Tascam CC-222MKII User manual

The CC-222MKII is the world's first CD recorder and cassette recorder combo deck, bringing the two most popular consumer media formats
in one very affordable package. The two decks can be used independently, perhaps for playback of material on one deck while the other
deck is recording. Or, you can use both decks for continuous play between the two decks.
The cassette deck provides Dolby B Noise Reduction for better sounding recordings. A ±12% pitch control allows for varied speeds during
recording or playback. This is ideal for performers, allowing them to adjust pitch and tempo to suit their needs.
Each deck offers analogue inputs and outputs on unbalanced RCAs, allowing truly independent operation. Digital I/O for the CD recorder is
provided on SPDIF coax and optical ports. As a bonus, the CC-222MKII is equipped with an RIAA phono input which allows direct connection
of a turntable for creating CD or cassette masters of your favorite LPs. For ease of operation a wireless remote control is included.
Main Features
Specifications
Links and Downloads
Rear panel drawing (31 KB)
Manuals
Quick Start Guide (203 KB)
Owners Manual (1.2 MB)
CC-222MKII
CD Recorder/Cassette Deck
Cassette to CD-R/RW dubbing and vice versa
Continuous playback between decks
Individual RCA unbalanced analogue inputs/outputs on both decks
RIAA phono input
Headphones output with level control
Wireless remote controller RC-222 supplied as standard
3U rack-mountable
CD-RW Recorder:
CD-R, CD-RW, CD-R-DA, CD-RW-DA discs applicable
24-bit A/D and D/A converters
Digital input level control
Digital direct recording (bypassing the SRC and digital level)
Sampling rate converter (32kHz – 48kHz)
Fade in and out (1 to 24 seconds, 1 second steps)
Auto Track Increment (via SPDIF or audio level)
Sync record
Adjustable sound level for auto track and sync recording
Record Mute
Erase CD-RW discs
Un-finalize CD-RW discs
Continuous play, random play, and program play (maximum 25
songs)
Repeat function (single, all, A–B)
Intro check
Timer play
Coaxial and optical digital input/output
Cassette deck:
Auto reverse
Dolby B noise reduction
Approx. ±12% pitch control
RTZ (Return to Zero)
Record Mute
CPS search function
Cassette Deck
Heads Record/playback (rotary reverse) x 1, Erase x 1
Motor DC servo capstan motor
Pitch control approx. ±12%
Inputs (analogue, unbalanced) RCA x 2
Page 1 of 2Tascam CC-222MKII
3/18/2005http://www.tascam.de/en/cc-222mkii.html

Design and specifications subject to change without notice.
© Tascam Division · TEAC Europe GmbH · All rights reserved.
Last update: 27/08/2004
Nominal level -10 dBV
Nominal impedance 50k ohm
Maximum level +6dBV
Outputs (analogue, unbalanced) RCA x 2
Nominal level -10 dBV
Nominal impedance 1k ohm
Maximum level +6dBV
Frequency response 50 Hz to 12.5 kHz (High Position)
50 Hz to 10 kHz (Normal)
Signal-to-Noise Ratio 46 dB (Dolby off)
52 dB (with Dolby-B)
Fast Winding Time 120 sec (approx.) with C-60 cassette
CD-R/RW Recorder
Applicable discs CD, CD-R, CD-RW, CD-R-DA, CD-RW-DA
Quantisation 16 bit
Sampling frequencies 44.1kHz
Inputs (analogue, unbalanced) RCA x 2
Nominal level -10dBV
Nominal impedance 50k ohm
Outputs (analogue, unbalanced) RCA x 2
Nominal level -10dBV
Nominal impedance 1k ohm
Inputs (digital, coaxial) RCA, IEC60958 Type II (SPDIF)
Sampling frequencies accepted 32kHz, 44.1kHz, 48kHz
Inputs (digital, optical) TOS LINK, IEC60958 Type II (SPDIF)
Sampling frequencies accepted 32kHz, 44.1kHz, 48kHz
Outputs (digital, coaxial) RCA, IEC60958 Type II (SPDIF)
Outputs (digital, optical) TOS LINK, IEC60958 Type II (SPDIF)
Frequency response 20Hz –20kHz, ±1dB (playback)
20Hz – 20kHz, +1dB, -1.5dB (recording)
Signal-to-noise ratio 92dB (playback), 88dB (recording)
Dynamic range 92dB (playback), 88dB (recording)
Total harmonic distortion <0.008% (playback)
<0.01% (recording)
Channel separation >80 dB (1kHz, playback)
>75 dB (1kHz, recording)
General
Headphones output 6.3-mm stereo phone jack
Output power 10mW x 2 (32ohm)
RIAA phono input RCA x 2
Nominal input voltage 5.6mV, 47k ohm
Signal-to-noise ratio 60dB
Voltage requirements 120 VAC / 230 VAC, 50-60 Hz
Power consumption 28W
Dimensions (W x H x D) 483mm x 138mm x 295mm
Weight 7.4kg
