Team Losi Mini-Late Mode User manual

1/18th scale ready-to-run mini-late model
Owner’s Manual
Thank you for choosing the Mini-Late Model from Losi. This guide contains the basic instructions for operating your new
Mini-Late Model. While the Mini-Late Model is great for first-time RC drivers, it does require some mechanical experience and/
or parental supervision for drivers under 14. It is critical that you read all of the instructions in order to operate your model
correctly and avoid unnecessary damage. Please take a moment to look over all the printed materials before operating your
new Mini-Late Model.
Not responsible for errors. All prices subject to
change without notice.
Losi, a Division of Horizon Hobby, Inc.
TM

Page 2
Safety Precautions
This is a sophisticated radio controlled model that must be operated with caution and common sense. Failure to operate your
Mini-Late Model in a safe and responsible manner could result in damage to the model and property. The Mini-Late Model is
not intended for use by children without direct adult supervision. Losi and Horizon Hobby shall not be liable for any loss or
damages, whether direct, indirect, special, incidental, or consequential, arising from the use, misuse, or abuse of this product
or any product required to operate it.
• Thismodeliscontrolledbyaradiosignalsubjecttointerferencefrommanysourcesoutsideyourcontrol.Thisinterference
may cause momentary loss of control, so it is advisable to always keep some distance in all directions around your model
as a safety margin to avoid collisions.
• Alwaysoperateyourmodelinanopenareaawayfromcars,tracandpeople.
• Avoidrunningyourmodelinthestreetwheredamagecanoccur.
• NeverrunyourMini-LateModelwithlowtransmitterbatteries.
• Carefullyfollowthedirectionsandwarningsforthisandanyoptionalsupportequipment.
• Keepallchemicals,smallpartsandanythingelectricaloutofthereachofchildren.
Tools and Items You Will Find Handy
• Softbristlebrushforcleaning
• 5.5mmnutdriverforthewheelnuts.
• #0or#1Phillipsscrewdriver
• .050-inchAllenWrench(LOSA99100)
Note: Use only Losi tools or other high-quality tools. Use of
inexpensive tools can cause damage to the small screws and
parts used on this type of model.
The Radio System
ThefollowingisanoverviewofthevariousfunctionsandadjustmentsfoundontheMini-LateModelradiosystem.Since
the Mini-Late Model operates on a radio signal you control, it is important for you to read and understand about all of these
functions and adjustments before driving.
The Receiver
1. ThrottlePort:WheretheElectronicSpeedControl(ESC)plugsin.
2. SteeringPort:Wherethesteeringservo(s)plugsin.
3. Bind Port: Used to“bind” the receiver to the transmitter.
4. IndicatorLight:Showsthatafrequency/channelisbeingreceived.
The Electronic Speed Controller (ESC)
1. On/OSwitch:PowersthereceiverandESC.
2. SetupButtonandIndicatorLight:UsedforresettingtheESC.
3. Battery Lead: Connects to the battery pack for power.
4. Motor Lead: Connects to the wire leads from the motor.
4
1
2
3
1
3
2
4

Page 3
The Transmitter
1. SteeringWheel:Controlsdirection(left/right)ofthemodel.
2. ThrottleTrigger:Controlsspeedanddirection(forward/reverse)
of the model.
3. Antenna: Transmits signal to the model.
4. On/OSwitch:Turnsthepoweronforthetransmitteroperation.
5. IndicatorLights:Green(top)lightindicatesadequatebattery
power.Red(bottom)lightindicatessignalstrength.
6. SteeringTrim(ST.TRIM):Adjuststhe“handso”directionofthe
model.
7. ThrottleTrim(TH.TRIM):Adjuststhemotorspeedtostopat
neutral.
8. SteeringRate:Adjustsamountfrontwheelsmovewhenthe
steering wheel is turned left or right.
9. SteeringReverseSwitch(ST.REV):Reversesthefunctionofthe
steering when the wheel is turned left or right.
10. ThrottleReverseSwitch(TH.REV):Reversesthefunctionofthe
speed control when pulled back or pushed forward.
11. Bottom Cover: Covers and holds the batteries powering the
transmitter.
