TechniSat DiGYBOXX T4 User manual

For the reception of free DTT programmes.
Operating Instructions
DiGYBOXX T4

1Table of Contents
2
1Table of Contents ......................................2
2 Illustrations...........................................5
3Please Read Before Operation............................8
3.1 Important notes for use ............................................8
3.2 Disposal instructions ..............................................8
3.3 Safety instructions ................................................9
3.4 Breaks in operation ...............................................9
4 Connecting the DVB Receiver ...........................10
4.1 Outdoor unit .................................................... 11
4.2 Connection to a television set ...................................... 11
4.2.1 Via HDMI cable ................................................. 11
4.2.2 Via SCART cable ................................................ 11
4.2.3 Via RF cable.................................................... 11
4.3 Video recorder (VCR)............................................. 11
4.4 Hi-fi amplifier ................................................... 11
4.4.1 Analogue ...................................................... 11
4.4.2 Digital .........................................................12
4.5 Mains connection ................................................12
5 Initial installation .....................................13
6Settings.............................................16
6.1 Menu language .................................................16
6.2 Basic settings ...................................................17
6.2.1 Country........................................................17
6.2.2 Time offset selection .............................................18
6.2.3 GMT time offset (hrs.) ............................................18
6.2.4 Antenna feed 5 V ................................................18
6.2.5 Automatic standby ...............................................18
6.3 Audio/Video settings..............................................18
6.3.1 HDMI resolution .................................................19
6.3.2 Display format ..................................................19
6.3.3 Picture format...................................................19
6.3.4 HDCP .........................................................20
6.3.5 Audio delay ....................................................20
6.3.6 Digital audio ....................................................20
6.3.7 Digital volume adjustment .........................................20
6.4 Language settings ...............................................20
6.5 Antenna adjustment ..............................................21
7Operation ...........................................22
7.1 Switching on/off .................................................22
7.2 Programme selection .............................................22
7.2.1 Using the programme up/down buttons...............................22
7.2.2 Using the number buttons .........................................22
7.2.3 Using the navigator (programme list).................................23
7.2.4 Accessing blocked programmes ....................................24
7.2.5 Infobox ........................................................24

5
7.3 Volume control ..................................................24
7.4 Switching between TV and radio ....................................25
7.5 Selecting a different language (TV mode) or station (radio mode) ..........25
7.6 Returning to the previously selected programme .......................25
7.7 Displaying clock and programme information ..........................25
7.8 Additional programme information ...................................26
7.9 Channel information ..............................................26
7.10 Teletext........................................................26
7.10.1 Using your television set's teletext decoder............................26
7.10.2 Using the internal teletext decoder ..................................27
7.11 Subtitles ......................................................27
7.12 Electronic programme guide (EPG) ..................................27
7.12.1 Opening the electronic programme guide .............................28
7.12.2 EPG info.......................................................29
7.12.3 Timer .........................................................30
7.12.4 Exiting the EPG .................................................30
7.13 Timer recordings ................................................30
7.13.1 Manually programming the timer ....................................30
7.13.2 Timer overview..................................................32
8Changing the Basic Program Settings.....................33
8.1 Configuring the favourites list.......................................33
8.1.1 Opening the programme list management.............................33
8.1.2 Adding programmes to the favourites list .............................35
8.1.3 Deleting programmes (removing them from the favourites list).............35
8.1.4 Sorting programmes..............................................35
8.2 Parental settings ................................................36
8.2.1 Select channels .................................................36
8.2.2 Change receiver PIN .............................................37
8.2.3 Menu lock......................................................38
8.2.4 Age limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
8.3 Programme search...............................................38
8.3.1 Automatic search ................................................39
8.3.2 Manual search ..................................................39
8.3.3 After the search is complete .......................................40
8.4 Service settings .................................................40
8.4.1 Restore factory settings ...........................................41
8.4.2 Delete all channels...............................................41
8.4.3 Update software .................................................42
8.5 System configuration .............................................42
9 Technical Terms ......................................43
10 Technical Data .......................................45
11 Troubleshooting ......................................48

6
Your unit bears the CE mark and meets all the necessary EU standards.
Subject to changes and printing errors. Version: 10/09
TechniSat and DiGYBOXX T4 are registered trademarks of
TechniSat Digital GmbH
Postfach 560
54541 Daun, Germany
www.technisat.com

3
2 Illustrations
blue Fast forward
red Rewind
yellow Pause/Play
green PVR navi-
gator/Stop
On/Standby
Programme list on/off
Exit
Volume +
Menu on/off
Mute
Language selection*
PIP (Picture in Picture)
Sleep timer
Option*
in TV mode:
select sound/subtitle,
special functions
in radio mode:
programme selection by
switching the sound
subcarrier
Volume -
Programme +
Programme -
TV/radio mode
Teletext on/off*
STILL/
Jog shuttle on/off
SFI
Record
Multi-function buttons
Programme +
Volume -
Programme -
Number buttons
0/AV
OK
Volume +
Info
Right arrow button
Left arrow button
Up arrow button
Down arrow button
Remote control option:
By switching the remote control option, this remote control unit can be used to control two
TechniSat receivers and one TechniSat television set with the same coding.
> To switch the remote control option, press the desired button
(SAT1, SAT2 or TV)and the OK button at the same time.
Remote control
*This function is only available when the
corresponding data is transmitted to the
selected programme position.

4
Antenna
input
SCART socket
TV
SCART socket
VCR
DC input
HDMI
output
Antenna
output USB port
Audio outputs:
analogue
Audio output:
digital (electrical)
Programme
selection
up/down
On/Standby
LED display

7
Dear customer,
Congratulations on your purchase of the DiGYBOXX T4 digital receiver. These operating
instructions should help you to get the maximum use and enjoyment from your new digital
receiver.
We have made these operating instructions as brief and easy to understand as possible.
Your device will continue to get additional functions through software updates. This may
mean that some operating steps are new and may not be covered in these operating instruc-
tions. Currently existing functions may also be changed. For this reason, you should visit
the TechniSat homepage from time to time to download the latest version of the operating
instructions.
We hope you enjoy using your TechniSat DiGYBOXX T4!
Your
TechniSat team
Technical hotline
[phone]*
*(€0.14/minute from the German landline network,
prices may vary when calling on mobile phones or from outside Germany)
This product incorporates copyright protection technology that is
protected by U.S. patents and other intellectual property rights.
Use of this copyright protection technology must be authorised by
Macrovision, and is intended for home and other limited viewing
uses only unless otherwise authorised by Macrovision. Reverse
engineering or disassembly is prohibited.

3Please Read Before Operation
> Before using the device, first check to make sure that all of the parts are included.
The scope of delivery includes:
1 digital receiver, 1 mains adapter, 1 remote control, 2 batteries (1.5 V AAA battery),
1 operating instructions on CD-ROM, 1 quick reference guide, 1 warranty card.
> Place the supplied batteries in the battery compartment of the remote control (make
sure that the polarity is correct).
3.1 Important notes for use
The on-screen display (OSD) makes it easier to use the digital receiver and reduces the
number of remote control buttons that need to be pressed. All functions are displayed on the
screen and can be controlled with just a few buttons. Related functions are grouped together
as a MENU. The selected function is highlighted in colour. The function buttons are repre-
sented by four coloured bars (red, yellow, green, blue) at the bottom of the screen. These
coloured bars represent differing functions in the individual menus, which can be activated
by pressing the corresponding coloured button (multi-function button) on the remote control.
The function buttons are only active when a brief designation appears in the corresponding
field. Button designations and terms that appear in the OSD menu are printed in bold text
throughout these operating instructions.
Help:
When available, you can display/hide the help text in the menus by pressing the blue func-
tion button.
3.2 Disposal instructions
The packaging that was used to ship this device is made exclusively from recyclable mate-
rials. Please dispose of packaging in accordance with local ordinances. In Germany, the
packaging can should be sorted and recycled using the “dual system”.
When this product has reached the end of its service life, do not dispose of it with the normal
household rubbish. Instead, it must be brought to a collection point for the recycling of elec-
trical/electronic devices. This is indicated by the symbol on the product, instruction manual or
packaging.
The materials can be recycled in accordance with their markings.
Recycling old devices, the materials used to manufacture them, or any other form of
re-utilisation serves as an important contribution in the protection of our environment.
Please contact your local government to find the appropriate waste disposal point in your
area.
Do not dispose of used batteries (for the remote control) or other electronic waste with the
household rubbish. Instead, make sure they are properly disposed of (return to the retailer,
hazardous waste).
8

