Before operating this product, please read these instructions completely.

Thank
you
for
choosing
the
SL-B202.
For
optimum
performance
and
safety,
please
read
these
instructions
carefully.
Keep
page
2
folded
out
while
reading
the
instructions.
Caution for safe use
of this apparatus
(For UNITED KINGDOM)
Caution
This apparatus is double insulated, safety earth not required.
Important
The wires in this mains lead are coloured in accordance with
the following code:
Blue:
Brown:
Neutral
Live
As the colours of the wires in the mains lead of this apparatus
may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows.
The wire which is coloured BLUE must be connected to the
terminat which is marked with the letter N or coloured
BLACK. The wire which is coloured BROWN must be con-
nected to the terminal which is marked with the letter L or
coloured RED.
This equipment should be disconnected from the mains
when not in use.
Before use
Caution:
Do not plug in the AC power plug before completing assembly.
Attach the dust cover last to make assembly and adjustments
easier.
These instructions apply to units of different color.
@ Checklist of parts
Turntable
unit
........
eee
e
eee
Sop
delat
Glniagd
we
aware
aerevinge
1
Turntable platter . .
Turntable
mat
........6eee-
.
1
Dust COVEr ..... cece eee eee
45-rom adaptor
Counterweight
Headshell/cartridge.....
6...
seer
ereeeeee
‘
@ Installing the turntable platter
1, Place the platter on the center spindle.
2. Holding the belt by the ribbon, fit the belt over the
capstan. Then remove the ribbon. (Fig. 1)
3. Place the turntable mat on the platter.
Note:
After placing the mat on the platter, turn the platter
clockwise about ten full rotations by hand.
This is necessary to assure correct operation of the
automatic mechanism. :
H
Attaching
the
headshell
(Fig.
2)
Insert
the
headshell
plug
into
the
end
of
the
tonearm
and
turn
the
locking
sleeve
clockwise
(viewed
from
the
rear)
while
holding
the
headshell
horizontal.
B
Attaching
the
counterweight
(Fig.
3)
Fit
the
weight
onto
the
rear
end
of
the
tonearm.
@
Balancing
the
tonearm
and
adjusting
stylus
pressure (tracking force)
1.
If
your
cartridge
has
a
detachable
stylus
protector,
remove
it.
Be
careful
not
to
touch
the
stylus
tip.
2.
Release
the
arm
clamp
and
lift
the
tonearm
away
from
the
arm
rest.
3.
Turn
the
counterweight
clockwise
or
counterclockwise
until
the
tonearm
is
balanced
horizontally
so
it
floats
freely.
(Figs.
4
and
5)
Note:
(A):
Weight
advanced
too
much.
Move
backward.
(B):
Weight
not
advanced
enough.
Move
further.
(C):
Properly
balanced.
While
balancing
the
tonearm,
be
careful
not
to
let
the
stylus
contact
the
turntable
mat
or
base.
4. After balancing the tonearm, clamp the tonearm into the
arm rest.
5. While holding the counterweight stationary, rotate the
weight ring so that the “0” on the ring scale is lined up
with the center line on the tonearm shaft. (Fig. 6)
This completes tonearm balancing (horizontal zero
balance).
6. Turn the counterweight in the direction of the arrow so
that the weight ring shows the correct stylus pressure
number lined up with the center line. (Fig. 7)
(Follow the cartridge manufacturer's recommendation.)
When the counterweight is turned, the weight ring moves
with it. Stylus pressure is indicated by the number on the
scale aligned with the center line.
Note:
Set the stylus pressure to the maximum recommended
value for your cartridge in cases where the record has an
extremely high recording level, or where the unit is
operated in a room at low temperature, or in places in
which the unit is subjected to vibrations.
@ Adjusting the anti-skating control (Fig. 8)
Set
the
anti-skating
control
to
the
same
value
as
the
stylus
pressure.
Note:
When a cartridge with integral dust brush is used, follow
the cartridge manufacturer's recommendation for adjust-
ing both stylus pressure and anti-skating control.
@ Attaching the dust cover (Fig. 9)
Hold both sides of the cover and lower it into the hinge
slots. To remove the cover, open it and pull upward.
Note:
Opening or closing the cover during play may cause
vibrations and groove skipping.
If you must open the cover during play, do so very gently.

