Tatu Marchesan COP 15 User manual

1
INTRODUCTIONINTRODUCTION
INTRODUCTIONINTRODUCTION
INTRODUCTION
COP and COP SUPREMA planters are especially designed
to make the No-Till or Conventional planting of Corn, Soybean,
Bean, Rice, Peanut, Delinted Cotton, Sorghum, etc...
The permanent row units floating control guarantees the
accompaniment of the soil topography variations.
COP makes the precision planting with horizontal perforated
plates for several crops.
COP SUPREMA uses the vacuum seed metering, with
exclusive sealing system that assures larger useful life and a
continuous and uniform job.
The fertilizer distribution is done with auger type metering,
guaranteeing an uniform distribution in all the row units.
The calibration for different rates of fertilizer and seed is easily
obtained by the sprocket combination mechanism, without using
any tools.
The seed depth control is done through the oscillating rubber
wheels, that accompany the ground and favor the plants
emergence for equal.
This Manual contains the necessary information for the best
planter performance. The operator must read with attention the
whole manual before operating and be aware of the safety
recommendations.
To obtain any information, or in the eventuality of technical
problems, consult the dealer, as well as Marchesan's customer
service, that will guarantee the planters full operation.

2
TO THE OWNER ............................................................................................................................................................... 3
TO THE OPERATOR ................................................................................................................................................ 4 to 8
TECHNICAL SPECIFICATIONS ........................................................................................................................ 9 and 10
ASSEMBLY ........................................................................................................................................................ 11 and 12
Drawbar assembly ........................................................................................................................................... 11
Row markers and row units assembly ......................................................................................................... 12
SET-UP INSTRUCTIONS ....................................................................................................................................... 13 to 40
Preparing the tractor, hitching to the tractor and planter leveling ...................................................... 13
Putting the planter in transport position ...................................................................................................... 14
Spacing between rows and positioning the row units in the chassis ......................................... 15 to 33
Procedures for changing the row spacings ..................................................................................... 34 to 36
Planning of the plantation - Correct stand .................................................................................. 37 and 38
Procedure before planting and ideal speed operation......................................................................... 38
Graphite use ....................................................................................................................................................... 39
List of standard seed plates ............................................................................................................. 39 and 40
ADJUSTMENTS and OPERATIONS ................................................................................................................... 41 to 61
Seed Distribution - Calibrating ............................................................................................................ 41 to 48
Fertilizer Distribution - Calibrating ....................................................................................................... 49 to 51
Practical test of seed and fertilizer distribution .......................................................................................... 52
Auxiliary calculation for fertilizer distribution ............................................................................................. 53
Oscillating coulter blades (No Till) ................................................................................................................ 54
Fertilizer furrow opening .................................................................................................................... 54 and 55
Seed furrow opening ........................................................................................................................................ 56
Adjusting the press wheels .............................................................................................................................. 57
Auxiliary depth control ..................................................................................................................................... 58
Instructions for half planter working ............................................................................................................. 58
Row markers and disc working angle........................................................................................... 59 and 60
OPERATIONS - Important points ..................................................................................................................... 61
OPTIONAL ....................................................................................................................................................... 62 and 63
Seed plates ......................................................................................................................................................... 62
Attachment for two planters .......................................................................................................................... 63
MAINTENANCE.................................................................................................................................................. 64 to 70
Lubrication ............................................................................................................................................... 64 to 66
Maintenance of the fertilizer metering ........................................................................................................ 67
Cleaning of the seed metering ...................................................................................................................... 68
Maintenance of the openers bearing assemblies .................................................................................... 68
How to replace the tires .................................................................................................................................. 69
Planter maintenance ....................................................................................................................................... 70
COP SUPREMA
ASSEMBLY ........................................................................................................................................................ 72 and 73
SET-UP INSTRUCTIONS ....................................................................................................................................... 74 to 76
ADJUSTMENTS and OPERATIONS ................................................................................................................... 77 to 86
Seed distribution - Calibrating ............................................................................................................. 77 to 81
Changing the seed plates ............................................................................................................................. 81
Deflector plate adjustment ............................................................................................................................ 82
Appropriate suction ......................................................................................................................................... 83
Adjusting the selectors..................................................................................................................................... 84
Troubleshooting Chart ...................................................................................................................... 85 and 86
SAFETY STICKERS ........................................................................................................................................................... 87
MAINTENANCE............................................................................................................................................................ 88
Seed metering and turbine maintenance .................................................................................................. 88
IMPORTANT................................................................................................................................................................... 89
INDEXINDEX
INDEXINDEX
INDEX

