Technotherm VPS series User manual

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS / VPS H / VPS DSM / VPS plus / VPS RF Wall
Please read attentively and keep in a safe place!
Subject to alterations!
Id_no. 911 360 870
Issue 08/18
Types:
• VPS 1000
• VPS 1200
• VPS 1500
• VPS 2000
• VPS H 1000
• VPS H 1200
• VPS DSM 1000
• VPS DSM 1200
• VPS DSM 1500
• VPS DSM 2000
• VPS RF 1000
• VPS RF 1200
• VPS RF 1500
• VPS RF 2000
• VPS plus 1000
• VPS plus 1200
• VPS plus 1500
• VPS plus 2000

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
1. General informaon about our surface storage heaters
With our variety of electric surface storage heaters, you can nd the right soluon
for your needs in any spaal situaon. The TECHNOTHERM paral thermal-stor-
age heaters are available as addional or transional heang for all rooms in
the living area, with the excepon of the special cases stated in the safety in-
strucons. They are designed for connuous operaon. Prior to dispatch, all our
products undergo an extensive funcon, safety and quality test. We guarantee
a construcve design complying with all currently applicable internaonal, Eu-
ropean and German safety standards and rules. You can see this in the labelling
of our products with the well-known cercaon marks: “TÜV-GS”, “SLG-GS”,
“Keymark” and “CE”. Our heaters are evaluated in accordance with the interna-
onally applicable lEC-regulaons. The manufacture of our heaters is constantly
supervised by a state-accredited test centre.
This heater can be used by children aged from 8 years and above and by phys-
ically, sensory or mentally restricted persons if they are supervised or given in-
strucons on safe use and understand the hazards involved as it does not require
any experience or knowledge. This device is not a toy for children to play with!
Cleaning and user maintenance shall not be carried out by children without su-
pervision. The use of heat radiators is to be given a parcular duty of care by su-
pervisors. Children under the age of 3 are to be kept away unless they are conn-
ually supervised. Children between the age of 3 and 8 are only allowed to switch
the heater on or o if they are supervised or given instrucons on safe use and
understand the hazards involved, provided that it has been placed or installed in
its intended normal operang posion. Children between the age of 3 and 8 shall
not plug in, regulate and clean the heater or perform user maintenance.
Cauon: Some parts of the product can become very hot and cause burns. Pay
parcular aenon when children and vulnerable people are present
Warning! this device has to be grounded
This device may only be operated using alternang current and the operang voltage indicated on
the power rang plate
• Nominal Voltage 230V AC, 50 Hz
• Protecon Class I
• Degree of Protecon IP 24
• Room Thermostat 7°C ll 30°C

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
2.1 User Manuel VPS RF Model
2.1.1 Seng the Room Thermostat
Press the receiver buon for more than 3 seconds, unl the indicator light begins to ash. Subsequent-
ly press the transmier key in the conguraon mode. (see User Manual Receiver) As soon as the indi-
cator light stops ashing the two products are assigned.
2.1.2 Seng the sender
Press the receiver buon for at least 3 seconds unl the indicator light starts ashing.
Two modes of operaon are possible.
Slow ashing: On\O switch
Fast ashing: insgator
To switch the mode again, press the key briey. Take the transmier into the Conguraon mode (see
user manual transmier). Check that the indicator light is no longer ashing.
Applicaon Example
The use of a room thermostat in combinaon with a opening detector is ideal, because the opening de-
tector will detect if a window is open and will automacally switch to frost protecon. By pressing the
receiver buon for approximately 10 seconds, you can change the relay´s seng. You know the seng
is changed as soon as the signal light stops ashing.
2.1.3 Deleng Allocaons
To delete the seng simply press the receiver key for approximately 30 seconds unl you see the recei-
ver light ash briey. All transmiers are now deleted.
2.1.4 Receiver RF- Technical Specicaons
• Power Supply 230 V, 50 Hz +/-10%
• Protecon Class II
• Expenditure : 0,5 VA
• Switching capacity max.: 16 A 230 Ve Cos j =1 or max. 300 W with lighng control
• Radio Frequency 868 MHz (NormEN 300 220),
• Radio Range up to 300 m in an open eld, indoors up to ca. 30m, depending on the construcon of
the building and the electromagnec interference
• Maximal Number of receivers: 8
• Mode of operaon: type 1.C (Micro-disconnecon)
• Operang Temperature: -5°C to +50°C
• Storage Temperature: -10 °C +70°C
• Dimensions: 120 x 54 x 25 mm
• Degree of Protecon : IP 44 - IK 04
• To be installed in average polluted Areas4. Installaon DSM Thermoastat / DAS Schnistelle.