3.3 Safety instructions
For your own protection, you should carefully read through the safety precautions before
operating your new device.
The manufacturer assumes no liability for damage caused by improper use or failure to
comply with safety precautions.
> In order to provide sufficient ventilation, place the device on a smooth, level surface,
and do not place any objects on top of the device. The top of the device has ventila-
tion slots that allow the heat to escape from the interior.
> Do not place any burning objects (e.g. burning candles) on the device.
> Do not expose the device to dripping/splashing water, and do not place objects that
contain fluids (such as vases) on the device.
> Do not operate heaters near the device. This will cause the device to become hotter.
> The device may only be operated in a moderate environment.
> Never open the device. This could give you an electric shock. Any necessary repair
work should be performed only by trained technicians.
You should disconnect the device from the mains and contact a technician in the
following cases:
> When the power cable or mains adapter is damaged
> When the device has been exposed to moisture or when fluid has gotten into the
device
> When there are serious malfunctions
> When the device has suffered significant external damage
3.4 Breaks in operation
Disconnect the device from the mains and the antenna during a thunderstorm or when the
device is not being used for an extended period of time (e.g. when you are on holiday).
9

a. Connection between the antenna and the antenna input on the DVB receiver.
b. HDMI connection between the DVB receiver and the television set.
c. SCART connection between the DVB receiver and the television set.
d. Connection between the antenna output and the television set.
e. SCART connection between the DVB receiver and the video recorder
f. Connection between the audio outputs and a hi-fi system.
g. Mains connection
10
4 Connecting the DVB Receiver
f
a
d
g
b
c
e
VCR

4.1 Outdoor unit
aConnect the cable that extends from the terrestrial antenna (roof antenna or
indoor antenna) to the terrestrial antenna input on the receiver.
Use a roof antenna, if possible. An indoor antenna may be sufficient if you have
favourable reception conditions. When using an active antenna,
the antenna feed must be switched on (section 6.2.4).
4.2 Connection to a television set
4.2.1Via HDMI cable
bUse an HDMI cable to connect the receiver (HDMI output) with the television set
(HDMI input).
If your television set is appropriately equipped, it will automatically switch to the HDMI
input when you turn on the digital receiver.
4.2.2Via SCART cable
cUse a SCART cable to connect the receiver (TV SCART socket) with the televi-
sion set (SCART socket). If your television set is appropriately equipped, it will auto-
matically switch to AV (and therefore to DTT mode) when you turn on the digital
receiver.
4.2.3Via RF cable
In order to continue receiving existing analogue programmes, the digital receiver must be
connected to the antenna input on your television set. This connection is used exclusively
to transmit analogue programmes to the television set. In order to display DTT programmes
on your television set, you must make the HDMI connection or the SCART connection (see
sections 4.2.1 and 4.2.2).
dUse a suitable TV connection cable to connect the receiver (antenna output) with
the antenna input on your television set.
4.3 Video recorder (VCR)
eConnect the video recorder to the VCR SCART socket. During playback, the video
recorder sends a switching signal to the digital receiver. The video recorder's signal
is thereby automatically received by the TV set. If your video recorder does not
provide switching voltage, use the AV button to switch your digital receiver to the
external AV input. Pressing this button again will return the device to normal opera-
tion.
4.4 Hi-fi amplifier
4.4.1Analogue
fTo obtain the best possible sound quality, you can connect the digital receiver to
a hi-fi amplifier. To do so, use a suitable cable to connect the right audio and
left audio RCA jacks on the digital receiver with an input on your hi-fi amplifier
(e.g CD or AUX; Note: the phono input is not suitable).
11

