Tatu Marchesan GAPCW-EP User manual

OPERATOR’S
MANUAL
GAPCW-EPGAPCW-EP

Dealer:
Owner:
Firm / Farm:
City: State:
No. of the Certificate of Guarantee:
Serial / No.:
Date: Invoice No.:
Product:
Notes:
IDENTIFICATION

1
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
Introduction
The GAPCW-EP disk harrow was designed to work in
any kind of soil, with excellent application on the soil
preparation for annual crops, sugar cane etc.
The heavy-duty structure with proper dimensioning is
made of bent steel plates joined by a good penetration
weld and fine finishing, with tough parts in the load
concentration.
The GAPCW-EP transportation is made through an
efficient wheelset system composed by tires and hydraulic
cylinders, which allows long-distance transportations.
This operator's manual contains the necessary
information for the best performance of this harrow. The
operator must carefully read the entire manual before
working with the equipment. Also, read and understand
the safety recommendations.
For any further explanations or in the case of technical
problems that may arise during the service, consult your
dealer and the Technical Support department of the
factory. They can fully ensure the functioning of your
TATU disk harrow.

2Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
Table of contents
1. To the owner 03
2. To the operator 04 to 11
3. Data sheet 12 & 13
4. Components 14
5. Assembly 15 to 34
Using the set of wrenches 15
Assembly of bearings and spacer spools 16 to 19
Disc gangs assembly sequence 20 & 21
Assembly of the disc gangs on the frame 22
Scrapers assembly / Frame junction assembly 23
Junction extension assembly / Shock absorber assembly 24
Front and rear stabilizer bars assembly 25
Stabilizer bars cylinder assembly 25
Assembly of the wheelset arms 26
Wheelset locks and cylinders assembly 26
Assembling the hubs to the wheelset arms / Tires assembly 27
Traction set assembly 28
Hose support and jack assembly / Drawbar articulation set assembly 29
Hydraulic circuit valves assembly 30
Hydraulic circuit 31 to 33
Assembly of the hitch for transportation / SMV sign assembly 34
Depth stops location 34
6. Set-up instructions 35 to 40
Preparing the tractor / Preparing the equipment 35
Hitching to the tractor 36
Hitching the equipment to the tractor for transportation 37 to 39
Hitching to the tractor to operate the harrow 40
7. Adjustments and operations 41 to 50
Cutting depth 41 & 42
Tractor position related to the previous pass - Lateral displacement 42
Fixation holes on the hitch bar / Junction extensor adjustment 43
Drawbar articulation extensor adjustment 43
Ways to start the harrowing 44
Correct harrowing 45
Direction of the maneuvers 46
Troubleshooting guide 47 & 48
Operations - Important points 49 & 50
8. Maintenance 51 to 58
Lubrication / Lubrication points 51 & 52
Wheelset hubs lubrication 53
Hydraulic cylinder maintenance / assembly 54 & 55
Hydraulic safety 56
Disk harrow maintenance 57
Tires inflation 58
9. Important data 59 to 61
Hourly income calculation 59
Average income table 60
Torque table 61
10. Important 62

3
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
General information
Important
To the owner
The acquisition of any Tatu product assures to the original purchaser the following
rights:
• Warranty certificate;
• Operator's manual;
• Technical assistance by the dealer on equipment delivery.
However, the owner must check the condition of the equipment on delivery, as well
as knowing the warranty terms.
Special attention should be given to the safety recommendations, operation precautions
and maintenance of the equipment.
The instructions in this manual indicates how to get the best performance and allow
the operator to get maximum income, increasing the equipment lifetime.
This manual should be read by operators and maintenance staff.
• Only people who own a full knowledge of the tractor and equipment
must transport, operate and carry out any maintenance on them;
• Marchesan is not responsible for any damage caused by accident
on transporting, misuse or inadequate storage, either by negligence
and/or lack of experience from any person;
• Marchesan is not responsible for any damage caused by unpredictable
situations or for the incorrect use of the equipment.
The warranty shall not be applied to any equipment or any part that has been
altered elsewhere than at the place of manufacture, or which the original
purchaser thereof at retail has used or allowed to be used parts, not made
or supplied by Marchesan.
NOTE
Right and left hand side indications are made observing the equipment from the rear.
To order any parts or request technical assistance services, it is required to provide
the data contained on the nameplate, which is located on the equipment's frame.

4Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
To the operator
Working safely
Be careful with the environment
Dear operator!
Respect the ecology. Do not throw trash away. This gesture
of goodwill helps to protect our environment.
Products such as oil, fuel, filters, batteries and others are
spilt over the soil and can penetrate to the underground layers,
compromising nature. Ecological and conscious disposal of them
should be done.
This equipment is simple to operate, requiring however the
basic and essential cautions to its handling.
Always keep in mind that safety requires constant attention,
observation and prudence during work, transportation, maintenance
and storage.
• Security aspects must be carefully observed, to avoid
accidents.
• This symbol is a warning used to prevent accidents.
• The instructions under this symbol refers to the safety of the
operator, mechanician or third parties, therefore they should
be carefully read and observed. If the safety instructions are
not being followed, a serious accident or even death may
occur.
Read and understand the information before making any
adjustment or maintenance.
Have extreme caution when operating with the power take-off
(PTO), which you should not get closer during operation.
When hitching the equipment to the tractor, use a chain to
lock the equipment drawbar to the tractor hitch bar. This procedure
will prevent a possible rupture of any hydraulic hose or breaks on
the hitching system, what would make the equipment tilt up.

5
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
To the operator
Never use your bare hands to check hydraulic leaks, the high
pressure can cause injuries.
Never attempt to change the adjustments, clean or lubricate the
equipment when the same is switched on or in movement.
Be careful while driving on slopes. Risk of overturn.
Prevent that chemical products (i.e.: fertilizers and treated
seeds) make any contact with your skin or clothes.
Keep access and work places clean or free from oil and grease.
Risk of accidents.
Never transport the equipment on highways or paved roads.
Avoid that the tractor wheels touch the drawbar in sharp turns.
The presence of any other people on the tractor or equipment
is stricly forbidden.
Have extreme caution when driving under electrical power lines.
Any contact may result in severe shocks, injuries or death.
For your protection and safety, always wear adequate clothes
and footwear while operating the equipment.
Always use the safety locks to carry out any maintenance or to
transport the equipment.

6Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
To the operator
• Only trained and qualified personnel are allowed to operate the equipment.
• While working or during transportation, only the presence of the operator is
allowed in the tractor.
• Do not allow children to play or to get over the equipment while it is operating,
during transportation or storage.
• When setting the equipment to transport position, check if there are no people
or animals close or under it.
• Use personal protective equipment (PPE).
• Wear appropriate clothes and footwear. Avoid clothes that are either loose or
hanging from the body, which may become entangled in moving parts.
• Wear protective gloves to work near the cutting parts.
• Never operate the equipment without its protective devices.
• Have full knowledge of the soil before starting to work. Use the speed which is
suitable to the conditions of the ground or pathways to be covered. Provide the
delineation of obstacles or hazardous locations.
• Carefully check the transport width on narrow locations.
• Be careful while hitching the equipment to the tractor.
• Only pull the equipment using a tractor with appropriate power.
• Do not drive the equipment under the influence of alcohol or any soothing/
stimulating medicine, as it may result in a serious accident.
• In case of a fire outbreak or any possible hazard, the operator must leave the
area as fast as possible and look for a safe place. Always have emergency
numbers in hands.
• In case of emergency, know how to stop the tractor and equipment quickly.
• Always shut down the engine, remove the key and use the handbrake before
leaving the tractor seat.
• Never attempt to change the adjustments, clean or lubricate the equipment while
it is moving.
• Whenever you unhitch the equipment, either in the field or shed, do it on a
flat and firm surface and use jacks. Make sure that the equipment is properly
supported.
• We suggest that you carefully read the manual, as it will be a guide for periodic
verifications that need to be done and will allow that you assure the maintenance
of your equipment.
• If there is any doubt after reading it, ask your dealer. For more complicated
operations, there will be the right person to help you there.
• Please check the general safety instructions on the back cover of this manual.

