TDK-Lambda CME Series User manual

CME-1
・
All specifications are subject to change without notice.
Features
• Medical safety standard (IEC60601-1) approved.
• Leakage current 0.3mA or less (at 265VAC)
• EMI class B approved.
CME SERIES
Product line up
Single Output 150W - 240W
Applications
MED
Model CME150-24 CME240P-24
Output voltage 24V 24V
Max output current 6.3A 10A
Max output power 151.2W 240W
Peak output current 7.5A 20A
Peak output Power 180W 480W
UL60601-1
CSA 22.2
No.601-1, M90
(cUL-certified)
EN60601-1
Y
E
A
R
S
warranty
3
This means that, in conformity with EU Directive 2002/95/
EC, lead, cadmium, mercury, hexavalent chromium, and spe-
cific bromine-based flame retardants, PBB and PBDE, have
not been used, except for exempted applications.
Conformity to RoHS Directive

CME-2
CME
・
All specifications are subject to change without notice.
MODEL
ITEMS/UNITS CME150-24 CME240P-24
Input
Voltage Range (*3) V AC85 - 265
Frequency (*3) Hz 47-63
Power Factor (100/200VAC)(Typ)
(*2)
0.99 / 0.95
Efciency (Typ) (*2) %82 80
Current (100/200VAC)(Typ)
(*2)
A 2.0 / 1.0 3. 2/ 1.6
Inrush Current (100/200VAC)(Typ) (*4) A 14 at 100VAC, 28 at 200VAC, Ta=25°C, Cold Start
Leakage Current ( 265VAC) (*10) mA Less than 0.3 Less than 0.22
Output
Nominal Voltage VDC 24
Maximum Current A 6.3 10
Maximum Peak Current (*1) A 7.5 20
Maximum Power W 151.2 240
Maximum Peak Power (*1) W 180 480
Maximum Line Regulation
(*5,*6)
mV 96
Maximum Load Regulation (*5,*7) mV 150 192
Temperature Coefcient Less than 0.02% / °C
Maximum Ripple & Noise 0<Ta<60
°C
(*5)
mVp-p 150 240
Maximum Ripple & Noise -10<Ta<0
°C
(*5)
mVp-p 180 360
Hold-up Time (Typ) (*2) ms 20
Voltage Adjustable Range
(*10)
VDC 21.6-26.4 21.6-28.8
Function
Over Current Protection (*8) A 7.87 - 20.5 -
Over Voltage Protection (*9)
VDC 27.6 - 32.4 30.0 - 35.0
Remote ON/OFF Control -
Parallel Operation -
Series Operation Possible
Environment
Operating Temperature (*11) °C -10
to +60°C
(-10 to +50°C:100%, +60°C:80%)
-10 to +60
°C
(-10 to +45°C:100%, +60°C:60%)
Storage Temperature °C -30
to +85°C
Operating Humidity
%RH
30 - 90 (No dewdrop)
Storage Humidity
%RH
10 - 95 (No dewdrop)
Vibration At no operating, 10-55Hz (Sweep for 1min.)
19.6m/s² Constant, X,Y,Z 1hour each
Shock (In package) Less than 196.1m/s²
Cooling Convection Cooling
Isolation
Withstand Voltage Input - FG : 2kVAC (20mA), Input - Output : 4kVAC (20mA)
Output - FG : 500VAC (100mA) for 1min.
Isolation Resistance More than 100MΩ at 25°C and 70%RH, Output - FG : 500VDC
Standards
Safety Standards (*12) Approved by UL60601-1,EN60601-1
Built to meet UL60950-1,CSA60950-1,EN60950-1, and DENAN
PFHC Built to meet EN61000-3-2
EMI (*13) Built to meet EN55011 / EN55022-B, FCC-ClassB, VCCI-B
Immunity Built to meet EN61000-4-2, -3, -4, -5, -6, -8, -11
Mechanical
Weight (Typ.) g 500 800
Size (W×H×D) mm 80 x 40 x 208 (Refer to Outline Drawing) 105 x 50 x 242 (Refer to Outline Drawing)
Specifications
*Read instruction manual carefully, before using the power supply unit.