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
WARNING
Do not install this device in areas that present an explosion hazard like a garage. Remove all
protecve coverage before turning on the device. When using the device for the rst me you
might detect a strong odor. This is no reason for concern; it is caused by residues of producon
and will disappear shortly.
The rising heat may cause stains on the ceiling, however this phenomena can be caused by any other
heang device as well. Only a qualied electrician may open or remove the device from the power
supply.
3. User Manuel for the VPS DSM
Please see addional manual at www.lucht-lhz.de/lhz-app-gb.html and download the manual
4. Maintenance
Before cleaning the device be sure to turn it o. To clean use a damp towel and a mild detergent.

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
5. Details for operaon of Types VPS plus /VPS H plus/VPS TDI
Digital control display
TDI – “ plus ” Thermostat
Mounting
Mounted on the side of the radiator using
screws.
Connection
Connection on the radiator’s power card.
Adjustment
buttons
part to connect to
the power card
réf : 7709936
On / Off
/
mode
Configuration
Menu 3: Backlight time out setting
The time out can be adjusted between 0
and 225 seconds, in steps of 15 seconds
(set on 90 seconds by default).
To modify, press on the + or - buttons then
press OK to confirm and go to the next setting.
When in Off mode,
press and hold down the On/Off button
for 10 seconds to access the first configuration
menu.
>10 sec.
Menu 4: AUTO mode temperature display option
Menu 1:ECO set-point adjustment
By default, Economy setting = Comfort setting - 3.5°C.
0 = Continuous display of room temperature.
1 = Continuous display of set-point temperature.
To modify, press on the + or - buttons then
press OK to confirm and go to the next setting.
This reduction can be set between
0 to -10°C, in steps of 0.5°C.
Menu number
To adjust the reduction, press on
the + or -
buttons then press OK to confirm
and go to the next setting.
Menu 5: Product number
This menu allows you to view the product
number.
To allow the user to modify the set-point, press
on the + button in Economy mode until “----” is
displayed on the screen.
To exit the configuration mode, press OK.
Menu 2: Correction of the measured temperature
If there is a difference between the temperature noted
(thermometer) and the temperature measured and displayed by
the unit, menu 2 acts on the measurement of the probe so as to
compensate for this difference (from -5°C to +5°C in steps of
0.1°C).
To modify, press on the + or - buttons then press
OK to confirm and go to the next setting.

