T&C TC36ST User manual

082406-40 TC36.CSTE 5056.42801.C
WARNING: If the information in this
manual is not followed exactly, a re or
explosion may result causing property
damage, personal injury or loss of life.
-- Do not store or use gasoline or other
ammablevaporsandliquidsinthevicinity
of this or any other appliance.
-- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Donottouchany electrical switch; do
not use any phone in your building.
• Immediately call your gas supplier
from a neighbour’s phone. Follow
the gas supplier’s instructions.
• Ifyoucannot reach yourgassupplier,
call the re department.
--Installation and service must be
performed by a qualied installer, service
agency or the gas supplier.
FOR YOUR SAFETY
IMPORTANT:
THESE INSTRUCTIONS ARE TO
REMAIN WITH THE
HOMEOWNER
INSTALLATION
AND OPERATING
INSTRUCTIONS
MODEL TC36ST
SERIES C
MODULAR
DIRECT VENT
SEE-THRU FIREPLACE
This appliance may be installed in
an aftermarket permanently located,
manufactured home (USA only) or mobile
home,where notprohibitedbylocalcodes.
This appliance is only for use with the
type of gas indicated on the rating plate.
This appliance is not convertible for use
with other gases, unless a certied kit is
used.

2 TC36.CSTE 082406-40
Contents
CAUTION............................................................................................................................ 3
SAFETY .............................................................................................................................. 3
FIREPLACE DIMENSIONS ................................................................................................ 3
MINIMUM CLEARANCES TO COMBUSTIBLES .............................................................. 5
MANTEL CLEARANCE CHART ........................................................................................ 5
INSTALLATION REQUIREMENTS.................................................................................... 6
TOP STANDOFFS.............................................................................................................. 6
LOCATING THE FIREPLACE............................................................................................ 6
FRAMING AND FINISHING................................................................................................ 7
STEEL STUD FRAMING KIT DIMENSIONS ...............................................................................7
CONCRETE BOARD DETAIL ......................................................................................................8
MINIMUM COMBUSTIBLE FRAMING DIMENSIONS .................................................................8
RECESSED INSTALLATION DETAIL .........................................................................................8
MAESTRO CONTROL SYSTEM........................................................................................ 9
INSTALLATION ............................................................................................................................9
BURNER INSTALLATION..........................................................................................................10
PROPANE CONVERSION..........................................................................................................11
STANDING PILOT FUNCTION ..................................................................................................13
CONTROL SYSTEM (REMOTE CONTROL SETUP) ................................................................13
INITIAL SETTINGS ....................................................................................................................15
CHILDPROOF LOCK..................................................................................................................15
CONTROL SYSTEM - OPERATION ..........................................................................................15
MANUAL MODE ........................................................................................................................15
COUNTDOWN TIMER MODE ...................................................................................................15
PROGRAM MODE .....................................................................................................................15
THERMOSTATIC MODE ............................................................................................................17
ACTIVATE A SET POINT TEMPERATURE...............................................................................17
HEARTH EXTENSION...................................................................................................... 18
VENTING .......................................................................................................................... 18
WALL TERMINATION VENTING ...............................................................................................19
WALL TERMINATION VENTING CHART..................................................................................21
ROOF TERMINATION VENTING CHART..................................................................................22
ROOF TERMINATION VENTING ...............................................................................................23
VENT PIPE SEALANT................................................................................................................24
VENT TERMINAL CLEARANCE................................................................................................25
VENT RESTRICTOR ADJUSTMENT .........................................................................................27
MANUFACTURED (MOBILE) HOME.........................................................................................27
GAS SUPPLY ................................................................................................................... 28
WINDOW FRAME REMOVAL.......................................................................................... 29
FIREBOX PANELS INSTALLATION ............................................................................... 30
LIGHTING INSTRUCTIONS ............................................................................................. 31
FIRST FIRE.................................................................................................................................31
APPENDIX A .................................................................................................................... 32
MAINTENANCE................................................................................................................ 32
REPLACEMENT PARTS............................................................................................................33
REPLACEMENT PARTS - MAESTRO CONCEALED VALVE ..................................................34
ROOF TERMINATION KIT .........................................................................................................35
WALL TERMINATION KIT .........................................................................................................35
WALL SHIELD/CEILING FIRESTOP THIMBLE ........................................................................35
VENT PIPE DIMENSIONS..........................................................................................................36
VENT OFFSET CHART ..............................................................................................................37
STEEL STUD FRAMING KIT......................................................................................................38
SAFETY LABEL LOCATION......................................................................................................40

