Technics RAK-SA614MH Operating instructions

This remote contro! can be used to operate the receiver you
purchased plus other of our compact cassette decks, CD changers
(and CD players), TVs, VCRs and laser disc players, provided they
are equipped with the remote control sensor.
It is also possible to change-over the remote control code so that
the remote control transmitter can operate TVs, VCRs and laser
disc players which have not been manufactured by this company.
© ®
SCAMNICS | reremor retou
e For an explanation on how to set up your remote control and
precautions, see “Concerning the remote contro!” in the instruction
manual that came with your receiver.
e For details on operating other equipment, see the instruction
manual provided with the specific unit.
How to use the remote
control transmitter
RAK-SA614MH
RQT3788-P

To operate the receiver
Basic operations
Facing toward the receiver
To turn the power
ON/OFF
To select an input
source
To turn on the Dolby Pro
Logic and select the
desired mode
To turn on the SFC
function and select the
desired mode
To output a test signal
To adjust the output
level of the center
speaker
To adjust the output
level of the surround
Speakers
To turn the Dolby Pro
Logic/SFC OFF and ON
To display simple receiver
information and procedures
for remedying trouble
To mute the sound level
To adjust the volume
level
POWER Once the power has been set to
CA =o ON, it can be turned ON and OFF
[Note]
simply by pressing POWER.
After turning the power of the TV, VCR or laser disc player ON
or OFF, always press TUNER before pressing POWER when
turning the power of the receiver ON and OFF.
TAPE
TVWOVO VCR VDP TUNER CD MONITOR
© PHONO can not be selected with this remote control.
o Selecting TAPE MONITOR turns ON the tape monitor
function. Pressing it again or another input select button turns
the function OFF.
Changes as follows each time the button is
pressed.
SURROUND = 3 STEREO
OO PRO LOGIC
Changes as follows each time the button is pressed.
HALL————- CLUB ————-LIVE
t- SIMULATED -— THEATER —
When the SURROUND or 3 STEREO mode is ON
TEST i
C) Press once more.to stop.a test signal.
When the SURROUND, 3 STEREO or THEATER (SFC) mode
is ON
[Noted
When the SURROUND mode is ON and
the center mode is on PHANTOM, you
cannot select the center channel.
— CENTER +
When the SURROUND or SFC mode is ON
— SURROUND +
ee)
The message “MUTING ON NOW” runs
repeatedly from right to left across the display as
long as the muting function is on.
Press once more to return to the original volume.
MUTING

To operate the receiver (continued)
To listen to radio broadcasts
Facing toward the receiver
To switch the remote
control transmitter to
tuner operation mode
To select the desired
channel sequentially
(Preset tuning)
To select the desired
channel directly
(Preset tuning)
To select radio stations
by frequency
(Direct tuning)
To operate a cassette deck
Be sure to press this button before operating the
receiver.
{Example: Channel 1)
Cc
{Example: Channel 10)
ll 1 a
L OmOQ
hg ad
within 10 seconds
First select between FM and AM with the BAND button on the
receiver.
wae 202
O OoOO
OOOO
(Example; 107.9MHz)
OOOO
within 10 seconds
Turn the cassette deck ON before trying to operate it by remote control.
To switch the remote
control transmitter to
Facing toward the cassette deck
cassette deck operation
mode
Only when using a double
cassette deck
To select the tape deck
(DECK 1/DECK 2)
To start playback
To fast-forward or
rewind the tape
To stop playback
temporarily
To stop playback
Be sure to press this button before operating the
cassette deck.
TAPE
MONITOR
DECK 1/2
=
(Reverse) (Forward)
While the tape is stopped
4
CIE
With TPS-equipped cassette decks, while the tape is playing,
you can move to the beginning of a track by pressing these
buttons.
C
Press once again to resume playback.

To operate CD changers (or CD players)
Turn the CD changer (or CD player) ON before trying to operate it by remote control.
To switch the remote
contro! transmitter to CD
changer (or CD player)
operation mode
Facing toward the CD changer
(or CD player)
To start play
Be sure to press this button before operating the
CD changer or CD player.
For 5 CD changer
SS o © O = Select disc
number.
CJC
For MEGA CD changer x
<ED
OQO
>
[CD changer only] CIB ODO => ( )
To start play from the
desired disc
7 4 + v
Dy Gs a
Select the disc number.
(When selecting discs, the 210/ENTER button
does not respond to touch.)
For your reference
DISC
ENTER
To start play from the
desired track
To skip a track
To stop play temporarily
To stop play
X By “MEGA CD changer’, it is meant any Technics CD changer
that takes more than 50 discs.
lf you press this button instead of the > button
shown in the above procedure, the CD changer
will stop and display the disc number. To start the
disc, press >.
Select the track number.
(Example: Track 1)
©
(Example: Track 10)
210
GD ODO
Press Db to resume play.
You can operate the following cassette decks, CD chacgers and CD players with this remote control.(As of February 1997)
RS-TR373, RS-TR474, RS-TR575, RS-BX501, RS-TR252, RS-TR262, RS-TR272
SL-PG440, SL-PD847, SL-PD947, SL-PS840, SL-PD667, SL-P9066, SL-PD867, SL-PD967, SL-PD1000, SL-PD687,
SL-PD787, SL-PD887, SL-PD987, SL-PD1010, SL-MC50, SL-MC60, SL-MC300, SL-MC400, SL-MC700
Some of the above models are not sold in certain areas.