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
Time Setting
Use
Continuous Frost Protection
Day
In Off mode, press the
The days flash.
mode button.
Hours
Pressing and holding the + or - buttons lets you
change the current set-point (+5 to +15°C) in
steps of 0.5°C.
Press + or - to set the day, then press OK
to confirm and go on to set the hour and then
the minutes.
Minutes
Press
the mode button once to access the pro-
gramming,
and press the On/Off button once to exit the
s
etting mode.
AUTOMATIC mode
In this mode the device follows the programming
set.
To modify the programming, press the PROG
button once.
Programming
When starting up, the “Comfort mode from 8am
to 10pm” program is applied to all the days of
the week.
Timer mode
To set a set-point temperature for a certain
To change the programming, press the PROG
button in Off or AUTO mode.
The 1
st
time slot flashes on and off.
period of time, press on the
button once.
To set the temperature you want (+5°C to
+30°C), use the + and - buttons, then press OK
to confirm and go on to set the duration.
To set the duration you want (30 min
to 72 hours, in steps of 30 min), use
Day
the + and – buttons (e.g. 1 hr 30 min), then press OK.
To cancel the timer mode, press on the OK button.
Program
profile
Confirm
and go to
the next day
Frost protection
mode for 1 hour
1
st
time
slot
Comfort
mode for 1 hour
Absence mode
You can set your device to Frost protection
mode for a period between 1 and 365 days,
Economy
mode for 1 hour
by pressing on the
button.
Quick programming:
To
apply the same program to the following day,
press and hold
the OK button
for
approximately 3 seconds until the program of
the following
day is displayed.
To exit the programming mode, press on the On/Off button.
To set the number of days of absence,
press on the + or – buttons, then confirm by
pressing OK.
To cancel this mode, press on the OK button
again.
Use
The Mode button allows you to select the different operating
Locking the keypad
If you press and hold the central buttons
simultaneously during 5 seconds, it enables
you to lock the keypad. A key symbol appears
briefly on the display.
To unlock the keypad, press simultaneously on
the central buttons.
modes:
Comfort,
Economy,
Frost protection,
programming AUTO mode.
Pressing the
i button gives you the temperature of the room
or the set
-
point temperature, according to your configuration
settings in menu 5.
If the
ON icon is displayed, this means that the device is in
heating demand mode.
Once the keypad is locked, the key symbol
appears briefly if you press on a button.
Continuous Comfort
Pressing and holding the + or
-
buttons lets you
change the current set
-point (+5 to +30°C) in
steps of 0.5°C.
Continuous Economy mode
The Economy set
-point is indexed according to
the Comfort set
-point. The reduction can be
modified
in the configuration settings for menu 1.
Modifying the
Economy set-point
The
set-point can be modified if it
was authorized
in the
configuration settings in menu 1 (“----”).
Pressing and holding the + or
- buttons lets you
change the current set
-point (+5 to +30°C) in
steps of 0.5°C.
Menu 5: Open Window detection
The detection of an open window occurs
when the room temperature falls rapidly.
In this case, the display shows a flashing
pictogram, as well as the frost
protection set-point temperature.
0 = Open window detection is deactivated
1 = Open window detection is activated
To modify, press on the + or – buttons,
then press OK to confirm and to go to the
next setting.
Please note: an open window cannot be
detected in OFF-Mode.
This feature can be temporarily interrupted
by pressing on .

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
Technical characteristics
•
Power supplied by the power card
•
Dimensions in mm (without mounting lugs):
H = 71.7, W = 53, D= 14.4
•
Screw-mounted
•
Install in an environment with normal pollution levels
•
Storage temperature: -10°C to +70°C
•
Operating temperature: 0°C to +40°C
Menu 6: Adaptive start control
This feature enables to reach the set-point
temperature at a set time.
When this feature is activated, the display shows a
flashing .
0 = Adaptive start control deactivated
1 = Adaptive start control activated
To modify, press on the + or – buttons, then press
OK to confirm and to go to the next setting.
Adjusting the time-temperature-slope (when
adaptive start control is activated)
From 1°C to 6°C, in steps of 0.5°C.
If the set-point temperature is reached too early,
then a lower value should be set.
If the set-point temperature is reached too late,
then a higher value should be set.
Menu 7: Productnumber
This menu allows you to view the product
number.
To exit the configuration mode, press OK.

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
6.1 Assembly instrucon
This Manual is very important and has to be kept at a safe place at all mes. Be sure to hand this ma-
nual to any other succeeding owner of the device. The device comes with a power plug that has to be
plugged into an outlet.
The device is designed to be connected to 230V (nominal) alternang current (AC).
7.1 Wall Installaon
When installing the device, the safety distance must be strictly adhered to, so that ammable materials
can not ignite. Install the device to a wall which is heat resistant up to 90 ° C.
• Due to possible re hazard the safety distances are observed during assembly:
Side walls of the heater to any masonry: 5 cm
Side walls of the heater to combusble materials: 10 cm
Distance radiator to the oor: 25 cm
arranged spaced upper radiator limit to about components or covers (. Eg window):
ammable 15 cm
nonammable 10 cm
To prevent inammable materials from catching re be sure to keep the prescribed safety distance
when installing the device. Mount the device to a wall that is reproof up to 90 °C.
The safety distance to the oor should be 25 cm, and at least 10 cm to all other devices. Furthermore
there has to be safety distance of approximately 50 cm between the venlaon grille, windowsills, roof
slopes and ceilings.
If you want to install the device in your bathroom, be sure to keep it out of reach for people taking a
shower or a bath.
When mounng the device to the wall, be sure to keep to the dimensions as indicated in the illustraon
on page 11. Drill two or three (if available) 7 mm holes and aach the corresponding plug. Then screw
the 4 x 25 mm screws into the holes, leaving a distance of 1-2mm between the head of the screw and
the wall.
Hang the device in the two or three ngs and ghten it down. See also the addional mounng infor-
maon at the following pages!