(*1) Operating period at peak output current is less than 10sec.
Input voltage < 95V : Duty < 0.2
Input voltage > 95V : Duty < 0.35
(Average output power and current is less than Maximum output power and current)
For peak load derating method, please refer to the instruction manual for details.
(*2) At 100/200VAC, Ta=25°C and maximum output power.
(*3) For cases where conformance to various safety specs (UL,CSA,EN) are required, to be described as100 - 240VAC, 50/60Hz on name plate.
(*4) Not applicable for the in-rush current to Noise Filter for less than 0.2ms.
(*5) Please refer to Fig. A for measurement of line & load regulation and ripple voltage.(Measure with JEITA RC-9131 probe)
(*6) 85 - 265VAC , constant load.
(*7) No load - Full load (maximum power), constant input voltage.
(*8) Constant current limit and hiccup with automatic recovery. Avoid to operate at overload or dead short condition for more than 30 seconds.
(*9) OVP circuit will shut down output, manual reset.(Line recycle)
(*10) Measured by the each measuring method of IEC, UL, CSA, EN and DENAN(at 63Hz).
(*11) At standard mounting.
- Load (%) is percent of maximum output power or maximum output current, whichever is greater.
- For other mountings, refer to derating curve.
(*12) As for DENAN, built to meet at 100VAC.
(*13) No load - Full load (maximum power), constant current and input voltage.

CME-3
・
All specifications are subject to change without notice.
Output Derating
100
-10 0 10 20 30 40 45 50 60
80
60
40
20
0
LOAD (%)
Ta (°C)
(STANDARD MOUNTING)
MOUNTING A MOUNTING B MOUNTING C MOUNTING D MOUNTING E
CN1 (input) CN1
CN1 CN1 CN1
25 35 45
MOUNTING A, B
MOUNTING C, D
MOUNTING E
100
-10 0 10 20 30 40 50 60
80
60
40
20
12.5
0
LOAD (%)
Ta (°C)
CME150 CME240P
MOUNTING B
MOUNTING C, D
MOUNTING A
MOUNTING E
Outline Drawing
CONNECTOR USED
PART DESCRIPTION PART NAME MANUFACT QTY
CME150 CME240P
PIN HEADER (INPUT SIDE CN1) B3P5-VH J.S.T. 1
PIN HEADER(OUTPUT SIDE CN51) B6P-VH B8P-VH J.S.T. 1
* OUTPUT CURRENT OF EACH CONNECTOR PIN MUST BE LESS THAN 5A.
MATCHING HOUSINGS & PIN.(*NOT INCLUDED WITH THE PRODUCT.)
PART DESCRIPTION PART NAME MANUFACT
QTY
CME150 CME240P CME150 CME240P
SOCKET HOUSING (CN1) VHR-5N J.S.T. 1
SOCKET HOUSING ( CN51 ) VHR-6N VHR-8N J.S.T. 1
TERMINAL PINS (CN1, CN51) SVH- 1T-P1.1 J.S.T. 9 11
HAND CRIMPING TOOL: YC-160R (MANUFACTURER : J.S.T.)
37±1
80±1
70±0.5
Ground the FG to the safety ground of
the equipment or device
There must be at least 4 mm gap
between the end of the printed
circuit board and the equipment case
198±0.5
VOLTAGE
ADJUSTMENT
208±1
CN1
5
5
5
3
1
FG
N
L
COMPONENT SIDE
Input
(48.9)
(194.3)
(61)
(40.7)
VR51
CN51
1
2
3
4
5
6
-V
Output
+V
4- 3.5 Use all the screws to secure
the CME series power supply to the equipment case.
(For details, see the installation procedures
in the instruction manual.)