082406-40 TC36.CSTE 3
CAUTION
FOR YOUR SAFETY - Do not install or operate your Town
and Country replace without rst reading and understanding
this manual. Any installation or operational deviation from the
following instructions voids the Town and Country FireplacesTM
Warranty and may prove hazardous.
This appliance and its individual shutoff valve must be discon-
nected from gas supply piping system during any pressure
testing of that system at test pressures in excess of 1/2 psig
(3.5 kPa).
This appliance must be isolated from the gas supply piping
system by closing its individual manual shutoff valve during
any pressure testing of the gas supply piping system at test
pressures equal to or less than 1/2 psig (3.5 kPa).
Note: When lit for the rst time, the appliance will emit
a slight odour for a couple of hours. This is due to the
curing of paints, sealants and lubricants used in the
manufacturingprocess.Thiscondition istemporary. Open
doors and windows to ventilate area. Smoke and fumes
caused by the curing process may cause discomfort to
some individuals.
Do not use the replace if any part has been under water.
Immediately call a qualied service technician to inspect the
replace and to replace any part of the control system and
any gas control which has been under water.
SAFETY
Due to high temperatures, this gas appliance should be located
out of trafc and away from furniture and draperies.
Children and adults should be alerted to the hazards of high
surface temperatures and should stay away to avoid burns
or clothing ignition.
Young children should be carefully supervised when they are
in the same room as the appliance.
Clothing or other ammable material should not be placed on
or near the appliance.
Any grill, panel or door removed for servicing the unit must
be replaced prior to operating. Failure to do so may create a
hazardous condition.
Installation and repair should be done by a qualied service
person. The appliance should be inspected before use and
at least annually by a professional service person. More
frequent cleaning may be required due to excessive lint from
carpeting, bedding material, etc. It is imperative that control
compartments, burners and circulating air passageways of
the appliance be kept clean.
It is our policy that no responsibility is assumed by the Company
or by any of its employees or representatives for any damages
caused by an inoperable, inadequate, or unsafe condition
which is the result, either directly or indirectly, of any improper
operation or installation procedures.
Fig # 1
FIREPLACE DIMENSIONS
TOP
STANDOFFS
CENTER OF FLUE OUTLET
TOP VIEW SIDE VIEW FRONT VIEW

4 TC36.CSTE 082406-40
IMPORTANT NOTE FOR THE COMMONWEALTH OF MASSACHUSETTS
From Massachusetts Rules and Regulations 248 CMR 5.08:
(a) For all side wall horizontally vented gas fuelled equipment installed in every dwelling, building or structure used in
whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall
exhaust vent termination is less than seven (7) feet above nished grade in the area of the venting, including but not limited to
decks and porches, the following requirements shall be satised.
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of the side wall horizontal vented
gas fuelled equipment, the installing plumber or gastter shall observe that a hard wired carbon monoxide detector with an
alarm and battery back-up is installed on the oor level where the gas equipment is to be installed, in addition, the installing
plumber or gastter shall observe that a battery operated or hard-wired carbon monoxide detector with an alarm is installed on
each additional level of the dwelling, building or structure served by the side wall horizontal vented gas fuelled equipment. It
shall be the responsibility of the property owner to secure the services of qualied licensed professionals for the installation of
hard-wired carbon monoxide detectors.
a. In the event that the side wall horizontally vented gas fuelled equipment is installed in a crawl space or an attic, the
hard-wired carbon monoxide detector with alarm and battery back-up may be installed on the next adjacent oor level.
b. In the event that the requirements of this subdivision cannot be met at the time of completion of installation, the owner
shall have a period of thirty (30) days to comply with the above requirements; provided, however, that during said thirty (30)
day period, a battery operated carbon monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as required in accordance with
the above provisions shall comply with NFPA 720 and be ANSI/UL 2034 listed as IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be permanently mounted to the exterior of the building at a
minimum height of eight (8) feet above grade directly in line with the exhaust vent terminal for the horizontally vented gas
fuelled heating appliance or equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS VENT
DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas fuelled equipment shall not
approve the installation unless, upon inspection, the inspector observes carbon monoxide detectors and signage installed in
accordance with the provisions of 248 CMR 5.089(2)(a) 1 through 4.
(b) EXEMPTIONS. The following equipment is exempt from 248 CMR 5.089(2)(a) 1 through 4.
1. The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented” in the most current edition of
NFPA 54 as adopted by the Board; and
2. Product Approved side wall horizontal vented gas fuelled equipment installed in a room or structure separate from the
dwelling, building or structure used in whole or in part for residential purposes.
(c) MANUFACTURER REQUIREMENTS – GAS EQUIPMENT VENTING SYSTEM PROVIDED. When the manufac-
turer of Product Approved side wall horizontally vented gas equipment provides a venting system design or venting system
components with the equipment, the instructions provided by the manufacturer for installation of the equipment and the venting
system shall include:
1. Detailed instructions for the installation of the venting system design or the venting system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS – GAS EQUIPMENT VENTING SYSTEM NOT PROVIDED. When the manu-
facturer of a Product Approved side wall horizontally vented gas fuelled equipment does not provide the parts for venting the
fuel gases, but identies “special venting systems”, the following requirements shall be satised by the manufacturer.
1. The referenced “special venting system” instructions shall be included with the appliance or equipment installation
instructions; and
2. The “special venting systems” shall be Product Approved by the Board, and the instructions for that system shall
include a parts list and detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally vented gas fuelled equipment, all
venting instructions, all parts lists for venting instructions, and/or all venting design instructions shall remain with the appliance
or equipment at the completion of the installation.

