TALARIA STING TL3000 L1E User manual

Talaria-Owner’s-Manual-Sting
TALARIA POWER TECH (CHONGQING)CO, LTD.

TALARIA POWER TECH (CHONGQING) CO., LTD.
STING TL3000 L1E Owner’s Manual

TALARIA POWER TECH (CHONGQING) CO., LTD.
Contents
I. Itroduction........................................................................................................ 1
(I) Introduction............................................................................................................1
(II) About This Manual............................................................................................... 1
II. Useful Information for Safe Riding.................................................................... 2
(I) Useful Information for Safe Riding....................................................................... 2
III. Identification Numbers...................................................................................... 3
(I) Electric motorcycle Identification Number............................................................3
(II) Motor Identification Number................................................................................4
IV. General Information........................................................................................... 5
(I) Major Technical Parameters...................................................................................5
(II) Electric motorcycle Outline Parameter.................................................................7
(III) Electrical Diagram...............................................................................................8
V. Safety Information................................................................................................9
(I) Position Diagram of Anti-Theft Alarm.................................................................. 9
(II) General Safety Precautions.................................................................................10
(III) Position of Warning Signs................................................................................. 11
VI. Controls and Components................................................................................12
(I) Handlebar Controls.............................................................................................. 12
(II) Diagram of Dash.................................................................................................13
(III) Top View............................................................................................................16
(IV) Left Side View...................................................................................................17
(V) Right Side View..................................................................................................18
VII. Starting and Operating Diagram................................................................. 19
(I) Pre-ride Inspection............................................................................................... 19
(II) Riding Operation................................................................................................ 20
VIII. Charging and Battery Information..............................................................23
(I) Definition of charging through the battery discharge port...................................23
(II) Battery charging and charger usage....................................................................24
(III) Remove the Battery........................................................................................... 27
(IV) Install the Battery.............................................................................................. 28
IX. Troubleshooting.................................................................................................29
(I) Precautions for Electric Motorcycle.................................................................... 29
(II) General Troubleshooting.................................................................................... 30
(III) Dash Fault Code and Description and Troubleshooting....................................31
X. After-sale Service................................................................................................ 41
(I) Warranty Description........................................................................................... 41
(II) User's Note..........................................................................................................41
XI. Maintenance Service.........................................................................................43
(I) Owner's Responsibilities...................................................................................... 43
(II) Scheduled Inspection.......................................................................................... 43
XII. Service and Maintenance Record Card........................................................ 52
Maintenance Items.................................................................................................... 52
Maintenance Record Card.........................................................................................53
Customer Information Card...................................................................................... 52

TALARIA POWER TECH (CHONGQING) CO., LTD.
I. Introduction
—
1
—
(I) Introduction
Dear Customer,
Thank you for choosing our products. We will be truly grateful if
you can give us any opinions or suggestions about the products. Your
satisfaction is our ultimate goal.
As a professional designer and manufacturer of electric electric
motorcycles, we develop and produce electric electric motorcycles
featuring innovative appearance, comfortable riding experience, easy
operation, strong power, long endurance mileage, and high safety and
reliability, making them a new generation of ideal eco-friendly
transportation and entertainment tool. In order to ensure favorable
services of the electrical electric motorcycle, please read the Owner’s
Manual carefully beforehand, so you can fully understand the
performance, operation and maintenance of the electric motorcycle
and make sure that the electric motorcycle is operating with
maximum performance, less failure and longer service life.
Do not lend the electric motorcycle to persons that are unable to
ride. Always wear a helmet when using this electric motorcycle.
Follow the traffic regulations strictly and ride in the slow lane.
Slowdown in rainy and snowy days and on slippery roads, and
keep a safe following distance to ensure safety.
We are constantly improving our products, so the products
delivered to the customers may be different from those described
herein. We reserve the right of final interpretation.
For 24-hour updates and additional information about your
motorcycle, visit the official TALARIA POWER TECH website:
http://www.talaria.cn
(II) About This Manual
This manual is only used for TL3000 L1E Electric Motorcycle
produced by Talaria. It covers the information on electric motorcycle
introduction, usage, troubleshooting, after-sales and maintenance for
the electric motorcycle.
A good place to locate information about the motorcycle is in the
index of the manual.
The terms "right" or "left" refer to the rider's right or left when sitting
on the motorcycle.
1

