Technica 100BASE-T1 SPY Mini User manual

100BASE-T1
MEDIACONVERTER
BCM
Manual-Version: 2.0
Hardware-Version: all
USER MANUAL
November 2018
100BASE-T1
MEDIACONVERTER
EMC_Set

100BASE-T1 MediaConverter_EMC User Manual
2
CONTENT
1GENERAL INFORMATION........................................................................................... 3
1.1 Functionality and Features of the 100BASE-T1 MediaConverter_EMC ........... 3
1.2 Warranty and Safety Information ........................................................................ 5
1.3 Declaration of conformity .................................................................................... 6
2HARDWARE INTERFACES .......................................................................................... 7
2.1 Connectors............................................................................................................ 7
2.1.1 Black MQS Connector ................................................................................... 7
2.1.2 SFP-Interface ................................................................................................. 9
2.2 Other interfaces .................................................................................................... 9
2.2.1 DIP-Switches .................................................................................................. 9
2.2.2 Status LEDs.................................................................................................... 9
3CONFIGURATION OF THE DEVICE........................................................................... 10
4EMC Measurement Setup......................................................................................... 11
5100BASE-T1 FILTER.................................................................................................. 12
6GENERAL EMC TEST INFORMATION...................................................................... 13
7ADDITIONAL INFORMATION.................................................................................... 14
8LIST OF FIGURES....................................................................................................... 15
9CHANGELOG ............................................................................................................. 16
10 CONTACT................................................................................................................ 17

100BASE-T1 MediaConverter_EMC User Manual
3
1GENERAL INFORMATION
1.1 Functionality and Features of the 100BASE-T1
MediaConverter_EMC
The Technica Engineering 100BASE-T1 MediaConverter_EMC is always in a set of
two devices. One Device transmits data frames directly from the physical layer
100BASE-T1 to a proprietor optical Ethernet SFP-module port. The Delay time is
constant 2.0µs. The standard operational area is getting a connection to a device
under test in a shielded EMC Chamber. The recommended application can be seen in
the following picture:
Figure 1—2: Recommended application of the 100BASE-T1 MediaConverter_EMC_Set
(For more details please see chapter 4)
Figure 1—1: 100BASE-T1 MediaConverter_EMC_Set

100BASE-T1 MediaConverter_EMC User Manual
4
Features of one device:
•1 Port BroadR-Reach Ethernet 100 MBit/s Fullduplex on a single unshielded
twisted pair
•1 Port optical Ethernet SFP Module
•Automotive Tyco MQS Connectors for BroadR-Reach and Power Supply
•Robust steel case
•DIP Switches for easy configuration
General Information:
Power requirement:
10 to 13 Volt DC (nominal 12 Volt DC)
Power consumption:
3 Watt
Size:
92 x 63 x 30 mm
Weight:
0,2 kg
International Protection:
IP 2 0
Operating temperature:
-40° to +80 °Celsius
LINKS:
The User can download the latest firmware and documentation for the 100BASE-T1
MediaConvert_EMC_Set here:
https://technica-engineering.de/produkt/100base-t1-mediaconverter_emc-set/

100BASE-T1 MediaConverter_EMC User Manual
5
1.2 Warranty and Safety Information
Before operating the device, read this manual thoroughly and retain
it for your reference.
The latest documentation for the 100BASE-T1 MediaConverter_EMC
can be downloaded here:
https://technica-engineering.de/produkt/100base-t1-
mediaconverter_emc-set/
Use the device only as described in this manual.
Use only in dry conditions.
Do not apply power to a damaged device.
Do not open the device. Otherwise warranty will be lost.
This device is designed for engineering purpose only.
Special care has to be taken for operation.
Do not use this device in a series production car.
As this device is likely to be used under rough conditions, warranty is
limited to 1 year.
Manufacturer liability for damage caused by using the device is
excluded.

100BASE-T1 MediaConverter_EMC User Manual
6
1.3 Declaration of conformity
Figure 1—3: Declaration of conformity

100BASE-T1 MediaConverter_EMC User Manual
7
2HARDWARE INTERFACES
2.1 Connectors
On the label on top of the device you can see an overview about all HW-Interfaces of
the 100BASE-T1 MediaConverter_EMC
2.1.1 Black MQS Connector
The pinning of the ECU connectors is listed on the label on top of the device as well.
(See Figure 2—1).
The Connector color is black.
The power supply for the device is supplied by pin 1 (12 Volt) and pin 10 (Ground)
Warning: If you apply a voltage higher than 13 Volt, the device will be damaged!
Figure 2—1: Label of 100BASE-T1 MediaConverter_EMC with pinning information

100BASE-T1 MediaConverter_EMC User Manual
8
The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.
Name
Part Number
Tyco, MQS Abdeckkappe 2x9 Pol, black
Alternative
1-967416-1
1-1355350-1
Tyco, MQS Buchsengehäuse 2x9 Pol
Alternative
965778-1
962108-2
Tyco crimp contact
928999-1
Table 2—1: Parts of black MQS connector
Note: You can use the official Tyco tool for these crimp contacts. A cheap variant is
the crimp tool for “PSK” contacts.
Pin
Function
Pin
Function
1
Battery +12 Volt Input
10
Power Ground
2
Reserved
11
Reserved
3
n.c.
12
n.c.
4
Power output + fed through CMC*
13
n.c.
5
Power output - fed through CMC*
14
n.c.
6
n.c.
15
n.c.
7
n.c.
16
n.c.
8
BroadR-Reach Port, Negative
17
n.c.
9
BroadR-Reach Port, Positive
18
n.c.
Table 2—2: Pinning of black MQS connector
*These pins supply power to another device with common mode choke filter inside.
Note: The power supply on these pins are maximum 0,6A

100BASE-T1 MediaConverter_EMC User Manual
9
2.1.2 SFP-Interface
There is one SFP cage for a MiniGBIC module.
It is not possible to use standard SFP-modules in this SFP-cage. In the parts list of the
100BASE-T1-MediaConverter_EMC_Set there are special reworked optical SFP-
modules, which are matching to the 100BASE-T1 MediaConverter EMC. It is
recommended to use these modules.
2.2 Other interfaces
2.2.1 DIP-Switches
The 100BASE-T1 MediaConverter_EMC has two DIP-Switches for configuration (see
Chapter 3).
2.2.2 Status LEDs
The 100BASE-T1 MediaConverter_EMC_Set has two status LEDs at the frontside of
the case for the 100BASE-T1 Port.
Upper LED:
Green Color. It is lit when there is a linkup on the 100BASE-T1 port.
Lower LED:
Yellow Color. It is toggling in alternation with the green LED when there is
communication.
Note: There is a bug in the used BroadR-Reach PHY. When the BR Plus and Minus lines
are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit, but there
is no data transmission possible. So please connect the 100BASE-T1 lines correctly.

100BASE-T1 MediaConverter_EMC User Manual
10
3CONFIGURATION OF THE DEVICE
The 100BASE-T1 MediaConverter EMC is configured by two DIP-Switches on the front
of the device.
DIP-Switch
Status
Description
1
ON (up)
OFF (down)
100BASE-T1 Port is set to Master
100BASE-T1 Port is set to Slave
2
ON (up)
OFF (down)
100BASE-T1 Port is set to FullOut
100BASE-T1 Port is set to HalfOut
Table 3—1: Configuration of DIP-Switches
Note:In a 100BASE-T1 Link one device must be set to Master, the other must be set
to Slave Mode.
Note: The MediaConverter should always be set to FullOut. HalfOut was a former
configuration for EMC optimization but will cause an instable link.

100BASE-T1 MediaConverter_EMC User Manual
11
4EMC Measurement Setup
The following diagram shows a typical EMC measurement setup.
The device under test is placed in a shielded EMC chamber together with one optical
MediaConverter. All devices inside the chamber are supplied by a 12 V car battery.
The only connection to the outside is a fiber Ethernet connection so no guided
radiation can occur.
The optical MediaConverter has been built to be EMC clean. So the source of all
radiation measured in the chamber will be the DUT.
Shielded
EMC Chamber
BroadR-Reach
Optical
Ethernet
BroadR-
Reach
Fast
Ethernet
BATTERY
12 V DC
Figure 4—1: Measurement Setup
Note: The standard 100BASE-T1 MediaConverter (100BASE-T1 to Fast Ethernet) is not
part of the 100BASE-T1 MediaConverter_EMC_Set.

100BASE-T1 MediaConverter_EMC User Manual
12
5100BASE-T1 FILTER
The following 100BASE-T1 Filter is used in the 100BASE-T1 MediaConverter_EMC:
In Version 3.0 the TDK CMC ACT45L-201-2P is used for L32.
All Filter Versions are compatible and it will be possible to set up a stable link.
However, it is recommended to use the latest filter version.
Figure 5—1: Used Filter in100BASE-T1 MediaConverter EMC

100BASE-T1 MediaConverter_EMC User Manual
13
6GENERAL EMC TEST INFORMATION
Testcases:
We test our EMC products with 350 V/m in a Stripline setup from 1 MHz to 1 GHz. The
devices are not damaged in this setup.
There will be no Link Drop on 100BASE-T1 or 1000BaseT1.
Warning: At frequencies below 1 MHz immunity must be tested at a maximum of
100V/m. Otherwise the devices will be permanently damaged!
We test our EMC products with 200 mA in a BCI substitution setup from 1 MHz to 1
GHz. The devices are not damaged in this setup.
There will be no Link Drop on 100BASE-T1 or 1000BaseT1.
Warning: BCI closed loop method is not allowed for 100BASE-T1 or 1000BaseT1
products. This test would permanently damage any device (independent of the vendor
of device) if your generator is strong enough.
Warning: At frequencies below 1 MHz the immunity must be tested at a maximum of
40 mA. Otherwise the devices will be permanently damaged!
Emission:
We test our EMC devices according to automotive emission standards. Because
standards and expectations vary, we grant a 4 week return period. You can test our
device according to your needs in your chamber. If you are not satisfied with the result
you can return the devices and get refunded.

100BASE-T1 MediaConverter_EMC User Manual
14
7ADDITIONAL INFORMATION
•The delay time is constant 2.0µs. The delay is independent of the Ethernet packet
frame size.
•The 100BASE-T1 MediaConverter_EMC is optimized for automotive use. The
maximum line length for each BroadR-Reach segment is limited to 15 meters.
•For best EMC performance only linear power regulators have been used in the EMC
version of the MediaConverter. The case has been designed to act as a heat sink.
•At 12 Volt VBAT the loss is very big. If you have the chance to use 10 Volt VBAT
this would prevent the device getting hot.

100BASE-T1 MediaConverter_EMC User Manual
15
8LIST OF FIGURES
Figure 1—1: 100BASE-T1 MediaConverter_EMC_Set ...................................................... 3
Figure 1—2: Recommended application of the 100BASE-T1 MediaConverter_EMC_Set
.............................................................................................................................................. 3
Figure 1—3: Declaration of conformity ............................................................................. 6
Figure 2—1: Label of 100BASE-T1 MediaConverter_EMC with pinning information .... 7
Figure 4—1: Measurement Setup .................................................................................... 11
Figure 5—1: Used Filter in100BASE-T1 MediaConverter EMC ...................................... 12

100BASE-T1 MediaConverter_EMC User Manual
16
9CHANGELOG
Version
Chapter
Description
Date
1.0
All
First release
2.0
All
Rework of design and update of all information
16.11.2018

100BASE-T1 MediaConverter_EMC User Manual
17
10 CONTACT
If you have any questions regarding this product, please feel free to contact us:
Technica Engineering GmbH
Leopoldstr. 236
80807 München
Germany
Technical support:
[email protected]
General information:
[email protected]
Most current user manuals and product information:
https://technica-engineering.de/
