Task Force Tips EF1 RC MONITOR Programming manual

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
MANUAL: EF1 RC MONITOR
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
DANGER
Understand manual and documents in additional literature before use. Operation of this device
without understanding the manual and receiving proper training is a misuse of this equipment.
Obtain safety information at www.tft com/serial-number
This instruction manual is intended to familiarize reghters and maintenance personnel with the operation, servicing and safety
procedures associated with the EF1 RC Monitor series.
This manual should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
See Section 3.2.2 for
Flow/Pressure
Operating Envelope

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Fireghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Fireghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufactures and Service Association
P.O. Box 147, Lynneld, MA 01940 • www.FEMSA.org
ADDITIONAL MANUALS
©Copyright TaskForce Tips, Inc. 2008-2016 LIY-500 May 31, 2016 Rev11
MANUAL: Remote Control (RC)
Monitor Electrical Controls
Supplemental Instructions for use with RC Monitor Manual
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION AND MAINTENANCE
DANGER Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at www.tft.
com/serial-number
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com
3701 Innovation Way, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
SECTION 4.1
Monitor Mounted
Operator Station
SECTION 4.2
Panel Mount
Operator Station
(Y4E-RP)
SECTION 4.3
Panel Mount With Display
Operator Station
(Y4E-RP-D)
SECTION 4.4
Tethered
Operator Station
(Y4E-CT-##)
SECTION 4.5
Tethered Operator Station
With Display
(Y4E-CT-##-D)
SECTION 4.6
Wireless
Operator Station
(YE-RF-##)
SECTION 4.7
Wireless Operator Station
With Display
(YE-RF-##-D)
SECTION 3.0
General Information and Specifications
SECTION 4.0
Electrical Controls Installation and Operation
SECTION 4.11
Monitor Position Display
(Y4E-DISP)
SECTION 4.12
Remote Auxiliary Function
Interface Control
(YE-REMAUX)
SECTION 4.13
Electric RC Monitor Aerial
Truck Installation
SECTION 4.16
Electric Nozzle Actuator
SECTION 4.17
Valve Kits
(YE-VK-PH)
SECTION 5.0
Troubleshooting
SECTION 4.14
Multiplex Interface Control (YE-CAN#)
SECTION 4.15
Ethernet Interface Control
SECTION 4.9
Toggle Switch Monitor
Operator Station
(Y4E-TS)
SECTION 4.10
Monitor Communication
Interface Control
(Y4E-COMM)
SECTION 4.8
Joystick
Operator Station
(Y4E-JS)
MANUAL: Remote Control (RC) Monitor Electrical Controls
LIY-500

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
3
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 PART IDENTIFICATION
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
3.2.2 SAFE OPERATING ENVELOPE
3.3 USE WITH SALT WATER
3.4 INLETS AND OUTLET OPTIONS
3.5 OVERALL DIMENSIONS
4.0 INSTALLATION
4.1 STRUCTURAL REQUIREMENTS
4.2 TRAVEL RANGES
4.2.1 TRAVEL STOPS
4.3 NOZZLE INSTALLATION
4.4 PRESSURE GAGE
4.5 DRAINING RESIDUAL WATER
5.0 SPRAY TRAJECTORY ADJUSTMENT
6.0 OPERATION OF RC MONITORS
7.0 RECOMMENDED PARK POSITION
7.1 OVERRIDE HEX DRIVE
8.0 FLOW CHARACTERISTICS
8.1 STACKED TIPS FLOW
8.2 EF1 RC MONITOR FRICTION LOSS
9.0 DRAWINGS AND PARTS LIST
10.0 WARRANTY
11.0 MAINTENANCE
11.1 LUBRICATION
11.2 TROUBLESHOOTING
11.3 REPAIR
12.0 ANSWERS TO YOUR QUESTIONS
13.0 INSPECTION CHECKLIST
Table Of Contents