082406-40 TC36.CSTE 5
A 9" D 12"
B 6" E 6 3/4"
C 3" F 1 1/2"
MINIMUM CLEARANCES TO
COMBUSTIBLES
Side standoffs...................... 0 in. (0 mm)
Back standoffs..................... 0 in. (0 mm)
Top standoffs....................... 0 in. (0 mm)
Bottom of appliance............. 0 in. (0 mm)
Adjacent side wall................ 2 in. (51 mm)
Ceiling to appliance ........... 24 in. (610 mm)
*Mantel to appliance ..........See Figure #2
**Maximum
mantel extension ..........See Figure #2
Mantel support..................... 2 in. (51 mm)
Vertical vent pipe........... 1-3/4 in. (45 mm)
Horizontal vent pipe
Top ........................... 1-3/4 in. (45 mm)
Sides ........................ 1-3/4 in. (45 mm)
Bottom ...................... 1-3/4 in. (45 mm)
Fig. # 3
CEILING
ADJACENT
WALL OR
MANTEL
SUPPORT
MANTEL
UNIT MAY BE RECESSED UP TO
6" WITH NON-COMBUSTIBLE
MASONRY TYPE MATERIAL
(SEE FIG. # 9)
COMBUSTIBLE FRAMING
AND FINISH WALL ABOVE
STANDOFFS
MAY USE COMBUSTIBLE
FACING MATERIAL IN THIS
AREA
NON-COMBUSTIBLE
FINISH MATERIAL
SEE FIG #7
TOP
STANDOFFS
STEEL FRAMING
FIREPLACE FRONT
TOP OF LINTEL BAR
MANTEL CLEARANCE CHART
REF. MANTEL
DEPTH
REF.
MANTEL
CLEARANCE
Fig. # 2
NON-COMBUSTIBLE ZONE.
DO NOT INSTALL ANY
COMBUSTIBLE MATERIAL,
ELECTRICAL WIRING OR
GAS PLUMBING IN THIS
AREA.

6 TC36.CSTE 082406-40
INSTALLATION REQUIREMENTS
The Town & Country Fireplace installation and venting must
conform to the current CAN/CGA-B149 installation code (in
Canada) or the current National Fuel Gas Code, ANSI Z223.1
(in the USA), and approved per local codes. Only qualied
(licensed or trained) personnel should install this product.
In the state of Massachusetts, only a licensed Plumber
and Gas Fitter may install this product.
Fig. # 4
Fig. # 5 EXAMPLES OF COMMON LOCATIONS
TOP STANDOFFS
The top standoffs are shipped loose inside the replace and
must be installed on top of the replace as shown in Fig. # 4.
Assembly:
1) Remove the standoffs from inside the replace.
2) Position the standoffs in place and secure with screws
provided.
LOCATING THE FIREPLACE
In planning the installation for the replace, it is necessary to
determine where the unit is to be installed, location of vent
system and where gas supply piping may be plumbed. Vari-
ous installations are possible, such as, into an existing wall,
a built-in wall, peninsula or a partition wall (see Fig. #5). Due
to high temperatures, do not locate this replace in areas of
high trafc or near furniture or draperies.
Theminimum clearancesfromthereplacetocombustible
surfaces must be adhered to and are shown on Fig. # 2
and #3.
CAUTION: When selecting a location, ensure
that there is adequate room on the side of the
replace for the control box.
TOP STANDOFFS
SEE FIG #9 FOR
DIMENSIONS
SEE FIG. # 9
FOR DIMENSIONS