TALARIA POWER TECH (CHONGQING) CO., LTD.
II. Useful Information for Safe Riding
—
2
—
(I) Useful Information for Safe Riding
This manual contains the word WARNING to indicate
something that could hurt you or others. It also contains the
word CAUTION to indicate things that could damage your
electric motorcycle.
CAUTION! Please read this manual carefully and
completely before operating this electric motorcycle. Do not
attempt to operate this electric motorcycle until you have
attained adequate knowledge of its controls and operating
features and have been trained in safe and proper riding
techniques. Regular inspections and proper maintenance,
along with good riding skills, help you safely enjoy the
capabilities and the reliability of this electric motorcycle.
Disregarding the aforementioned, however, may render
the warranty invalid.
This symbol is located in various locations on the
electric motorcycle to inform you
that exposure to high voltage can
cause shock, burns and even death.
The high voltage components
on the electric motorcycle should be
serviced only by technicians
receiving special training. High
voltage cable or wiring has an orange covering. Do not
probe, tamper with, cut, or modify high voltage cable or
wiring.
2

TALARIA POWER TECH (CHONGQING) CO., LTD.
II. Useful Information for Safe Riding
—
3
—
(I) Electric motorcycle Identification Number
Caution: For convenient maintenance, repair and service, each of our electric motorcycle has a unique Electric
motorcycle Identification Number and motor number, so the dealer can provide you with better services.
The Electric motorcycle Identification Number (VIN) is a 17-digit number located on the right side of the vertical tube
of the frame. Do not alter or remove this number as it is the legal identifier for your moped.
VIN Breakdown will help you understand the significance of each digit or character.
3

TALARIA POWER TECH (CHONGQING) CO., LTD.
III. Identification Numbers
4
—
4
—
(II) Motor Identification Number
The Motor Identification Number is stamped on the motor shell (2).
☆182ZW6043407NA☆; internal management code in another line: electric motorcycle model (6
digits) + manufacturing year, month and day (2 digits respectively) + manufacturer identification number (1
digit) + serial number (4 digits):
For example, ☆TL3000-21042010001☆
Motor Identification Number
4

TALARIA POWER TECH (CHONGQING) CO., LTD.
IV. General Information
—
5
—
(I) Major Technical Parameters
The Technical Parameter List will help you get to know your moped in depth.
PARAMETER
ITEM
PARAMETER
VALUE
Electric
motorcycle
Dimension
1890mm
×
815mm
×
1155mm
Wheelbase
1250mm
Electric
motorcycle
Weight
55kg
(exclude
battery)
/68kg
(Include
battery)
Max.
Load
100kg
Min.
Ground
Clearance
300mm
Seat
Height
870mm
Rake
26
°
Max.
Climb
Ability
70%
EEC
Homologation
Limited
Top
Speed
45km/h
(or
25km/h)
Rated
Motor
Output
Power
3000W
E
EC
Homologation
Limited
Motor
Output
Power
3
500W
(or
1500W)
Peak
Motor
Output
Power
6000W
Peak
Drive
Sprocket
Output
Power
34N.m
Battery
Pack
60V38Ah
L
ithium-ion
battery
pack
Range
/
Charge
70km
@
45km/h;
100km
@25km/h
Charging
Time
3.5-4.5h
(depending
on
the
charger)
Charger
Input
Voltage
110V
/
230V
(depending
on
the
charger)
Optional
Riding
Modes
Economy/sports
mode
Rim
Size
Fr.:
1.9
×
14;
Rr.:1.9
×
16
Tire
Size
Fr.:
70/100-19;
Rr.:
80/100-19
5

