Techni Sport RTA-TS38C User manual

TECHNI SPORT MESH OFFICE-PC CHAIR
REV.ZK-7268-0423
MODEL RTA-TS38C
ASSEMBLY INSTRUCTIONS
Thank you for purchasing our product

K
x1
P.1 P.1
RTA-TS38C
PART # SIZE / DESCRIPTION
A
x1 B
x1 C
x1 D
x1
Backrest Seat with retractable
foot rest 5-Leg star nylon base Multi-function
Mechanism
E
x1 F
x5 G-L
x1 G-R
x1
Lift cylinder Rollerbade
Caster Left armrest Right armrest
Support for
backrest
MAIN PARTS LIST
USE IN
Headrest Backrest cover
QTY
M6x20
9Mechanism to seat,
backrest to support,
headrest to backrest
M6x306
Support to mechanism
M8x20
3
Armrests to seat
M
N
O
P
HARDWARE LIST
Ø8.5, Ø17, 1mm
Metal washer
6Armrests to seat
(Front) (Front)
Sitting on the
chair, not
looking at it
H
x1 I x1 J
x1
M5 Allen wrench
1Use in steps 1, 2, 3, 6 & 7
INCLUDED TOOLS
Q
Plastic washer
2Armrests to seat
(Scaled
reference)
Lift cover, SET
of 3 cones L
x1 Headrest cover
Sitting on the
chair, not
looking at it
Replacement Parts for International
Customers & AK-HI-PR orders:
RTA Products will replace the part free of
charge, while the customer is responsible
for shipping costs plus any International
local taxes or duties.
Do a quick inventory
of all the parts and
hardware listed below.
For Support, assembly questions
& Replacement Parts within the
48 Contiguous United States:
Please email us at:
[email protected]

P.2 P.2
BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
• On each step read the instructions thoroughly and
analyze the illustrations before proceeding to do the
assembly.
• Follow the instructions step by step and do not skip any
unless our Customer Service advises it is OK to do so.
• Do not overtighten or force the screws as they might
break, strip, damage the threads of the holes or get stuck
inside the part.
• Make sure you understand which hardware will be
used on each step. Using the wrong size of screw,
bolt or pin might strip the threads or cause damage
to the part in which it is being used.
• To avoid misalignments, always leave the screws loose
and tighten them until all pieces are positioned correctly.
• If the hole seems too small for the screw, make sure you
are using the correct size of screw and/or that you are
installing it in the correct hole.
• Do not discard this manual or any of the packaging
material until the unit has been completely assembled.
√
√
M6
30mm
M6x30
RTA-TS38C
• If during assembly you find an issue or need clarification,
please contact our Customer Service for assistance.
Please refer to the last pages on this manual.

(Front)
STEP 1
Hardware
P.3 P.3
Place the mechanism Dwith its tilt knob facing towards the FRONT, and assemble
it with screws M.
ASSEMBLY STEPS
MM6x20 4
Pcs
Flip over the seat Band pull out the footrest to allow acces to the side holes. Put
the plastic washers Qover the INNERMOST holes, and assemble the armrests
G-L, G-R in their respective sides with screws N and metal washers P.
PLEASE NOTE:
• The armrests lean forward towards the FRONT of the chair.
• The side (left or right) is defined with you sitting on the chair, not looking at it.
STEP 2
Hardware
NM6x30 6
Pcs
K
PMetal
Washer
6
Pcs
RTA-TS38C
PULL OUT FOOTREST AND
PLACE PLASTIC WASHERS
RIGHT
G-R
PLASTIC WASHERS
FOR INNERMOST
HOLES ONLY
LEFT
G-L
(Front)
ASSEMBLE THE
ARMRESTS
N
P
K
D
B
I
Assemble the support Iunder the plate of the mechanism Dwith screws O.
The screws go through the plate and into the holes of I.
OM8x20 3
Pcs
STEP 3
Hardware
I goes under
the plate
K
D
M
M
QPlastic
Washer
2
Pcs
Q
Q
(RIGHT)
(LEFT)

A
I
STEP 5
P.4 P.4
Join the base parts to the seat making
sure the tip of the lift Eenters correctly
into the hole of the mechanism D.
RTA-TS38C
MM6x20 3
Pcs
STEP 6
Hardware
K
Flip the unit upright and assemble the backrest Ato the support Iwith screws M.
MM6x20 2
Pcs
STEP 7
Hardware
K
Assemble the headrest Jto
the backrest Awith screws M.
M
E
D
STEP 8
Attach the backrest cover Kto the support Iand
the headrest cover Lto the headrest J.
STEP 4
Insert the casters Finto each
leg of the base Cusing
pressure, then place the lift
cylinder Ein the middle of the
base and cover it with H.
F
C
E
H
J
A
J
I
L
K
M