082406-40 TC36.CSTE 7
STEEL STUD FRAMING KIT DIMENSIONS
(TC36.BSFRKITA)
FRAMING AND FINISHING
Note: The replace should be in place and venting in-
stalled before framing in or building an enclosure around
the unit.
The Town & Country Fireplace must be framed in as described
below or totally enclosed with non-combustible material, such
as facing brick.
Determine the total thickness of facing material to be used.
A thickness of 3/4" will allow the nishing surface to be ush
with the front of the unit. If preferred, additional masonry type
non-combustible material can be installed above and to the
sides up to 6 inches proud of the appliance. The nishing
material must not interfere with glass frame access.
Two Steel Stud Framing Kits are supplied with the replace
and must be used unless the replace is totally enclosed with
non-combustible material. Assemble the framing kits as per
their instructions. Attach the steel frame to the replace once
the replace is in its nal position. Secure the steel frame to
the framing brackets on each side of the unit. Ensure that
the studs are set back far enough to allow for thickness of
nishing surface.
The sides and top of the replace can be framed in up to the
steel studs and the replace standoffs using conventional lum-
ber. Consult local building codes for specic requirements.
Due to high temperatures, concrete board is supplied with
the replace and must be used to sheet in the front of the
replace, extending 12" above and 5 3/4" to the side of the
framing edge bars. See gure #7. Standard sheetrock (drywall)
may be used beyond this.
Chase Insulation: When installing this replace against a
non-insulated exterior wall or chase, it is recommended that the
outer walls be insulated to same degree as other exterior walls.
Do not place replace directly against the insulation. Cover the
insulation and plastic vapour barrier with a solid surface, such
as drywall (sheetrock). Consult local codes. Do not insulate
or use plastic vapour barrier within the framing kit.
Fig. # 6
ALL OTHER FRAMING
CAN BE DONE WITH
CONVENTIONAL
LUMBER
NON-COMBUSTIBLE
ZONE. DO NOT INSTALL
ANY COMBUSTIBLE
MATERIAL, ELECTRICAL
WIRING, INSULATION,
PLASTIC VAPOUR
BARRIER OR GAS
PLUMBING WITHIN THE
STEEL STUD FRAMING
NOTE: FOR CLARITY ONLY
ONE FACE OF THE TWO-
SIDEDFIREPLACEISSHOWN
WITH STEEL STUD FRAMING
KITATTACHED.BOTHFACES
MUST BE FRAMED WITH
THE STEEL STUD FRAMING
KIT SUPPLIED WITH THE
FIREPLACE.

8 TC36.CSTE 082406-40
6"
RECESSED INSTALLATION DETAIL
Fig. # 7
Fig. # 9 MINIMUM COMBUSTIBLE FRAMING DIMENSIONS
WARNING: Fireplace should be in its
nal location before framing.
CONCRETE
BOARD
STEEL
STUDS
NON-COMBUSTIBLE
MASONRY TYPE
MATERIAL
Fig. # 8
Concrete board (or other non-combusti-
ble material) must extend 12" above and
7 1/2" to the sides of the framing edges.
CONCRETE
BOARD
CONCRETE BOARD DETAIL

082406-40 TC36.CSTE 9
MAESTRO CONTROL SYSTEM
The gas control system is located on the right hand side of
the rebox behind an access panel and the decorative brick
panel. The replace is operated via a wall switch that can be
located up to 25 ft away from the replace and also by a hand
held remote control unit.
SERVICE CONNECTIONS
1) Locate the replace in the desired location.
2) Remove access panel from right hand side of the rebox
(Fig. #10)
3) Connect a 110v AC electrical supply to the outlet installed
inside the control box (Fig. #11)
4) Connect the gas supply to the valve (Fig. #12)
5) Plug the A/C adaptor into the outlet (Fig. #13)
6) Attach the electrical box for the supplied wall control to the
framing in the desired location (up to 25ft away).
7) Route the control cable as required to the wall control
electrical box.
8) Attach the control cable to the wall control. (Fig. #14)
9) Insert the 4 supplied “AA” batteries into the battery pack
and connect to wall control. (Fig. #15)
10) Fasten the wall switch to the electrical box.
11) Fasten the faceplate to switch
12) Remove the burner from the packaging and install as per
its installation instructions.
Fig. # 10
Fig. # 11
Fig. # 12
Fig. # 13
Fig. # 14
ACCESS PANEL
OUTLET
AC ADAPTER
AC ADAPTER