Re-Binding the Transmitter to the Receiver
The Losi™DSM®radiosystemincludedintheMini-LateModeloperateson2.4GHz,andprovides79dierentchannels,which
are automatically selected when the transmitter and vehicle are turned on. The communication between the transmitter and
receiver starts in the few seconds after the transmitter and vehicle are both turned on. This is called the “binding process.”The
LosiDSMradiosystemwillnotinterferewithprevioustechnologyradiosystemsthatoperateon27MHzor75MHzfrequencies
and you will not receive any interference from them.
Although set at the factory, below are the steps required to re-bind your transmitter to the receiver should the need arise.
During the bind process there is a unique ID from the transmitter communicated to the receiver to ensure trouble free radio
operation.
Steps to Re-Bind the Receiver to the Transmitter
1. Ensurethatthetransmitterandvehiclearebothturnedo.
2. UsingthesuppliedBindplug(whichlookslikeastandardreceiver
plugwithawireloopinstalled)insertorplugintothereceiverslot
labeled “BIND”. Looking down on the receiver this slot would be
below the LED and is the furthest from the LED, or nearest to the
corner of the receiver.
Note: You do not need to remove any of the other plugs
to re-bind.
3. With the Bind plug installed, turn on the vehicle. Notice a blinking
OrangeLEDwithinthereceiver
4. Now you are ready to turn on the transmitter. You should notice
onthebackofthetransmitterasimilarblinkingOrangeLED
under the translucent cover.
5. BoththereceiverandtransmitterblinkingOrangeLEDwill
stop blinking and become solid indicating they have“bound”
themselves together.
6. Pleaseturnoboththevehicleandtransmittertoremovethe
Bind plug from the receiver. Failing to remove the Bind plug will
cause the transmitter to attempt to rebind every time you turn on the vehicle and transmitter.
7. Turn on both the vehicle and transmitter to ensure operation. If the transmitter does not control the vehicle, please
repeatsteps1to6.ShouldthisnotcorrecttheproblempleasecallHorizonService/Repairforfurtherassistance.
8. The Bind process is complete. Your vehicle’s radio system should be ready for use.
1
7
6
3
9
10
5
4
8
11
2

Page 4
Resetting the ESC
TheESCcomesfromthefactorypre-setandreadyforuse.IfforsomereasonyoushouldneedtoresettheESC,usethe
following instructions.
1. TurnonthetransmitterandESC.Pressthesetupbutton—boththeREDandGREENLEDswillcomeon.
2. Pullthethrottletriggerallthewayback(fullspeed)andpressthesetupbuttononce—onlytheGREENLEDwillcomeon.
3. Pushthethrottletriggerfullforward(brake/reverse)andpushthesetupbuttononce—onlytheREDLEDwillcomeon.
4. Letthethrottletriggerreturntotheneutral(center)positionandpressthesetupbuttononcemoretosavetheprogram
andexitsetupmode—onlytheGREENLEDwillbeon.
Notes:
 A: IfthereceiverdoesnotreceiveasignalfromtheTransmitter,theESCwillnotentertheProgrammode.
B: While in Program mode, the motor will not run.
 C: Ifthesetupbuttonisnotpressedfor20secondswhileintheProgrammode,theESCwillexittheProgrammodeand
the data will be saved.
Chassis Tuning
The Mini-Late Model has several adjustments available to you for tuning the performance for your needs. Although
there are multiple shock positions and camber link locations provided, we have built the model with the best overall
settings. The following are simple adjustments and easily maintained settings to assure proper operation and performance.
It is advised when making any adjustment that you do so in small increments and always check for other parts of the chassis
thatareaected.