3
MODELO
SÉRIE/Nº
DATA
PESO
IND. BRASILEIRA
MARCHESAN IMPL. E MÁQ.
AGRÍCOLAS TATU S/A
Av. Marchesan, 1979 - MATÃO - SP - BRASIL
Fone: [phone] - Fax: [phone]
CNPJ: 52.311.289/0001-63
Inscr. Est. 441.000.151.114
TO THE OWNERTO THE OWNER
TO THE OWNERTO THE OWNER
TO THE OWNER
The acquisition of any TATU product assures to the original purchaser the following
rights:
- Warranty certificate;
- Instructions manual and the
- Technical assistance by the dealer on the equipment delivery.
The owner has obligation to inspect the conditions of the product on delivery,
as well as knowing the warranty terms.
Special attention should be given to safety recommendations, operation cares
and maintenance of the product.
Be sure to read and understand the instructions for adjusting and operating the
equipment as reported in this manual. Check each item referred to obtain efficient
operation and maximum trouble free performance. Remember, an equipment which
is properly lubricated and adjusted saves you time, labor and fuel.
IMPORTANT:- ONLY PERSON WHO OWNS A FULL KNOWLEDGE OF THE TRACTOR AND
IMPLEMENT, MUST OPERATE THEM.
- MARCHESAN IS NOT RESPONSIBLE FOR ANY DAMAGE CAUSED BY
ACCIDENT ON TRANSPORT, INCORRECT UTILIZATION OR NO ADEQUATE
STORAGE.
- AFTER THE OPERATING SEASON, THOROUGHLY CLEAN YOUR IMPLEMENT
AND INSPECT IT. PREVENTIVE MAINTENANCE PAYS DIVIDENDS.
- YOUR DEALER HAS ORIGINAL EQUIPMENT PARTS WHICH ASSURE PROPER
FIT AND BEST PERFORMANCE.
Note: THE WARRANTY SHALL NOT BE APPLIED TO ANY EQUIPMENT, OR ANY PART THEREOF,
WHICH HAS BEEN ALTERED ELSEWHERE THAN AT THE PLACE OF MANUFACTURE OR
WHICH THE ORIGINAL PURCHASER THEREOF, AT RETAIL, HAS USED OR ALLOWED
TO BE USED PARTS, NOT MADE OR SUPPLIED BY MARCHESAN S/A.
General information
- The right-hand and left- hand sides of the planter are determinated by facing
in the direction the implement will travel when moving forward.
- When ordering parts please be sure to furnish the quantity, part number and
name of each part wanted. It is also important to give the machine Serial Number,
which is placed on the mainframe.