10 TC36.CSTE 082406-40
13) Turn on the gas supply and check that all connections are
tight and leak free.
14) Turn on gas and electrical supplies.
15) Press the center button on the wall control (Fig. #16). The
igniter will start to spark. After a short delay the pilot will
light, followed by the main burner.
16) Press the up button on the wall control and hold it for 5
seconds or until a clicking sound is heard from the gas
control. Release the button, check manifold pressure and
ensure that it’s correct. (Fig. #17)
17) Press the center button of the wall control. The replace
will shut off.
Note: If you need to test the supply pressure, turn off the
gas supply before removing the blank plug from the supply
pressure test port.
1) Remove the pressure test point plug from the manifold
test port. The plug is located between the right side lintel
and rebox side. (Fig. # 18)
2) Thread the extension piece into the open test port.
(Fig. # 19)
3) Attach a pressure gauge onto the hose barb of the installed
extension piece.
4) After testing remove the pressure gauge and the exten-
sion piece and thread the pressure test pipe plug into
the pressure test port. Thread sealant is required on the
threads and verify that the connections are tight.
Fig. # 15
Fig. # 16
Fig. # 17
Fig. # 18
Fig. # 19

082406-40 TC36.CSTE 11
STANDING PILOT FUNCTION
(only for use where permitted)
The control system on this replace is shipped as a non-stand-
ing pilot replace. If required the system can be converted to
a standing pilot by depressing a recessed button located on
the lower right hand side of the wall control. (Fig. #20) This
should be depressed with a paperclip, pencil or other thin
object. Once activated the pilot will run continuously. Please
check with your local inspector to ensure that this is permit-
ted in your area.
CONTROL SYSTEM (REMOTE CONTROL SETUP)
This replace is supplied with a wall control and hand held
remote control. Please note only genuine Town & Country
Fireplace wall controls and hand held remote controls
can be used on this replace.
1) Initial set up of the hand held remote is required. A “learn”
button is located on the lower left hand side of the wall
switch. This should be depressed with a paperclip, pencil
or other thin object. (Fig. #21)
2) Once this has been pressed, press the center button on
the hand held remote. (Fig. #22) The replace will then
turn on.
3) Turn off the replace by pressing the center button again.
The handset is now synchronized with the replace.
Fig. # 20
STANDING PILOT
BUTTON
Fig. # 21
LEARN BUTTON
Fig. # 22
ON/OFF BUTTON
Fig. # 23
HOLD
A2
FLASHES
DAY
HOUR:
MIN
HOLD
A1

12 TC36.CSTE 082406-40
INITIAL SETTINGS
(time and temperature)
1) Press and hold the A1 and A2 buttons at the same time
until the temperature symbol ashes. (Fig. #22)
2) Use the up and down arrows to set preferred temperature
units. (°F or °C)
3) Press OK and the “hour” value will start to ash.
4) Use the up and down arrows to set the “hour” value.
5) Press OK and the “minute” value will ash.
6) Use the up and down arrows to set the “minute” value.
7) Press OK and the “day” value will ash.
8) Use the up and down arrows to set the “day” value.
9) Press ok to end the initial set up.
CHILDPROOF LOCK
An additional feature of this remote control is the childproof
lock. To activate this system press and hold the timer and
thermostat buttons for approx. 5 seconds until the “lock”
symbol appears on the remote display. (Fig. #24) The remote
control hand set buttons are now locked and the lock symbol
will reappear every time a button is pressed on the remote
control until the timer and thermostat buttons are pressed
and held again.
Note: The replace can still be operated normally using the
wall control even with the remote control buttons locked.
CONTROL SYSTEM - OPERATION
Each Town and Country Maestro Control system comes
equipped with a manual mode on the wall control and hand
held remote, and three programmable modes accessible with
the hand remote.
MANUAL MODE
(on remote and wall control)
Basic operation of the replace can be performed with the
wall control or remote hand set. (ON/OFF, as well as ame
modulation UP/ DOWN).
The center button on the remote control can be used to turn
the replace ON and OFF. With the replace off, press the
center button to turn it on. (The “MAN” and ame icons will be
displayed on the screen) A second push will turn it off. (The
“MAN” and ame icons will disappear from the screen)
When the replace is on, the up and down buttons located
above and below the center button are used to modulate the
ame height. (Fig. #25)
COUNTDOWN TIMER MODE
(Operates the replace for a preset length of time)
1) Press the timer button and the time will ash on the lower
center of the display. (Fig. #26)
2) When display is ashing, use the up and down arrows to set
the length of time you would like the replace to run. (The
range is 10 minutes minimum to 180 minutes maximum).
(Fig. #27)
3) Press the OK button and the timer is set and the control
is in countdown timer mode.
4) To exit the timer mode press the Program, Manual or
Thermostat buttons. Please note that the rst press of the
Manual button will turn the replace off.
PROGRAM MODE
(to preset up to two on and off periods per day)
The program mode has two settings for weekdays and two for
weekends. The hand held remote comes with the following
pre programmed settings:
Fig. # 24
Fig. # 25
HOLD
HOLD
FLAME
DOWN
FLAME
UP
ON/
OFF

