT and verify Radio B unmutes and audio is
heard on the expected speaker. Release the F2 Programmable PTT and verify Radio B mutes.
5. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
6. Radio B performs a ‘hard’ power-cycle by disconnecting and reconnecting the battery.
7. Respond to the Bluetooth® device prompt to connect on Radio B.
8. Press and Hold Radio A F2 Programmable PTT and verify Radio B device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio B device mutes.
9. Press and Hold Radio B F2 Programmable PTT and verify Radio A device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio A device mutes.
TP3350
1. Pair Bluetooth® device(s) to Radio A and/or Radio B depending on the test.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Press and Hold Radio A PTT and verify Radio B device unmutes and audio is heard. Release
PTT and verify Radio B device mutes.
5. Press and Hold Radio B PTT and verify Radio A device unmutes and audio is heard. Release
PTT and verify Radio A device mutes.
6. Radio A performs a ‘hard’ power-cycle by disconnecting and reconnecting the battery. The
device should automatically reconnect to Radio A.
7. Press and Hold Radio A PTT and verify Radio B device unmutes and audio is heard. Release
PTT and verify Radio B device mutes.
8. If the device doesn’t reconnect automatically, on Radio A, search devices (Menu > Accessories
Bluetooth > My devices > Search devices).
9. Follow the radio UI prompts until the device is connected.
10. Press and Hold Radio A PTT and verify Radio B device unmutes and audio is heard. Release
PTT and verify Radio B device mutes.
11. Press and Hold Radio B PTT and verify Radio A device unmutes and audio is heard. Release
PTT and verify Radio A device mutes.

TN-2817c-AN www.taitradio.com Page 12 of 14
Power-Cycle Bluetooth® Device
TP9300/9400/9500/9600
1. Pair Bluetooth® device to Radio B.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth® device.
4. Radio B device to be power-cycled (as per manufacturer’s instructions).
5. Wait until the device has automatically connected.
6. Press and Hold Radio B F2 Programmable PTT and verify Radio A unmutes and audio is
heard on the expected speaker. Release the F2 Programmable PTT and verify Radio A
mutes.
7. Press and Hold Radio A F2 Programmable PTT and verify Radio B device unmutes and audio
is heard. Release the F2 Programmable PTT and verify Radio B device mutes.
TP3350
1. Pair Bluetooth® device(s) to Radio A and Radio B.
2. Ensure both radios are on the same channel.
3. Wear the paired and connected Bluetooth device.
4. Radio A device to be power-cycled (as per manufacturer’s instructions).
5. Press and Hold Radio A PTT and verify Radio B device unmutes and audio is heard. Release
the PTT and verify Radio B device mutes.
6. Press and Hold Radio B PTT and verify Radio A device unmutes and audio is heard. Release
PTT and verify Radio A device mutes.

TN-2817c-AN www.taitradio.com Page 13 of 14
Further Reference Information
If you have any queries or issues in regards to the basic configuration of the Bluetooth® device you are
trying to configure and connect to your radio, we recommend that you read and reference where applicable
the Tait Programming Application Online Help files and Portable Radio User’s Guides – in particular the
following sections: ‘Setting up Bluetooth®’ in the Online Help and ‘Using a wireless headset’ in each of the
Radio User’s Guides.
Additional Notes
Please note that if the desired radio configuration and use includes a Wired PTT Accessory, repeat steps in
Section 1.5 using a Wired PTT Accessory on EPTT1 (AUX).
If all the tests are successful, and there is no obvious usability or performance issues, then the basic
functionality of the Bluetooth® device under test is deemed acceptable.
Copyright and Trademarks
All information contained in this document is the property of Tait International Limited. All rights reserved.
This manual may not, in whole or in part, be copied, photocopied, reproduced, translated, stored, or
reduced to any electronic medium or machine-readable form, without prior written permission from Tait
International Limited.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth® SIG, Inc, and any
use of such marks by Tait International Limited is under licence.
The word TAIT and the TAIT logo are trademarks of Tait International Limited.
Other trademarks and trade names referenced are those of their respective owners.
Contact Information
Tait International Limited
P.O. Box 1645
Christchurch
New Zealand
For addresses and telephone numbers of regional offices refer to https://www.taitradio.com/contact/

TN-2817c-AN www.taitradio.com Page 14 of 14
Publication Information
Related
Documentation
TD-0016-04 –TP3350 TP9300 TP9400 Bluetooth® Functionality
TN-3022-SR - TP3000 Firmware Release 1.04.00
TN-3154 –Bluetooth Device Known Limitations
Compliance Issues
None.
Compatibility Issues
None.
Confidentiality
Confidential –This message or document contains proprietary information
intended only for the person(s) or organization(s) to whom it is addressed.
All recipients are legally obliged to not disclose Tait technological or
business information to any persons or organizations without the written
permission of Tait.
Distribution Level
Associate.
Document History
Issue
Date
Description
Author
-
25 September 2018
First release
TP9300 TP9400
M Down
J Way
b
20 June 2019
Added TP3350
T Osten
c
2 August 2021
Added TP9500 and
TP9600 models, and
improved test case
coverage for TP9300
/ 9400 / 9500 / 9600
K Tan
