INSTRUCTIONS MANUAL
RC²E 4500

Dealer:
Owner:
Firm / Farm:
City: State:
No. of the Certificate of Guarantee:
Serial / No.:
Date: Invoice No.:
Product:
Notes:
IDENTIFICATION

1
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC²E 4500
Introduction
The RC²E 4500 rotary cutter makes the mowing operations with
better efficiency and high quality.
The advanced design and the great working width allow a
reduction around fifty percent in the operational cost; especially in
the cleaning of citric and similar orchards, in the elimination of crop
remains and services that demand quickness in its accomplishment.
Especially designed for extensive areas, the RC²E 4500 model
possesses a central frame and two highly resistant lateral frames, in
order to work in severe situations. The articulations allow to follow
the ground surface contours, maintaining an even cutting height in
all its long range.
The cutting blades operates in an overlapped way, avoiding the
formation of non mowing strips.
Equipped with direction transmission. The gearboxes (multipliers
and divider) are protected by slip clutches; offering a larger lifetime
and low maintenance cost.
The heavy-duty structure possesses beams in the upper surface
of the rotary cutter, avoiding the earth accumulation in the lower
surface.
This instructions manual contains the necessary information
for the best performance of this rotary cutter. The operator must
carefully read the entire manual before working with the equipment.
Also, read and understand the safety recommendations.
For any further clarification or in the event of technical problems
that may arise during the service, consult your dealer and the
Technical Support department of the factory. They can ensure the
fully functioning of your TATU rotary cutter.

2Marchesan Implementos e Máquinas Agrícolas “TATU” S.A.
RC²E 4500
Table of contents
1. To the owner 3
2. To the operator 4 to 10
Working safely 4 to 6
Truck or trailer transportation / Lifting points 7
Safety stickers 8 to 10
3. Data sheet 11
4. Components 12
5. Working preparation 13 to 19
Hitching to the tractor 13 to 15
Transporting position / Working position 16
Assembly of the oil level marker with vent 17
Transversal leveling 18
Longitudinal leveling 19
6. Adjustments and operations 20 to 25
Inversion of the lateral wheelsets / Lateral articulation 20
Cutting height adjustment 21
Direction of blades rotation and serial number 22
Main cardan shaft 23
Slip clutch 24
Operations - Important points 25
Adjustments and quick inspections 26
7. Maintenance 27 to 32
Lubrication / Lubrication points 27
Reversion or replacement of the blades 28 & 29
Replacement of the skid guides / Maintenance precautions 29
Slip clutch 30 & 31
Multipliers and triple divider 32
Cardan shaft 32
Rotary cutter storage 32
8. Important 33
9. Notes 34

3
Marchesan Implementos e Máquinas Agrícolas “TATU” S.A. RC²E 4500
General information
Important
To the owner
• Right and left hand side indication are made observing the equipment from the rear.
• To order any parts or request technical assistance services, it is required to provide
the data contained on the nameplate, which is located on the equipment frame.
The acquisition of any Tatu product assures to the original purchaser the following
rights:
• Warranty certificate;
• Instructions manual;
• Technical assistance by the dealer on equipment delivery.
However, the owner must check the condition of the equipment on delivery, as well
as knowing the warranty terms.
Special attention should be given to the safety recommendations, operation precautions
and maintenance of the equipment.
The instructions in this manual indicates how to get the best performance and allow
the operator to get maximum income, increasing the equipment lifetime.
This manual should be read by operators and maintenance staff.
• Only people who own a full knowledge of the tractor and equipment
must operate them;
• Marchesan is not responsible for any damage caused by accident
on transporting, incorrect utilization or inadequate storage, either
by negligence and/or lack of experience from any person;
• Marchesan is not responsible for any damage caused by unpredictable
situations or the incorrect use of the equipment.
The warranty shall not be applied to any equipment or any part thereof which
has been altered elsewhere than at the place of manufacture or which the
original purchaser thereof at retail has used or allowed to be used parts,
not made or supplied by Marchesan S/A.
NOTE