Slipper Adjustments
TheMini-LateModelisequippedwithaslipperdeviceoeringbothtraction
control and protection for the transmission. The slipper is primarily used to help
absorb sudden impacts on the drivetrain due to landing big jumps or when
using more powerful aftermarket motors and/or battery packs. Additionally,
it can be used to smooth out the flow of power to the rear wheels and limit
wheel spin when running on extremely slick surfaces. Adjustment is made by
turningthe3mmadjustmentnutclockwise(totheright)toreducetheslip,
orcounterclockwise(totheleft)toincreasetheslip.When
adjusted properly, you should be able to hold the rear tires
firmly and barely be able to push the spur gear forward with
your thumb. To track test, turn the Mini-Late Model on and
place it on the ground. As you push it backwards allowing it to
roll freely, punch the throttle. The slipper should slip no more
than an inch or two as it accelerates. With the included motor
and battery pack it should slip just a little. Make sure you
replace the gear cover before running.
Steering Rate
Your transmitter is equipped with a steering rate control to the left of the steering wheel. This advanced feature, usually found
only on competition-type radios, allows you to adjust the amount the front tires move when you turn the steering wheel. This
is really helpful when you are on slick, as well as high-traction surfaces. If your Mini-Late Model turns too sharply and/or spins
outeasily,tryturningthesteeringratedownbyrotatingtheknobcounterclockwise(totheleft).Forsharperoradditional
steering,tryturningtheknobclockwise(totheright).
Less Rate Full Rate
IncreaseSlip DecreaseSlip

Page5
Camber
Camber is the angle of the tires to the racing surface when viewed from the
front or rear of the vehicle. You want to keep both the front and rear tires
straight up and down or leaning in at the top very slightly. If you are running
on carpet or similar high-traction surfaces, you may find leaning the tires in
a bit more helps. This adjustment is made with the threaded links extending
from the front or rear bulkhead to the spindle carrier or rear hub. Making
the camber rods shorter increases the camber and lean-in of the tire, while
making the camber rods longer decreases the camber.
Toe-In/Toe-Out
This is the relationship of the left and right side
tires to one another. Ideally you want the front of
the tires to be pointed inward to each other just
slightly when viewed from above. This makes the
model track straight and stable. This is controlled
with the threaded steering rods on either side.
As you make them longer you will increase the
toe-in and vice versa. By shortening the links, you
will gain toe-out, which will give the model more
o-powersteeringandmakeitwanderonthe
straightaway.
Ride Height
Thisistheheightthechassissitsandrunsat.SpringspacersincludedwiththeMini-LateModel,wheninstalledbetweenthe
shock top and spring, will increase the pre-load on the spring and raise the chassis. You may want to try this when running on
extremely rough surfaces.
Battery Location
The Mini-Late Model has multiple battery locations. The stock configuration is with the battery in the center of the vehicle in
the back location. You are also able to run the battery in the forward location by putting the battery foam in the rear of the
batterytrayandmovingthebatteryforward.Runningthebatteryintheforwardlocationwillyieldlesso-powersteering
but more on-power steering. The battery also can be used on the left side of the chassis for improved corner speed. Please be
awaresomesetupchangemaybeneededwhenosettingthebatteryontotheleftsideofthevehicle.
Tires
TheMini-LateModelcomeswithhardcompoundfronttiresandstandard(soft)compoundreartires.
Service/Repair
Radio/Speed Control and Motor
If you have any problems other than those covered in the troubleshooting section, please call the electronics service
departmentat(877)504-0233.Theywillbeabletogiveyourspecicproblemadditionalattentionandinstructyouastowhat
needs to be done.
Chassis
Ifyouhaveanyquestionsotherthanthosecoveredinthetroubleshootingormaintenancesections,pleasecall(877)
504-0233.
Cleaning
Performance can be hindered if dirt gets in any of the moving suspension parts. Use compressed air, a soft paintbrush, or
toothbrush to remove dust or dirt. Avoid using solvents or chemicals as they can actually wash dirt into the bearings or
moving parts as well as cause damage to the electronics.
Receiver/Speed Control (ESC) Installation/Removal
Unplugthepowerlead,motorleadsandsteeringservo.Donotattempttoopenthereceiverorelectronicspeedcontrol(ESC)
asonlyafactorytechnicianhasthepropertoolsandpartstomakeanyrepairsnecessary.ThereceiverandESCaremounted
with double-sided foam tape. Use your thumb and index finger at the bottom of the front corners to pull them from the
mount.Ifthisisdicult,askforhelp.Ifnecessary,carefullyusealargeatbladescrewdriverbetweentheunitandthemount
to pry it loose. Make sure you remove any leftover foam or adhesive before remounting with common servo tape or hobby-
type foam tape.
