TDK-Lambda GH10-150 Setup guide

Series
Programmable DC Power Supplies
GH1.5kW in 1U Half-Rack 0-600V / 0-150A
Built in compliant LAN, USB, RS-232 & RS-485 Interface
Optional Interface: IEEE488.2 (GPIB), MODBUS TCP or EtherCAT
SAFETY & INSTALLATION MANUAL
GH10-150
GH80-19
GHB10-150
GHB80-19
GH20-75
GH100-15
GHB20-75
GHB100-15
GH30-50
GH150-10
GHB30-50
GHB150-10
GH40-38
GH300-5
GHB40-38
GHB300-5
GH60-25
GH600-2.6
GHB60-25
GHB600-2.6
Manual Supplements
The full user manual is available on TDK-Lambda website or can be ordered, refer to User manual IA761-04-02_.
For units equipped with MODBUS TCP interface option, refer to MODBUS TCP User manual IA761-04-04_.
For units equipped with EtherCAT interface option, refer to EtherCAT User manual IA761-04-05_.
Modbus® is a registered trademark of Schneider Electric, licensed to the Modbus Organization, Inc.
EtherCAT® is a registered trademark and patented technology, licensed by Beckhoff Automation GmbH,
Germany.
IA762-04-01

This page intentionally left blank

TABLE OF CONTENTS
GENERAL INFORMATION .............................................................................................................................................. 1
WARRANTY .................................................................................................................................................................. 1
ENVIRONMENTAL COMPLIANCE................................................................................................................................... 1
LONG-TERM STORAGE METHOD AND LONG-TERM STORAGE PERIOD.......................................................................... 2
SAFETY & EMC APPROVALS .......................................................................................................................................... 4
GENERAL SAFETY INSTRUCTIONS.................................................................................................................................. 5
ALLGEMEINE SICHERHEITSVORSCHRIFTEN.................................................................................................................... 7
INSTRUCCIONES DE SEGURIDAD GENERALES................................................................................................................ 9
CONSIGNES GÉNÉRALES DE SÉCURITÉ..........................................................................................................................11
ISTRUZIONI GENERALI DI SICUREZZA ...........................................................................................................................13
INSTRUÇÕES GERAIS DE SEGURANÇA ..........................................................................................................................15
PRODUCT SAFETY INSTRUCTIONS................................................................................................................................17
CHAPTER 1: GENERAL INFORMATION..........................................................................................................................23
1.1 User Manual Content ..........................................................................................................23
1.2 Introduction.........................................................................................................................23
1.2.1 General Description..............................................................................................23
1.2.2 Multiple Output Power System............................................................................23
1.2.3 Control via Communication Ports ........................................................................23
1.2.4 Analog Voltage Programming and Monitoring ....................................................24
1.2.5 Parallel Operation ................................................................................................24
1.2.6 Output Connections .............................................................................................24
1.2.7 Cooling and Mechanical Construction .................................................................24
1.3 Accessories ..........................................................................................................................24
1.3.1 Accessories Provided With the Power Supply......................................................24
1.3.1.1 Input connector protection for 1.5kW models ..................................24
1.3.1.2 AC input plug for 1.5kW models ........................................................24
1.3.1.3 Output protection cover for models up to 100VDC output...............24
1.3.1.4 Output connector for models above 100VDC output........................25
1.3.1.5 Serial link cable...................................................................................25
1.3.1.6 Misc. hardware...................................................................................25
1.3.1.7 Bus bars screws kit .............................................................................25
1.3.2
Optional Accessories .........................................................................................25
1.3.2.1 Printed user manual ........................................................................25
1.3.2.2 Serial port cables .............................................................................25
1.3.2.3 Paralleling cable .................................................................................25
1.3.2.4 Rack mount kit ...................................................................................25
1.3.2.5 AC cables ...........................................................................................26
CHAPTER 2: FRONT/REAR PANEL CONTROLS AND CONNECTORS ................................................................................27
2.1 Introduction.........................................................................................................................27
2.2 Front Panel Display and Controls ........................................................................................27
2.3 Blank Front Panel.................................................................................................................30
2.4 Rear Panel Connectors ........................................................................................................31
CHAPTER 3: OUTLINE ...................................................................................................................................................33
3.1 Power Supplies Outline .......................................................................................................33

