Targus NOTEBOOK SECURITY DEFCON User manual

USER GUIDE
notebook security
DEFCON®
ultra combination
cable lock
système de sécurité
DEFCON®
ultra
Visit our Website at http://www.targus.com/ca/
Features and specifications subject to change without notice.
© 2006 Targus Group International, Inc., Targus Canada
PA400C / 410-0072-002A
30

2
Table of Contents
Targus Notebook Security DEFCON®
Ultra Combination . . . . . . . . . . . . . . . . . . . . . . 3
Système de Sécurité Targus DEFCON®
Ultra . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
English
Français
English

3
TARGUS NOTEBOOK
SECURITY DEFCON
®
ULTRA COMBINATION
CABLE LOCK
Thank you for purchasing the Targus DEFCON® Ultra
Security System. The DEFCON Ultra helps deter theft of
your valuable property, such as a carrying case or note-
book computer, using a high strength, vinyl coated,
stainless steel cable, resettable four-digit combination
lock and a motion activated alarm with two sensitivity
settings.
In addition to this user's guide, this package contains:
• DEFCON Ultra Security System
• Security Lock Adapter (SLA)
Using the DEFCON Ultra
WARNING: TOUSE THE DEFCON ULTRA OR RESET THE COMBINATION YOU
MUST HAVE THE CORRECT CURRENT COMBINATION.
The DEFCON Ultra comes with the combination 0000
preset. You should set a new combination before using
the lock. See “Setting the Combination” on page 4 for
details.
If you wish to secure a notebook computer, you need to
use the supplied Security Lock Adapter. See “Using the
DEFCON Ultra Security Lock Adapter” on page 12.

4
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
You can use the DEFCON Ultra without batteries to pro-
vide physical security. To power the alarm siren, the
DEFCON Ultra requires three AAA batteries.
The alarm sounds when:
• The cable is severed.
• The DEFCON Ultra is tilted, shaken or moved while the
optional motion alarm feature is set. (This feature is
unsuitable for use in moving vehicles where vibration
can trigger the alarm.)
For information on fitting the batteries, see “Installing the
Batteries” on page 8. For details of the motion alarm
feature, see “Using the DEFCON Ultra Motion Alarm
Feature” on page 10.
Setting the Combination
1 Make sure the DEFCON Ultra is unlocked and the
cable is fully retracted.
2 Locate the combination dials at the top of the lock.
3 Using the dials, enter the current combination so that
the numbers align vertically with the embossed arrows
next to the first and last dial.
DEFCON Ultra top view
0
0
9
0
9
0
9
Combination
set button

5
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
If you are setting the combination for the first time, enter
the preset combination 0000.
4 Press and firmly hold the combination set button
located next to the cable. Do not release the button
until AFTER you have set all four combination
dials to the new values.
NOTE: FOR BEST RESULTS, PRESS AND HOLD THE COMBINATION SET BUTTON
AND THEN PRESS THE CABLE PLUG HEAD DOWN UNTIL YOU HEAR A"CLICK." TO
RELEASE THE BUTTON, PRESS THE TRIGGER AND PULL THE CABLE PLUG HEAD
UP.
WARNING: YOU MUST EITHER SECURE OR MAINTAIN CONSTANT PRESSURE
ON THE COMBINATION SET BUTTON UNTIL YOU HAVE ENTERED THE ENTIRE
COMBINATION NUMBER SEQUENCE.
5 Using the dials, enter the new combination.
6 Release the combination set button, or pull the cable
plug head up, to save the new combination.
7 Record the combination in either the space provided
at the end of this guide or another secure, easy-to-find
place.
8 Test the combination BEFORE attaching the lock to
an item.
The combination is now set and your DEFCON Ultra is
ready for use.

6
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
Securing and Locking the
DEFCON Ultra
Select an object in the room to which you will secure your
property with the DEFCON Ultra. For added security, you
can activate the motion alarm. See “Activating the Motion
Alarm” on page 11for more information.
1 Locate the combination dials at the top of the lock.
2 Using the dials, enter the current combination so that
the numbers align vertically with the embossed arrows
next to the first and last dial.
3 Press the cable trigger, below the red release button,
and extend the cable to the required length. For more
detail, see “Adjusting the Cable Length” on page 7.
DEFCON Ultra front view
DEFCON
®
ULTRA
Cable plug head
Combination
set button
Cable lock
port
Release
Trigger
Button
1