RTA-TS38C
P.5 P.5
To raise or lower the chair’s height, flip DOWN the handle on the lever that is under the seat on
the right side. The chair goes down while sitting on it, or up if you lift your body.
To recline the backrest to a specific angle, pull OUT the same lever, recline and then push IN
the lever to lock at the desired angle. To return to the normal upright position, UNLOCK the
lever, push back a little bit on the backrest, then pull yourself forward and lock the lever.
You can turn the tension knob at the front of the mechanism under the seat to make the
reclining feel either easier or with more resistance according to your preference.
To use the footrest, pull it out from under the seat, and flip it UP. To close it while you are still
sitting on the chair, flip it back DOWN and push it IN under the seat.
WARNING: NEVER try to get up from the chair while the footrest is OUT.
To adjust the armrest height, press the button that is on the outside of the armrest and release
it once the desired height is reached.
For comfort, the headrest can be adjusted UP and DOWN or tilted forward/backwards.
To clean the chair it is recommended to use a soft cloth lightly damped in a solution of smooth
soap and water, then dry with a clean towel.
Do not use solvents or abrasive materials to clean any part of the chair.
Before using a cleaning agent, test on a small hidden area of the chair, like underneath the seat.
Do not expose the product to direct sunlight or to extreme environmental conditions.
Inspect the chair completely every 4 months and make sure that all screws are tighten. Do not
use if parts are bent, damaged, or if screws are loose or missing.
CHAIR'S FUNCTIONS
2
1
1
2
3
4
6
!
CARE AND MAINTENANCE
WARNINGS
Do not exceed the indicated weight limit.
Do not stand up on the chair or use it as ladder.
Only one person at a time can sit on the chair.
Do not use the chair if parts are bent, damaged, or if screws are loose or
missing.
NEVER try to get up from the chair while the footrest is OUT.
If small children are sitting on the chair, keep close observation on them.
Do not allow small children to play with the chair.
Not paying attention to these warnings could result in injuries.
5
WEIGHT LIMIT
275
Lbs
(125 Kg)
5
34
6
!Read warning above

P.6 P.6
RTA-TS38C
TECHNI SPORT CHAIR WARRANTY
RTA Products, LLC has warranted the Techni Sport products to the original purchaser who acquired a new
product from RTA Products or its authorized re-sellers of the product against defects in material or
workmanship.
This warranty is expressly limited to the repair or replacement (at its option) of defective product
components or materials as a result of a defect in materials or workmanship. This warranty is limited to
merchandise purchased in the Continental United States, excludes AK, HI and PR. No assembly labor is
included. The word "defects" as used in this warranty, is defined as imperfections that impair the utility of
the product.
Replacement Parts under Warranty for International / AK-HI-PR orders : RTA Products will replace the part
free of charge, while customer is responsible for shipping costs plus any International local taxes or duties.
Warranty for International orders - replacement parts: buyer is responsible for shipping costs plus any
local taxes or duties.
This warranty applies under conditions of normal use, but does not apply to defects that result from
intentional damage, wear & tear, negligence, unreasonable use or exposure.
Internal metal frame*: Refers to the internal metal steel structure of the seat and back only.
Liability for consequential damages is excluded to the extent exclusion is permitted by law. This warranty
gives you specific legal rights, and you may have other rights that vary from State to State.
RTA Products does not warrant: a) natural variations in character marks b) changes in surface finishes
due to aging or exposure to light c) marks, scars, or wrinkles occurring naturally in leather d) failure
resulting from normal wear and tear e) the matching of colors, grains, or textures of natural materials f) the
colorfastness or the matching of textiles, including an exact match to cuttings or to swatch cards g)
damage, marking, or staining of veneer surfaces due to contact with rubber or similar compounds,
damage from sharp objects or imprinting from writing instruments, or prolonged exposure to direct sunlight
h) we do not warrant products that are exposed to extreme environmental conditions or that have been
subject to improper storage.
RTA Products shall not be liable for loss of time, inconvenience, commercial loss, or incidental or
consequential damages.
Any modification to the original product voids the warranty. We do not warrant the performance of the
product when used in combination with other than original products.
This product has been designed for and is intended for office, home-office and gaming use only. This
warranty is Original Purchaser’s sole remedy for product defects, and this warranty does not extend to any
product, or damage to any product, caused by or attributed to abuse or misuse, products used for
commercial or rental purposes, use modifications of, or attachments to the product, and products or parts
not used, maintained, or extended here under is in lieu of any and all other warranties, express or implied,
including without limitations any implied warranty or merchant ability or of fitness for a particular purpose.
To file a Claim within the 48 contiguous United States:
Email us to [email protected] to explain the defect and provide your name, address, phone
number, model number of our product, date and place, and proof of purchase. Please provide pictures of
the damage or defect. If we determine that a replacement will remedy the situation, and in order to
determine the extent or the cause of the defect, purchaser may be requested to send the part in question
at purchaser’s expense. Once we receive the part, we will examine it and determine whether the claim is
valid (or not), and then proceed to send the replacement. We will ship the replacement at our expense.
Replacement Parts for International Customers & AK-HI-PR orders:
RTA Products will replace the part free of charge, while the customer is responsible for shipping costs plus
any International local taxes or duties.
GAMING CHAIR: 2-YEAR WARRANTY
INTERNAL METAL FRAME*: LIFETIME WARRANTY
