1Product description
1.1 Functionality
Figure 1-1: 100BASE-T1 MediaConverter_NXP
The Technica Engineering 100BASE-T1 MediaConverter_NXP transmits data frames
directly from the physical layer BroadR-Reach (100BASE-T1) to Fast Ethernet
(100BASE-TX) with a constant delay time of 2.0µs.
1.1.1 Features
1 port BroadR-Reach (100BASE-T1) Ethernet with NXP TJA1100 Transceiver
1 port Fast Ethernet (100BASE-TX)
Automotive Tyco MQS Connector for 100BASE-T1 and power supply
Robust steel case
DIP Switches for easy configuration

100BASE-T1 MediaConverter NXP User Manual
4
1.1.2 Technical data
Voltage requirement:
8 to 16 Volt DC (nominal 12 Volt DC)
Power consumption:
2 Watt
Size:
92 x 63 x 30 mm
Weight:
0,2 kg
International Protection:
IP 2 0
Operating temperature:
-40° to +80 °Celsius
1.1.3 Links
The User can download the latest firmware and documentation for the 100BASE-T1
MediaConvert_NXP here:
1.1.4 General operating and safety strategy of TE Products
Technica Engineering’s products are designed for operation in automotive systems
and for supply voltages of nominal 12 V or 24 V. The applicable limit, values adhere to
the standard norms for 12 V or 24 V automotive onboard power systems
correspondingly and can be found in the mentioned norms.
Should Technica Engineering’s products be operated in voltage ranges beyond those
specified in the norms, which represents a breach of the conditions of operation, then
this will void the product warranty and Technica Engineering will assume no liability
whatsoever for the results and/or consequences thereof.
This is especially valid whenever the voltage level reaches or exceeds the limits of the
low-voltage directive. In this case, damage to the devices cannot be excluded. Due to
the manufacturing characteristics of the devices, there is no imminent fire hazard from
the device itself, if the devices are being operated in an environment according to the
conditions of use. A secondary fire hazard cannot be excluded, should those
conditions not be met. Protection against overvoltage cannot be provided in such a
breach of the conditions of use.
1.1.5 General design rules for the power supply of TE
products
The power supply solution of Technica Engineering’s products is equipped with a self-
protection mechanism. This automatic function protects the internal electronic
components against excessive temperature and too high supply-voltage by switching
the device off. This automatic switch-off function is independent of any software
function. Excessive temperatures in the device, can be caused by high environmental

100BASE-T1 MediaConverter NXP User Manual
5
temperatures or internal failures of the device. The device can protect itself by shutting
down its own power supply avoiding further damage to itself.
The operator/user of this devices must take measures for the right protection of the
power supply lines and the according connector. The maximum power consumption
of the Technica Engineering products is written in this user manual.
Please take care that some of the products are working with a step-up converter. So,
the current needed in case of undervoltage conditions must be considered as higher
than at nominal voltage level. The user must choose the right fuse or other over current
protection measures.
1.2 Warranty and safety information
Before operating the device, read this manual thoroughly and retain
it for your reference.
The latest documentation for the 100BASE-T1 Media Converter NXP
can be downloaded here:
As a user of this device, you may only perform tasks that are
described in this document valid for the corresponding firmware
version.
Technica Engineering assumes no liability for any kind of damages
arising from the use of or in relation with the use of our devices. Full
responsibility of operation rests on the side of the end user.
Manufacturer warranty of Technica Engineering products only
applies as long as the user ensures proper installation, configuration
and use of the device as described in this user manual.
Use the device only as described in this manual.
Use only in dry conditions.
Do not insert any foreign object in the slots/openings of the housing.
Do not apply power to a damaged device.
The device is to be used only by specialists.
Do not open the device. Otherwise, the warranty will be lost.

100BASE-T1 MediaConverter NXP User Manual
6
This product is intended for use in automobiles or automotive-like
environments. An automotive-like environment includes test setups
or test benches in the office, laboratory and workshop areas. In the
test setups, the same environmental conditions apply as in vehicle
electrical systems. Technica Engineering products are not intended
to be used as standard IT equipment. The test systems and
products from Technica Engineering are designed as customer and
application-specific test modules that are only used by specialists
for the development and test facilities.
When integrating the modules in a vehicle or test set-up, the user
must ensure appropriate ventilation or air convection.
Technica Engineering products must not be considered as a safety
element out of context when using safety-critical systems and must
be included in the safety assessment when used. The development
class in a safety system must be taken into account with standard
QM referred to ISO26262.
The device can get hot.
The device can get hot.
Do not cover the device due to fire danger.
Do not place the device near highly flammable materials due to fire
danger.
Do not use the device above the specified operating temperature.
The operating temperature is the ambient temperature of the
installation space.
This symbol is only valid in the European Union. If you wish to discard
this product, please contact your local authorities or dealer and ask
for the correct method of disposal. Technica Engineering GmbH is
registered as a manufacturer of the brand "Technica Engineering"
and the device type "Small devices of Information- and
Telecommunications- technology for exclusive use in non-private
Households”. WEEE reg. No. DE 20776859
Please refer to CHAPTER 10 for the EU Declaration of Conformity
following Directive 2014/30/EU.

100BASE-T1 MediaConverter NXP User Manual
7
1.3 RoHS certificate of compliance
Technica Engineering’s 100BASE-T1 MediaConverter NXP complies with RoHS
(Restriction of Hazardous Substances Directive) Certificate of Compliance.
1.4 Scope of delivery
The delivery includes:
1x 100BASE-T1 MediaConverter NXP
1x 1m Ethernet Cable
1x Black MQS Connector
1x 1m 100BASE-T1 Cabling
MQS Crimps

100BASE-T1 MediaConverter NXP User Manual
8
2Hardware interfaces
2.1 Connectors
On the label on top of the device, you can see an overview of all HW interfaces of the
100BASE-T1 MediaConverter_NXP.
Figure 2-1 100BASE-T1 MediaConverter_NXP
2.1.1 Black MQS connector (1)
The pinning of the ECU connectors is listed on the label on top of the device as well.
(See FIGURE 2-1).
The power supply for the device is supplied by pin 1 (12 Volt) and pin 10 (Ground)
If you apply a voltage higher than 18 volts, the device will be damaged!
1
3
2
4

100BASE-T1 MediaConverter NXP User Manual
9
The Tyco Electronics (TE) Micro Quad Lock System (MQS) is used.
Name
Part Number
Tyco, MQS Abdeckkappe 2x9 Pol, black
Alternative
1-967416-1
1-1355350-1
Tyco, MQS Buchsengehäuse 2x9 Pol
Alternative
965778-1
962108-2
Tyco crimp contact
928999-1
Table 1: Parts of black MQS connector
You can use the official Tyco tool for these crimp contacts. A cheap variant is the
crimp tool for “PSK” contacts.
Pin
Function
Pin
Function
1
Battery +12 Volt Input
10
Power Ground
2
reserved
11
reserved
3
n.c.
12
n.c.
4
n.c.
13
n.c.
5
n.c.
14
n.c.
6
n.c.
15
n.c.
7
n.c.
16
n.c.
8
100BASE-T1 port, negative
17
n.c.
9
100BASE-T1 port, positive
18
n.c.
Table 2: Pinning of black MQS connector
2.1.2 RJ-45 ethernet connectors(3)
There is one RJ45 Standard Ethernet connector for Fast Ethernet (100BASE-TX).

100BASE-T1 MediaConverter NXP User Manual
10
2.2 Other interfaces
2.2.1 DIP switches (4)
The 100BASE-T1 MediaConverter_NXP has two DIP switches for configuration (see
CHAPTER 3).
2.2.2 Status LEDs (2)
The 100BASE-T1 MediaConverter_NXP has two status LEDs at the front side of the
case for the 100BASE-T1 Port.
color
Description
Green
It is lit when there is a linkup on the 100BASE-T1 port.
Yellow
It is toggling in alternation with the green LED when there is communication.
Table 3: Status LEDs
There is a bug in the used BroadR-Reach PHY. When the 100BASE-T1 Plus and
Minus lines are swapped, and the 100BASE-T1 port is set to Slave then the Link
LED is lit, but there is no data transmission possible. So please connect the
100BASE-T1 lines correctly.

100BASE-T1 MediaConverter NXP User Manual
11
3Configuration
The 100BASE-T1 MediaConverter is configured by two DIP switches on the front of the
device.
DIP-Switch
Status
Description
1
ON (up)
OFF (down)
100BASE-T1 Port is set to Master
100BASE-T1 Port is set to Slave
2
ON (up)
OFF (down)
100BASE-T1 Port is set to FullOut
100BASE-T1 Port is set to HalfOut
Table 4: Configuration of DIP-Switches
In a 100BASE-T1 Link one device has to be set as Master, the other has to be set
as Slave.
The 100BASE-T1 MediaConverter_NXP should always be set to FullOut. HalfOut
was a former configuration for EMC optimization but it will cause an unstable link.

