Environmental reception effects
The station obtains the accurate time with wireless technology. Same
as all wireless devices, the reception is maybe affected by the
following circumstances:
long transmitting distance
nearby mountains and valleys
near freeway, railway, airports, high voltage cable etc.
near construction site
among tall buildings
inside concrete buildings
near electrical appliances (computers, TV’s, etc) and metallic
structures
inside moving vehicles
Place the station at a location with optimal signal, i.e. close to a
window and away from metal surfaces or electrical appliances.
Precautions
This main unit is intended to be used only indoors.
Do not subject the unit to excessive force or shock.
Do not expose the unit to extreme temperatures, direct sunlight,
dust or humidity.
Do not immerse in water.
Avoid contact with any corrosive materials.
Do not dispose this unit in a fire as it may explode.
Do not open the inner back case or tamper with any components
of this unit.
Batteries safety warnings
Use only alkaline batteries, not rechargeable batteries.
Install batteries correctly by matching the polarities (+/-).
Always replace a complete set of batteries.
Never mix used and new batteries.
Remove exhausted batteries immediately.
Remove batteries when not in use.
Do not recharge and do not dispose of batteries in fire as the
batteries may explode.

WS9132 Manual
Ensure batteries are stored away from metal objects as contact
may cause a short circuit.
Avoid exposing batteries to extreme temperature or humidity or
direct sunlight.
Keep all batteries out of reach from children. They are a choking
hazard.
Use the product only for its intended purpose!
Consideration of duty according to the battery law
Old batteries do not belong to domestic waste because
they could cause damages of health and environment.
You can return used batteries free of charge to your
dealer and collection points. As end-user you are committed by
law to bring back needed batteries to distributors and other
collecting points!
Consideration of duty according to the law of electrical devices
This symbol means that you must dispose of electrical
devices separated from the General household waste
when it reaches the end of its useful life. Take your unit
to your local waste collection point or recycling centre.
This applies to all countries of the European Union, and to other
European countries with a separate waste collection system.

WS9132 Manual
Features:
DCF Radio controlled time function
12/24 hour format
Daily Alarm Function
Snooze function (OFF or 1~60min)
Low battery indicator
Maximum /minimum value record of temperature and humidity
Temperature in °C or °F
Outdoor thermometer ice alert
Humidity measurable range: 20%RH ~ 95%RH
Temperature:
—Indoor temperature measurement ranges: -9.9°C (14.2°F) ~
50°C (122°F)
—Outdoor temperature measurement ranges: -25°C (-13°F) ~
50°C (122°F)
Remote Sensor:
—Wall Mount or Table Stand
—3 Channels selectable
—433.92MHz RF transmitting frequency
—30 meter transmission range in an open area
Weather forecasting function
Power Supply:
Weather Station:
Battery: 2 x LR03 AAA
Remote Sensor:
Battery: 2 x LR06 AA

WS9132 Manual
Weather Station Appearance

WS9132 Manual
Part A –Weather station
A1: Time
A2: Indoor temperature and humidity
A3: Ice alert icon
A4: Radio Controlled Icon
A5: DST icon
A6: Weather forecast pattern
A7: Outdoor temperature
A8: Operation buttons
A9: Stand cover
A10: Battery door
Part B –Remote sensor
B1: Transmit indicate LED
B2: Battery door
B3: Channel switch
B4: Reset button
Initial operation:
Open the Weather Station battery compartment cover
Insert 2 x AAA batteries observing polarity [ “+” and “ –“ marks]
When you insert the batteries, all icons on the LCD display will light
up for 3 seconds, you will hear a beep tone and the station detects
indoor temperature & humidity.
The Weather Station will now start to make a connection to the
outdoor remote sensor. This operation takes about 3 minutes and
is displayed by a flashing reception RF antenna symbol in the
“OUTDOOR” display area on the receiver.
Open Wireless Outdoor Sensor battery compartment cover, Insert 2
x AA batteries observing polarity [ “+” and “–“ marks].