TALARIA POWER TECH (CHONGQING) CO., LTD.
IV. General Information
—
6
—
Front Fork Adjustable hi-performance dual crown fork with 200mm
travel
Rear
Suspension
Adjustable
85mm
travel
shock
absorber
with
linkage
Brake
Fr.
&
Rr.
Hydraulic
disc
brakes
1
st
Transmission
Hi-efficiency
quiet
running
gearbox
2
nd
Transmission
Chain
(420-106)
Lamps
Type
LED
Dash Type TFT
6

TALARIA POWER TECH (CHONGQING) CO., LTD.
IV. General Information
—
7
—
(II) Electric motorcycle Outline Parameter
7

TALARIA POWER TECH (CHONGQING) CO., LTD.
IV. General Information
—
8
—
(III) Electrical Diagram
8

TALARIA POWER TECH (CHONGQING) CO., LTD.
V. Safety Information
9
—
9
—
(I) Position Diagram of Anti-Theft Alarm
1. Ignition Switch: Turn the key clockwise, and the whole electric
motorcycle is powered on; turn it anticlockwise, and the whole
electric motorcycle is powered off, and then remove the key.
2. Steering Lock: Turn the handlebar to the leftmost position, insert
the key and turn it anticlockwise to lock the steering, and then
remove the key; insert the key and turn it clockwise to unlock the
steering, and then remove the key.
3. Battery Case Lock: Insert the key and turn it anticlockwise, and
then open the Battery Case Lock.
9

TALARIA POWER TECH (CHONGQING) CO., LTD.
V. Safety Information
10
—
10
—
(II) General Safety Precautions
Please follow the traffic rules and maintain a safe running speed. (The maximum speed is 45km/h or 25km/h depend
the version you order)
Before operating the electric motorcycle, please read this manual and practice in an open and safe place, so you can
master the riding skills and be familiar with the structure of this electric motorcycle. This is the basis of safe riding.
CAUTION!
Persons not skilled in or unable to ride should not use this electric motorcycle. It is extremely dangerous to ride with a
single hand or no hand on the handlebar, or after drinking alcohol. Wet roads in rainy or snowy days are also very dangerous.
Do not ride at high speed. Be careful when turning. Use the brake in advance at any abnormal circumstances to prevent any
accidents. Wear qualified helmet and buckle the fasteners.
Wear loose clothes in bright color with no puff sleeves to make sure you can move freely. Do not wear slippers or high
heels.
Avoid heavy load. The control feeling is different to ride with and without load. Too heavy load will severely influence
the operating and may put you in danger. Only 1 passenger is allowed on this motorcycle. Additional ones may cause safety
risks and component damage.
10

TALARIA POWER TECH (CHONGQING) CO., LTD.
V. Safety Information
11
—
11
—
(III) Position of Warning Signs
11

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
12
—
(I) Handlebar Controls
1-1 Horn button
1-2 Dash (see the next page for instructions)
1-3 Starting button, the assembly of throttle. Trigger the button before normal starting of the electric motorcycle, and it is
allowed to run when the instrument shows READY.
1-4 Oil level sightglass
Special note:
a. At the "ECO" mode, the electric motorcycle is set at the running mode of limited power and maximum speed, which is
suitable for beginners and the need of longer battery life.
b. At the "SPORT" mode, the electric motorcycle is set to full-power output, which is suitable for entertainment and off-road
riding.
c. To avoid overcharge and protect the battery, energy recovery intervenes only when battery SOC is below 90%.
12

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
13
—
(II) Diagram of Dash
Functions of the dash buttons:
3-1 The button 1 can be used for display switch among RT SPEED, AVG SPEED, MAX SPEED, TIME and ODO after
entering the main interface. It can also be used to exit the current setting dialog box after entering the setting interface.
3-2 Setting button: Press for 2 times to enter the setting interface, as shown in Figs. 3 and 4. Press the buttons 3 and 4 to
select the upper and lower option, press the button 2 to enter the selected setting dialog box, press the buttons 3 and 4 again
to select the parameters and set the parameters using the button 2. Press the button 1 to exit the current parameter setting
interface, and press the button 2 for 2 times to directly enter the main interface. (During riding, the button 2 cannot be used
to enter the setting interface). Press the button 2 for more than 1s, and the USB icon of the dash is on, and the USB port is
available (Note: The drive capacity of the port is 5V/500mA; higher capacity may damage the USB port).
1
2
2
3
3
4
4
1
5
5
6
6
7
7
8
8
9
9
10
10
11
11
12
12
Instrument
Dash buttons
Main
interface
Instrument
Dash setting interface 1 Instrument
Dash setting interface 2
13

