Techni Sport Echo Series User manual

GAMING CHAIRS
ASSEMBLY INSTRUCTIONS
REV.ZK-7062-1222
Thank you for purchasing our product
(General representation of our gaming
chairs. The styles, materials, colors and
features vary with series and models)
SERIES MODELS
Echo TSF44
TSF71
Geo TS70
ProGamer2 TS43
TS90
TS92
GG TS51
Lux TS42
Cow Print TS85
Pastel TS86
GameMaster TS83

P.1 P.1
TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
PART # SIZE / DESCRIPTION
A
x1 B
x1 C
x1 D
x1
Backrest Seat 5-Leg star base Mechanism E
x1
F
x5 G-L
x1
G-R
x1
Lift cylinder
Caster Left
armrest
Right
armrest H
x1
Set
Lumbar pillow
Lift cover,
Set of 3 cones
The replacement parts service is limited to
the 48 contiguous United States.
If you reside in AK, HI, PR, U.S. territories
or other countries,
please contact the
supplier from where
the unit was purchased.
Missing, damaged and defective
parts can be replaced at no cost
to you. Please refer to the last
pages on this manual.
Do a quick inventory
of all the parts and
hardware listed below
MAIN PARTS LIST (General representation; the styles, materials, colors and features vary from models
K
USE IN
I-L
x1 Left cover for
seat bracket
I-R
x1 Right cover for
seat bracket J-L
x1 Neck pillow
J-N
x1
Sitting on the chair,
not looking at it
TS85: No straps.
TS42: Heart
shaped with no
straps.
TSF71 doesn't
include neck
pillow.
TS51 & TS83 come
with metal base, the
rest use nylon bases
QTY
M5 Allen wrench
1Steps 1, 2, 5, 6
M8x20
4Mechanism to seat
M8x25
12 Armrests to seat,
seat to backrest
M5x12
2Covers to brackets
L
M
N
O
P
Q
R
HARDWARE LIST AND INCLUDED TOOLS
Ø12, Ø9
O-Ring
16 Mechanism,
armrests, brackets
Ø17, Ø9
Washer
16 Mechanism,
armrests, brackets
Ø25, Ø9
Felt gasket
4Mechanism
4Bracket and seat
side covers
Ø14, Ø11
Hole cover
* Please see below
for important note
about the brackets.
* The left metal bracket on the seat is loose, while the right is stiff and can only move until the chair is assembled.

TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
P.2 P.2
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
• If during assembly you find an issue or need clarification,
please contact our Customer Service for assistance.
Please refer to the last pages on this manual.
• On each step read the instructions thoroughly and
analyze the illustrations before proceeding to do the
assembly.
• Follow the instructions step by step and do not skip any
unless our Customer Service advises it is OK to do so.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes or get stuck
inside the part.
• Make sure you understand which hardware will be
used on each step. Using the wrong size of screw,
bolt or pin might strip the threads or cause damage
to the part in which it is being used.
• To avoid misalignments, always leave the screws loose
and tighten them until all pieces are positioned correctly.
• Sometimes the fabric or material might cover partially or
entirely the screw hole, making the hole appear to be too
small.
• If the hole seems too small for the screw, make sure you
are using the correct size of screw and/or that you are
installing it in the correct hole.
• Do not discard this manual or any of the packaging
material until the unit has been completely assembled.
√
√
M6
30mm
M6x30

O in the middle of the set
STEP 1
Hardware
K
PWasher 4
Pcs
TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
P.3 P.3
Flip over the seat Band place the felt gaskets Qover the innermost holes in the
middle and back of the frame.
Place the mechanism Dover the felt gaskets, making sure its tension knob
faces towards the FRONT.
Secure the mechanism to the seat with screws L, O-rings Oand washers P,
making sure the O-ring go in the middle of the hardware set.
RIGHT
G-R LEFT
G-L
(Front)
ASSEMBLY STEPS
MM8x25 8
Pcs
Assemble the armrests G-L, G-R to the
seat Bin their respective sides with
screws M, O-rings Oand washers P,
making sure the O-ring go in the middle of
the hardware set.
OO-ring 8
Pcs
STEP 2
Hardware STEP 3
Insert the casters Finto the legs of the
base Cusing pressure, then place the
lift cylinder Ein the middle of the base
and cover it with H.
K
PWasher 8
Pcs M
O
P
B
H
E
C
F
LM8x20 4
Pcs
OO-ring 4
Pcs
B
(Front)
(Front) L
O
P
(8 sets of hardware)
(4 sets of hardware)
QFelt gasket
4
Pcs
Q
D
O in the middle of the set

TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
STEP 4
P.4 P.4
Attach the covers I-L, I-R to the seat brackets on their respective sides with screws
N, then cover the screw holes with R.
Join the base parts to the seat making
sure the tip of the lift Eenters correctly
into the hole of the mechanism D.
Assemble the backrest Ato the metal
brackets on the seat Bwith screws M,
O-rings Oand washers P, making sure
the O-ring go in the middle of the
hardware set.
D
E
Buckle-up
from behind
MM8x25 4
Pcs
OO-ring 4
Pcs
STEP 5
Hardware
K
PWasher 4
Pcs
MO P
(4 sets of
hardware)
NM5x12 2
Pcs
R4
Pcs
STEP 6
Hardware
KR N
RIGHT
I-R
LEFT
I-L
RN
R
R
STEP 7 Attach the pillows J-L (lumbar) and J-N (neck) to the backrest Aby fastening the
strap buckles from behind.
J-N
J-L NOTES:
1. The lumbar pillows on
TS42 and TS85 have
no straps.
2. TSF71 doesn't include
a neck pillow.
A
AB
B
O in the middle
of the set

TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
P.5 P.5
To raise or lower the chair’s height, pull UP the lever that is under the seat on the right side.
The chair goes down while sitting on it, or up if you lift your body.
The chair also tilts by pulling OUT the same lever to unlock, but please note that unlike regular
chairs, gaming chairs have their balance centered farther back, so the chair feels harder to tilt.
The mechanism under the seat has a tension knob at the front that you can turn and it will
make the tilting feel little easier, but please refer to the notes in point 2 about the tilting.
To recline the backrest to a specific angle, pull UP the short lever located on the right side of
the seat, recline and then release the lever to lock into the desired position.
To adjust the armrest height, press the button that is on the outside of the armrest and release
it once the desired height is reached. Some models have additional functions for the arm pads
such as turning and sliding.
To clean the chair it is recommended to use a soft cloth lightly damped in a solution of smooth
soap and water, then dry with a clean towel.
Do not use solvents or abrasive materials to clean any part of the chair.
Before using a cleaning agent, test on a small hidden area of the chair, like underneath the seat.
Do not expose the product to direct sunlight or to extreme environmental conditions.
Inspect the chair completely every 4 months and make sure that all screws are tighten. Do not
use if parts are bent, damaged, or if screws are loose or missing.
CHAIR'S FUNCTIONS
2
1
1
2
3
4
5
!
CARE AND MAINTENANCE
WEIGHT LIMIT AND WARNINGS
Do not exceed the indicated weight limit.
Do not stand up on the chair or use it as ladder.
Only one person at a time can sit on the chair.
Do not use the chair if parts are bent, damaged, or if screws are loose or
missing.
Unlike regular chairs, gaming chairs have their balance centered farther
back, so do not sit near the edge of the seat to avoid going beyond your
balance point and falling off the chair, and always sit properly.
If small children are sitting on the chair, keep close observation on them.
Do not allow small children to play with the chair.
Not paying attention to these warnings could result in injuries.
5
3
250
Lbs
TS43
TS70
TS90
TS92
TSF44
TSF71
300
Lbs
TS42
TS51
TS83
TS85
TS86
MODELS
LIMIT
4
WARNING: For your safety, the tilt's function should be in the LOCKED (IN) position prior
to use the backrest reclining function . 2
4
!Read
warning
above