4
TO THE OPERATO THE OPERA
TO THE OPERATO THE OPERA
TO THE OPERATORTOR
TORTOR
TOR
Raising or lowering
the planter do not
allow any person
come closer to it,
especially in the
row markers action
area.
Operation Safety
- ONLY WITH A COMPLETE CO-OPERATION OF IMPLEMENT OPERATOR THE
ACCIDENTS CAN BE PREVENTED.
- THIS SYMBOL IS A WARNING DEVICE WHICH SHOULD BE KEPT IN PLACE,
CLEAN AND VISIBLE WHEN TRANSPORTING THE IMPLEMENT DURING THE
DAY OR NIGHT. USE ACESSORY LIGHTS AND OTHER DEVICES IN ORDER TO
GIVE ADEQUATE WARNING TO OPERATORS OF OTHER VEHICLES
Dear User !
Respect the Ecology.
Do not throw the trash away.
This gesture of goodwill helps to
protect our Environment.
Do not spill combustible oil, battery and
filter residues in the soil. The trash in
contact with the soil reach the sub layer
which directly damage to the
Environment. Look for information to
delivery these contaminated elements
to whom knows how to recycle or re-use
them.
The COP Planters are easy to operate,
therefore some basic and indispensable
cares are required on their handling.
Have always on mind that safety
requires constant attention, observation and
prudence during the operation, transport,
maintenance and storage of the machine.
When working
near the PTO or
driving mechanisms
have a special care.
Never come
closer to rotating
parts.
Read and
understand the
informations
before realize
adjustments and
maintenance.

5
Never use your
hands to check for
hydraulic leaks.
Escaping hydraulic
oil under pressure
can have sufficient
force to penetrate
the skin causing
personal injury.
Be careful when
moving around
steep graders to
avoid overturn.
Be careful with use
of fertilizer or
chemicals.
These products in
contact with skin
could cause
personal injury to
the body.
Never attempt to
change the
adjustments, clean
or lubricate the
implement when in
movement.
Keep the
entrances and
places acessible
to working, clean
and free of the oil
and grease to
prevent
accidents.
Never transport
the implement on
rough roads during
the night. when
operating avoid to
make sharp turns
that may cause tire
to make contact
with implement
Never allow riders
on the tractor or
implement unless
an additional seat
is available.
Use extreme
caution when
circulating with the
implement under
electrical power
lines, any contact
could result in
severe shock, injury
or death.
In order to protect
yourself always
wear adequate
clothes and shoes
during the
operations.
Always use the
cylinder transport
locks when
transporting the
implements.
TO THE OPERATO THE OPERA
TO THE OPERATO THE OPERA
TO THE OPERATORTOR
TORTOR
TOR

6
TO THE OPERATO THE OPERA
TO THE OPERATO THE OPERA
TO THE OPERATORTOR
TORTOR
TOR
Safety Stickers
The safety stickers are used to alert you to hazards in the most dangerous parts in
the planter. Keep the stickers clean and replace them when it's necessary.
Read the manual before
attempting to work with the
equipment.
Lea el manual antes de iniciar el
uso del equipo.
0503031779
CAUTION
ATENCION
WARNING
ADVERTENCIA
Use the SAFETY LOCKS before adjusting or servicing
under the planter.
 Utilice las TRABAS DE SEGURIDAD antes de efectuar
ajustes o mantención debajo de la sembradora.
AVOID ACCIDENTS.
EVITE ACCIDENTES.
0503031780

7
TO THE OPERATO THE OPERA
TO THE OPERATO THE OPERA
TO THE OPERATORTOR
TORTOR
TOR
Before starting to raise or move the planter check for people or
animalsnear or under the planter, especially inthe row markers action
area.
Place the hydraulic cylinders lock before transporting, servicing or
storing the planter.
 Antes de accionar la sembradora observe si no hay personas o
animales en el área de acción de los marcadores de línea o debajo de
la sembradora.
 Coloque las trabas en los cilindros hidráulicos antes de transportar,
almacenar o efectuar servicios de mantención.
WARNING ADVERTENCIA
0503031782
WARNING ADVERTENCIA
0503031781
PRECAUTIONS DURING WORKINGAND
TRANSPORTATION:
The ladders to the platform must be raised.
Never transport any person on the ladders,
seat, platform or any planter parts.
PRECAUTIONSDURINGADJUSTMENTS:
Alltheprotectionguardsmustbekeptinplace
and in good conditions to avoid accidents.
CUIDADOS DURANTE EL TRABAJO Y EL
TRANSPORTE:
Lasescalerasdeaccesoalaplataforma deben
estar levantadas. Nunca transporte personas
sobre la plataforma, escalera o cualquier otra
parte de la sembradora.
CUIDADOS DURANTE LA CALIBRACIÓN:
Todas las tapas de protección deben ser
mantenidas en su sitio y en buen estado, para
evitar accidentes.