More Camber
Toe-In Toe-Out
Normal

Page 6
Rebuilding the Differential
Thegearsinthedierentialwillwearovertime.Thesameistruefortheoutdrives,driveshaftsandrearaxles.Wesuggest
using a small rag or paper towel to lay out the parts you remove to make it easier to reassemble.
Disassembly
1. Unplug the motor.
2. Removethegearcover(threescrews).
3. Remove the two screws at the extreme rear bottom of the chassis.
4. Remove the screw attaching the rear shock tower to the transmission and the
four screws at the bottom of the chassis holding the gearbox in place and slide it
out of the chassis.
5. Removetheleftsideofthegearboxbyremovingthethreescrews.
6. Remove any shims on the bevel gears and set them aside so they can be
reinstalled in the same location.
7. Carefully remove the large plastic sun gear and the bevel gears on
eithersideofit.Youcanusetheremoveddierentialassemblyasa
guideforputtingtogetherthereplacementunit(alittleLosiTeon
grease#LOSA3066canbeappliedforevenbetterperformance).
8. Remove the center mounted idler gear from the gearbox. Remove
the shaft and push out the ball bearings from either side. Install these
bearings in the new gear.
Reassembly
Replace the idler gear and shaft into the center of the same right side of
the gearbox. Replace any shims removed from the right bevel gear and
slideitthroughthelowerbearing.Replaceanyshimsthatcameoofthe
left side bevel gear and allow them to slide through the lower bearing as
you put the left gear box half back into position. Replace the screws and
reinstall the rebuilt gearbox using the steps in reverse order that were used
to remove it.
Changing the Spur Gear
Removethegearcoverbyremovingthethreesmallscrews.Ifyouarereplacingthespurgearwithoneofadierentsize
(numberofteeth),youmustrstloosen(donotremove)thetwoscrewsthatsecurethemotorandslideitbackslightly.
Remove the 3mm nut at the end of the slipper shaft and all of the slipper parts on the outside of the spur gear as well as
the old gear. Place the new spur gear into position and replace the slipper parts. If you have changed the size of the spur,
seeSettingtheGearMeshbelow.Afteryouhavechangedthespurgear,youwillhavetoadjusttheslipperasdescribed
elsewhere.
Changing the Pinion Gear/Gear Ratio
Before you change the pinion gear ask yourself why you are doing it. In general, if you change to a larger pinion the top speed
will improve but you will see less acceleration and run time. This would only be advisable for really long track layouts with few
tight turns. Changing to a smaller pinion will give you quicker acceleration and possibly a bit longer run time but a little less
topspeed.Thiswouldbegoodforshortlayoutsorwhenrunninghottermotors.ThepinionontheMini-LateModeloersthe
best balance of both. To change the pinion, remove the gear cover, loosen the motor screws, and slide the motor back. Use a
pairofsmallneedle-nosepliersbetweenthemotorplateandbackofthepiniontopushthepiniono.Placethenewpinion
on the end of the motor shaft and, using the flat of the pliers or a similar flat tool, push it on to the same position as the one
removed.SeeSettingtheGearMeshbelow.YourMini-LateModelcomesequippedwitha16-toothpinion,whilethispinion
gear is optimal for most tracks you may find that the included 12-tooth and 14-tooth pinion gears can be advantageous on
shorter tracks.
Warning: When running aftermarket motors, check with the motor manufacturer for correct gearing. Never over-gear
the motor as it can cause overheating, damaging it and the speed control.
Setting the Gear Mesh
Themotorscrewsshouldbeslightlyloose.Slidethemotorforwardallowingthepiniongeartomesh
withthespurgear.Snug(nottight)thebottommotorscrewandtryrockingthespurbackandforth.
There is a slight bit of movement before the motor is forced to turn over. If not, pull the top of the
motor back slightly and recheck. If there is too much slop between the gears, push the top of the
motor forward. When set properly the wheels can be spun forward freely with very little noise. Make
sure to tighten both motor screws and replace the gear cover before running.
