Techni Sport RTA-TS220L User manual

2 PERSONS
REQUIERED
MODEL RTA-TS220L
ASSEMBLY INSTRUCTIONS
Thank you for purchasing one of our products.
Please read carefully the assembly instructions before the
installation.
Do not discard this manual or any of the packaging material until
the unit has been completely assembled.
Distributed By

Leg Structure Leg Structure
Long Tabletop
Short Tabletop
Long Frame Structure
Fixing SET
Stand Panel
Bracket
Small Cup Holder Large Cup
Holder
Earphone Hanger
Stand Support
MAIN PARTS LIST
P.2
RTA-TS220L
P.2
Stud
Left Base
Structure
Middle Base
Structure
Right Base
Structure
Short Frame Structure

MAIN PARTS LAYOUT (FOR REFERENCE):
P.3
RTA-TS220L
P.3
SCREWS LIST:

BEFORE YOU START THE ASSEMBLY, PLEASE READ THE FOLLOWING TIPS AND WARNINGS.
P.4
RTA-TS220L
P.4
☛
Do a quick inventory to make sure the product contains all the parts and hardware.
☛
Missing, damaged and defective parts can be replaced at no cost to you. Please
refer to the CONTACT card included with the product.
☛
The replacement parts service is limited to the continental United States. If you reside in
Hawaii, Puerto Rico, U.S. Dependencies or other countries, please contact the supplier
from where the unit was purchased.
☛
If during assembly you find an issue or need clarification, please contact our Customer
Service for assistance. Please refer to the CONTACT card included with the product.
☛
On each step read the instructions and analyze the illustrations thoroughly before
proceeding to do the assembly.
☛
To avoid misalignments, always leave the screws loose and tighten them until all pieces
are positioned correctly.
☛
Do not overtighten or force the screws as they might break, strip, damage the threads
of the holes or get stuck inside the part.
☛
Sometimes the laminate might cover partially or entirely the hole on a panel, but the
hole should still be located under the laminate.
☛
If there is no visible hole for the screw, pass and press the tip of your finger over the
area where the hole should be located to feel the indentation, and once found, carefully
pierce the laminate to reveal the hole underneath.
☛
If the hole seems too small for the screw, first make sure you are using the correct size
of screw and that it’s been installed in the correct hole. If the hole still appears to be too
small, carefully pierce the laminate to reveal the hole’s actual size.
☛
Make sure you understand which hardware will be used on each step. Using the wrong
size of screw, bolt or pin might strip the threads or cause damage to the part in which it
is being used.

ASSEMBLY STEPS
P.5
RTA-TS220L
P.5
Insert the studs (6) to the bottom of the leg structures (1) and (2), and to the corner of each base structure
(3), (4) and (5) as shown.
With the short frame structure (7) oriented as shown, attach the structures as indicated:
1st: Leg (1) to frame (7).
2nd: Base (3) to leg (1).
3rd: Leg (2) to base (3) and frame (7) as shown.
(1ST)
(This view shows the back side of the frame upside-down on the floor)
(2ND)
(3RD)
(3RD)

P.6
RTA-TS220L
P.6
Using screws (A), secure the legs (1) and (2) to the base (3) and the frame (7) as shown.
With the long frame structure (8) oriented as shown, attach the structures as indicated:
1st: Leg (1) to frame (8) on the right, and leg (2) to frame (8) on the left;
2nd: Base (4) to leg (1) on the right, and base (5) to leg (2) on the left.
3rd: Leg (2) to base (4) and frame (8) on the right, and leg (1) to base (5) and frame (8) on the left.
PAY CLOSE ATTENTION TO THE ORIENTATION OF THE PARTS.
(1ST)
(2ND)
(3RD)
(1ST)
(This view shows the back side of the frame upside-down on the floor)
(This view shows the back side of the frame upside-down on the floor)

P.7
RTA-TS220L
P.7
Using screws (B), washers (F) and nut caps (E), assemble the frame (7) to frame (8) as shown.
Using screws (A), secure the legs (1) and (2) to the bases (4) and (5), and to the frame (8) as shown.
(This view shows the back side of the frame upside-down on the floor)
PAY CLOSE ATTENTION TO THE ORDER
AND ORIENTATION OF THE HARDWARE.

P.8
RTA-TS220L
P.8
With the tabletops (9) and (10) upside-down and oriented as shown, attach to them the brackets (11)
using screws (A) as shown.
(This view shows the tabletops upside-down on the floor)
With the help of another person, place the frame from step 6 upside-down over the tabletops (9) and (10)
making the holes coincide, then assemble the frame using screws (C) as shown.
TO AVOID
MISALIGNMENTS, FIRST
SCREW LOOSELY AND
TIGHTEN AFTER ALL THE
SCREWS ARE IN PLACE.
Assemble the stand support (14) to the stand panel (13) using screws (A), then insert the protectors from
the fixing set (12) in the supports as shown.

P.9
RTA-TS220L
P.9
Carefully and with the help of another person, turn the unit upright, then select the option of your
preference: 🅐, 🅑or 🅒, and attach the stand panels to the tabletops by inserting and tightening the
screw knobs (12) into the supports from underneath as shown.
OPTIONS:
VERY IMPORTANT:
BEFORE ATTACHING, MAKE
SURE THE SUPPORTS HAVE
THE PROTECTORS INSERTED
AS INDICATED IN STEP 9.
(This view shows the unit upright and from its back)

P.10
RTA-TS220L
P.10
DONE! Before you start using, please read all the warnings in the next page.
☛You have different options for the assembly of the accessory items on either side of the unit;
install them according to your needs.
Using screws (D), assemble on either side and from underneath the tabletops (9) and (10), the earphones
hanger (15), the small cup holder (16), and the large cup holder (17).

P.11
RTA-TS220L
P.11
•Do not exceed the indicated weight limits.
•Do not expose the surfaces to direct sunlight or to extreme environmental conditions.
•Clean the surfaces preferable with a clean cloth damped in a solution of mild soap and water, then dry with a
clean towel.
•Do not use solvents or abrasive materials to clean the unit.
•If you decide to use a cleaning agent, test first on an area hidden from view such as underneath the tabletops.
•Do not seat on the unit or lean against it.
•Do not allow small children to play on or below the unit, or with the stand shelves or the accessories.
•The unit must be handled by at least 2 persons when moving in the same or adjacent rooms, preferable 3
persons: 2 holding the ends and 1 holding the corner.
•Before moving the unit, make sure to remove any object that is heavy or might fall off, and try to handle it from
their structures. Lifting from the tabletops alone might put too much stress on the screws which can lead to part
damage/separation.
•When lifting the unit, use both hands and bend your knees, not your backs.
•When transporting the unit to places far away, protect and secure the unit to avoid damage in transit.
•Shall any part of the unit become defective during the warranty period, replacement parts might be available to
you at no charge. Please refer to the WARRANTY card included with the product.
•The warranty does not extend to regular wear and tear, nor the manufacturer assumes liability for damages or
consequences due to accidents, incorrect assembly, negligence, improper use, modifications, or not heeding the
above warnings.
AFTER THE ASSEMBLY IS DONE, PLEASE READ CAREFULLY THE FOLLOWING
CARE AND MAINTENANCE WARNINGS:
WEIGHT LIMITS 11 Lbs. (5 Kg)
130 Lbs. (60 Kg)
3.25 Lbs. (1.5 Kg)
3.25 Lbs. (1.5 Kg)
3.25 Lbs. (1.5 Kg)
130 Lbs. (60 Kg)
