TMAA03-09/TMAA03-12 Plinth Installation Kit
Installation Instructions
Introduction
The TMAA03-09 plinth installation kit (for 25W radios) and the TMAA03-12 plinth
installation kit (for 30–50W radios) are used for desktop installation of mobile radios.
The plinth can be placed on the desk or on the TMAA13 power supply.
The plinth installation kits are
supplied with an 8 foot (2.5m)
power cable, four thumb screws to
attach the mobile radio and a
microphone clip (with screws and
washers).
The connector plug on the power
cable differs for 25W and 30–
50W mobile radios. Ensure that
you have the plinth installation kit
that is appropriate for your radio.
Installation
Mounting the microphone clip
The microphone clip can be mounted on
either side of the plinth, allowing for left-
handed or right-handed use.
■Mount the microphone clip to the side of
the plinth with the supplied screws and
washers.
power cable
4 thumb screws
plinthmicrophone clip
3 screws
3 washers
microphone clip
mounting holes microphone clip

2TMAA03-09/TMAA03-12 Plinth Installation Kit
© Tait Limited May 2012
Mounting the radio on the plinth
1 Position the radio in the plinth so that
the mounting holes in the plinth line up
with the holes in the radio chassis.
2 Fasten the radio with the four thumb
screws.
Connecting the power supply to
the radio
1 Disconnect the power supply from the
mains supply.
2 Connect the power cable’s positive wire
(red) to the positive terminal (red) and
connect the negative wire (black) to the
negative terminal (black) of the power
supply.
3 Re-connect the power supply to the
mains supply.
To complete the installation
1 If an external speaker is required, connect it as described in the installation documenta-
tion for the speaker.
2 Connect the antenna to the radio.
3 Connect the power supply to the mains supply and switch it on.
4 Make sure that the power indicator in the switch illuminates. If the indicator fails to
light up, check the connection and mains power outlet. If the problem persists, refer to
the documentation of the power supply.
5 Connect the radio’s antenna.
6 Turn on the radio and make sure that it operates satisfactorily, as described in the user
documentation for the radio.
More Information
Refer to your radio provider for more information about this product.
thumb screws
supply wires 30–50W power connector
25W power connector