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
4
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identied by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI standard Z535-2011, the denitions of the four signal words are as follows:
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE NOTICE is used to address practices not related to physical injury.
2.0 SAFETY
The operation of this monitor can be dangerous. The following must be observed at all times.
WARNING
An inadequate supply of nozzle pressure and/or ow will cause an ine󰀨ective stream and can
result in injury, death, or loss of property. See ow graphs or call 800-348-2686 for assistance.
WARNING Injury or death may occur by attempting to use a damaged monitor. Before using the monitor,
inspect it for damage resulting from, but not limited to:
• Failure to drain monitor followed by exposure to freezing conditions.
See section DRAINING RESIDUAL WATER for instructions.
• Exposure of monitor to temperatures in excess of 160°F (71°C).
• Missing parts, physical abuse, exposure to severe chemicals.
• Deformed or cracked anges damaged as a result of improper installation.
- Excessive bolt torque
- Wrong tightening sequence
WARNING Injury can result from an inadequately supported monitor. The monitor mount must be capable of
supporting 145 lbs (66 kg) of nozzle reaction force.
WARNING
The stream exiting a monitor is very powerful and capable of causing injury and property damage.
Make sure the monitor is securely attached to the base and pointing in a safe direction before
water to the monitor is turned on. Use care in directing the stream.
WARNING
The monitor may be damaged if frozen while containing su󰀩cient amounts of water. Such damage
may be di󰀩cult to detect visually and can lead to possible injury or death. Any time the monitor is
subject to possible damage from freezing, it must be hydrostatically tested by qualied personnel
before being considered safe for use.
WARNING
Keep hands and ngers away from moving parts of the oscillating unit when water is owing.
There are moving parts that can pinch ngers and hands.
WARNING
This equipment is intended for use by trained personnel for reghting. Their use for other
purposes may involve hazards not addressed by this manual. Seek appropriate guidance and
training to reduce risk of injury.
CAUTION The electric monitor may be remotely operated. The electric drives are current limited but may
still produce enough force to cause injury. Keep hands and ngers away from pinch points on
the monitor.
CAUTION Do not use the manual override while the electric controls are in operation. The electric drives
produce enough torque to cause injury.
CAUTION Exceeding the operating envelope of the monitor can result in injury. Observe safe operation by
staying within the published limits.
CAUTION
On many vehicle installations, the monitor is the highest point on the apparatus. Be sure there
is su󰀩cient clearance to safely pass under any doors or overhead obstructions. Always check
parked position of the monitor before moving.
NOTICE To prevent mechanical damage, do not drop or throw equipment.

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
5
3.0 GENERAL INFORMATION
The EF1 RC monitor is extremely compact, yet it has a large 1-½ inch waterway, capable of owing up to 200 gpm, making it the
ideal forestry bumper turret. Waterway with turning vane has only 15 psi (1.3 bar) friction loss at 200 gpm (760 l/min). Elevation range
is 90° above horizontal to 45° below. Horizontal travel is 270° (135° either side of a center position). Field changeable horizontal
travel stops are factory set to give 180° (90° either side of a center position). Designed for 12 VDC or 24 VDC operation, selection
is automatic. The motor control circuits use position encoders and current limiting to protect the drive train at the ends of travel. Unit
has waterproof factory installed plug on power wire for easy removal or reinstallation. Electric drives and control box are waterproof.
Main waterway made from hardcoat anodized ANSI 356-T6 aluminum. Silver powder coat nish. Various inlets are available.
3.1 PART IDENTIFICATION
REMOVE CAP TO ACCESS
MANUAL OVERRIDE HEX NUT
FOR ELEVATION
MODEL & SERIAL
NUMBER ON LABEL
OUTLET
TURNING VANE
INLET FLANGE
HORIZONTAL ROTATION
TRAVEL STOP
SEE SECTION 4.2
ELEVATION
GREASE FITTING
ELECTRONICS
ENCLOSURE
HORIZONTAL
GREASE FITTING
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
Fig. 3.1
EF1 RC Monitor Part Identication