7
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
4 Wrap the cable around your property and the selected
object.
NOTE: WRAP THE CABLE AROUND APART OF THE OBJECT THAT WILL PREVENT
ATHIEF FROM SLIPPING THE CABLE OFF (FOR EXAMPLE, ATABLE OR DESK LEG
WITH ACROSS BAR).
5 Insert the plug head into the lock port until you hear a
"click."
If the batteries are installed, the DEFCON Ultra then
"beeps" and the status light flashes once every
second, confirming that it is locked.
6 Turn the dials to conceal your combination.
Unlocking the DEFCON Ultra
1 Using the dials, enter the current combination.
2 Press the red release button to eject the plug head.
3 Retract the cable by pressing and holding the trigger
while guiding the cable into the unit.
WARNING: THE CABLE RETRACTS QUICKLY AND MAY CAUSE THE PLUG HEAD
TO WHIP AROUND IF NOT CONTROLLED. SEE THE NEXT SECTION "ADJUSTING
THE CABLE LENGTH" FOR MORE INFORMATION.
4 Let go of the trigger when the cable is fully retracted.
Adjusting the Cable Length
To extend or retract the cable, you must use the cable
trigger. The trigger is designed to operate only when the
DEFCON Ultra is unlocked.

8
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
Before adjusting the cable length, enter the current com-
bination and unlock the DEFCON Ultra.
To extend the cable:
1 Press and hold down the trigger.
2 Pull the cable away from the unit.
3 Let go of the trigger to set the cable length.
Repeat the above steps until the cable reaches the
length you want.
To retract the cable, or shorten the length, press and hold
down the trigger while guiding the cable into the unit. Let
go of the trigger when you have finished rewinding the
cable.
WARNING: THE CABLE RETRACTS QUICKLY AND MAY CAUSE THE PLUG HEAD
TO WHIP AROUND IF NOT CONTROLLED. TOAVOID POSSIBLE PROPERTY
DAMAGE OR PERSONAL INJURY WHEN RETRACTING THE CABLE, PRESS AND
RELEASE THE TRIGGER IN APULSING MOTION SO THAT IT REWINDS SLOWLY.
Installing the Batteries
The DEFCON Ultra is equipped with a two-level motion
alarm feature. To use this feature, or to hear the alarm
siren if the cable is tampered with, you must install three
AAA batteries.
To prevent a potential thief from silencing the alarm, the
battery cover is designed to lock when the DEFCON
Ultra is locked. To add or change the batteries:
1 Using the dials, enter the current combination.

9
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
2 If the cable is locked, press the red release button to
eject the plug head. To avoid possible property dam-
age or personal injury, retract the cable.
3 Press and hold down the red release button.
4 Slide the battery cover from the body of the DEFCON
Ultra and then let go of the release button.
DEFCON Ultra back view
5 Insert the new batteries. Press and hold down the red
release button again and slide the battery cover back
into place.
6 Let go of the release button and check that the battery
cover is secure.
www.targus.com
PA400 v4.0
OPEN
Release
Speaker
button
Battery
cover

10
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
Low Battery Warning
The DEFCON Ultra provides a low battery warning to
prompt you to replace the batteries. When the battery
charge is low, the DEFCON Ultra sounds five short beeps
when you lock the unit.
Using the DEFCON Ultra Motion
Alarm Feature
NOTE: TOUSE THE MOTION ALARM FEATURE YOU MUST INSTALL THREE AAA
BATTERIES. SEE “INSTALLING THE BATTERIES” ON PAGE 8.
The DEFCON Ultra features a two-level motion alarm
that you can activate when you lock the unit. When the
motion alarm is active, the unit chirps if it's picked up or
detects movement, such as bumps or vibrations.
The chirping sound warns that the motion alarm is active.
If the movement continues, or the cable is severed, the
alarm:
• Beeps four times, then
• Sirens for 45 seconds, and then
• Rearms itself to the current sensitivity level
The available sensitivity levels are:
Level 1 - This is a low sensitivity setting at which the
motion alarm sirens after eight seconds of continuous
movement.
Level 2 - This is a high sensitivity setting at which the
motion alarm sirens after four seconds of continuous
movement.

11
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
Activating the Motion Alarm
NOTE: NEVER ACTIVATE THE MOTION ALARM WHEN IN AMOVING VEHICLE
SUCH AS ABUS, TRAIN, OR AIRPLANE, AS THE VIBRATIONS MAY TRIGGER THE
ALARM.
Level 1 - Low Sensitivity
To set the motion alarm for low sensitivity:
1 Secure and lock the DEFCON Ultra. See “Securing
and Locking the DEFCON Ultra” on page 6 for more
information.
2 Press and hold the activate motion alarm button until
you hear two beeps.
3 Release the button.
The status light flashes twice every second indicating
that the motion alarm is armed at level 1.
Level 2 - High Sensitivity
To set the motion alarm for high sensitivity:
1 Secure and lock the DEFCON Ultra. See “Securing
and Locking the DEFCON Ultra” on page 6 for more
information.
2 Press and release the activate motion alarm button,
then immediately press and hold the button again until
you hear three beeps.
3 Release the button.
The status light flashes three times every second
indicating that the motion alarm is armed at level 2.