082406-40 TC36.CSTE 13
Weekday Program
(Monday through Friday)
Program one (P1) turns ON at 7:00am and turns OFF at
8:00am
Program two (P2) turns ON at 5:00pm and turns OFF at
7:00pm
Weekend Program
(Saturday and Sunday)
Program one (P1) turns ON at 9:00am and turns OFF at
10:00am
Program two (P2) turns ON at 6:00pm and turns OFF at
9:00pm
Activate the programs by pressing the program button on the
lower left hand side of the remote hand set. (Fig. #28)
To customize these setting:
1) Hold the program button down until the display ashes.
(P1, weekday ON time - [Fig. #29])
2) Use the up and down buttons to change the time to the
desired ON time.
3) By pressing the OK button, the P1 weekday OFF time will
ash.
4) Use the up and down buttons to set the desired OFF
time.
5) Press the OK button and the P2 weekday ON time will
ash.
Fig. # 26
Fig. # 27
Fig. # 28
Fig. # 29
TIMER
TIMER RUN
DURATION
PROGRAM

14 TC36.CSTE 082406-40
6) Repeat the process to set the P2 weekday, P1 weekend
and P2 weekend programs.
7) When the P2 OFF time is set and the OK button is pressed
the display will stop ashing and the remote will be in
program mode.
The program settings are now stored in the remote handset
and will not change unless the above process is repeated or
the batteries are removed from the handset.
To switch out of program mode, simply press one of the
manual, timer or thermostat mode buttons. Please note that
if the manual button is pressed it will turn the replace off.
THERMOSTATIC MODE
(Operates the replace within a set temperature range, use
only where permitted.)
The replace is shipped with thermostatic mode function
deactivated. If this function is permitted for use in your area
it can be activated by depressing the recessed button on
the underside of the hand held remote. (Fig. #30) Once
activated, the thermostat symbol (Fig. #31) will be displayed
when the thermostat button is pressed
Fig. # 30
Fig. # 31
Fig. # 32
Fig. # 33
THERMOSTATIC
MODE BUTTON
DEACTIVATED
THERMOSTAT
SYMBOL
THERMOSTAT
BUTTON
TEMPERATURE
SETTING
ACTIVATE A SET POINT TEMPERATURE
1) Press the thermostat button on the lower right hand side
of the hand held remote to activate the thermostat mode.
(Fig. #32) The temperature and thermostat symbols will
appear.
2) Press and hold the thermostat button for 5 seconds. The
temperature icon on the display will ash. (Fig. #33)
3) While the temperature icon is ashing use the up and down
arrows to set the temperature to the desired setting.
4) Once the desired setting is reached, press the OK button.
If the OK button is not pressed the icon will continue to
ash for 5 seconds and then set itself to the temperature
displayed.
5) The replace is now in thermostatic mode. To exit the
thermostatic mode press the program, manual or timer
buttons. Please note that the rst press of the manual
button will turn the replace off.