LEAD CUT
LESS THAN 3mm
CME150
50 MAX
CN1
VR51
105±1
242±1
95±0.5
5
5142±0.5
232±0.5
(227)
(87.4)
(58.7)
(62.5)
5
3
1
FG
N
L
CN51
1
2
3
4
5
6
7
8
-V
+V
Ground the FG to the safety ground of
the equipment or device
There must be at least 4 mm gap
between the end of the printed
circuit board and the equipment case
VOLTAGE
ADJUSTMENT
COMPONENT SIDE
Input Output
4- 3.5 Use all the screws to secure
the CME series power supply to the equipment case.
(For details, see the installation procedures
in the instruction manual.)
LEAD CUT
LESS THAN 3mm
CME240P

CME-4
CME
・
All specifications are subject to change without notice.
Be sure to read the following precautions thoroughly before using
this power supply unit.
Pay attention to all warnings and cautions before using the unit.
Incorrect usage could lead to an electrical shock, damage or a re
hazard.
WARNING
• Do not make unauthorized changes to power supply unit,
otherwise you may have electric shock and void warranty.
• Do not touch the internal components, they may have high
voltage or high temperature. You may get electrical shock or
burned.
• When the unit is operating, keep your hands and face away from
it; an accident may injure you.
• Do not use unit under unusual condition such as emission of
smoke or abnormal smell and sound etc. It might cause re and
electric shock.
In such case, please contact us; do not repair by yourself, as it is
dangerous for the user.
• Do not drop or insert anything into unit. It might cause failure
and re, when using the unit under such condition.
• Do not operate these units at the condition of condensation. It
may cause re and electric shock.
CAUTION
• This power supply is primarily designed and manufactured to
use and enclose in other equipment.
• Input voltage, Output current, Output power, ambient temperature
and ambient humidity should be within specifications, otherwise
the unit will be damaged.
• The unit might be broken down by accident or unexpected
situation. For application equipment, which requires very high
reliability (nuclear related equipment, trafc control equipment,
medical equipment, etc.), please provide fail safety function in
the equipment.
• Do not make an improper wiring to input and output terminals. It
may cause damage.
• Do not use in environment such as strong electromagnetic eld,
erosive gas etc, or any environment where conductive foreign
substance may enter.
• Do not operate and store this unit at the condition of condensation.
In such case, waterproof treatment is necessary.
• Do not operate this unit after it falls down.
• The output voltage of this power supply is considered to be a
hazardous energy level, and must not be accessible to an operator.
CME Instruction Manual
BEFORE USING THE POWER SUPPLY UNIT
Important safety instructions
Input markings and symbols
Caution refer to supplementary documents
EMC performance
Immunity
Test Standard Passed Comments
Electrostatic discharge IEC61000-4-2 Level 3 Air discharge 8kV
Contact discharge 6kV
Electromagnetic field IEC61000-4-3 Level 3 10V/m
Fast / burst transient IEC61000-4-4 Level 3 Tested to 2kV
Surge immunity IEC61000-4-5 Level 3, 4 Common mode to 4.0kV
Differential mode 2.0kV
Conducted RF immunity IEC61000-4-6 Level 3 10V
Power frequency magnetic field IEC61000-4-8 Level 4 30A/m
Voltage dips, variations, interruptions IEC61000-4-11 Pass -
Emissions
Test Standard Comments
Radiated electric field EN55022 Class B (as per CISPR 22)
Conducted emissions EN55022 Class B (as per CISPR 22)
Conducted harmonics IEC61000-3-2 Compliant
Flicker IEC61000-3-3 Compliant
Servicing
These products are not customer serviceable. Repairs may only be
carried out by TDK-Lambda Corporation or their authorised agents.
These products are not authorised for use as critical components
in nuclear control systems, life support systems or equipment
for use in hazardous environments without the express written
approval of the Managing Director of TDK-LAMBDA Corporation.
Safety Class of Protection
These products are designed for the following parameters :
Material Group IIIa, Pollution Degree 2, Over voltage Category II,
Class I (earthed), Indoor use as part of an overall equipment such
that the product is accessible to service engineers only.