CHAPTER 4: INSTALLATION ..........................................................................................................................................35
4.1 General ................................................................................................................................35
4.2 Preparation for Use..............................................................................................................36
4.3 Initial Inspection ..................................................................................................................36
4.4 Rack Mounting Option.........................................................................................................37
4.4.1 GH/RM Option Kit ................................................................................................37
4.4.2 Single Unit Installation .........................................................................................37
4.4.3 Dual Unit Installation............................................................................................39
4.4.4 GH\RM Rack Mounting Outline Drawings............................................................41
4.5 Benchtop Stacking Option ...................................................................................................42
4.5.1 GH/MO Option Kit................................................................................................42
4.5.2 GH/MO Installation ..............................................................................................42
4.6 Location, Mounting and Cooling .........................................................................................43
4.6.1 Foot Snaps Assembly............................................................................................43
4.7 AC Input Power Connection ................................................................................................44
4.7.1 AC Input Connector..............................................................................................46
4.7.2 AC Input Wire Connection....................................................................................47
4.8 Turn-On Checkout Procedure..............................................................................................49
4.8.1 General .................................................................................................................49
4.8.2 Priorto Operation .................................................................................................49
4.8.3 Constant Voltage Check (Standard Power Supply) ..............................................49
4.8.4 Constant Voltage Check (Blank Panel Power Supply) ..........................................50
4.8.5 Constant Current Check (Standard Power Supply) ..............................................50
4.8.6 Constant Current Check (Blank Panel Power Supply) ..........................................51
4.9 Connecting the Load............................................................................................................52
4.9.1 Load Wiring ..........................................................................................................52
4.9.2 Current Carrying Capacity ....................................................................................52
4.9.3 Bus bar Cover Limitation ......................................................................................53
4.9.4 Wire Termination .................................................................................................53
4.9.5
Noise and Impedance Effects ...........................................................................53
4.9.6
Inductive Loads ..................................................................................................54
4.9.7 Making the Load Connections..............................................................................54
4.9.8 Grounding Outputs...............................................................................................58
4.10 Local and Remote Sensing ...................................................................................................59
4.10.1 Sense Wiring.........................................................................................................59
4.10.2 Local Sensing ........................................................................................................59
4.10.3 Remote Sensing....................................................................................................59
4.10.4 J8 Sense Connector Technical Information..........................................................60
4.11 Repackaging for Shipment...................................................................................................60
CHAPTER 5: SPECIFICATIONS .......................................................................................................................................61
5.1 GH1.5kW Series Specifications ............................................................................................61