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
6
3.2 SPECIFICATIONS
3.2.1 MECHANICAL
Electric
US METRIC
Weight 14.2 lbs 6.5 kg
Min. Flow Area 1.5” Inlet 1.77 in211.4 cm2
Min. Flow Area 2.0” Inlet 3.14 in220.3 cm2
Max Flow See gure 3.2.2
Max Operating Pressure 200 psi 14 bar
Horizontal Travel Range 270° (135° left and right)
Materials Used ANSI A356.0-T6 Aluminum,
Stainless
Maximum Torque Elevation 26 ft•lbs 35 n•m
Maximum Torque Horizontal 26 ft•lbs 35 n•m
Speed Elevation 33 deg/sec
Speed Horizontal 33 deg/sec
3.2.2 SAFE OPERATING ENVELOPE
0 200 400 600 800 1000 1200
0
2
4
6
8
10
12
14
0
25
50
75
100
125
150
175
200
225
0 50 100 150 200 250 300
Flow (lpm)
Pressure (bar)
Pressure (psi)
Flow (gpm)
EF1 Opera�ng Envelope
Nozzle
Pressure
Monitor Inlet
Pressure
K=2
NOZZLE
K=8
NOZZLE
K=15
NOZZLE
K=20
NOZZLE
MONITOR LOSS
Nozzle A ows 20 gpm (80 l/min) at 100 psi (7 bar), K factor = 2
Nozzle B ows 80 gpm (300 l/min) at 100 psi (7 bar), K factor = 8
Nozzle C ows 150 gpm (570 l/min) at 100 psi (7 bar), K factor = 15
Nozzle D ows 200 gpm (760 l/min) at 100 psi (7 bar), K factor = 20
Figure 3.2.2
Safe Operating Envelope

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
7
3.3 USE WITH SALT WATER
Use with salt water is permissible provided the monitor is thoroughly cleaned with fresh water after each use. The service life of the
monitor may be shortened due to the e󰀨ects of corrosion and is not covered under warranty.
3.4 INLET AND OUTLET OPTIONS
Available inlets and outlets are shown below and should be specied at time of order.
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
Note: Outlet thread options are machined into elbow.
2.0" NPT
FEMALE
(Y1401)
2.0" BSP
FEMALE
(Y1403)
1.5" NPT
FEMALE
(Y1400)
2.0" ANSI 150
(Y1417)
1.5" BSP
FEMALE
(Y1402)
1.5" ANSI 150
(Y1412)
Fig 3.4a
Inlets and Outlets
INLET OPTION Weight
2.0" BSP FEMALE (Y1403) 2.1 lb 0.95 kg
1.5" BSP FEMALE (Y1402) 2.1 lb 0.95 kg
2.0" ANSI 150 (Y1417) 3.0 lb 1.4 kg
1.5" ANSI 150 (Y1412) 2.2 lb 1.0 kg
2.0" NPT FEMALE (Y1401) 2.1 lb 0.95 kg
1.5" NPT FEMALE (Y1400) 2.1 lb 0.95 kg
Figure 3.4b
Inlet Weight
OUTLET OPTIONS
OPTION # THREAD ELBOW
1 1.5" NH MALE Y1311ANF
2 1.5” NPSH MALE Y1311AIF
3 1.5” BSP MALE Y1311ABF

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
8
3.5 OVERALL DIMENSIONS
7.0”
[178mm]
SWING
2.2”
[55mm]
7.0”
[178mm]
90°
10.8”
[276mm]
3.4”
[85mm]
2.7”
[69mm]
45°
135° LEFT
135° RIGHT
Fig 3.5a
EF1 RC Monitor Dimensions
INLET OPTION Additional Overall
Height
2.0" BSP FEMALE (Y1403) 2.7 in 69 mm
1.5" BSP FEMALE (Y1402) 2.7 in 69 mm
2.0" ANSI 150 (Y1417) 1.8 in 45 mm
1.5" ANSI 150 (Y1412) 1.7 in 43 mm
2.0" NPT FEMALE (Y1401) 2.7 in 69 mm
1.5" NPT FEMALE (Y1400) 2.7 in 69 mm
Fig 3.5b
Inlet Heights

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
9
4.0 INSTALLATION
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) For RC monitor.
4.1 STRUCTURAL REQUIREMENTS
The structure that the EF1 RC Monitor is mounted to must
withstand the internal pressure of the monitor as well as shear
and bending forces due to nozzle reaction. Nozzle reaction can be
as high as 150 lbs (70 kg) (200 gpm at 200 psi).
For anged connections the use of at anges without raised
faces is recommended. Use a ring gasket as dened in ASME
16.21 or ISO 7483. Tighten ange bolts in an alternating sequence
as shown in gure 4.1. Tighten sequentially each bolt or stud
three times with 30%, then 60%, and nally 100% of the specied
torque. Tighten to 76-80 ft-lb (100-110 Newton-Meters).
1
3
2
4
Tighten Sequentially
Each Bolt
Three Times
Fig 4.1
Flange Bolt Tightening Sequence
FLANGE TYPE OUTSIDE
DIAMETER
THICKNESS BOLT
HOLE
CIRCLE
# OF
BOLTS
SIZE OF
BOLTS
TORQUE ON
BOLTS
in mm in mm in mm in mm ft-lb N-m
1.5 ANSI 150 5127 0.63 16 3.88 98.4 41/2 13 20-40 27-54
2.0 ANSI 150 6152.4 0.75 19 4.75 120.7 45/8 16 40-70 54-95
4.2 TRAVEL RANGES
The EF1 RC Monitor is available with various inlet ttings. These Inlet Adapters must be oriented upon installation so the EF1 RC will
point in the desired direction. Figure 3.4A shows examples of Inlet Adaptors. Travel ranges relative to the Straight Ahead Reference
Mark are shown in Figure 4.2. Figure 4.2.1 gives the location of the travel stops.
90°
45°
135° LEFT
135° RIGHT
HORIZONTAL
TRAVEL
ELEVATION
TRAVEL
Fig 4.2 Travel Ranges Relative to
Straight Ahead Reference Mark