100BASE-T1 MediaConverter NXP User Manual
12
4Standard usecase
Here you can see a standard use case of the 100BASE-T1 MediaConverter_NXP:
Figure 4-1: Example of a use case
MC
MediaConverter
DUT
Device under Test.
DIP-Switch 2 should be always ON, DIP-Switch 1 is dependent on the DUT. If DUT
is Master, MC must be configured as Slave (DIP-switch 1: OFF) and vice versa.

100BASE-T1 MediaConverter NXP User Manual
13
5100BASE-T1 filter
The following 100BASE-T1 filter is used in the 100BASE-T1 MediaConverter_NXP
Hardware version 1.0 and following
Figure 5-1: 100BASE-T1 filter for HW v1.0 and following

100BASE-T1 MediaConverter NXP User Manual
14
6Additional information
The 100BASE-T1 MediaConverter_NXP is optimized for automotive use. The maximum
cable length for 100BASE-T1 segments is limited to 15 meters
The difference between the 100BASE-T1 MediaConverter_BCM and 100BASE-T1
MediaConverter_NXP is the used transceiver for the 100BASE-T1 PHY. At the beginning of
development, there were problems with the interoperability of different PHY manufacturers.
Now the interoperability is given, and the functionality is independent of the PHY
manufacturer.

100BASE-T1 MediaConverter NXP User Manual
15
7List of figures
Figure 1-1: 100BASE-T1 MediaConverter_NXP................................................................ 3
Figure 2-2 100BASE-T1 MediaConverter_NXP................................................................. 8
Figure 4-1: Example of a use case ..................................................................................12
Figure 5-1: 100BASE-T1 filter for HW v1.0 and following..............................................13

100BASE-T1 MediaConverter NXP User Manual
16
8Changelog
Version
Chapter
Description
Date
1.0
All
First release
2.0
All
Rework of design and update of all information
21.09.2018
2.1
All
Design and rework of content
25.02.2019
2.2
1.4, 4
Chapters added
08.05.2019
2.3
1.2
Extension of warranty and safety
23.03.2020
2.3
All
Optical adaption
23.03.2020
2.4
All
Small spelling corrections
May 2020
2.5
1.1.4
Added information on General Operating and Safety Strategy
of Technica Engineering’s Products
July 2020
1.1.5
Added information on General Design Rules for the Power
Supply of Technica Engineering’s Products
1.2
Warranty and Safety Information updated
1.3
RoHS Certificate of Compliance added
10
Declaration of conformity added

100BASE-T1 MediaConverter NXP User Manual
17
9Contact
If you have any questions regarding this product, please feel free to contact us:
Technica Engineering GmbH
Leopoldstr. 236
80807 München
Germany
Technical support:
[email protected]
General information:
[email protected]
Most current user manuals and product information:
https://technica-engineering.de/en/

100BASE-T1 MediaConverter NXP User Manual
18
10 Declaration of conformity
Български
С настоящото Technica Engineering GmbH
декларира, че продуктът Модул за улавяне
100BASE-T1 MediaConverter NXP (TE1600), е
в съответств ие с Директива 2014/30/ЕС.
Цялостният текст на ЕС декларацията за
съответствие може да се намери н а
следния интернет адрес:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Čeština
Tímto Technica Engineering GmbH prohlašuje,
že produkt 100BASE-T1 MediaConverter NXP
(TE1600), je v souladu se směrnicí
2014/30/EU. Úplné znění EU prohlášení o
shodě je k dispozici na této internetové
adrese:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Dansk
Hermed erklærer Technica Engineering
GmbH, at produktet 100BASE-T1
MediaConverter NXP (TE1600), er i
overensstemmelse med Direktiv 2014/30/EU.
EU-overensstemmelseserklæringens fulde
tekst kan findes p følgende internetadresse:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Deutsch
Hiermit erklärt Technica Engineering GmbH,
dass das Produkt 100BASE-T1
MediaConverter NXP (TE1600) die Richtlinie
2014/30/EU entspricht. Der vollständige Text
der EU-Konformitätserklärung ist unter der
folgenden Internetadresse verfügbar:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Eesti
Käesolevaga deklareerib Technica
Engineering GmbH, et toode hõivamismoodul
100BASE-T1 MediaConverter NXP (TE1600),
vastab direktiivi 2014/30/EL nuetele. ELi
vastavusdeklaratsiooni tielik tekst on
kttesaadav jrgmisel internetiaadressil:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
English
Hereby, Technica Engineering GmbH declares
that the product 100BASE-T1 MediaConverter
NXP (TE1600), complies with Directive
2014/30/EU. The full text of the EU declaration
of conformity is available at the following
internet address:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Español
Por la presente, Technica Engineering GmbH
declara que el producto 100BASE-T1
MediaConverter NXP (TE1600), es conforme
con la Directiva 2014/30/UE. El texto
completo de la declaración UE de
conformidad está disponible en la página web
siguiente:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Ελληνικά
Με την παρούσα ο/ηTechnica Engineering
GmbH, ότι το προϊόν 100BASE-T1
MediaConverter NXP (TE1600), πληροί την
οδηγία 2014/30/ΕΕ. Το πλήρες κείμενο της
δήλωσης συμμόρ φωσης ΕΕ διατίθεται στην
ακόλουθη ιστοσελίδα στο διαδίκτυο:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Français
Le soussigné, Technica Engineering GmbH,
déclare que le produit 100BASE-T1
MediaConverter NXP (TE1600), est conforme
la directive 2014/30/UE. Le texte complet de
la déclaration UE de conformité est disponible
l'adresse internet suivante:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Hrvatski
Technica Engineering GmbH ovime
izjavljuje da je proizvod 100BASE-T1
MediaConverter NXP (TE1600) u skladu s
Direktivom 2014/30/EU. Cjeloviti tekst EU
izjave o sukladnosti dostupan je na sljedećoj
internetskoj adresi:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf

100BASE-T1 MediaConverter NXP User Manual
19
Italiano
Il fabbricante, Technica Engineering GmbH,
dichiara che il prodotto 100BASE-T1
MediaConverter NXP (TE1600), conforme alla
direttiva 2014/30/UE. Il testo completo della
dichiarazione di conformità UE disponibile al
seguente indirizzo Internet:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Latviešu
Ar šo Technica Engineering GmbH deklarē, ka
produkts 100BASE-T1 MediaConverter NXP
(TE1600), atbilst Direktīvai 2014/30/ES. Pilns
ES atbilstības deklarācijas teksts ir pieejams
šādā interneta v ietnē:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Lietuvių
Aš, Technica Engineering GmbH,
patvirtinu, kad produktas sugavimo modulis
100BASE-T1 MediaConverter NXP (TE1600),
atitinka Direktyvą 2014/30/ES. Visas ES
atitikties deklaracijos tekstas prieinamas šiuo
internet adresu:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Magyar
Technica Engineering GmbH igazolja, hogy a
termék 100BASE-T1 MediaConverter NXP
(TE1600) a 2014/30/EU irányelvnek. Az
EUmegfelelőségi nyilatkozat teljes szövege
elérhető a következő internetes címen:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Malti
B'dan, Technica Engineering GmbH,
niddikjara li l-prodott 100BASE-T1
MediaConverter NXP (TE1600), huwa
konformi madDirettiva 2014/30/UE. It-test
kollu tad-dikjarazzjoni ta' konformit tal-UE
huwa disponibbli f'dan l-indirizz talInternet li
ġej:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Nederlands
Hierbij verklaar ik, Technica Engineering
GmbH, dat het 100BASE-T1 MediaConverter
NXP (TE1600) product voldoet aan richtlijn
2014/30/EU. De volledige tekst van de
EUconformiteitsverklaring kan worden
geraadpleegd op het volgende internetadres:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Polski
Technica Engineering GmbH niniejszym
oświadcza, że produkt 100BASE-T1
MediaConverter NXP (TE1600), jest zgodny z
dyrektywą 2014/30/UE. Pełny tekst deklaracji
zgodnośc I UE jest dostępny pod
następującym adre sem internetowym:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Português
O(a) abaixo assinado(a) Technica Engineering
GmbH declara que o produto 100BASE-T1
MediaConverter NXP (TE1600), está em
conformidade com a Diretiva 2014/30/UE. O
texto integral da declarao de conformidade
está disponível no seguinte endereo de
Internet:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Română
Prin prezenta Technica Engineering GmbH
declară ca produsul 100BASE-T1
MediaConverter NXP (TE1600), este în
conformitate cu Directiva 2014/30/UE. Textul
integral al declarației UE de conformitate este
disponibil la următoarea adresă internet:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
Slovensko
Technica Engineering GmbH potrjuje, da je
izdelek 100BASE-T1 MediaConverter NXP
(TE1600), skladen z irektivo 2014/30/EU.
Celotno besedilo izjave EU o skladnosti je na
voljo na naslednjem spletnem naslovu:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf

100BASE-T1 MediaConverter NXP User Manual
20
Slovensky
Technica Engineering GmbH týmto vyhlasuje,
že produkt Capture Module LIN Combo (TE-
1170), je v slade so smernicou 2014/30/EÚ.
Úplné EÚ vyhlásenie o zhode je k dispozícii na
tejto internetovej adrese:
https://technica-engineering.de/wp-
content/uploads/2021/03/eu-declaration-of-
conformity-1600.pdf