7
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
Transportation over truck or trailer
To the operator
Marchesan does not advise the equipment traffic on highways, because this
practice involves serious security risks and it is prohibited by the current traffic
law. The transportation for long distances should be done on truck, trailer or
others by following these safety guidelines:
• Use adequate ramps to load or unload the equipment. Do not make the loading
on ditch banks, it can cause a serious accident.
• When lifting with a hoist, use the appropriate points to lift.
• Underpin the equipment properly.
• Use chock blocks and safety chains to secure the equipment to the truck or
trailer during the transport.
• Make sure the SMV (Slow Moving Vehicle) sign and all the lights and reflectors
that are required by the local highway and transport autorithies are in place,
clean and can be seen clearly by all overtaking and oncoming traffic.
• After 8 to 10 km transporting, please inspect the load condition. Repeat this
procedure every 80 to 100 km. Give more attention when transporting the
equipment on rough roads, slopes and other adverse conditions.
• Always be careful with the load height, especially when passing under electrical
power lines, bridges and others.
• Check all laws and regulations regarding the height limits and load width while
transporting the equipment on truck or trailer. If necessary, use banners, lights
and other devices, in order to give adequate warning to the other drivers.

8Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
To the operator
Working safety standards
It is important to have knowledge not only about the functioning, operation of the
equipment and its technology, but also about the working legal aspects when using the
equipment, such as safety standards, operator's manual and working safety.
The equipment and tools used on the rural area must be properly handled, otherwise
health and safety of involved personnel may be compromised.
The operator must be capable and authorized to operate the tractor, meaning that the
person must comprehend the functioning instructions of the tractor and know about the
safety standards related to the job that will be performed.
The Ministry of Labor and Employment created safety standards that aim to decrease
the risk of accidents that may occur to the rural worker. Related to the subject of agicultural
machines and equipments, we specifically mention the NR 06, NR 12 and NR 31 standards.
Regulatory Standard - NR 06:
• For purposes of applying this Regulatory Standard, Personal Protective Equipment
(PPE) is considered any device or product that is worn by an individual worker for protection
against risks that could threaten safety and health at work.
Regulatory Standard - NR 12:
• This Regulatory Standard and its annexes provide technical references, basic
principles and protective measures to ensure the health and physical integrity of workers,
and establishes minimum requirements for the prevention of accidents and occupational
diseases in the design stages and use of machinery and equipment of all kinds, and also to
its manufacture, importation, trading, exhibition and cession in any way. It is understood to
be used to the construction, transportation, assembly, installation, adjustment, operation,
cleaning, maintenance, inspection, disabling and dismantling of machinery or equipment.
Regulatory Standard - NR 31:
• This Regulatory Standard has the purpose to establish the precept to be applied on
the organization and on the working environment, in order to make compatible the planning
and development of agriculture, livestock, forestry, forest exploration and aquaculture with
safety in the working environment.

9
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
To the operator
Lifting points
This equipment has adequate lifting points located on the frame. When lifting with a
hoist, it is essential to hitch the cables to these points.
• Use chains of at least 3 meters long to lift the equipment safely.
• Use the adequate points for lifting and be sure that the equipment is
safe. Avoid accidents.
• Always keep a safe distance from the equipment.

10 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
The safety decals warn about the equipment points that require more attention, and
they should be kept in good repair. If these decals become damaged or illegible, replace
them. Marchesan provide decals upon request and indication of the respective serial number.
To the operator
Safety decals
Para evitar acidentes, instale as travas dos cilindros antes
do transporte ou antes de efetuar serviços no equipamento.
In order to avoid accidents activate cylinder locks
before transportation or carrying out any service on
the equipment.
Para evitar accidentes, instale las trabas de los cilindros
antes del transporte o antes de efectuar trabajos en el
equipo. 05.03.03.1738
A
A
D
D
V
V
E
E
R
R
T
T
Ê
Ê
N
N
C
C
I
I
A
A
/
/
W
W
A
A
R
R
N
N
I
I
N
N
G
G
/
/
A
A
D
D
V
V
E
E
R
R
T
T
E
E
N
N
C
C
I
I
A
A

11
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
To the operator
Safety decals
Qty. Model Serial number
1GAPCW-EP decal 05.03.03.4603
1TATU logotype decal 05.03.03.3795
1Danger decal 05.03.03.1739
1Lubricate and tighten daily decal 05.03.03.1827
4Lifting points decal 05.03.03.4078
1Read the manual decal 05.03.03.1428
1Warning decal 05.03.03.1738
1Attention decal 05.03.03.3038
1Grip coupler colors decal 05.03.03.4499
1Warning decal 05.03.03.4438
Decal set