To Remove Transmission
ToRemoveGearCover

Page 7
Rebuilding/Refilling the Shocks
Steering Servo Installation/Removal
Unplug the servo lead from the receiver. Remove the four small screws that
secure the servo mount/chassis brace to the chassis. Use a screwdriver or
smallplierstopopthesteeringlinkooftheservo,soitcanberemoved.
There is no need to remove the servo mounts on either side as all service can
be done with them on. Replace in the reverse sequence used to remove it.
Step1
After removing the shock, push
up on the lower spring cup and
remove it from the shaft. Remove
the spring and preload spacers.
Step2
Turn the shock upside down
and remove the black shock
cartridge/shaft assembly from
the shock body by turning it
counterclockwise.
Note: If you only wish to change or
lltheshockuid,skiptostep5.
Step3
Remove the top E-clip from the
shock shaft. Remove the shock
piston. Remove second E-clip.
Remove the old cartridge.
Put a drop of oil on the shock
shaft before installing a new
shock cartridge.
Step4
ReinstallthelowerE-clip.Slide
the shock piston onto the shock
shaft against the E-clip. Reinstall
the top E-clip.
Step5
If you plan on completely
changing the shock fluid
(suggested),dumpoutthe
old fluid from the shock body.
Carefully fill the shock body
with fluid to the bottom of the
threads inside the shock body.
Note: Your Mini-Late Model
comeswith100wtshockuid
from the factory.
Step6
Pull the shaft out so the piston is
next to the cartridge and reinstall
the assembly into the shock body,
turn in a clockwise direction until
snug—DONOTTIGHTENyet!
Step7
Turntheshockoverandusea#0
Phillips screwdriver to remove the
small bleed screw at the top of
theshock.Slowlypushtheshock
shaft up until it stops. Excess fluid
should flow out of the bleed hole.
Slowlypulltheshockshafthalfway
back and replace the bleed screw.
Use pliers to tighten the cartridge,
being careful not to strip the plastic
lobes on the cartridge.
Step8
Replace the spring and spring
cup and test the shock action for
smoothness and leaks. Retighten
the bleed screw or cartridge if
either leaks. Remount the shock on
your truck.
ServoRemoval
Remove these four screws

Page 8
LOSI DSM Radio System
Thisdevicecomplieswithpart15oftheFCCrules.Operationissubjecttothefollowingtwoconditions:(1)Thisdevicemay
notcauseharmfulinterference,and(2)thisdevicemustacceptanyinterferencereceived,includinginterferencethatmay
cause undesired operation.
Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the equipment.
This product contains a radio transmitter with wireless technology which has been tested and found to be compliant with the
applicableregulationsgoverningaradiotransmitterinthe2.400GHzto2.4835GHzfrequencyrange.
The following countries associated regulatory agencies recognizing the noted certifications for this product as authorized for
sale and use are:
USA - Belgium - Canada - Denmark - Finland - France - Germany - Italy - Netherlands - Spain - Sweden - UK
Warning
AnRCmodelisnotatoy!Ifmisused,itcancauseseriousbodilyharmanddamagetoproperty.Operateonlyinopenareasand
follow all instructions included with your radio and model.
Warranty Information
Warranty Period
HorizonHobby,Inc.,(Horizon)warrantiesthattheProductspurchased(the“Product”)willbefreefromdefectsinmaterials
and workmanship at the date of purchase by the Purchaser.
Limited Warranty
(a)ThiswarrantyislimitedtotheoriginalPurchaser(“Purchaser”)andisnottransferable.REPAIRORREPLACEMENTAS
PROVIDEDUNDERTHISWARRANTYISTHEEXCLUSIVEREMEDYOFTHEPURCHASER.ThiswarrantycoversonlythoseProducts
purchased from an authorized Horizon dealer. Third party transactions are not covered by this warranty. Proof of purchase
is required for warranty claims. Further, Horizon reserves the right to change or modify this warranty without notice and
disclaims all other warranties, express or implied.