CME-5
CME
・
All specifications are subject to change without notice.
• These products are Class Ι and must therefore be reliably
earthed and professionally installed in accordance with the
prevailing electrical wiring regulations and the safety standards
covered herein.
• These products are IPX0, and therefore chemicals/solvents,
cleaning agents and other liquids must not be used.
• The rst protective earth connection in the nal installation must
be marked with the protective earth symbol.
General installation instructions
• These products are designed for continuous operation within an
overall enclosure, and must be mounted such that access to the
mains terminals is restricted. See Clause 16, IEC/EN/UL60601-1.
• These products are NOT suitable for use in the presence of
ammable anaesthetic mixtures with air or with oxygen or with
nitrous oxide.
• These products are classed as ordinary equipment according to IEC/
EN/UL60601-1 and are NOT protected against the ingress of water.
• Connect only apparatus complying with IEC/EN/UL60601-1 to
the signal ports.
• Except for permanently installed equipment as dened in Clause
57.6 of IEC/EN/UL60601-1 the overall equipment in which these
products are installed must have double pole fusing on the input
mains supply. The products themselves have single pole fusing
in the live line.
• These products provide reinforced insulation between mains
and output, with reference to IEC/EN/UL60601-1.
• Reference should be made to local regulations concerning the
disposal of these products at the of their useful life.
• These products have not been assessed to IEC/EN60601-1-2
(EMC) but EMC test data is available from TDK-L AMBDA
Corporation.
Special Instructions for IEC/EN/UL/ 60601-1
1. Terminal Explanation
CME150
CME240P
(1) L: AC input terminal (pin 1 of CN1)
Live line (fuse in line)
(2) N: AC input terminal (pin 3 of CN1)
Neutral line
(3) FG: Input terminal FG (pin 5 of CN1)
Safety earth (Frame Ground) Connect to safety ground of
apparatus or equipment.
(4) FG: Frame Ground (Connected to pin 5 of CN1)
Must be connected to electrically safety ground of appa-
ratus or equipment by electrically conductive spacers. For
the way of mounting, refer to 4-2
(5) + : + Output terminal
(6) - : - Output terminal
(7) V.ADJ: Output voltage adjust trimmer.
(The output voltage rises when a trimmer is turnedclockwise.)
2. Terminal Connection Method
Pay attention to the input wiring. If it is connected to wrong
terminal, the power supply will be damaged.
• Input must be off when making connection.
• Connect FG terminal to ground terminal of the equipment.
CME150
CME240
• Output current of each terminal pin must be less than 5A.
• The output load line and input line shall be separated and
twisted to improve noise sensitivity.
• When connecting or removing connector, do not apply stress to PCB.
• Use the input/output connector specified in outline drawing.
Also, use recommended crimping tool.
Connector is not included with this product.
Input & Output Connector (J.S.T)
Connector Housing Terminal Pin
CME150 CME240P
Input: CN1 B3P5-VH VHR-5N SVH-1T-P1.1
Output: CN51 B6P-VH VHR-6N VHR-8N SVH-1T-P1.1
Hand Crimping Tool : YC-160R(J.S.T)
5
3
1
FG
N
L
CN1
VR51
CN51
1
-
+
2
3
4
5
6
OUTPUT
INTPUT COMPONENT SIDE
COMPONENT SIDE
-
+
OUTPUT
LOAD(%)
LOAD(%)
85VAC
265VAC1
5
3
1
FG
N
L
CN1
INTPUT
85VAC
265VAC1
CN51
VR51
1
2
3
4
5
6
7
8
5
3
1
FG
N
L
CN1
VR51
CN51
1
2
3
4
5
6
1
2
3
4
5
6
7
CN51
VR51
1
2
3
4
5
6
7
8
5
3
1
FG
N
L
CN1
1
2
3
4
5
6
7

CME-6
CME
・
All specifications are subject to change without notice.