1
GENERAL INFORMATION
Documentation (including this Manual) is subject to change without notice. Refer to TDK-Lambda Technical Data
web page for an up-to-date documentation:
https://www.emea.lambda.tdk.com/uk/technical-data/data.aspx?resource=Installation-Manuals
WARRANTY
This TDK-Lambda product is warranted against defects in materials and workmanship for a period of five years
from date of shipment. During the warranty period, TDK-Lambda will, at its option, either repair or replace
products, which prove to be defective.
Limitation of Warranty
The warranty shall not apply to defects resulting from improper or inadequate usage or maintenance by the buyer,
buyer supplied products or interfacing. The warranty shall not apply to defects resulting from unauthorized
modifications or from operation exceeding the environmental specifications of the product or if the QA seal has
been removed or altered by anyone other than TDK-Lambda authorized personnel. TDK-Lambda does not
warrant the buyers’ circuitry or malfunctions of TDK-Lambda products resulting from the buyers’ circuitry.
Furthermore, TDK-Lambda does not warrant any damage occurring as a result of the buyer's circuitry or the
buyer's - supplied products. No other warranty is expressed or implied.
Warranty Service
This product must be returned to an authorized TDK-Lambda service facility for repairs or other warranty service.
For products returned to TDK-Lambda for warranty service, the buyer shall prepay shipping charges to TDK-
Lambda and TDK-Lambda shall pay the shipping charges to return the product to the buyer. Refer to section 4.11
for Repackaging for Shipment.
Disclaimer
The information contained in this document is subject to change without notice. TDK-Lambda shall not be liable
for errors contained in this document or for incidental or consequential damages in connection with the furnishing,
performance or use of this material. No part of this document may be photocopied, reproduced or translated into
another language without the prior written consent of TDK-Lambda.
ENVIRONMENTAL COMPLIANCE
TDK-Lambda recognizes its duty and responsibilities towards promoting a sustainable environment. Our policy is
to comply with applicable global legislation and to follow TDK Corporation Environmental Policy which goes
beyond mandatory International laws.
For additional environmental information, refer to the TDK-Lambda environmental compliance web page at
https://www.emea.lambda.tdk.com/uk/support/environmental-compliance.aspx.This page contains the
environmental regulations ad directives with which TDK-Lambda complies, as well as other environmental
information not included in this document.
Waste Electrical and Electronic Equipment (WEEE)
EU Customers: At the end of the product life cycle, all products must be sent to a WEEE recycling center.

2
LONG-TERM STORAGE METHOD AND LONG-TERM STORAGE PERIOD
1. Please keep the product in its carton box.
2. Please do not apply excessive vibration, shock or mechanical stress applied directly on the product.
3. Please keep away from direct sunlight.
4. For long-term storage temperature and humidity, the following conditions shall be usedas a guidline:
Temperature range: 5°C ~ 30°C.
Humidity range: 40% ~ 60~ RH.
Please keep away from places where temperature and humidity can change extremely. It can cause
condensation on the product or deterioration.
5. For long-term storage period, we recommend to use within 2 years after receiving the product.
There is tendency that the leakage current of an aluminium electrolytic capacitor may increase when stored
witout usage for a long time.
This phenomenon can be minimized by applying voltage to the aluminium electrolytic capacitor to reduce the
increased leakage current through the self-recovery effect of the electrolyte.
For reference, before using products that have been stored for a very long time, please warm-up first for 30
minutes or more without load.
1. Implementation period: 1 year or above after delivery.
2. Electrical continuity condition
Input voltage: Rated.
Load: 0 Amperes (no load condition).
Ambient temperature: according to product specifications.
Time: 30 minutes or more.

3
China ROHS
中
华
人民共和国中国
电
子行
业标
准SJ/T11364-2014（中国RoHS2)
People's Republic of China Electronic Industry Standard SJ/T11364-2014 (China RoHS2)
产品 / Product: Genesys+ GH1.5kW Series
零件名称
/ Part Name
有毒有害物
质或元素 / Hazardous Substances
铅
Pb
汞
Hg
镉
Cd
六价
铬
Cr6+
多溴
联
苯
PBB
多溴二苯
醚
PBDE
电
路模块/ PCB Assembly ○○○○○○
机箱
（如适用）/ Enclosure (if applicable)
○
○
○
○
○
○
包装
/ Packaging ○○○○○○
此表依照
SJ/T11364-2014规
定制定
This table is prepared in accordance with the provisions of SJ/T11364-2014
o =
指明
产
品所有均
质
材料包含的有害物
质
要低于
GB/T26572
限定的要求
Indicates that said hazardous substance contained in all of the homogeneous
materials for this part is below the limit requirement of GB/T 26572
x=
指明
产
品所用的至少一种均
质
材料包含的有害物
质
高于
GB/T26572
限定的要
求
Indicates that said hazardous substance contained in at least one of the
homogeneous materials used for this part is above the limit requirement of
GB/T26572.