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
14
—
3-3 After entering the main interface, the buttons 3 and 4 can be used to set the grade of kinetic energy recovery. Press the
button 3 to decrease the grade within the scope of grade 4 to 0; press the button 4 to increase the grade within the scope of
grade 0 to 4. Grade 4 indicates that the motor has the maximum drive towards the tire, and grade 0 indicates no energy
recovery.
Display of the dash interface:
3-4 Number 5: battery power.
3-5 Number 6: charging icon (Bluetooth and wifi icons will be used, but not enabled yet).
3-6 Number 7: riding mode (ECO\SPORT).
3-7 Number 8: failure icon.
3-8 Number 9: energy consumption.
3-9 Number 10: electric motorcycle status (WAIT\READY).
3-10 Number 11: grades of energy recovery (0, 1, 2, 3 and 4). The arrows for grade 0 circulation are in white; the arrows for
grade I circulation are in light blue, and the corresponding I symbol is in light blue and the others in white; the arrows for
grade II circulation are in light blue, and the corresponding II symbol is in light blue and the others in white; the arrows for
grade III circulation are in light blue, and the corresponding III symbol is in light blue and the others in white; the arrows
for grade IV circulation are in light blue, and the corresponding IV symbol is in light blue and the others in white.
3-11 Number 12: real-time riding speed. Press the button 1 to switch the display of RT SPEED, AVG SPEED, MAX SPEED,
TIME and ODO.
14

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
15
—
Dash setting interface:
3-12 Brightness: adjust brightness of the dash backlight from grade 1 to 5, in which grade 1 is lowest and grade 5 is the
highest.
3-13 Clock: dash time setting.
3-14 System: system setting, including metric and imperial unit display, power display in percentage or voltage, gear ratio
and energy recovery. The operating steps are as follows: enter the System option, press the buttons 3 and 4 to skip among
the setting items, press the button 2 to select them, then press the buttons 3 and 4 again to set the parameters, and press the
button 2 to confirm the setting.
3-15 Auto off: not available yet.
3-16 Wheel: wheel diameter.
3-17 Advance setting: not available yet.
3-18 Battery: battery information.
3-19 Factory Setting: restore factory setting.
3-20 Password: not available yet.
3-21 Information: Basic information, including AVG SPEED, MAX SPEED, TRIP and ODO.
3-22 Screen direct: not available yet.
3-23 Exit: exit the setting interface, which can also be achieved by pressing the button 2 for 2 times.
15

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
16
—
(III) Top View
3-1 Front Right Turn Signal
3-2 Front Brake Lever
3-3 Right Rearview Mirror
3-4 Right Handlebar Grip (Plus throttle)
3-5 Ignition Switch
3-6 Battery Case Cover
3-7 Footpeg
3-8 Seat
3-9 Rear Right Turn Signal
3-10 Front Left Turn Signal
3-11 Rear Brake Lever
3-12 Left Rearview Mirror
3-13 Left Handlebar Grip
3-14 Side Kickstand
3-15 Rear Left Turn Signal
16

TALARIA POWER TECH (CHONGQING) CO., LTD.
VI. Controls and Components
—
17
—
(IV) Left Side View
4-1 Headlight
4-2 Front Fork
4-3 Left Reflector
4-4 Front Fender
4-5 Front Wheel
4-6 Front Disc Brake Disc
4-7 Front Disc Brake Pump
4-8 Battery Charging Port
4-9 Controller
4-10 Motor Protective Cover
4-11 Gearbox Decorating Cover
4-12 Rear Fork
4-13 Rear Wheel Fender
4-14 Rear Fender
4-15 Rear Disc Brake Pump
4-16 Rear Disc Brake Disc
4-17 Rear Wheel
17
