Task Lighting Sempria LED Q Series User manual

800.445.6404 •tasklighting.com
20
PRE-WIRING
RunseparatewirefromDriver(15VoltDC)locationtoeachzone.WhentotalwattageofSempria®LEDxturesinzone
exceeds75Watts,useaseconddriverandrunadditional18/2solidwireforadditionalzone.Lengthofwirefromdriverto
rstxtureineachzoneisnottoexceed30feet.Wiringmaystartateitherendofxture.(Option:separatewiremaybe
runfromdrivertoeachxture.)
• SomeDriversmaybeconvenientlyconcealedwithinourTRSeriesAnglePowerStriporLightedPowerStrip.
• Asinkbaseorthetopofacabinetareothercommondriverlocations.
• Drivermustbeaccessible.
• DO NOT LOCATE DRIVER IN ATTIC.
• A 15 VOLT DC DRIVER MUST BE USED! Driver must be
15 volt DC supplied by Task Lighting only!*
• AllwiringmustmeetNEC®orlocalcodes.
• 18/2solidwireisrecommendedfromdrivertoxturesand
betweenxtures.
(If 18/2 solid wire is not available, 18/2 stranded wire may also be used. Tin
ends of wire if possible.)
• Amaximumof75WattsofSempria®LEDLightingis
allowedonazone.
• Limitwirelengthto30 feetfromdrivertolights.
• Placeswitchesonthe120VoltsideoftheDriver.
• De-burrallWireWayedgestoensurewiresafety.
• IfotherthanTaskspecieddimmersaredesired,
 callTaskLightingforinstructions.
GENERAL GUIDELINES
*Improper installation or applying improper voltage to xture will void warranty. See tasklighting.com for full warranty info.
S-Q&E-SERIES-INSTALL-0517
DRIVER (15 volt DC) LOCATIONS
Sempria®LED Q & E Series
Installation Instructions
section
3/8"
1/2"
1/2"
section
5/8"
1/2"
1/2"

800.445.6404 •tasklighting.com 21
D
D
$
Driver #1
15vDC
120V Switch
Driver #2
Startbothsetsofwires
fromdriversatacommon
pointandwirethezonesin
oppositedirections.
NOTE:
If using stranded wire we recommend tinning the end of the wire rst. If stranded wire is used without tinning, terminal block
tabs must be depressed when inserting wires. Note that wiring with untinned stranded wire may result in a poor connection.
S-Q&E-SERIES-INSTALL-0517
INSTALLING FIXTURES
1.Slidelensbacktoexposeconnectorsorremovelensfromxture.
2.Strip¼"fromRedwireandinsertintoterminalblockopeningwithRedmarking.StripBlackwire,insertintoterminal
blockopeningwithBlackmark.
3.Cutwirestotbetweenadjacentxtures.Insertwiresintoterminalblocks,maintainingpolarity(RedwiretoRedterminal,
BlackwiretoBlackterminal.)MAINTAINPOLARITYORTHEFIXTUREWILLNOTWORK.
4.Ifxturedoesnotlight,reversewires.
5.Mountingsurfacemustbenishedanddust-freeformountingtapetoproperlyadhere.Removebackingfrommounting
tapeandpressxturermlyintoplace.
6.Usingscrewsprovided,securextureinplace.DO NOTpierceLEDstripwithscrews,nails,staples,oranyother
mechanicaldevice.
7.Slideorsnaplensbackintoplace.
Sempria®LED Q & E Series
Installation Instructions
WHEN USING TWO DRIVERS:
