TDT MA3 Application guide

MA3 Microphone Amplier
Hardware Reference
Updated 2022-10-31

© 2016-2022 Tucker-Davis Technologies, Inc. (TDT). All rights reserved.
Tucker-Davis Technologies
11930 Research Circle
Alachua, FL 32615 USA
Phone: [phone]
Fax: [phone]
Notices
The information contained in this document is provided "as is," and is subject to being changed,
without notice. TDT shall not be liable for errors or damages in connection with the furnishing, use, or
performance of this document or of any information contained herein.
The latest versions of TDT documents are always online at https://www.tdt.com/docs/
MA3 Microphone Amplier | 2

Table of Contents
MA3 Microphone Amplier
4MA3 Overview
4Power
4MA3 Features
4Inputs
5Bias
5Gain Control
5Outputs
5MA3 Technical Specication
6MA3 Output
6MA3 Frequency Response
Table of Contents | 3

MA3 Microphone Amplier
MA3 Overview
The MA3 is a two-channel microphone amplier for auditory scientists. This high-quality low-
cost system is designed for use with both ¼" audio jack microphones and balanced XLR inputs
for optimum impedance and noise characteristics. The MA3 can provide a bias voltage for
microphones that require it. Two BNC connectors provide analog output. A variable gain knob
provides amplication from 10 dB to 55 dB in 5 dB steps. A toggle switch provides 20 dB of
additional gain for over 5000x total amplication.
Power
The MA3 Microphone Amplier is powered via the System 3 zBus (ZB1PS). No PC interface is
required.
MA3 Features
Inputs
The MA3 comes with three inputs: an XLR microphone input and two ¼" TRS connector inputs.
Signals from two microphones can be amplied simultaneously.
MA3 Microphone Amplier | 4

Bias
The Bias switch produces a bias voltage for microphones that require it.
Gain Control
The gain control amplies the microphone input in 5 dB steps from 10-55 dB (~3x - ~560x).
The Gain Switch adds an additional 20 dB (10x) of gain for a maximum amplication of
~5600x.
Outputs
Two BNC outputs give easy connection to any TDT System 3 device. The maximum voltage
output is ±10 Volts. Clip lights indicate and overvoltage on the signal output.
MA3 Technical Specication
Input Signal Range ±10 V peak
-3 dB Bandwidth 200 kHz @ 40 dB gain
Gain Accuracy ±1 dB
Spectral Variation 1 dB from 20 Hz to 20 kHz
Signal/Noise 110 dB (20 Hz to 30 kHz at 9.9 V)
Noise Floor 9.2 uVrms
THD <0.002% (1 kHz tone, ±7 V peak)
Input Impedance 600 Ohm
Output Signal Range ±10 V peak
Bias Voltage 10 V, 150 mA max, superimposed onto microphone
Output Impedance 5 Ohm
MA3 Microphone Amplier | 5

MA3 Output
MA3 Frequency Response
MA3 Microphone Amplier | 6