WS9132 Manual
After receiver has created a connection to the outdoor remote
sensor, After 3 minutes it will enter the Radio control time receive
mode.
Reception of the DCF signal:
The clock will automatically search the DCF (radio controlled time)
signal after 3 minutes of any restart or changing of new fresh
batteries. The radio mast icon starts to flash.
At 1:00 /2:00 / 3:00 am, the clock automatically carries out the
synchronization procedure with the DCF signal to correct any
deviations to the exact time. If the synchronization attempt is
unsuccessful (the radio mast icon disappears from the display), the
system will automatically attempt another synchronization at the
next full one hour. This procedure is repeated automatically up to
total 5 times.
To start manual DCF signal reception, press and hold the “ ”
button for 3 seconds. If no signals received within 7 minutes, then the
DCF signal search stops (the radio mast icon disappears) and start
again at the next full one hour.
During RC reception，to stop searching radio signal, press the “”
button once.
Please note:
A flashing radio mast icon indicates that the DCF signal reception
has started
A continuously displayed radio mast icon indicates that the DCF
signal was received successfully
We recommend a minimum distance of 2.5 meters to all sources of

WS9132 Manual
interference, such as televisions or computer monitors
Radio reception is weaker in rooms with concrete walls (e.g.: in
cellars) and in offices. In such extreme circumstances, place the
system close to the window.
During the DCF reception mode, only the “ ” button has a
function, other buttons are not functional, If you want to carry out
other functions of operation, please press “ ” button to exit the
DCF receiving mode.
Manual settings:
Press and hold the “ ”, 12/24HR start to flash. Now use “+” and
“-” buttons to set the set 12 or 24 hour mode.
Press the “ ”button to confirm your setting. The time zone start
to flash. Now use “+” and “-” buttons set a time zone (-12 to +12).
For example for UK, the time zone is -01, for Germany it is 00.
Press the “ ”button to confirm your setting, the Hour display
starts to flash. Now use “+” and “-”buttons to set the hour.
Press the “ ”button to confirm your setting, the Minute display
starts to flash. Now use “+” and “-”buttons to set the minute.
Press the “ ”button to confirm your setting, the temperature
unit starts to flash. Now use “+” and “-” buttons to choose
between °C or °F temperature unit.
Press the “ ”button to confirm your setting, the barometric
pressure unit starts to flash, Now use “+” and “-”buttons to set the
barometric pressure unit in mB/hPa or inHg.
Press the “ ”button to confirm your setting, the barometric
pressure data starts to flash. Now use “+” and “-”buttons to set the

WS9132 Manual
barometric pressure data according to the local relative air
pressure.
If not changed, the value corresponds to the absolute air pressure.
Press the “ ”button to confirm your setting, the weather
forecast pattern starts to flash. Now use “+” and “-”buttons to set
the weather forecast pattern according to the current weather..
Press the “ ”button to confirm your setting and to end the
setting procedures, the display will return to the normal mode.
Please note:
If there is no valid operation within 20 seconds, the station will
automatically return to normal time mode from the set mode.
Setting the alarm:
Press “ ” button once, LCD displays the “ ” icon, the alarm
function is ON. Then press “ ” button once, the “ ” icon will
disappears from the display, the alarm function is OFF.
Press once “ ” button, LCD display alarm time, then press and
hold “ ” button for 3 seconds until the hour of alarm time starts
to flash. Use the “+” and “-” buttons to set the hour.
Press “ ”button to confirm your setting. The minute of the alarm
time starts to flash. Use the “+” and “-” buttons to set the minute.
Press “ ”button to confirm your setting. The snooze time starts
to flash. Use the “+” and “-”buttons to set the snooze time. The
snooze time can be set from OFF to 60 minutes.
Press “ ”button to confirm your setting and to end the setting
procedure.