12
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
Changing the Motion Alarm from
Low to High Sensitivity
If the motion alarm is set to low sensitivity and you want
to change it to high, press and hold the motion alarm but-
ton until you hear three beeps. The status light flashes
three times every second indicating that the motion alarm
is rearmed to high sensitivity.
NOTE: TOCHANGE THE MOTION ALARM FROM HIGH SENSITIVITY TO LOW, YOU
MUST DISARM THE MOTION ALARM BY UNLOCKING THE DEFCON ULTRA AND
THEN REACTIVATE THE MOTION ALARM AS PREVIOUSLY DESCRIBED.
Disarming the Motion Alarm
To neutralize the motion alarm and turn off the siren,
unlock the DEFCON Ultra. See “Unlocking the DEFCON
Ultra” on page 7 for more information.
Using the DEFCON Ultra Security
Lock Adapter
For your convenience, the DEFCON Ultra comes with a
Security Lock Adapter (SLA) that enables you to secure
your notebook computer with the DEFCON Ultra. In addi-
tion, the length of the cable allows you to simultaneously
secure your computer with other property, such as a car-
rying case.
NOTE: TOUSE THE SECURITY LOCK ADAPTER, YOUR NOTEBOOK COMPUTER
MUST HAVE ASECURITY LOCK SLOT.

13
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
To use the SLA:
1 Locate the security lock slot on your computer.
2 Unlock the SLA by pulling the black plastic piece out
of the lock shaft.
Unlocking the SLA
3 Insert the SLA into your computer’s security lock slot.
Inserting the unlocked SLA into a security lock slot
4 Lock the SLA by pushing the black plastic piece back
into the lock shaft.
5 Thread the DEFCON Ultra cable through the hole in
the SLA.
Attaching the DEFCON Ultra to the locked SLA
Notebook Security lock slot
DEFCON cable

14
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
6 Lock the DEFCON Ultra and set the motion alarm, if
desired.
To remove the SLA:
1 Unlock the DEFCON Ultra and unthread the cable.
2 Unlock the SLA by pulling the black plastic piece out
of the lock shaft.
3 Remove the SLA from the security lock slot.
Technical Support
For technical questions, please visit:
Internet: http://www.targus.com/support.asp
Email: [email protected]
Product Registration
Targus recommends that you register your Targus
accessory shortly after purchasing it. To register your
Targus accessory, go to:
http://www.targus.com/support.asp
You will need to provide your full name, email address,
phone number, and company information (if applicable).
Warranty
Targus warrants this product to be free from defects in
materials and workmanship for one year. If your Targus
accessory is found to be defective within that time. we
will promptly repair or replace it. This warranty does not
cover accidental damage, wear and tear, or consequential
or incidental loss. Under no conditions is Targus liable for
loss of, or damage to a computer; nor loss of, or damage

15
Targus Notebook Security DEFCON®Ultra Combination Cable Lock
to, programs, records, or data; nor any consequential or
incidental damages, even if Targus has been informed
of their possibility. This warranty does not affect your
stautory rights.

16
SYSTÈME DE
SÉCURITÉ TARGUS
DEFCON
®
ULTRA
Nous vous remercions d'avoir choisi le système de sécu-
rité Targus DEFCON Ultra. Le DEFCON Ultra est un
dispositif antivol qui permet de dissuader le vol de vos
objets de valeur, tels qu'une mallette ou un ordinateur
portable, grâce à un câble à forte résistance en acier
inoxydable enduit de vinyle, un verrou à combinaison de
quatre chiffres modifiables et une alarme à deux niveaux
de sensibilité activée par le mouvement.
En plus du mode d'emploi, ce conditionnement com-
prend ce qui suit :
• Système de sécurité DEFCON Ultra
• Adaptateur de verrou de protection (SLA)
Utilisation du DEFCON Ultra
AVERTISSEMENT : POUR UTILISER LE DEFCON ULTRA OU POUR REMETTRE
LA COMBINAISON ÀL'ÉTAT INITIAL, VOUS DEVEZ DÉTENIR LA COMBINAISON
ACTUELLE CORRECTE.
Le DEFCON Ultra est livré avec une combinaison
préréglée sur 0000. Avant d'utiliser le verrou, vous devez
régler une nouvelle combinaison. Pour obtenir plus
d'informations, veuillez vous référer à la rubrique
“Réglage de la combinaison” en page 17.
Si vous désirez protéger un ordinateur portable, vous
devez utiliser l'adaptateur du verrou de protection.