󱫀 Input Voltage Range
Input voltage range is single phase 85 - 265VAC (47 - 63Hz) or
120 - 370VDC. Input voltage which is out of specication may
cause unit damage. For cases where conformance to various
safety specs(IEC,UL,CSA,EN) are required, input voltage range
will be 100 - 240VAC(50/60Hz).
󱫂 Output Voltage Range
V.ADJ trimmer(VR51) that is nearly output connector can adjust
the output voltage within the range. Output voltage range is
within CME150 : ±10%, CME240P : -10％ +20% of nominal out-
put voltage. To turn the trimmer clockwise, the output voltage
will be increased. Note over voltage protection ( OVP ) function
may trigger if the output voltage is increased ex-cessively.
󱫄 Inrush Current
This model has used Power Thermistor to pro-tect the circuit
from Inrush Current. Please carefully select input switch and
fuse in cases of the high temperature and re-input the power.
󱫆 Over Voltage Protection (OVP)
The OVP function ( Inverter shut down method, manual reset
type ) is provided. OVP function operates within CME150:
115-135%, CME240P:125-145% of nominal output voltage.
When OVP triggers, the output will be shut down. The input
shall be removed for a few minutes, and then re-input for re-
covery of the output. OVP setting shall be xed and not to be
adjusted externally.
󱫈 Over Current Protection (OCP)
Constant current limiting, automatic recovery. OCP function
operates when the output current exceeds CME150:125%,
CME240P:205% of maximum output current of specication.
The output will be automatically recovered when the overload
condition is re-moved. Do not operate overload or dead short
conditions for more than 30 seconds, which could result in
damage or insulation failure.
󱫊 Output Ripple & Noise
The standard specication for maximum ripple value is mea-
sured according to measurement cir-cuit specied by JEITA-
RC9131. When load lines are longer, ripple becomes larger. In
this case, electrolytic capacitor, lm capacitor, etc., might be
necessary to use across the load terminal. The output ripple
cannot be measured accurately if the probe ground lead of os-
cilloscope is too long.
󱫌 Series Operation
For series operation, either method (A) or (B) is possible.
Method (A) Method (B)
󱫎 Parallel Operation
（A）
To increase the output current is not possible.
（B）
To use as Back-up Power Supply
1. Set power supply output voltage higher by the forward
voltage drop(VF) of diode.
2.Adjust the output voltage of each power supply to be the
same.
3.Use within the specications for output voltage and out-
put power.

󱫐 Peak Output Current
CME150
For CME150-24, relation with average output current and peak
output current must satisfy formulas below. Also operating
time at peak output is less than 10sec.
When using pulse load, audible noise can be heard from power
supply unit.
Ip : Peak output current (A)
Iav : Average output current
(Maximum output current of Specication (A))
Im : Average output current (A)
τ : Pulse width of peak output current (sec)
(Operating time at peak output)
T : Period (sec)
3. Explanation of Functions and Precautions
Input
L
R
C1
Oscillo Scope
Bandwidth : 100MHz
NFG
P.S. C2
150mm
Load
1.5m 50Ω Cable
C3
+
+
-
R : 50Ω
C1: 4700pF film capacitor
C2: 100μF electrolytic capacitor
C3: 0.1μF film capacitor
Output
Terminal
Output
Terminal
Load
Load
Output
Terminal
Output
Terminal
Load
Output
Terminal
Output
Terminal
Load
Output
Terminal
Output
Terminal
Load
Ip
0A
Im
TIav≥Im=Ip×
T
Ip
0A
aA
Im
T
Iav≥Im=(Ip-a)×
T+a

CME-7
CME
・
All specifications are subject to change without notice.
CME240P
For CME240P-24, the peak output current should satisfy the
conditions below:
(1) Should not exceed the rated peak current in the specications.
(2) Duty cycle of the peak output current should be ≤ 35%(at
input voltage < 95V : ≤ 20%), and operating time of peak
output current is less than 10 seconds. If the power supply
is oper-ated under convection cooling, and ambient ex-
ceeds 45°C, the following operating period for peak current
is recommended.