Ribbon
10~120¥
SELECT
The strobe-line
for 60 Hz, 33-1/3 rpm
seems to be stationary.
In the U.S.A. and CANADA use
60Hz lines.
The 50Hz lines are for European
countries.
[3 | Auxiliary weight (Optional)
a,
Rear end of
the tonearm
v
Approx. 5 mm(3/16”)
Headsheil
terminals
Auto-return
adjustment

Parts identification
Hinge
45-rpm
adaptor
Counterweight
Weight ring
Anti-skating control
| Arm rest
Turntable
mat
FP
Center spindle
Turntable
platter
Tonearm
Locking sleeve
Strobe-illuminator/
pilot lamp
Headshell/cartridge
Turntable base
Speed
selector
\eastnmnmam
“oe
eo
Stop
switch
Pitch
control
Cueing
control
Allowable cartridge weight.
Supplied
headshell
In
combination
with
other
parts.
(Included
the
cartridge
mounting
screws)
4g 5 6 7 8
es
es
es
Ce
Gs
ee
es
5g 75g
ent Sail
é
we '
Headshell only (89) (Optional)
zo +
Shell weight (2 g) (SFCZB30505)
Optional)
1
SEFS+S
Auxiliary weight
(SFPWG17202)
(Optional)
To purchase any of the optional accessories indicated in this book, please contact your nearest audio dealer.
“Warning: To prevent fire or shock hazard,
do not expose this appliance to rain or moisture.”
==

Hf Place the unit in a stable and horizontal position where there
is little or no vibration.
Place the unit away from the speakers so that it will be
subject to as little direct sound radiation as possible.
H Do not place the unit where It will be exposed to direct sun-
light, dust, moisture or heat.
@ Place it in a well ventilated location.
Connections
@ Connect the output jacks. (Fig. 10)
Output jacks Amplifier or receiver
L (White) —————__—-» [IJ Channel
R (Red) ————————> BIG Channel
GND (Spade lug) ———> ERD}
Note:
To avoid hum, be sure to make a secure ground connec-
tion between turntable and amplifier or receiver.
@ Plug in the AC power plug.
Plug the AC power plug into an AC wall socket.
Caution:
Never plug into a DC socket.
Make sure the turntable’s AC line-voltage selector is
matched to your local voltage before plugging in the AC
power plug.
If the pre-selected voltage is different from your local
voltage, turn the AC line-voltage selector with a screw-
driver so that it corresponds to your local voltage.
The AC line-voltage selector is under the platter. (Fig. 10)
Put a record on the turntable mat.
. Ifthe cartridge has a detachable stylus protector, remove
it.
. Release the arm clamp.
Push the speed selector to the correct speed. (Fig. 11)
Set the cueing control to the “¥" position. (Fig. 12)
. Move the tonearm over the record. The strobe-illumi-
nator/pilot lamp will light up and the platter will rotate.
. Set the cusing control to the “yw” position. (Fig. 13)
The tonearm will descend and play will begin.
At the end of the record, the tonearm will automatically
return to the arm rest and the turntable will stop.
8. Securing the tonearm helps avoid damage to the stylus
tip.
The stylus protector should be attached for the same
reason.
OPnao wo
MN
H Stopping the turntable
Push the stop switch. (Fig. 14)
The tonearm will return to the arm rest and the turntable will
stop.
@ Temporarily interrupting play
Set the cueing control to the “¥” position.
This will make the tonearm rise off the record.
@ Playing 45-rpm records having large center
holes
Put the 45-rpm adaptor over the center spindle. (Fig. 15)
Push the speed selector for 45 rpm (=).