082406-40 TC36.CSTE 15
1
/
4"
1"
MAX
Vent System Town &
Components Country
12" Pipe Length ........................... TCVT.811X12
18" Pipe Length ........................... TCVT.811X18
24" Pipe Length ........................... TCVT.811X24
48" Pipe Length ........................... TCVT.811X48
12" Adjustable Pipe Extension .... TCVT.811X12ADJ
45° Elbow .................................... TCVT.811XLB45
90° Elbow .................................... TCVT.811XLB90
Wall/Offset Support ..................... TCVT.811XOS
Wall Termination Kit .................... TCVT.WTA
Roof Termination Kit.................... TCVT.RTA
Wall Shield/Ceiling Firestop......... TCVT.THIMA
Roof Flashing, Adjustable............ TCVT.811FLADJ
Roof Flashing, Flat ...................... TCVT.811FLFLT
Roof Flashing, Steep................... TCVT.811FLSTP
or any that ts 11" pipe
Fig. # 35
WINDOW
FRAME
HEARTH
EXTENSION
WINDOW
TRACK
SUB-
FLOOR
Fig. # 34
HEARTH EXTENSION
While a hearth extension is not required
for this replace, one is recommended for
aesthetic reasons. The hearth extension
should be non-combustible and must not
be any more than 1" above the bottom of
the replace. If thicker, replace must be
raised up accordingly.
Caution: Hearthextensions thicker than
1" will interfere with the window frame.
VENTING
Before installing venting for this unit, the installer should read
these instructions to insure that the proper vent conguration
has been selected.
Use only Town and Country Termination kits #:
TCVT.WTA - Wall Termination Kit
TCVT.RTA - Roof Termination Kit
Vent system components approved for use with the Town and
Country Fireplace are shown in Figure #35.
Various combinations of vertical and horizontal runs may be
used. Refer to Figure # 39 and 40 for details. For optimum
performance and ame appearance, keep the vent length
to a minimum and limit the number of elbows. Connections
between each vent system component must be tightly joined,
secured with sheet metal screws and sealed. A horizontal run
of vent should have a 1/4" rise for every 1 ft. of run towards
the termination.
CAUTION: UNDER NO CONDITION SHOULD COMBUS-
TIBLE MATERIAL BE CLOSER THAN 1 3/4 INCHES FROM
THE SIDES AND BOTTOM AND 1 3/4 INCHES FROM
THE TOP OF A HORIZONTAL SECTIONS OF THE VENT
PIPE AND 1 3/4 INCHES FROM A VERTICAL SECTION
OF PIPE.

16 TC36.CSTE 082406-40
WALL TERMINATION VENTING
Exterior wall opening:
Determine the exact position of the replace so that the vent pipe is centred
(if possible) between two building framing members. Consult your local
building codes prior to proceeding. The vent kit will accommodate up to
a maximum wall thickness of 12 inches.
1) Having determined the position of the replace, cut and frame a 14-
1/2 inch opening centred at a minimum height of 61 inches above the
oor. The opening may be round or square. Height of the opening will
vary with each installation. As the horizontal vent run increases, so
does the minimum vertical rise (see Fig. # 39).
IMPORTANT: When locating the opening, it should be noted that
vent terminal clearances must be maintained. See "Vent Terminal
Clearances" section for proper clearances.
A minimum 1 foot length of pipe is required for any wall termination. With
this minimal vertical rise in combination with a 90° elbow, a maximum
horizontal run of 24 inches is permitted. For longer horizontal runs greater
than 18 inches, increase vertical rise appropriately. The rise and run
must be constrained to the boundaries of the chart shown in g. # 39.
The horizontal run of vent should have a 1/4" rise for every 1 ft. of run
towards the termination.
Wall thimble:
Where a vent pipe passes through a combustible wall, a wall thimble/shield
must be used to retain insulation and maintain proper clearances. The wall
thimble may be cut to length for various wall thicknesses up to 12" thick.
Measure the wall thickness including the siding. Trim the shield to match
the wall thickness. Position the wall thimble from inside through the 14-
1/2" opening. Properly trimmed, the thimble should be ush with the outer
wall surface.
WALL THIMBLE AND VENT
MUST NOT PROTRUDE
BEYOND SIDING
Fig. # 36 Fig. # 37
TRIM TO LENGTH

082406-40 TC36.CSTE 17
Fig. # 37 HORIZONTAL
TERMINAL
TCVT.9360
14 1/2" FRAMED
OPENING
* Minimum height from the oor to center of the
opening with a maximum horizontal run of 32 1/2"
from the center of the ue outlet to the outside
face of the outer wall. The height will need to be
increased with longer horizontal pipe
WALL SHIELD
THIMBLE
TCVT.THIMA
24" VENT PIPE
TCVT.811X24
90° ELBOW
TCVT.811XLB90
12" VENT PIPE
TCVT.811X12
Vent pipe:
Install vent pipe through the wall thimble and attach to ue
outlet collar on top of the replace. Secure all joints with
screws and seal with approved "High Temp." self-adhesive
aluminum tape provided.
The replace position may need to be adjusted to ensure
that the vent pipe does not protrude beyond the outer wall
or be recessed any more than 12 inches.
Wall vent terminal:
1) Engage the 8" vent collar with the vent pipe and slide
terminal into place. Attach the terminal to the outside
wall. The vent terminal must not be recessed into the
exterior wall or siding.
2) Caulk in place to prevent any moisture entering the
building.
NOTE: MINIMUMCLEARANCES TOTHEVENT TERMINAL
MUST BE MAINTAINED (see Fig. #45).