8
TO THE OPERATO THE OPERA
TO THE OPERATO THE OPERA
TO THE OPERATORTOR
TORTOR
TOR
- During the operation or transport do not allow riders on the tractor or
implement. Serious personal injuries could result from falling in the path of
the machine while in operation or transport.
- Never allow children playing near the place that you are operating in.
- Learn about the area before starting the operation. Delimit the dangerous
places or the obstacles.
- Use the most appropriate speed according to the land conditions or roads
to travel.
- Use individual equipments for your own protection.
- Wear clothes and adequate shoes. Avoid large or loosen clothes that could
twine on the movable parts.
- Never operate without the machine protection devices.
- Be careful when hitching the implement to the tractor. Hands or fingers
can be injured when caught between the hitch and tractor drawbar.
- Before starting to raise or move the planter check for people or animals
near or under the planter.
- Verify with attention the transport width in narrow places.
- When disconnecting the implement move it to level area, preferably a
hard surface, on the field or at the warehouse. Certify that the machine is
properly stationed.
- See the general safety instructions in the back-cover of this Manual.
When Transporting the Implement on Truck or Trailer
To transport the equipment at long distances use a truck or trailer. However,
the safety instructions should be followed carefully:
- Use adequate loading dock to load and unload the equipment. Never
use a ditch bank, this practice could result in serious personal injury.
- In the event of lifting up with hoist use the appropriate points to hold.
- Use the planter stands to prop it correctly.
- The planter drawbar should be rised and locked in the vertical position or
it should be moved away and tied to the cargo.
- Tie the hopper covers and other mobile parts that can come unfastened
causing accidents.
- Underpin the planter wheels appropriately.
- Use chock blocks and safety chains to secure the implement to the truck
or trailer during the transport.
- After 8 to 10 km transporting, please inspect the condition of the cargo.
Repeat this procedure every 80 to 100 km. Give more attention when
transporting the implement on rough roads, steep graders and other adverse
conditions.
- Be careful with transport height, specially when passing under electrical
power lines. Any contact could result in severe shock, injury or death.
- Observe all laws and regulations as to the height limits and cargo width while
transporting the implement on truck or trailer. If necessary use banners, lights
and other devices in other to give adequate warning to the drivers of other
vehicles.