12 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
Data sheet
Type: ........................................................................................................... Disk Harrow
Model: ..........................................................................................................GAPCW-EP
Spacing between disc blades (mm):...........................................................................340
Disc blades dimension: ..............................Ø 30" x 7.5 mm, Ø 30" x 9 mm, Ø 32" x 9 mm
......................................................Ø 32" x 12 mm, Ø 34" x 9 mm
Disc blade type:....................................................................................Concave notched
Bearings - length: ............................................................................................... 330 mm
- type: ........................................................................ Conical oil bath bearings
Oil volume on the bearings: ..................................................................................600 ml
Spacer spools - length: .......................................................................................330 mm
- type: .........................................................................................Iron cast
Axle diameter: ......................................................................................Ø 54 mm (2.1/8")
Hitching type (work):.......................................................................................... Drawbar
Hitching type (transportation):............................................................... Three-point hitch
Tires: ............................................................................................ 400/60 - 14 L (52 PSI)
Working speed:.............................................................................................. 5 to 7 km/h
Transport speed:................................................................................................. 30 km/h
NOTE • The weights above are obtained using Ø 30" x 7.5 mm disc blades.
• The soil conditions may change the tractor required engine power.
Model Number of
disc blades
Cutting width
(mm) Weight (kg) Tractor required power (cv)
GAPCW
EP
30 4877 6477 260 - 280
32 5182 6543 280 - 300
34 5486 6799 310 - 330
40 6096 7725 350 - 370

13
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
Data sheet
Height:............................................................................................................ 2,100 mm
Width:............................................................................................................. 3,820 mm
Length - 30 disc blades:.................................................................................. 6,700 mm
- 32 disc blades:.................................................................................. 7,035 mm
- 34 disc blades:.................................................................................. 7,370 mm
- 40 disc blades:.................................................................................. 8,140 mm
HeightHeight
LengthLength
WidthWidth
GAPCW-EP dimension (transport position)

14 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
Components
GAPCW - EP
0101
0202
0303
0404
0505
0606
0707
0808
0909
1010
1111
1212
1313
1616
1414
1515
1717
1818
1919
01 - Front frame 02 - Rear frame
03 - Junction 04 - Front stabilizer bar
05 - Rear stabilizer bar 06 - Hitch bar
07 - Upper and lower plates 08 - Drawbar
09 - Hose support 10 - Clevis hitch
11 - Jack 12 - Drawbar extensor
13 - Wheelset 14 - Opening hydraulic circuit
15 - Wheelset hydraulic circuit 16 - Junction extensor
17 - Front disc gang 18 - Rear disc gang
19 - Transport hitch bar

15
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
Assembly
First of all, put the parts in a clean place to identify them easier. Check the parts using
the list that comes inside the packing box.
Using the set of wrenches
NOTE We recommend wearing gloves, especially while assembling the disc gangs.
Use two box end wrenches (A) to tighten the nuts of the disc gang, being one to hold
the axle nut on one side while the other tighten the nut to the other end, thereby preventing
the axle from rotating.
Use a box end wrench (B) to tighten the nuts on the bearing bolts.
Use a box end wrench (C) to tighten the nuts on the traction set.
BB
CC
AA

16 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
Assembly
Disc gangs assembly
Before starting to assemble the disc gangs, check the correct position of the bearings
and spacer spools.
Assembly of bearings and spacer spools
GAPCW - EPGAPCW - EP
30 disc blades30 disc blades
12 bearings12 bearings
12 spacer spools12 spacer spools
Spacer spoolSpacer spool
BearingBearing

17
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. GAPCW - EP
Assembly
Assembly of bearings and spacer spools
GAPCW - EPGAPCW - EP
32 disc blades32 disc blades
12 bearings12 bearings
14 spacer spools14 spacer spools
Spacer spoolSpacer spool
BearingBearing

18 Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
GAPCW - EP
Assembly
GAPCW - EPGAPCW - EP
34 disc blades34 disc blades
12 bearings12 bearings
16 spacer spools16 spacer spools
Assembly of bearings and spacer spools
Spacer spoolSpacer spool
BearingBearing