18 TC36.CSTE 082406-40
Fig. # 39
WALL TERMINATION VENTING CHART
Minimum
1' Length
of Pipe
*Minimum Vent Pipe Centerline Height
NOTE: The vent must not exceed a total length of 65 feet.
Any combination of rise and run may be used but must be
constrained to the boundaries of this chart. A total of 3
90° elbows or combination of other elbows equalling 90°
can be used without reducing horizontal run. For each
additional 90° elbow, or an equal combination of elbows,
reduce horizontal vent run by 2 feet. Ensure vent pipe is
properly supported.
A
Minimum rise
B
Pipe length
C
Maximum run
D
Pipe length
Maximum
61” 1-12” 32 1/2" 1-24"
67" 1-18" 75 3/4" 1-48" 1-12"
73" 1-24" 9' 3 3/4" 2-48"
77 1/4” 1-12" 1-18” 13' 2" 3-48"
83 1/4” 1-24" 1-12” 17' 1/4" 4-48"
89 1/4” 1-24" 1-18” 18' 10 1/2" 4-48" 1-24"
97” 1-48” 20' 10 1/2” 5-48"
For other rise/run combinations see chart below
**
** All dimensions are approximate. Both rise and run may vary with differ-
ent combinations of pipe.

082406-40 TC36.CSTE 19
ROOF TERMINATION VENTING CHART
Fig. # 40
Minimum
1' Length
of Pipe
NOTE: The vent must not exceed a total length of 65 feet.
Any combination of rise and run may be used but must be
constrained to the boundaries of this chart. A total of 4 90°
elbows or combination of other elbows equalling 90° can be
used without reducing horizontal run. For each additional 90°
elbow, or an equal combination of elbows, reduce horizontal
vent run by 2 feet. Ensure vent pipe is properly supported.
A
Minimum rise
B
Pipe length
C
Maximum run
D
Pipe length
Maximum
61” 1-12” 41" 1-24"
67" 1-18" 75 1/4" 1-48" 1-12"
73" 1-24" 9' 3 1/4" 2-48"
77 1/4” 1-12" 1-18” 13' 2 1/2" 3-48"
83 1/4” 1-24" 1-12” 16' 11 3/4" 4-48"
89 1/4” 1-24" 1-18” 18' 10" 4-48" 1-24"
97” 1-48” 20' 10” 5-48"
For other rise/run combinations see chart below
**
** All dimensions are approximate. Both rise and run may vary with differ-
ent combinations of pipe.

20 TC36.CSTE 082406-40
B
14 1/2"
A
ROOF SUPPORT
BRACKET
(TCVT.93915)
VENT PIPE
ROOF TERMINATION VENTING
Ceiling and Roof opening:
1) Determine the exact position of the replace so that the
vent pipe is centered (if possible) between two building
framing members. Lay out the vent system path, minimiz-
ing the number of elbows and length of vent. Consult your
local building codes prior to proceeding.
2) Cut and frame a 14-1/2" opening in the oor, ceiling and
roof where the vent system will pass. Size of the opening
through the roof may need to be increased as the pitch of
the roof increases. Avoid cutting rafters.
Ceiling restop:
Where a vent pipe passes through a oor or ceiling, a ceiling
restop must be used to retain insulation and maintain proper
clearances.
From below, push the ceiling restop through the opening
and secure in place. If the restop is used to penetrate a
oor, the outer shield may be trimmed in length. If the restop
penetrates into an attic, leave the shield full length to keep
insulation away from the vent pipe. Additionally, after the vent
pipe is in place, install a storm collar on top of the shield. This
will prevent loose insulation from falling into the area between
the vent pipe and the shield.
Vent pipe:
1) Install the rst section of vent pipe onto the collar on top
of the replace. Secure in place with screws and seal with ap-
proved "High Temp" self-adhesive aluminum tape provided.
2) Continue adding vent pipe lengths up and through the
restop(s) and through the roof. The vent pipe must extend
at least 24" above the roof.
Seal the vent pipe as per "Vent Pipe Sealant" section.
Roof support bracket:
Slip the roof support bracket down over the vent pipe. Rotate
the 90° brackets to accommodate roof pitch. Attach the brackets
to the roof joists with nails or building screws. Tighten the band
around the vent pipe and secure in place with screws.
Fig. # 42
Size of the opening will have to increase with
the pitch of the roof to ensure a 1 3/4 inch
air space clearance between vent pipe and
combustibles.
Roof Pitch A B
0/12 14 1/2" 7 1/4"
4/12 16 1/2" 8 3/4"
6/12 18" 10"
8/12 19 3/4" 11"
12/12 24" 13 3/4"
Fig. # 41