GAMING CHAIR: 2-YEAR WARRANTY
INTERNAL METAL FRAME*: LIFETIME WARRANTY
TS42, TS43, TS51, TS70,TS83, TS85, TS86, TS90, TS92, TSF44, TSF71
P.6 P.6
TECHNI SPORT CHAIR WARRANTY
RTA Products, LLC has warranted the Techni Sport products to the original purchaser who acquired a new
product from RTA Products or its authorized re-sellers of the product against defects in material or
workmanship.
This warranty is expressly limited to the repair or replacement (at its option) of defective product
components or materials as a result of a defect in materials or workmanship. This warranty is limited to
merchandise purchased in the Continental United States, excludes AK, HI and PR. No assembly labor is
included. The word "defects" as used in this warranty, is defined as imperfections that impair the utility of
the product.
Replacement Parts under Warranty for International / AK-HI-PR orders : RTA Products will replace the part
free of charge, while customer is responsible for shipping costs plus any International local taxes or duties.
Warranty for International orders - replacement parts: buyer is responsible for shipping costs plus any
local taxes or duties.
This warranty applies under conditions of normal use, but does not apply to defects that result from
intentional damage, wear & tear, negligence, unreasonable use or exposure.
Internal metal frame*: Refers to the internal metal steel structure of the seat and back only.
Liability for consequential damages is excluded to the extent exclusion is permitted by law. This warranty
gives you specific legal rights, and you may have other rights that vary from State to State.
RTA Products does not warrant: a) natural variations in character marks b) changes in surface finishes
due to aging or exposure to light c) marks, scars, or wrinkles occurring naturally in leather d) failure
resulting from normal wear and tear e) the matching of colors, grains, or textures of natural materials f) the
colorfastness or the matching of textiles, including an exact match to cuttings or to swatch cards g)
damage, marking, or staining of veneer surfaces due to contact with rubber or similar compounds,
damage from sharp objects or imprinting from writing instruments, or prolonged exposure to direct sunlight
h) we do not warrant products that are exposed to extreme environmental conditions or that have been
subject to improper storage.
RTA Products shall not be liable for loss of time, inconvenience, commercial loss, or incidental or
consequential damages.
Any modification to the original product voids the warranty. We do not warrant the performance of the
product when used in combination with other than original products.
This product has been designed for and is intended for office, home-office and gaming use only. This
warranty is Original Purchaser’s sole remedy for product defects, and this warranty does not extend to any
product, or damage to any product, caused by or attributed to abuse or misuse, products used for
commercial or rental purposes, use modifications of, or attachments to the product, and products or parts
not used, maintained, or extended here under is in lieu of any and all other warranties, express or implied,
including without limitations any implied warranty or merchant ability or of fitness for a particular purpose.
Report any defects to RTA Products, LLC together with your sales receipt or other proof of purchase. If the
chair is defective within the terms of the warranty, RTA Products, LLC will furnish a replacement chair (at
its option) at no cost of equal or similar value and design.
RTA Products will advise you of the procedure to follow in making warranty claims. The following are the
procedures for warranty claims:
a) Contact us directly via e-mail to [email protected] Please provide your original ORDER#.
Explain in your e-mail the issue/s you have with our product. Please allow up to 24 hrs for our Customer
Support team to reply. If your matter is urgent and requires immediate attention, you are welcome to call
us between Monday - Friday - from 9am-4pm (Eastern Standard) at 866-782-5520. Please be advised that
you are still required to provide all details in writing via e-mail.
b) If we determine that replacement will remedy the situation, and in order to determine the extent or the
cause of the defect, purchaser will need to send the part in question at purchaser’s expense. Once we
receive the part, we will examine it and determine whether the claim is valid (or not), and then proceed to
send the replacement. We will ship the replacement at our expense.

Scan the following QR Code to send us a message:
[email protected]
EMAIL US:
To request replacement parts, email us with the model number
of the product, the part number or letter of the requested part,
and proof of purchase.
Your satisfaction is very important to us. Our Support agents can help
you with any issues you may have, please feel free to contact us with any
questions you have about our products, or to request replacement parts.
FOR ADDITIONAL INFORMATION
PLUS HELP OPTIONS
VISIT: WWW.TECHNISPORTUSA.COM
AND CLICK ON INFO/SUPPORT
