Tassoni & Pesenti PL 35-LM2 Operation instructions

MOUNTING INSTRUNCTIONS
PL 35-LM2
CLIII IP68 MADE IN ITALY
230 V 50-60 Hz
USE AND MANITENANCE INSTRUCTIONS - LED lighng luminaire
WARNINGS
The following instrucon should be applied to proper installaone, use and maintenance of product and serve to guarantee your
safety. Is necessary to preserve them for later consultaon.
These instrucon must be available and for those who will have the maintenance.
SAFETY NORM
- Switch o the power supply before performing any work on the luminaire, including cleaning.
- Check that the power supply circuit is equipped with a protecon device.
- Check that aer mounng the device is securely fastened.
- The safety can only be guaranteed by the appropriate use the installaon instrucons.
- Use the luminaire in the expected posion.
- Do not modify the luminaire without contact the manufacturer.
MAINTENANCE
- Before carrying out maintenance operaons switch o the system.
- To replace the ballast using the same type, same brand and same power indicated on the data plate, however with the security
mark (IMQ,VDE, UL, etc.).
USE OF THE LUMINAIRE
- We accept no liability for any damage occurred to the product, things and/or people, because incorrect installaon and/or
modicaons equipment, using accessories that are not suitable compared to the data on the label.
- Is forbidden even paral reproducon of the contained in these instrucon and in the installaon instrucon that accompany
each single device.
Disposal device - RAEE
At the end of the product life is a rejecon of that part of the Community Direcve 2002/967/EC-RAEE (Waste of Electrical and
Electronic Equipment), should not be treated as household waste and is user’s responsability to dispose of it properly.
To determin the locaon of the public areas contact the collecon agency for collecon of waste their municipality.
ATTENTION: ANY MODIFICATION OF THE DEVICE IS FORBIDDEN WITHOUT PERMISSION OF THE MANUFACTURER
The security of the device is guaranteed only compliance with the European Norms electric and instrucons contained in this
box, so you need to keep them.
Compliance with this instrucons is very important for the correct operaon of the appliance and system. The installaon must
be made by personal qualied. Disconnect the power supply before carrying out any maintenance and cleaning.
The devices in insulaon class I must be connected to the earth circuit of the system.
The light source contained in this lighng xture can be replaced only by the manufacturer.
IMPORTANT: THE WARRANTY DOES NOT APPLY IN THE FOLLOWING CASES:
- Incorrect installaon
- Incorrect connecon to the power supply line
- Negligent storage and handling
-Replacement of components with other components not supplied by us
- Tampering
- Lack of or incorrect maintenance
- Failure to comply with the annexed assembly instrucons
- Installaon in seismic areas or areas subject to strong vibraons
- Damages caused by vandalism
PLEASE NOTE:
Any aempt to intervene on the LEDs not authorised by the manufacturer shall immeditely void the warranty. Therefore, in case
of malfuncon, contact the manufacturer for repairing or replacing the product.
GENERAL INSTALLATION RACCOMANDATIONS:
Use only supply cables with double case. Do not enter with single cables.
Use only <HAR> exible cables of suitable diameter.
DO NOT USE HARD CABLES OR ARMOURED CABLES (Hard cable could eect the IP67 protecon)
N.B. : Prior to intervening on the xture, ensure that the main switch is disengaged.
Tassoni & Pesen S.r.l. Tassoni & Pesen S.r.l. – Tenuta Marcatuo 1 – 20080 – Albairate (MI) – www.tplight.it – in[email protected] – tel. [phone]

6
1
5
23
Tassoni & Pesen S.r.l. Tassoni & Pesen S.r.l.
1 - Place the casing on the ground 2 - Cemenng the casing inserted 3 - To pass the electric cables into the connector