4.4.2 Digital
fIf your amplifier is equipped with an appropriate electrical input, connect the digital
(electrical) audio output with the electrical input on your amplifier.
Depending on the particular station, sample rates of 32 kHz, 44.1 kHz and 48 kHz are avail-
able. Also, if it is broadcast, the Dolby Digital signal (AC3) is present at this output.
4.5 Mains connection
The digital receiver should not be connected to the mains power supply until after all of the
connections with other components have been made. This helps to avoid damage to the
digital receiver, as well as to other components.
gAfter all of the connections have been made, use the included mains adapter to con-
nect the receiver to an electrical outlet (230 V/50-60 Hz).
12

5 Initial installation
After you have read through the safety instructions and connected the device according to
the instructions contained in section 4, it is now time to switch on the device (as described
in section 7). When you start the device for the first time, the start screen of the Auto
Install installation wizard appears. The installation wizard helps you to make the most
important settings on the digital receiver.
You can cancel the initial installation at any time by pressing the red function button.
Use the green function button to return to the previous installation step should you need
to correct any erroneous entries.
If the initial installation is incomplete or cancelled, your device will start with the standard
presets.
The initial installation process shown here is only an example. The exact initial installa-
tion process depends on which settings you make. Therefore, follow the on-screen instruc-
tions precisely.
Menu language
> When you start the installation wizard, the first selection screen you see is for the
Menu language.
> Use the up/down arrow buttons to highlight the desired operating language.
> Confirm by pressing OK.
> Confirm by pressing OK,to accept the selection.
Country adjustment
> Use the up/down arrow buttons to select the time zone that corresponds to your
country.
The time is automatically set according to your selection.
> Confirm by pressing OK,to accept the selection and proceed to the antenna
configuration.
13

Basic setup
You make the display format and antenna feed settings in this installation step.
> Use the up/down arrow buttons to highlight the Display Format row, and then
use the left/right arrow buttons to set the display format to 16:9 or 4:3.
> To activate the antenna feed, highlight the antenna feed 5V row, and then use the
left/right arrow buttons to switch the feed on or off.
> Use the up/down arrow buttons to highlight the Proceed row, and then confirm
by pressing OK to proceed to the Antenna adjustment item.
Antenna adjustment
In this installation step, you can use the signal strength and signal quality indicators to adjust
the antenna optimally.
> Use the up/down arrow buttons to select the Channel field.
> Use the left/right arrow buttons to select a channel on which DTT programmes
are broadcast.
> Adjust the antenna so that the signal strength and signal quality indicators show their
strongest levels.
> Use the up/down arrow buttons to highlight the Proceed field, and then con-
firm by pressing OK.
14

Channel search
After the antenna adjustment, the channel search screen appears.
> The channel search starts automatically. During this process, the entire reception
frequency range is searched for digital programmes. This process can take a few
minutes to complete. Pay attention to further on-screen instructions.
If you are using an active antenna and the search finds no programmes (or not all of
the programmes that are available in your area), you have to switch on antenna feed
(see section 6.2.4).
Software update
After the search is complete, the digital receiver checks whether a software update is avail-
able for the device. If a new software version is available, you can update the software
automatically.
> Use the left/right arrow buttons to select the Update field, and then confirm
by pressing OK.
The new software for your device will now be downloaded. This process can take a
few minutes to complete.
15

Exiting the installation wizard
> Confirm the on-screen instruction by pressing OK to return to normal operation.
6Settings
After you have connected your new digital receiver and set it up, you can optimise the digital
receiver to meet your needs, if necessary.
6.1 Menu language
You can set the desired menu language in this menu item.
To change the operating language, proceed as follows:
> Use the MENU button to open the Main menu.
> Now select the Menu language row using the up/down arrow buttons to
highlight it.
> Confirm by pressing OK.
The Menu language submenu appears.
> Use the up/down arrow buttons to highlight the desired language.
> Save your selection by pressing the OK button.
> Press the EXIT button to return to the Main menu.
16

6.2 Basic settings
In order to optimally use your DVB receiver, you still need to configure it to meet your
individual needs.
> Open the Main menu by pressing the MENU button.
> Highlight the Settings row using the up/down arrow buttons.
> Confirm by pressing the OK button.
The Settings submenu appears.
> Now highlight the Basic settings row using the up/down arrow buttons.
> Confirm by pressing OK.
The Basic settings menu appears.
> Use the up/down arrow buttons to highlight the option you want. Change the
individual items as indicated below. When selecting a menu item, also pay attention
to any on-screen instructions that may appear. You can make the following settings:
6.2.1 Country
This function is used to automatically switch between standard and daylight saving time.
> In the Country row, use the left/right arrow buttons to select the country
in which the device is operated.
17