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
10
4.3 NOZZLE INSTALLATION
The nozzle is simply screwed onto the monitor’s exit threads.
CAUTION The nozzle threads must match the threads of the monitor elbow in both size and type. Mismatched
or damaged threads may cause the nozzle to leak or uncouple under pressure and could cause
injury.
CAUTION Do not connect aluminum to brass or brass to aluminum. Dissimilar metals coupled together
can cause galvanic corrosion that will freeze the threaded joint or cause complete loss of thread
engagement. If dissimilar metals must be coupled together, the e󰀨ects of corrosion can be greatly
delayed by various coatings on the metal such as powder paint, hard anodizing, or silicone grease.
4.4 PRESSURE GAGE
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
There is a raised boss on the front of the monitor.
This raised boss is not machined from the factory
but may be drilled and tapped for ¼ NPT threads if a
pressure gage is desired on the monitor.
Fig 4.4 Pressure Gage
4.2.1 TRAVEL STOPS
Vertical Travel Stops are cast into the elbow of the monitor. Instructions on how to install horizontal travel stops are shown below.
1. Rotate horizontal travel stop 90° one direction
and insert into coupling track.
2. Rotate back to original position ensuring the letter
is located at the top of the travel stop.
3. Rotate the monitor to the desired position, position
the travel stop next to the Monitor's Stop Ear.
4. Tighten set screws to lock the travel stop position.
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
Fig 4.2.1 Travel Stops

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
11
4.5 DRAINING RESIDUAL WATER
There is no drain on the EF1 RC Monitor itself. A drain valve should be installed on the piping to which the monitor is attached.
WARNING All monitors, valves, and standpipes exposed to freezing conditions must be drained immediately
following use to prevent damage. To drain a standpipe, a drainage port must be opened
underground below the frost depth to keep water out of the standpipe until the next use.
5.0 SPRAY TRAJECTORY ADJUSTMENT
CAUTION Injury can result from the monitor changing direction due to an o󰀨 center nozzle reaction. An o󰀨
center nozzle reaction may be caused by debris in the nozzle causing an asymmetrical stream.
6.0 OPERATION OF RC MONITORS
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions LIY-500 for operation of the EF1 RC Monitor.
7.0 RECOMMENDED PARK POSITION
For truck mounted applications it is recommended that the monitor be parked in a position such that the monitor’s nozzle rests
against a bracket or support surface. If a support surface is not available, run the elevation against one of its travel stops to take some
of the backlash out of the gear drive. This will minimize bouncing of the nozzle when the apparatus is traveling. Always be sure the
monitor is properly parked before moving the truck and know the overall height to avoid damage from overhead obstructions such
as doors or bridges.
See Remote Control (RC) Monitor Electrical Controls Supplemental Instructions (LIY-500) for information on programming,
OSCILLATE and PARK position of the EF1 RC monitor.
7.1 OVERRIDE HEX DRIVE
In the event of electrical system failure on the monitor or re truck, the EF1 RC Monitor is factory supplied with a hex drive so a 1/4”
hex wrench may be used for manual override. Pry the dust caps o󰀨 from the horizontal or vertical shafts to access the hex drives.
¼” Hex Wrench
Fig 7.1
Wrenching Hexes on Drive Shafts