@ Arm-lift height adjustment
The arm-lift height (distance between the stylus tip and
the record surface when the cueing control is at the “¥”
position) has been adjusted at the factory to approximately
5 mm (3/16"), (Fig. 16)
If the clearance is too narrow or too wide (because of dif-
ferent cartridge dimensions, for example), turn the adjust-
ment screw clockwise or counterclockwise. (Fig. 17)
Clockwise rotation
—distance between the record and stylus tip is decreased.
Counterclockwise rotation
—distance between the record and stylus tip is increased.
Adjustment of automatic return position (Fig. 18)
(Remove the rubber cap.)
1, Put the stylus protector on the cartridge.
2. Remove the tonearm toward the center of the record.
Then, the auto-return adjustment screw will appear.
If the tonearm tends to return to the arm rest before
play has finished,
—turn counterclockwise.
If the tonearm fails to return after the final groove,
—turn clockwise.
Speed adjustment (pitch control) (Fig. 19)
There are strobe-lines cut on this turntable platter to indicate
correct rotational speed.
If the strobe-line appears to be moving as the turntable
rotates, adjust while playing a record
1. Push the speed selector of the speed to be adjusted.
2. Watch the dot pattern on the side of the platter. Turn the
pitch control one way or the other until the dots appear to
stand still. This is the correct speed.
3. Turning the pitch control in the “+” direction increases
the speed.
4. Turning the pitch control in the “—” direction decreases
the speed.
Note:
Strobe dot pattern
This unit’s strobe illuminator operates at the AC line
frequency which generally has a 0.2% fluctuation.
This fluctuation, when present, may make the strobe
pattern appear to change. However, actual turntable
speed does not change, because the DC motor is not
affected by AC power line frequency.
Stylus replacement and
cartridge installation
@ Stylus replacement (Fig. 20)
The replacement stylus for this cartridge is EPS-25CS.
Replace the stylus at the first sign of wear or after about 1000
hours of use. Correct stylus pressure (tracking force) and
proper record and stylus care will help extend stylus life.
Stylus life varies with the conditions of use.
Noise or scratchiness may indicate a worn or damaged
stylus.
To avoid damaging records, do not use a stylus that seems
worn. Replace it immediately.
1. Loosen the tonearm locking sleeve to remove the head-
shell and cartridge.
2. Hold the headshell with the cartridge facing up. With your
other hand, grasp the stylus assembly and pull out and up
at a slant.
3. Line up the new stylus assembly with the cartridge and
push in firmly as far as it will go.
™ Cartridge installation (Fig. 21)
When installing a cartridge, follow the instructions that came
with the cartridge.
1. Connect the lead wires to the cartridge terminals.
The terminals of most cartridges are color coded. Con-
nect each lead wire to the terminal of the same color.
White (L+) .... cere eee e eee Left channel +
BIG ()recciieatantie Gries nee Left channel —
Red (R+) 0... cee cee eee eee Right channel +
Green (R—-) oc. cece reece eens Right channel —
2. Mount the cartridge in the headshell using the screws
provided with the cartridge.
@ About cartridge weight: (Refer to page 1)
Cartridges weighing between 3.5 and 7.5 g can be used on
this tonearm.
If you purchase the optional auxiliary weight (Part number:
SFPWG17202), or shell weight (Part number: SFCZB30505),
cartridges weighing up to 10.5 g can be used.
Note:
Attach the shell weight between the headshell and the
cartridge.
Attach the auxiliary weight to the rear end of the
tonearm.
When attached, the auxiliary weight bumps against the
dust cover, so remove the cover during play.
@ Overhang adjustment (Fig. 22)
15 mm is the correct overhang for this tonearm.
Loosen the screws and move the cartridge forward or back-
ward until the distance between the stylus tip and the plug
becomes 52 mm (2-3/64").
Tighten the screws without moving the cartridge.
Adjust the horizontal zero balance, stylus pressure and arm-
lift height whenever you change the cartridge.

Notes and maintenance
@ Do not touch or hold the tonearm during automatic opera-
tion.
@ Avoid pressing on the platter while it is rotating.
Do not try to hold it stationary.
@ Be careful when using differently shaped headshells.
(Fig. 23)
With some headshelis, the finger grip may strike the dust
cover during automatic operation. Should this occur, leave
the cover open during play.
@ Before detaching or attaching a headshell, be sure to turn off
the power on the amplifier or receiver.
Speakers may be damaged if a headshell is attached or
detached when the volume is turned up.
HF Carefully remove dust and dirt from records and stylus.
Dust and dirt degrade sound quality and cause excessive
wear of the stylus and grooves.
BB Wipe the headshell terminals from time to time. (Fig. 24)
Dirty terminals can cause noisy reproduction. If severe,
there may be no sound atall. Use a soft dry cloth to clean the
headshell terminals.
@ Wipe the dust cover and turntable base with a soft, dry cloth.
Never use volatile cleaners such as alcohol, benzine or
thinner.
Do not use chemically treated dust cloths. Do not expose the
cover to insecticide spray.
To remove stubborn spots, first pull out the AC plug and
detach the cover.
Then wipe the cover with a soft cloth slightly moistened with
a mild soap and water solution.
Do not wipe the cover during play, or the tonearm may be
attracted toward the cover due to the generation of static
electricity.
@ Transporting and shipping the turntable
Pack
the
unit
in
the
reverse
order
from
unpacking.
Use
the
original packing material if possible. Otherwise, take these
steps:
e Remove the platter and mat and wrap them.
e
Tape
or
tie
the
tonearm
to
the
arm
rest
so
it
cannot
shake
free.
e Remove the counterweight and wrap it carefully. Remove
the headshell with cartridge and wrap it carefully.
e Wrap the turntable base with a blanket or soft paper to
avoid scratches or damage.
How to remove and install the turntable platter (Fig. 25)
The belt is connected to the capstan and the inner drive rim
of the platter.
Before removing the platter, release the belt from the
capstan.
When reinstalling the platter, lower it over the turntable
shaft and then put the belt onto the capstan.
Note:
Be careful not to let oil or grease contact the belt.
If grease inadvertently contact the belt, disconnect the
AC power plug first and wipe the belt clean with alcohol.
Suggestions for safety
Before using this unit, be sure to read applicable items of the
operating instructions and these safety suggestions carefully;
and afterwards keep them handy for future reference. Take
special care to follow the warnings indicated on the unititself as
well as in the operating instructions.
1.
ce
10.
11.
12.
13.
Avoid places where there is water or humidity.
Do not use this unit near a bathtub, washbasin, swimming
pool, or the like. Damp basements should also be avoided.
Do not allow water or any forelgn object to get inside this
unit.
Do not place small metal objects or anything containing
liquid on or near the unit.
. Avoid placement of the unit where it will be exposed to the
direct rays of the sun, or where ventilation is inadequate.
Do not place this unit in a bookcase or between cabinets,
unless proper ventilation is provided, or where curtains or
furniture may obstruct the ventilation holes.
Place this unit away from heat-emitting appliances.
Never place this unit on or near a radiator, heat register,
stove, or any other heat-emitting equipment (including
amplifiers).
. Placement
Place the unit ona stable, vibration-free, level shelf or stand.
. Use of a cart or stand.
When deciding on a cart or stand, be sure to use only with
the cart or stand recommended by the manufacturer.
Wall or ceiling installation.
If the unit is to be mounted on a wallor ceiling, be sure todo
so only as recommended by the manufacturer.
. Check the voltage rating of this unit before connecting the
unit to a power source.
Be sure to connect the unit only to the type of power source
indicated in the operating instructions, or as indicated on
the unit itself.
Care of the power cord and plug.
Take care that the cord is not bent sharply (especially near
its connection to the unit or near the plug), that nothing is
placed on it, and that it is not pinched, crushed or frayed.
Never take hold of the plug or cord if your hand is wet, and
always be sure to grasp the plug body when connecting or
disconnecting it.
If the unit will not be used for an extended period of time:
Be sure to disconnect the power cord from the wail outlet.
Maintenance
Refer to the operating instructions for details.
Never attempt repairs yourself:
(a) If the power cord or plug is damaged.
(b) If a foreign object or liquid falls into the unit.
(c) If the unit is exposed to rain.
(d) If the unit does not function normally, or if operation
shows a distinct change in performance.
(e) If the unit has been dropped and the cabinet or chassis
are damaged...etc.
Unplug the power cord and have it checked by a qualified
technician (or the dealer from whom the unit was purchased
or the nearest servicenter).
Repairs
Except for adjustments explained in the operating instruc-
tions, do not attempt any repairs yourself. Be sure to re-
quest service from a qualified technician (or your dealer or
nearest servicenter).