6.2.2 Time offset selection
Your device is equipped with a clock. This clock is synchronised to Greenwich Mean Time
via DTT.
automatic
> Use the left/right arrow buttons to set to automatic.
The local time will now be automatically set according to the country that you selected
(section 6.2.1).
manual
> Use the left/right arrow buttons to set to manual.
Now you can manually adjust the local time in the GMT time offset (hrs.) menu item.
6.2.3 GMT time offset (hrs.)
> Use the left/right arrow buttons to set the time difference in relation to
Greenwich Mean Time.
6.2.4 Antenna feed 5 V
When you use an active antenna, you need to switch on the antenna feed (5 V/30 mA).
This supplies the antenna with power through the terrestrial antenna input.
> Highlight this row and use the left/right arrow buttons to switch the antenna
feed on or off.
In the event of an overload or short-circuit in the antenna feed, this will be automati-
cally switched off. If this happens, fix the error and then switch the antenna feed back
on.
> Press the EXIT button to return to the Settings menu or press the MENU button to
return to normal operation. Your settings are automatically saved.
6.2.5 Automatic standby
After the preset time has elapsed, the automatic standby circuit automatically switches the
device to standby mode, provided you have not operated any of the device's controls during
this period.
> Use the left/right arrow buttons to select a period of time after which the device will
automatically switch to standby mode.
6.3 Audio/Video settings
You can make additional settings in the Audio/Video settings menu so that the digital
receiver is configured for your television set.
> Use the MENU button to open the Main menu.
> Highlight the Settings row using the up/down arrow buttons.
> Confirm by pressing the OK button.
The Settings submenu appears.
18

> Now highlight the Audio/Video settings row using the up/down arrow
buttons.
> Confirm by pressing OK.
The Audio/Video settings menu appears.
> Use the up/down arrow buttons to highlight the option you want. Change the
individual items as indicated below. When selecting a menu item, also pay attention
to any on-screen instructions that may appear. You can make the following settings:
6.3.1 HDMI resolution
> Use the left/right arrow buttons to select automatic to have the resolution
automatically adjusted to the resolution of the connected TV set, or select one of the
preset resolutions.
6.3.2 Display format
> Use the left/right arrow buttons to adjust the display format to match your TV
set (4:3 or 16:9). This function automatically adjusts the picture to match the aspect
ratio of your television set.
6.3.3 Picture format
> Depending on which display format you select, use the left/right arrow buttons
to set the desired picture format.
If you selected the 16:9 display format, the following options are available: auto-
matic, Black Borders and Zoom.
If you selected the 4:3 display format, the following options are available: auto-
matic, Letter Box and Pan & Scan.
19

6.3.4 HDCP
> Highlight this row and use the left/right arrow buttons to switch the HDCP
(High Definition Content Protection) function on or off.
6.3.5 Audio delay
> Highlight this row and use the left/right arrow buttons to select from a range
of 0 ms to 250 ms.
6.3.6 Digital audio
> Highlight this row and use the left/right arrow buttons to select stereo or
multichannel.
6.3.7 Digital volume adjustment
> Highlight this row and use the left/right arrow buttons to adjust the volume of
the digital output.
6.4 Language settings
In this menu you can set your preferred menu language, audio language and subtitle
language.
> Use the MENU button to open the Main menu.
> Highlight the Settings row using the up/down arrow buttons.
> Confirm by pressing the OK button.
The Settings submenu appears.
> Now highlight the Language settings row using the up/down arrow buttons.
> Confirm by pressing OK.
The Language settings menu appears.
> Use the up/down arrow buttons to highlight the option you want. Change the
individual items as indicated below. You can make the following settings:
Menu language
> Use the left/right arrow buttons to select your preferred Menu language.
Primary audio language
Use this option to select your preferred audio language for digital programmes. This is auto-
matically selected when you switch on the device or change to a different programme (used
for multilingual broadcasts).
> Use the left/right arrow buttons to select your preferred Audio language.
20