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
12
8.0 FLOW CHARACTERISTICS
8.1 STACKED TIPS FLOW
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
50 PSI 80 PSI 100 PSI 150 PSI 175 PSI
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
FLOW
(GPM)
REACTION
(LBS)
1/2 INCH 53 20 66 31 74 39 91 59 98 69
5/8 INCH 82 31 104 49 116 61 142 92 153 107
3/4 INCH 118 44 149 71 167 88 205 132 221 155
NOZZLE INLET PRESSURE
NOZZLE
DIAMETER
4 BAR 6 BAR 8 BAR 10 BAR 12 BAR
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
FLOW
(l/min)
REACTION
(KG)
12 MM 190 9 230 14 270 18 300 23 330 28
16 MM 340 16 420 25 480 33 540 41 590 49
19 MM 480 23 590 35 680 46 760 58 830 69
Fig. 8.1
Stacked Tips Flow Table
8.2 EF1 MONITOR FRICTION LOSS
0 200 400 600 800 1000 1200
0
1
2
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
30
32
34
0 50 100 150 200 250 300
FLOW (LPM)
LOSS (BAR)
LOSS (PSI)
FLOW (GPM)
1.5
0.5
Fig 8.2
Friction Loss

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
13
9.0 DRAWING & PARTS LIST
Y1165
®
SERIAL# www.tft.com-Y123456
219-462-6161 • www.tft.com • MADE IN USA
ef1 rc
MODEL#
13
2
1
4
3
5
7
8
910
12
13 14 15 16
17
19
18
20 21 22 24
23
15
14
2516 26 27 28 29
30
31
29
33
32
34
35
36
37
38
11
6
ITEM # DESCRIPTION QTY PART #
1 BRAND LABEL 1 Y5703
2WARNING LABEL 1 ZB1069
3O-RING-006 5VO-006
4M4-0.7 X 25MM SOCKET
HEAD CAP SCREW
5VTM4-0.7SH25
5ENCLOSURE LID 1 Y1116
6O-RING-006 1 VO-006
7 O-RING-262 1 VO-262
8 6-32 X 3/16 SOCKET HEAD
CAP SCREW
4VT06-32SH188
9 SIGNAL AND COMMUNICA-
TION BOARD
1 Y5010
10 MOTOR CONTROL BOARD 1 Y5000
11 CIRCUIT BOARD STANDOFF 2Y5533
12 HEX PLUG 1 Y5248
13 GREASE FITTING 1/4-28 2VT25-28ZERK
14 3/8-24 X 3/8 SOCKET SET
SCREW
4VT37-24SS375
15 BALL 5/16" TORLON 100 VB.312TO
16 O-RING-229 2VO-229
17 ELBOW 1 See Fig 3.4
18 STRAIN RELIEF 1 Y5245
19 STRAIN RELIEF 1 Y5205
ITEM # DESCRIPTION QTY PART #
20 MOTOR MOUNT RETAINER 2Y1910
21 DRIVE SHAFT SUBASSEMBLY 2Y1915
22 SNAP RING 2VR4220
23 O-RING-215 2VO-215
24 CAP 2Y1161
25 NAME LABEL 1 Y1165
26 1/4-20 X 3/8 BUTTON HEAD
CAP SCREW
1 VT25-20BH375
27 3/8 LOOP CLAMP 1 Y4655
28 TRAVEL STOP RIGHT 1 Y1414
29 1/4-20 X 5/16 SOCKET SET
SCREW
4VT25-20SS312
30 RIGID BASE 1.5" ANSI 150 1 See Fig 3.4
31 TRAVEL STOP LEFT 1 Y1413
32 8-32 X 3/8 SOCKET HEAD CAP
SCREW
2VT08-32SH375
33 STOP EAR 1 Y1415
34 10-32 X 1/4 SET SCREW 1 VT10Y32SS250
35 LOWER SECTION 1 Y1110
36 M4-0.7 X 8MM SOCKET HEAD
CAP SCREW
8 VTM4-0.7SH8
37 MOTOR MOUNT 2Y1164
38 GEAR MOTOR 2Y6000