9
TECHNICAL SPECIFICATECHNICAL SPECIFICA TECHNICAL SPECIFICATECHNICAL SPECIFICA
TECHNICAL SPECIFICATIONSTIONS
TIONSTIONS
TIONS
Models/
No. of Rows
Hoppers Capacity
Row Spacings
(mm)
Working
Width (mm)
Net Weight (kg) Tractor hp Required
7/4 700, 750, 800, 850, 900 or 950 248 (200) 2,024 2,070
7/6 500, 550 or 600 2,900 372 (300) 2,428 2,556 65 - 75 89 - 90
7/7 400* or 450 434 (350) 2,630 2,760
9/4 950 248 (200) 2,450 2,390
9/5 750, 800, 850 or 900 310 (250) 2,652 2,634
9/6 550, 600, 650, 700 or 750 3,700 372 (300) 2,854 2,878 75 - 90 100 - 115
9/7 500 or 550 434 (350) 3,056 3,122
9/9 400* or 450 558 (450) 3,460 3,610
11/5 950 310 (250) 3,168 3,086
11/6 700, 750, 800, 850 or 900 372 (300) 3,370 3,330
11/8 550, 600 or 650 4,500 496 (400) 3,774 3,818 95 - 110 120 - 140
11/10 500 620 (500) 4,178 4,306
11/11 400* or 450 682 (550) 4,380 4,550
13/5 950 310 (250) 3,536 3,442
13/6 900 372 (300) 3,738 3,686
13/7 800, 850 or 900 434 (350) 3,940 3,930
13/8 650, 700 or 750 5,400 496 (400) 4,142 4,174 110 - 125 145 - 165
13/10 550 620 (500) 4,546 4,662
13/13 400* or 450 806 (650) 4,950 5,150
15/7 950 434 (350) 4,256 4,476
15/8 750, 800, 850 or 900 496 (400) 4,458 4,678
15/10 650 or 700 6,300 620 (500) 4,862 5,082 120 - 140 170 - 195
15/12 500 or 550 744 (600) 5,266 5,486
15/15 400* or 450 930 (750) 5,670 5,890
17/7 950 434 (350) 4,692 4,584
17/8 850 496 (400) 4,894 4,828
17/9 850 or 900 558 (450) 5,096 5,064
17/10 700, 750 or 800 7,200 620 (500) 5,298 5,308 150 - 180 200 - 230
17/12 650 744 (600) 5,702 5,796
17/14 500 or 550 868 (700) 6,106 6,242
17/17 400* or 450 1,054 (850) 6,510 6,730
19/9 950 558 (450) 5,846 6,272
19/10 750, 780, 800, 850 or 900 620 (500) 6,048 6,508
19/12 700 744 (600) 6,452 6,980
19/13 600 or 650 806 (650) 6,654 7,216
19/14 550 868 (700) 6,856 7,452
19/15 550 930 (750) 7,058 7,688
19/16 500 992 (800) 7,260 7,924
19/19 450 1,178 (950) 7,866 8,632
Double- Scarifier
Disc Spindle
1,170
(1,310)
COP COP
SUPREMA
COP / COP SUPREMA
Fertilizer Seeds
Liters (kg) Liters (kg)
1,480
(1,660)
1,755
(1,965)
2,065
(2,315)
2,340
(2,620)
2,650
(2,970)
2,960
(3,320) 170 - 200 225 - 260
* Mínimum Spacing in the driving wheels: 450 mm - Tractor Engine hp required.
Attachment to join two planters COP or COP SUPREMA are available.
Tires 700 x 16 - 10 ply: COP and COP SUPREMA 7 rows models = two tires. Models 9, 11,13 and 15 rows = four tires. Models 17 and 19 rows = six tires.
8,100

10
Model A B C D E F G G
7 3,740 3,240 2,300 3,120 4,740 1,950 1,100 1,400
9 4,540 4,040 2,300 3,120 4,740 1,950 1,100 1,400
11 5,340 4,840 2,300 3,120 4,740 1,950 1,100 1,400
13 6,240 5,740 2,300 3,120 4,740 1,950 1,100 1,400
15 7,140 6,640 2,300 3,120 4,740 1,950 1,100 1,400
17 8,040 7,540 2,300 3,120 4,740 1,950 1,100 1,400
19 8,800 8,500 2,300 3,120 4,740 1,950 1,100 1,400
Dimensions in milimeters.
A
C
DE
G
F
B
TECHNICAL SPECIFICATECHNICAL SPECIFICA
TECHNICAL SPECIFICATECHNICAL SPECIFICA
TECHNICAL SPECIFICATIONSTIONS
TIONSTIONS
TIONS
COP
COP SUPREMA
COP SUPREMACOP
(Row Markers)
(ChassiOutsides)

11
ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
Y
A
B
C
D
The planters are delivered with some detached parts, just remaining the placement
of those components according to orientations to proceed:
Drawbar Assembling
- Install the drawbar on the planter frame using the pins and locks (A).
- Install the stabilizer (B) between the drawbar and the frame.
- Install the hoses (C).
- Install the hose guard (D).

12
ASSEMBLASSEMBL
ASSEMBLASSEMBL
ASSEMBLYY
YY
Y
A
- HAVE ESPECIAL ATTENTION TO THE PRESENCE OF PEOPLE OR ANIMALS IN
THE ROW MARKERS ACTION AREA.
Assembly of the Row Units
- Assemble the row units using bolts (A) supplied inside the detached parts
packing-box.
Row Markers Assembly
Install the arms and disc markers.
Note: - THE ROW MARKERS POSSESS
SYNCHRONIZED MOVEMENTS
WITH THE RAISING AND
LOWERING PLANTER
MOVEMENTS.