WS9132 Manual
Please note:
If there is no valid operation within 20 seconds, the station will
automatically return to normal time mode from the alarm time set
mode.
The alarm will sound for 2 minutes if you do not deactivate it by
pressing any button. In this case the alarm will be repeated
automatically after 24 hours.
Rising alarm sound (crescendo, duration: 2 minutes) changes the
volume 4 times whilst the alarm signal is heard.
Switching off the alarm signal
Press any button except the “SNOOZE/LIGHT” button to stop the
alarm signal. It is not necessary to reactivate the alarm. It switches
itself automatically to the alarm time which has already been set.
Snooze function
When the alarm is ringing, press the “SNZ” button the alarm mode
to get to snooze mode. The alarm signal sounds again after already
been set. If OFF was selected in the SNOOZE time setting, the
alarm will not repeat.
RF Transmission Procedure:
The weather station automatically starts receiving transmission
from outdoor thermo sensor after batteries inserted.
The remote sensor will automatically transmit temperature signal to
the Weather Station after batteries inserted.

WS9132 Manual
If the Weather Station failed to receive transmission from outdoor
sensor (“- -.-”display on the LCD), press and hold the “CH”button
for 3 seconds to receive transmission manually. RF icon “ ”
flashes on the LCDof the Weather Station to receive the remote
sensor.
If the weather station is used with 2 or 3 transmitters, press “+/CH”
button shortly to display CH2, CH3 or cyclic display.
P re ss "+ /C H "
P re ss "+ /C H " P re ss "+ /C H " P re ss "+ /C H "
A u to m a tic A u to m a tic
A u to m a tic
5S 5S
Maximum/minimum temperature/humidity
Press “MEM” button once, the LCD will display maximum value of
temperature/ humidity. If the “MEM” button is pressed again the
minimum value is displayed.
While displaying MAX or MIN values, there is “MAX” or “MIN” on the
LCD.
Press and hold “MEM” button for 3 seconds. The
temperature/humidity maximum/minimum value will reset to the
current values
Please note:

WS9132 Manual
If the temperature reading is below ranges, the LL.L will be
displayed. If the temperature reading is above ranges, the HH.H will
be displayed.
Trend displaying
The current temperature/humidity/barometric pressure and the
temperature/humidity/barometric pressure trend are shown in the
LCD display.
After successfully connecting with the outdoor sensor, the weather
station can display the outdoor temperature and the indoor
temperature/humidity trend.
You may see the following displays:
The temperature/humidity/ barometric
pressure is rising.
The temperature/humidity/ barometric
pressure is steady.
The temperature/humidity/ barometric
pressure is falling.
Ice alert
The ice alert symbol appears and flashing next to the outdoor
temperature when the outdoor temperature at –1℃to + 2.9 ℃or
+30.2℉to + 37.2℉.
Weather forecasting function
The weather forecast is calculated from evaluation of fluctuations in
the barometric pressure and may deviate from the actual weather
conditions.

WS9132 Manual
The weather station displays the following weather symbols:
S u n n y
S lig h tly c lo u d y
C lo u d y
R a in y
S n o w
The weather symbols indicate the weather fluctuation over the next
eight hours and not the current weather.
Technical details
Supply voltage: 2.5~3.3V
Time zone: -12~12Hr
IN Temperature measuring range: -9.9~50℃/14.2~122℉
OUT Temperature measuring range: -25~50℃/-13~122℉
Temperature resolution: 0.1℃/℉
Temperature accuracy:
0℃～40℃: ±1℃
–25℃～-0℃, 40℃～50℃： ±2℃
Humidity measuring range：20-95%
Humidity resolution：1%
Humidity accuracy：
40-80%: ±5%
20~39%,81-95%: ±8%

WS9132 Manual
RF receiving distance：30meter (free field)
Air pressure measuring range: 850-1100hpa
Air pressure change accuracy: ±5hpa