Specifications
— General
Power supply:
Power consumption:
Dimensions:
(WXHXD)
Weight:
@ Turntable section
Type:
Drive method:
Motor:
Drive control method:
Turntable platter:
Turntable speeds:
Pitch control:
Wow and flutter:
Rumbie:
@ Tonearm section
Type:
Effective length:
Overhang
Tracking error angle:
Offset angle:
Stylus pressure
adjustment range:
Applicable cartridge
weight range:
Headshell weight:
—@ Cartridge section
Type:
Frequency response:
Output voltage:
Channel separation:
Channel balance:
Compliance (dynamic):
Stylus pressure:
Load impedance:
Weight:
Replacement stytus:
~110-120/220-240 V, 50 or 60 Hz
3 Ww
43 X 10.6 X 37.5 cm
(16-15/16” X 4-7/32” X 14-3/4")
Maximum height when top
(dust cover) is open.
43 X 37 X 42 cm
(16-15/16” X 14-9/16" X 16-17/32")
4.2 kg (9.3 lb.)
Automatic turntable
Auto return
Auto stop
Belt drive
DC motor
F-G servo control
Aluminum die-cast
Diameter 30.4 cm (12 inches)
33-1/3 rpm and 45 rpm
6% adjustment range
0.045% WRMS (JIS C5521)
+0.06% peak (IEC 98A Weighted)
—70 dB (IEC 98A Weighted)
Universal tonearm
“S$” shaped tubular arm
Static balanced type
230 mm (9-1/16")
15 mm (19/32”)
Within 2°32’ at the outer groove
of 30 cm (12”) record
Within 0°32’ at the inner groove
of 30 cm (12") record
22°
0—2.5g
(See page 1)
8g
Moving magnet
10 Hz to 35 kHz
20 Hz to 10 kHz +1 dB
2.5 mV at 1 kHz
5 cm/s. zero to peak lateral
velocity
(7 mV at 1 kHz 10 cm/s. zero to
peak 45° velocity [DIN 45 500])
22 dB at 1 kHz
Within 1.8 dB at 1 kHz
10 X 10° cm/dyne at 100 Hz
1,75 £0.25 g (17.5 £2.5mN)
47 kQ to 100 kN
5 g (cartridge only
EPS-25CS
Equivalent replacement
stylus: EPS-25ES
Specifications subject to change without notice.
Weight and dimensions shown are approximate.