(b)Limitations-HORIZONMAKESNOWARRANTYORREPRESENTATION,EXPRESSORIMPLIED,ABOUTNON-INFRINGEMENT,
MERCHANTABILITYORFITNESSFORAPARTICULARPURPOSEOFTHEPRODUCT.THEPURCHASERACKNOWLEDGESTHATTHEY
ALONEHAVEDETERMINEDTHATTHEPRODUCTWILLSUITABLYMEETTHEREQUIREMENTSOFTHEPURCHASER’SINTENDED
USE.
(c)PurchaserRemedy-Horizon’ssoleobligationhereundershallbethatHorizonwill,atitsoption,(i)repairor(ii)replace,any
Product determined by Horizon to be defective. In the event of a defect, these are the Purchaser’s exclusive remedies. Horizon
reserves the right to inspect any and all equipment involved in a warranty claim. Repair or replacement decisions are at the
solediscretionofHorizon.ThiswarrantydoesnotcovercosmeticdamageordamageduetoactsofGod,accident,misuse,
abuse, negligence, commercial use, or modification of or to any part of the Product. This warranty does not cover damage due
to improper installation, operation, maintenance, or attempted repair by anyone other than Horizon. Return of any goods by
Purchaser must be approved in writing by Horizon before shipment.
Damage Limits
HORIZONSHALLNOTBELIABLEFORSPECIAL,INDIRECTORCONSEQUENTIALDAMAGES,LOSSOFPROFITSORPRODUCTION
ORCOMMERCIALLOSSINANYWAYCONNECTEDWITHTHEPRODUCT,WHETHERSUCHCLAIMISBASEDINCONTRACT,
WARRANTY,NEGLIGENCE,ORSTRICTLIABILITY.Further,innoeventshalltheliabilityofHorizonexceedtheindividualprice
of the Product on which liability is asserted. As Horizon has no control over use, setup, final assembly, modification or misuse,
no liability shall be assumed nor accepted for any resulting damage or injury. By the act of use, setup or assembly, the user
accepts all resulting liability.
If you as the Purchaser or user are not prepared to accept the liability associated with the use of this Product, you are advised
to return this Product immediately in new and unused condition to the place of purchase.
Law:TheseTermsaregovernedbyIllinoislaw(withoutregardtoconictoflawprincipals).
Safety Precautions
This is a sophisticated hobby Product and not a toy. It must be operated with caution and common sense and requires some
basic mechanical ability. Failure to operate this Product in a safe and responsible manner could result in injury or damage to
the Product or other property. This Product is not intended for use by children without direct adult supervision. The Product
manual contains instructions for safety, operation and maintenance. It is essential to read and follow all the instructions and
warnings in the manual, prior to assembly, setup or use, in order to operate correctly and avoid damage or injury.

Page9
Questions, Assistance, and Repairs
Yourlocalhobbystoreand/orplaceofpurchasecannotprovidewarrantysupportorrepair.Onceassembly,setuporuseof
the Product has been started, you must contact Horizon directly. This will enable Horizon to better answer your questions
and service you in the event that you may need any assistance. For questions or assistance, please direct your email to
[e-mail],orcall877.504.0233tollfreetospeaktoaservicetechnician.
Inspection or Repairs
IfthisProductneedstobeinspectedorrepaired,pleasecallforaReturnMerchandiseAuthorization(RMA).PacktheProduct
securely using a shipping carton. Please note that original boxes may be included, but are not designed to withstand the
rigorsofshippingwithoutadditionalprotection.Shipviaacarrierthatprovidestrackingandinsuranceforlostordamaged
parcels,asHorizonisnotresponsibleformerchandiseuntilitarrivesandisacceptedatourfacility.AServiceRepairRequestis
availableatwww.horizonhobby.comonthe“Support”tab.Ifyoudonothaveinternetaccess,pleaseincludealetterwithyour
complete name, street address, email address and phone number where you can be reached during business days, your RMA
number, a list of the included items, method of payment for any non-warranty expenses and a brief summary of the problem.
Your original sales receipt must also be included for warranty consideration. Be sure your name, address, and RMA number are
clearly written on the outside of the shipping carton.