To watch TV broadcasts
The below procedures are examples for when a TV and VCR are connected to the receiver as shown in the receiver's instruction manual.
To watch TV broadcasts with just a TV
Facing toward the TV Facing toward the TV Facing toward the
receiver
POWER TW
TV/DVD
VIDEO
TV/OVD
Se Son Sas
Switch ON the Set the TV/VIDEO
power for TV. mode on the TV to
“Ty”.
Facing toward the TV
ES OOG
o OOO
CHY 7 a + D
C BL D
Select the desired channel.
To watch TV broadcasts with a VCR tuner
Facing toward the TV Facing toward the VCR Facing toward the TV
Set the input POWER POWER EP
selector on the TV/DVD VIDEO
crome oC l] L] H
“TUNER” Switch ON the Switch ON.the Set the TV/VIDEO
position power for TV. power for VCR. mode on the TV
to “VIDEO”.
Facing toward the VCR Facing toward the
, 2 3 receiver
CS OOO ae
ony O°o°.,¢
CD Sooo
Select the deslred channel.
MUTING —- VOUME +
To switch OFF the power for TV
POWER
TV/DVD
To switch OFF the power for VCR
POWER
s)
How to use the antenna input selection button
Each time the button is pressed, the antenna input at the VCR changes from “TV” to
“VCR” and vice versa.
This button is used when using ENTER to select a channel on a TV or VCR which
has not been manufactured by this company.

To watch video tapes/To record video or audio sources on the VCR
The below procedures are examples for when a TV and VCR are connected to the receiver as shown in the receiver's instruction manual.
To watch video tapes
Facing toward the TV Facing toward the VCR. Facing toward the TV Facing toward the
receiver
POWER POWER Tv
VIDEO VCR
SeallaSGeealeS » &
Switch ON the Switch ON the Set the TV/VIDEO
power for TV. power for VCR. mode on the TV to Li,
“VIDEO”,
Facing toward the VCR
>
CJ Playback will begin.
In the stop mode
To fast-forward or 4 p
rewind the video tape C) CJ
I
1o stop playback C) Press once again to resume playback.
temporarily
fm
To record video or audio sources on the VCR
Select the input source Facing toward the VCR
to be recorded [SET]
. Press these buttons
simultaneously.
VD VDP TUNER As (Recording will begin.)
> Start the selected
.
source,
Recording from the tape
deck is not possible.
To stop recording L ;
ez Press once again to resume recording.
temporarily
To stop recording
To switch OFF the power for TV
POWER
TV/OVD
Cj =
To switch OFF the power for VCR
POWER
a>
VCR

To operate laser disc players
The below procedures are examples for when a TV and laser disc player are connected to the receiver as shown in the receivers instruction
manual.
To watch a laser disc
Facing toward the TV Facing toward the Facing toward the TV Facing toward the
laser
disc
player
receiver
POWER POWER Ty
TV/DVD VIDEO VDP
S Ls slh’ 5 82 @
Switch ON the Switch ON the Set the TV/VIDEO
power for TV. power for laser mode on the TV to
disc player. “VIDEO”.
Facing toward the
laser disc player
>
C
Playback will begin.
In the play mode
To search for the desired | pp CDDP
position C) » ES PE
To stop playback VDP
L
temporarily
(
)
=
[2]
Press
>
to
resume
play.
To stop playback
To switch OFF the power for TV
POWER
TV/OVD
To switch OFF the power for laser disc player
POWER
=>
VDP

Changing the remote control code
Change the remote control code in either of the following circumstances:
o lf the Panasonic TV or VCR does not operate as a result of a difference in the remote control code.
o If you wish to operate some other make of TV, VCR or laser disc player.
{Refer to pages 5-7 for the buttons which can be operated.}
How to change the remote control code
9 (Tv) (VCR)
kami TD TE While holding down the button
corresponding to the component you wish to
(Laser
disc
player)
—
operate...
VDP
POWER
TV/DVD VCR VOP
C
AP D
co MONITOR| dH
Aim the remote control at the component you
wish to operate and press the numeric
buttons to enter the appropriate two-digit
code number. (Refer to the table below for the code
number.)
When the two-digit code number is entered, the remote
contro! will automatically output the power on/off signal.
if the remote control has been correctly changed to the code
for the component to be operated, the power of the
component will be switched on or off.
[Note]
If there is more than one code number indicated in the code
table, repeat the above procedure until you find a code
number for which the power of the component is switched on
or off.
VCR
anufacturer | Code No. Code No.
Ivania |07,11,15 [Panasonic [01
7,23 ;
03
i
e
Toshiba
6,07,15,20,22
5,06,07
ve 2
0. Not
Gold
Star
on
the
IATREXTRL
model, there may be
P cases where operation
is still not possible even
if the remote control
code is switched over.
1,02,08,09
03,04,08,09,10
11,12,23,24,26
If the remote control code is changed in accordance with the method given above, the code will be re-initialized to the Panasonic code
(code 01) when the batteries are replaced. To change the code back again, repeat the operations given above.