13
Preparing the Tractor
If necessary, add counterweights to the tractor rear wheels.
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
Hitching to the Tractor
- Hitch the planter drawbar to the
tractor with pin and lock.
- If necessary use the planter stabilizer
to raise or lower the hitch.
- The tractor drawbar must be allways
fixed in the center position.
- Clean and connect the hose
couplers to the tractor hydraulic system.
Leveling the Planter
Through the stabilizer, make the planter leveling after coupling to the tractor.
To facilitate the stabilizer handling it is enough to work the hydraulic cylinder,
alleviating the planter drawbar on the tractor drawbar.

14
Putting the Planter in Transport
Position
Raise the planter totally and lift the
stands up.
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
Place the safety locks of the row
markers.
Place the safety locks into the
hydraulic cylinders rod.

15
Spacing Between Rows
COP models are delivered with minimum row spacing according to the
requested number of rows, with flexibility for other row spacings; that is to say, for
plantation of crops that need a larger distance between the rows.
Positioning the Row Units in the Chassis
Even number of rows:
Mark The center of the chassis. From this mark you have to measure half spacing
to the right and half to the left, installing in these points the first two rows. From these
rows you mark the others with a spacing to each side.
Odd number of rows:
Install one row unit in the center of the chassis. From this row you mark the others,
with a spacing to each side.
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS

16
Positioning the Row Units in the Chassis
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
COP/COP SUPREMA 7/7 - 400 mm row spacing. COP/COP SUPREMA 7/7 - 450 mm row spacing.
COP/COP SUPREMA 7/6 - 500 mm row spacing. COP/COP SUPREMA 7/6 - 550 mm row spacing.
COP/COP SUPREMA 7/6 - 600 mm row spacing. COP/COP SUPREMA 7/4 - 700 mm row spacing.

17
Positioning the Row Units in the Chassis
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
COP/COP SUPREMA 7/4 - 750 mm row spacing. COP/COP SUPREMA 7/4 - 800 mm row spacing.
COP/COP SUPREMA 7/4 - 850 mm row spacing. COP/COP SUPREMA 7/4 - 900 mm row spacing.
COP/COP SUPREMA 7/4 - 950 mm row spacing.

18
Positioning the Row Units in the Chassis
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
COP/COP SUPREMA 9/9 - 400 mm row spacing. COP/COP SUPREMA 9/9 - 450 mm row spacing.
COP/COP SUPREMA 9/7 - 500 mm row spacing. COP/COP SUPREMA 9/7 - 550 mm row spacing.
COP/COP SUPREMA 9/6 - 550 mm row spacing. COP/COP SUPREMA 9/6 - 600 mm row spacing.

19
Positioning the Row Units in the Chassis
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
COP/COP SUPREMA 9/6 - 650 mm row spacing. COP/COP SUPREMA 9/6 - 700 mm row spacing.
COP/COP SUPREMA 9/6 - 750 mm row spacing. COP/COP SUPREMA 9/5 - 750 mm row spacing.
COP/COP SUPREMA 9/5 - 800 mm row spacing. COP/COP SUPREMA 9/5 - 850 mm row spacing.
COP/COP SUPREMA 9/5 - 900 mm row spacing. COP/COP SUPREMA 9/4 - 950 mm row spacing.

20
Positioning the Row Units in the Chassis
SETSET
SETSET
SET-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS-UP INSTRUCTIONS
-UP INSTRUCTIONS
COP/COP SUPREMA 11/11 - 400 mm row spacing. COP/COP SUPREMA 11/11 - 450 mm row spacing.
COP/COP SUPREMA 11/10 - 500 mm row spacing. COP/COP SUPREMA 11/8 - 550 mm row spacing.
COP/COP SUPREMA 11/8 - 600 mm row spacing. COP/COP SUPREMA 11/8 - 650 mm row spacing.