Ambient Temperature (°C) Peak current operating time
-10 -+45°C within 10 seconds
+45°C onwards within 5 seconds
(3) The relation between peak output current with average out-
put current is dened as below:
T
Ip
Im
0A
Ip : Peak output current (A)
Im : Minimum output current (A)
D : Duty cycle, τ /T
τ : Peak output current operating time (sec)
T : Period (sec)
Io : Maximum allowable average output current of specica-
tions (Io should be average load after derating at various
mounting and am-bient temperature) (A)
Formula:
At input voltage < 95V
Io2 ≥ Ι
p2 D+Im2 (1-D) (Duty ≤ 20%)
At input voltage ≥ 95V
1.5 Io2 ≥ Ι
p2 D+Im2 (1-D) (Duty ≤ 35%)
Example 1 : For CME240P-24 at Ta =60°C, Mounting A, Input
Voltage =100V, Max Io =6A (after 60% Derating)
(A): In case of Im =0, Ip =20A,
D ≤ 13.5%
(B): In case of Im =4A, Ip =20A,
D ≤ 9.9%
Example 2 : Following table illustrate some peak load operation
examples for CME240P-24 at input voltage 100V.
Please note that the actual Io in peak load opera-tion is low.
Max allowable average
load after derating by
vari-ous Mounting and Ta :
Examples of peak load derating,
calculated by
above formula
Actual Io
Average
Load(%) Io(A) Ip(A)max D max Im(A) Io(A)
100 10 20 35.0% 3.92 9.55
90 9 20 30.4% 0 6.08
80 8 20 24.0% 0 4.80
70 7 20 18.4% 0 3.68
60 6 20 13.5% 0 2.70
50 5 20 9.4% 0 1.88
40 4 20 6.0% 0 1.20
30 3 20 3.4% 0 0.68
20 2 20 1.5% 0 0.30
10 1 20 0.4% 0 0.08
(4) Peak output current operation (Maximum 10 seconds, Duty
: ≤ 0.2 at input voltage < 95V, ≤ 0.35 at input voltage ≥ 95V)
is possible after establish of output voltage. Please avoid
peak current operation during startup.
󱫒 Isolation Test
Isolation resistance between output and FG ( chassis ) shall
be more than 100MΩ at 500VDC. For safety operation, voltage
setting of DC isolation tester must be done before the test. En-
sure that it is fully discharged after the test
Output - FG (chassis)
500VDC 100MΩ or more
󱫓 Withstand Voltage
This model is designed to withstand 4.0kVAC between input and
output, 2.0kVAC between in-put and FG (chassis), and 500VAC
between output and FG (chassis), each for 1 minute. When test-
ing withstand voltage, set current limit of withstand voltage test
equipment at 20mA (Output-FG (chassis) : 100mA ). The applied
voltage must be gradually increased from zero to testing value
and then gradually decreased for shut down. When timer is
used, the power sup-ply may be damaged by high impulse
voltage at timer switch on and off. Connect input and output
as follows.
Input - Output (dotted line) 4kVAC 1min. (20mA)
Input - FG (chassis)(solid line) 2kVAC 1min. (20mA)
Output - FG (chassis) 500VAC 1min. (100mA)
+
_
AC(N)
AC(L)
FG
Isolation Tester
+
_
AC(N)
AC(L)
FG
Withstand
Voltage tester
+
_
AC(N)
AC(L)
FG
Withstand
Voltage tester

CME
・
All specifications are subject to change without notice.
󱫀 Output Derating according to the
Mount-ing Directions
Recommended standard mounting method is (A). Method (B),
(C), (D), and (E) are also possible. Refer to the derating below.
In the following derating curve, the average output current is
considered to be 100%.