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
14
10.0 WARRANTY
Task Force Tips, Inc., 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of its
nozzles and other equipment (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in
material and workmanship during the ve (5) year period from the date of purchase.
TFT’s obligation under this warranty is specically limited to replacing or repairing the equipment (or its parts) which are shown by
TFT’s examination to be in a defective condition attributable to TFT. To qualify for this limited warranty, the claimant must return the
equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA, within a reasonable time after discovery of the
defect. TFT will examine the equipment. If TFT determines that there is a defect attributable to it, it will correct the problem within a
reasonable time. If the equipment is covered by this limited warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended beneciary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT. It is agreed
and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states or countries do
not allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THE DOCUMENT.
This limited warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
15
11.0 MAINTENANCE
The EF1 RC Monitor requires little maintenance. The unit should be kept clean and free of dirt by rinsing with water after each use.
Any inoperable or damaged parts should be repaired or replaced before placing the unit in service. Equipment can be returned to
the factory for service and/or testing.
CAUTION Any alterations to the monitor and its markings could diminish safety and constitutes a misuse
of this product
11.1 LUBRICATION
The EF1 monitor generally should not require greasing. In the event that the operation becomes sti󰀨 grease may be applied to the
horizontal rotation and elevation worm gears. See gure 3.1 for grease port locations. Use medium viscosity automotive chassis
grease. Apply only enough grease to restore normal operation. If normal operation is not restored by greasing than inspect for other
causes of sti󰀨 operation.
Note: Do not over pump grease. The monitor’s greased areas lead to large chambers that could trap several pounds of
grease before becoming visible.
11.2 TROUBLESHOOTING
SYMPTOM POSSIBLE CAUSE REMEDY
Leaks Debris or damage in seal area Clean out debris or replace damaged parts
Elevation Binding Debris or damage to elevation drive parts Clean out debris or replace damaged parts
Lack of lubricant Grease, see section 11.1
May be electrical related See trouble shooting section of Electronics
Manual LIY-500
Horizontal Rotation
Binding
Debris or damage to horizontal drive parts Clean out debris or replace damaged parts
Lack of lubricant Grease, see section 11.1
May be electrical related See trouble shooting section of Electronics
Manual LIY-500
11.3 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory serviced appliances are repaired by
experienced technicians to original specications, fully tested, and promptly returned.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability
for damage to equipment or injury to personnel that is a result of user service.
For additional information on care, maintenance, and testing, refer to: NFPA 1962: Standard for the Care, Use, Inspection,
Service Testing, and Replacement of Fire Hose, Couplings, Nozzles, and Fire Hose Appliances, 2013 Edition
12.0 ANSWERS TO YOUR QUESTIONS
We appreciate the opportunity of serving you and making your job easier. If you have any problems or questions, our toll-free
“Hydraulics Hotline”, 800-348-2686, is normally available to you 24 hours a day, 7 days a week.

©Copyright Task Force Tips, Inc. 2017 LIY-210 December 4, 2017 Rev00
TASK FORCE TIPS, INC.
MADE IN USA • www.tft.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
13.0 INSPECTION CHECKLIST
BEFORE EACH USE, appliances must be inspected to this checklist:
• All valves (if so equipped) open and close fully and smoothly
• Waterway is clear of obstructions
• There is no damage to any thread or other connection
• All locks and hold-down devices work properly
• The pressure setting on the relief valve (if so equipped) is set correctly
• Gaskets are in good repair
• There is no obvious damage such as missing, broken, or loose parts
• There is no damage to the appliance that could impair safe operation (e.g. dents, cracks, corrosion, or other defects)
• All swiveling elements rotate freely
• Nozzle is securely attached
BEFORE BEING PLACED BACK IN SERVICE, appliances must be inspected to this list:
1. All valves open and close smoothly and fully
2. The waterway is clear of obstructions
3. There is no damage to any thread or other type connection
4. The pressure setting of the relief valve, if any, is set correctly
5. All locks and hold-down devices work properly
6. Internal gaskets are in accordance with NFPA 1962 (2013) Section 7.2
7. There is no damage to the appliance that could impair safe operation (e.g. dents, cracks, corrosion, or other defects)
8. All swiveling connections rotate freely
9. There are no missing parts or components
10. The marking for maximum operating pressure is visible
11. There are no missing, broken, or worn lugs on couplings
NFPA 1962: Standard for the care, use, inspection, service testing, and replacement of re hose, couplings, nozzles and re hose
appliances. (2013 ed., Section 6.2.1). Quincy, MA: National Fire Protection Agency.
WARNING Any monitor failing any part of the inspection checklist is unsafe and must have the problem
corrected before use. Operating a monitor that fails any of the above inspections is a misuse of
this equipment.