4
SAFETY & EMC APPROVALS
SAFETY/EMC Approvals
UL 60950-1 and CSA22.2 No.60950-1 - UL Listed. C-UL for Canada.
IEC 60950-1 - CB Report and Certificate.
EN 60950-1 - CE mark.
IEC/EN 61204-3 - Industrial environment.
Marking of the CE symbol indicates compliance to the EMC Directive and the Low Voltage Directive of the
European Union.
A “Declaration of Conformity” in accordance with the preceding directives and standards has been made and
is available on a file at our EU representative TDK LAMBDA Germany GmbH, Karl-Bold-Str. 40, Achern.
A “Declaration of Conformity” may be accessed via company web site:
https://www.emea.lambda.tdk.com/uk/technical-data/data.aspx?resource=Safety-Certification
WARNING
This product is designed for an industrial environment. In a residential, commercial or light industrial
environment it may cause radio interference. The user may be required to take adequate measures
to reduce interference.
NOTE
This product is a professional equipment, which is not intended for sale to generic public.
FCC Notice
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
NOTE
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy. If not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
WARNING
Modifications not expressly approved by the party responsible for compliance could void the users’
authority to operate the equipment under FCC Rules.

5
GENERAL SAFETY INSTRUCTIONS
READ SAFETY INSTRUCTIONS
The following safety precaution must be observed during all phases of operation, service and repair of this
equipment. Failure to comply with the safety precautions or warnings in this document violates safety
standards of design, manufacture and intended use of this equipment and may impair the built-in
protections within. TDK-Lambda shall not be liable for user’s failure to comply with these requirements.
SERVICING:
These products are not customer serviceable. Parts substitutions and modifications are by authorized
TDK-Lambda service personnel only. For repairs or modifications, the product must be returned to TDK-
Lambda service facility.
CRITICAL COMPONENTS:
These products are not authorized for use as critical components in nuclear control systems, life support
systems or equipment for use in hazardous environments without the express written approval of the
Managing Director of TDK-Lambda Ltd.
PRODUCT USAGE:
These products are designed for use as standalone equipment within a limits described in product Manual.
ENVIRONMENTAL:
These products are IP20, and therefore chemicals/solvents, cleaning agents and other liquids must not be
used.
ENVIRONMENT:
These products are designed for use within a Pollution Degree 2, Overvoltage Category II environment.
OUTPUT LOADING:
The output power taken from the products must not exceed the rating stated on the product label, except
as stated in the product Manual.
INPUT PARAMETERS:
These products must be operated within the input parameters stated in the product Manual.
END OF LIFE DISPOSAL:
The products contains components that require special disposal. Make sure that the unit is properly
disposed of at the end of its service life and in accordance with local regulations.

6
RISK OF ELECTRIC SHOCK
High Voltage Warning: Dangerous voltages are present within the power supply. To avoid injuries,
always disconnect power, discharge circuits and remove external voltage sources before touching
components.
Class I Warning: The unit is Class I product. To minimize electrical shock hazard, the unit must be reliably
earthed and professionally installed. Any interruption of the protective ground conductor or disconnection
of the protective earth terminal will cause a potential shock hazard that might cause personal injury.
Energy Hazards Warning: The main output of the unit is hazardous energy (240VA) and must not be
user accessible in the end application.
Hazardous output Warning: There is a potential shock hazard when using a power supply with an output
voltage greater than 60VDC. Do not turn ON power supply when output voltage is above 60VDC without
output bus-bars/or output connectors protection assembled. Turn OFF power supply or disconnect power
supply from AC mains before making or changing any rear panel connection.
Internal fuse Caution: Internal fuse protect the unit and must not be replaced by the user. In case of
internal defect, the unit must be returned to TDK-Lambda Ltd. or one of their authorized agents.
OTHER
The ventilation openings on these products must not be covered. Ensure that there is at least 10cm
spacing between any obstruction and the ventilation openings.