Output Derating (Convection cooling)
CME150
LOAD (%)
Mounting
Ta A B C D E
-10 - +40 °C 100 100 100 100 100
+45 °C 100 100 100 100 90
+50 °C 100 100 87 87 80
+55 °C 90 90 73 73 70
+60 °C 80 80 60 60 60
CME240P
LOAD (%)
Mounting
Ta A B C D E
-10 - +25 °C 100 100 100 100 100
+30 °C 100 100 100 100 87.5
+35 °C 100 100 90 90 75
+40 °C 100 93.3 80 80 62.5
+45 °C 100 86.7 70 70 50
+50 °C 86.7 80 60 60 37.5
+55 °C 73.3 60 50 50 25
+60 °C 60 40 40 40 12.5
󱫂 Mounting Method
Please use the mounting hole as:
CME150 : 4 holes of φ3.5
CME240P : 5 holes of φ3.5
And insert the spacer (MAXφ8mm) of height over 8mm to lift
the unit. Also use all 4 mounting holes for the unit installation.
The vibration spec. is the value taken when the unit is raised
by 8mm spacers.
And allowable area by metal pieces is 9mm from each PCB
corners. Refer to gure below.
CME150
CME240P
When mounting this power supply into host equipment, please
leave 4mm minimum spacing between all parts of the PCB as-
sembly except solder side and the earthed chassis of the host
equipment.
For solder side, please leave 8mm minimum spacing.
Otherwise, the insulation of medical requirement and with-
stand will not be satised.
4. Mounting Directions
Component side
Component side
(A)
STANDARD MOUNTING
CN1
CN1
CN1
(D) (E) (F)
(B) (C)
120
100
80
60
40
20
0
-10 0 10 20 30 40 50 60 70
LOAD (%)
Ta (°C)
MOUNTING(A), (B)
MOUNTING(C), (D)
MOUNTING(E)
Height more than 8mm spacer
Only CME240P
9mm9mm
9mm9mm
9mm
9mm
9mm
9mm
FG
N
CN1
L
+
-
-
More than 4mm
More than 4mm More than 4mm
More than 4mm
More than 4mm
More than 8mm
120
100
80
60
40
20
0
-10 0 10 20 30 40 50 60 70
LOAD (%)
Ta (°C)
MOUNTING(B)
MOUNTING(A)
MOUNTING(C), (D)
MOUNTING(E)
CN1 +
-
-
9mm9mm
9mm9mm
9mm
9mm
9mm
9mm 9mm
9mm
FG
N
L
CME-8

CME
・
All specifications are subject to change without notice.
FG should be connected to the earth terminal of the apparatus.
If not, the conducted noise and output noise will increase. Wire FG
Metal spacer
Chassis (Conductor)
• The output load line and input line shall be separated and
twisted to improve noise sen-sitivity.
• Use all lines as thick and short as possible to make lower
impedance.
• Noise can be eliminated by attaching a capacitor to the load
terminals.
• For safety and EMI considerations, connect FG to ground
terminal of equipment where power supply is mounted on.
• Recommended screw torque is 0.49N･m (5kgf･cm).
• Select the wire materials to adapt the connector as follows.
INPUT : AWG#22-#18
OUTPUT : AWG#22-#18
5. Wiring Method
Refer to the following fuse rating and use high-braking capac-
ity fuse when selecting the external fuses that are to be used
on input line. Surge current flows when line turns on. There-
fore use slow-blow fuse or time-lug fuse. Do not use fast-blow
fuse. Fuse rating is specified by in-rush current value at line
turn-on. Do not select the fuse according to input current (rms.)
values under the actual load condition.
CME150 : 5.0A
CME240P : 6.3A
6. External Fuse Rating
Before concluding that this product is at fault, make the follow-
ing checks.
• Check if the rated input voltage is connected.
• Check if the wiring of input and output is correct.
• Check if the wire material is not too thin.
• Check if the output voltage control (V.ADJ) is properly ad-
justed.
• Check if the output current and output wattage is not over
specication.
• Audible noise can be heard during dynamic-load operation.
• Audible noise can be heard when input voltage waveform is
not sinusoidal wave.
7. Before concluding that the unit is at fault
CME-1003E
CME-9

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
TDK-Lambda:
CME240P-24
