Techlogix TL-NS24R2S-POE User manual

TL-NS24R2S-POE
1G Network Switch with 24 RJ45 & 2 SFP - 30W PoE+
www.tlnetworx.com
The TL-NS24R2S-POE passes both data and electrical power to a number of PoE-
compatible devices via standard twisted pair cables. Equipped with 24 Gigabit Ethernet
ports, this switch can power wireless LAN access points and bridges, VoIP phones, IP video
cameras and more while delivering network speeds up to 1,000 Mbps.
The TL-NS24R2S-POE supports the IEEE 802.3at protocol and can inject up to 30 watts
of power per port with a total power budget of 370W. IEEE802.3af- or IEEE802.3at-
compliant devices attached to the switch need no additional power to help avoid the time
and expense of electrical rewiring and minimize the unsightly clutter of power supplies and
adapters on ceilings and walls. Any mix of PoE and non-PoE devices is supported, and
thanks to its short-circuit, overload and high-voltage protection function, your equipment
is well-protected.
Equipped with 24 auto-sensing 10/100/1000 Mbps RJ45 Gigabit Ethernet ports, the
TL-NS24R2S-POE offers plenty of performance for your computers, servers and other
networking devices. In addition, two small form-factor pluggable (SFP) GBIC module slots
provide fiber connectivity for greater distances. These are not shared combo-ports but true
Gigabit ports, pushing the total available bandwidth up to 52G.

LEDs
Switch
PWR – Power is supplied via the AC adapter or the PD port when lit.
Link/Act/Speed (Green) – A device is connected to the port at 1000 Mbps speeds when lit;
a network link has been established and data packets are being sent and received when
flashing; no network link is established when unlit.
Link/Act/Speed (Orange) – A device is connected to the port at 10/100 Mbps speeds when
lit; a network link has been established and data packets are being sent and received when
flashing; no network link is established when unlit.
PoE (Green) – Port is supplying power to a connected PoE device when lit; abnormal power
supply when flashing; no powered device (PD) is connected to the port when unlit.
Normal – Default mode; allows normal communication between ports 1 – 26.
Flow Control – Disables the switch’s flow-control function.
VLAN – Isolates ports 1 – 24 from each other while allowing them to connect to ports 25
and 26.
Power
Rackmount Installation
Use the included power cord to connect the device (on the rear panel) to an AC outlet.The
device supports AC 100 – 240 V, 50/60 Hz.
Located on the right side of the power supply connector, a grounding terminal connector is
used to provide proper grounding for the TL-NS24R2S-POE. If you use the chassis grounding
screw, it should be wired to an object that provides earth ground. In rackmount installations,
grounding is typically provided by the metal frame of the mounting rack.
The switch can be mounted in an EIA standard-sized, 19-inch rack. Attach the mounting
brackets on the switch’s side panels (one on each side) and secure them with the screws
provided. Use the screws provided with the equipment rack to mount the TL-NS24R2S-POE
on the rack.