17
Système de sécurité Targus DEFCON®Ultra
Veuillez vous référer à la rubrique “Utilisation de
l'adaptateur de verrou de protection DEFCON Ultra” en
page 27.
Vous pouvez utiliser le DEFCON Ultra sans piles pour
assurer une protection physique. Pour alimenter l'alarme,
le DEFCON Ultra exige trois piles AAA.
L’alarme retentit dans les cas suivants :
• Le câble est coupé.
• Le DEFCON Ultra est incliné, secoué ou déplacé alors
que la fonction d'alarme de mouvement livrée en
option est réglée. Cette fonction ne convient pas dans
les véhicules en mouvement car les vibrations peuvent
déclencher l'alarme.
Pour obtenir plus d'informations à propos de l'installation
de piles, veuillez vous référer à la rubrique “Installation
des piles” en page 22. Pour obtenir plus d'informations à
propos de la fonction d'alarme de mouvement, veuillez
vous référer à la rubrique “Utilisation de la fonction
d'alarme de mouvement DEFCON Ultra” en page 24.
Réglage de la combinaison
1 Assurez-vous que le DEFCON Ultra est déverrouillé
et que le câble est entièrement rentré.
2 Repérez les cadrans de combinaison en haut du ver-
rou.
3 Entrez la combinaison actuelle à l'aide des cadrans
de façon à ce que les numéros soient alignés verti-
calement avec les flèches estampées de chaque côté
du premier et du dernier cadran.

18
Système de sécurité Targus DEFCON®Ultra
Vue aérienne du DEFCON Ultra
Si vous réglez la combinaison pour la première fois,
entrez la combinaison préréglée sur 0000.
4 Appuyez et maintenez le bouton de réglage de la
combinaison situé en regard du câble fermement
enfoncé. Relâchez le bouton seulement APRÈS
avoir réglé les quatre cadrans de combinaison sur
les nouvelles valeurs.
AVERTISSEMENT : VOUS DEVEZ MAINTENIR UNE PRESSION CONSTANTE SUR
LE BOUTON DE RÉGLAGE DE LA COMBINAISON JUSQU'ÀCE QUE VOUS AYEZ
ENTRÉ TOUTE LA SÉQUENCE DES NUMÉROS DE LA COMBINAISON.
ENRELÂCHANT LE BOUTON, LA COMBINAISON EST SAUVEGARDÉE EXACTEMENT
TELLE QU'ELLE APPARAÎT ÀL'AVANT DU VERROU.
5 A l'aide des cadrans, entrez la nouvelle combinaison.
6 Relâchez le bouton de réglage de la combinaison
pour sauvegarder la nouvelle combinaison.
7 Notez la combinaison soit dans l'espace prévu à cet
effet à la fin de ce manuel soit dans un autre endroit
sûr mais facile à trouver.
8 Vérifiez la combinaison AVANT de fixer le verrou à un
objet.
0
0
9
0
9
0
9
Bouton de réglage
de la combinaison

19
Système de sécurité Targus DEFCON®Ultra
La combinaison est maintenant réglée et votre DEFCON
Ultra est prêt pour utilisation.
Fixation et verrouillage du
DEFCON Ultra
Choisissez un objet dans la pièce où vous souhaitez fixer
votre objet de valeur à l'aide du DEFCON Ultra. Pour
assurer une plus grande sécurité, vous pouvez activer
l'alarme de mouvement. Pour plus d'informations,
veuillez vous référer à la rubrique “Activation de l'alarme
de mouvement” en page 25.
1 Repérez les cadrans de combinaison en haut du
verrou.
2 Entrez la combinaison actuelle sur les cadrans de
façon à ce que les numéros soient alignés verticale-
ment avec les flèches estampées de chaque côté du
premier et du dernier cadran.
3 Appuyez sur le déclencheur de câble, sous le bouton
de dégagement rouge, et tirez sur le câble jusqu'à la
longueur désirée. Pour plus d'informations, veuillez
vous référer à la rubrique “Réglage de la longueur du
câble” en page 21.

20
Système de sécurité Targus DEFCON®Ultra
Vue avant du DEFCON Ultra
4 Enroulez le câble autour de votre objet de valeur et de
l'objet d'ancrage choisi.
REMARQUE : ENROULEZ LE CÂBLE AUTOUR D'UNE PARTIE DE L'OBJET QUI
EMPÊCHERA UN VOLEUR DE LIBÉRER LE CÂBLE PAR GLISSEMENT (PAR
EXEMPLE,UNE TABLE OU UN PIED DE CHAISE AVEC UNE TRAVERSE).
5 Insérez la tête de la prise dans le port du verrou
jusqu'à ce que vous entendiez un déclic.
Si les piles sont installées, le DEFCON Ultra émet un
bip et le voyant d'état clignote chaque seconde pour
confirmer le verouillage.
6 Tournez les cadrans pour dissimuler la combinaison.
DEFCON
®
ULTRA
Port de verrou
du câble
Tête de prise
du câble
Bouton de réglage
de la combinaison
Déclencheur
Bouton de
dégagement
1