Warranty Inspection and Repairs
To receive warranty service, you must include your original sales receipt verifying the proof-of-purchase date. Provided
warranty conditions have been met, your Product will be repaired or replaced free of charge. Repair or replacement decisions
are at the sole discretion of Horizon Hobby.
Non-Warranty Repairs
Shouldyourrepairnotbecoveredbywarrantytherepairwillbecompletedandpaymentwillberequiredwithoutnotication
orestimateoftheexpenseunlesstheexpenseexceeds50%oftheretailpurchasecost.Bysubmittingtheitemforrepairyou
are agreeing to payment of the repair without notification. Repair estimates are available upon request. You must include this
request with your repair. Non-warranty repair estimates will be billed a minimum of ½ hour of labor. In addition you will be
billed for return freight. Please advise us of your preferred method of payment. Horizon accepts money orders and cashiers
checks,aswellasVisa,MasterCard,AmericanExpress,andDiscovercards.Ifyouchoosetopaybycreditcard,pleaseinclude
yourcreditcardnumberandexpirationdate.Anyrepairleftunpaidorunclaimedafter90dayswillbeconsideredabandoned
and will be disposed of accordingly. Please note: non-warranty repair is only available on electronics and model engines.
Electronics and engines requiring inspection or repair should be shipped to the following address:
HorizonServiceCenter
4105FieldstoneRoad
Champaign, Illinois 61822
All other Products requiring warranty inspection or repair should be shipped to the following address:
HorizonProductSupport
4105FieldstoneRoad
Champaign, Illinois 61822
Pleasecall877-504-0233withanyquestionsorconcernsregardingthisproductorwarranty.
Instructions for Disposal of WEEE by Users in the European Union
This product must not be disposed of with other waste. Instead, it is the user’s responsibility to dispose of their waste
equipment by handing it over to a designated collection point for the recycling of waste electrical and electronic equipment.
The separate collection and recycling of your waste equipment at the time of disposal will help to conserve natural resources
and ensure that it is recycled in a manner that protects human health and the environment. For more information about
whereyoucandropoyourwasteequipmentforrecycling,pleasecontactyourlocalcityoce,yourhouseholdwaste
disposal service or where you purchased the product.

Page10
troubleshooting guide
•Doesn’toperate Battery not charged or plugged in Charge battery / plug in
Receiverswitchnot“On” Turnonreceiverswitch
Transmitternot“On”orlowbattery Turnon/replacebatteries
•Motorrunsbutrearwheels
don’t move
Pinion not meshing with spur gear Adjust pinion/spur mesh
Pinion spinning on motor shaft Replace pinion gear on motor
Slippertooloose Check&adjustslipper
Transmission gears stripped Replace transmission gears
Drivepininaxlemissing Check&replace
Servoplugnotinreceiver Checkifplugin/alltheway
Servogearsormotordamaged Replaceorrepairservo
•Steeringdoesn’twork
•Won’tturnonedirection Servogearsdamaged Replaceservogears
Motor plugs loose Plug in completely
Motor wire broken Repair or replace as needed
ESCdamaged CallElectronicsTech
•Motordoesn’trun
•ESCgetshot Motor over-geared Put smaller pinion on motor
Drivelineboundup Checkwheels&transforbinds
Ni-MH pack not fully charged Recharge
Charger not allowing full charge Try another charger
Slipperslippingtoomuch Check/adjustslipper
Motor worn out Replace motor
Drivelineboundup Checkwheels&transforbinds
•Poorruntimeand/or
sluggish acceleration
•Poorrange/glitches Transmitterbatterieslow Check&replaceasnecessary
Transmitterantennadamaged Check&tighten
Battery low in truck Replace or recharge
Loose plugs or wires Check motor and power plugs
•Slipperwon’tadjust Drive pin missing in shaft Replace drive pin
Spurgearfacewornout Replacespurgear&adjustslipper

Page 11
use this page to record building and operating notes

13117A
Losi
A Division of Horizon Hobby, Inc.
4105Fieldstone,Champaign,IL61821
www.Losi.com
1-877-504-0233
TM