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
8.2 Wall Mounng
Type Power
[Wa]
With
A
High
B
Deep
C
[mm]
D
[mm]
E
[mm]
F
[mm]
G
[mm]
H
[mm]
I
Weight
[kg]
VPS
1000
1000 750 450 85 442 140 375 250 115 375 11,5
VPS
1200
1200 750 450 85 442 140 375 250 115 375 11,5
VPS
1500
1500 1050 450 85 740 140 375 250 115 525 15,0
VPS
2000
2000 1050 450 85 740 140 375 250 115 525 15,0

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
9. Installaon of Electricity
The device was developed for an electrical voltage of 230 V(nominal) and an alternang current of (AC)
50 Hz. The electrical installaon may only be performed according to the user manual and only by a
qualied Electrician. The device was designed to be used with terminaon and the connecon cable
has to be plugged into an appropriate socket at all mes. (Noce Permanent cables may not be used)
The distance between the receptacle and the device hast to be at least 10cm. The connecon line may
not touch the device at any me.
10. Regulaon
From 01.01.2018, the EU conformity of these devices is addionally linked to the fulllment of the
Ecodesign requirements 2015/1188.
The installaon and commissioning of the devices is only permied in conjuncon with external room
temperature controllers that fulll the following funcons:
• electronic room temperature control
and has at least one of the following properes:
• room temperature control, with presence detecon
• room temperature control, with open window detecon
• with distance control opon
• with adapve start control
The following room temperature controller systems
• RF Receiver together with the TPF-Eco Thermostat (Art.Nr.: 750 000 641) and the Eco-Interface
(Art.Nr.750 000 640) or
• DSM-Thermostat with the DSM-Interface (Art.No.:911 950 101)
• TDI- Thermostat / plus-Thermostat
from Technotherm meet the following requirements and therefore the ErP Direcve:
• electronic room temperature control plus week mer (RF/DSM/TDI)
• room temperature control, with open window detecon (DSM/plus/TDI)
• with distance control opon (DSM/RF)
• with adapve start control (DSM/plus/TDI)
Use of the VPS / VP Standard range (without external/internal thermostat control) is only permit-
ted on feet.
Installaon of the receiver and the interfaces see separate instrucons. For customer service - see last
page.
Failure to comply with these requirements will result in the loss of the CE mark.

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
9. Addional wall mounng informaon
1. Drill three holes of 7mm and x the wall bracket. Screw in the three 4 x 25 mm screws into the wall
2. Click the heater rst at the top into the wall bracket and then at the boom. The heater will be xed
“automacally”.
Topside of heater
Wallmount:
xing with 3 screw!
mount locked!
Underside detailview
Press a screwdriver
into the groove to
unlock the mount.
mount is unlocked
Switch of the Heater from the
Wallmounng
1. Press the screwdriver into
the groove.
2. Remove the Heater from the
Wall
Wall

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
11.Informaon requirements for electrical local space heaters
Type: VPS RF (addional TPF Thermostat and Eco-Interface oonally necessary) / VPS plus RF plus
Item Symbol Value Value Item Value
Heat output Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output Pnom 1000 1200 1500 2000 Wa manual heat charge control, with integrated thermostat NO NO
Minimum heat
output (indicave) Pmin 1000 1200 1500 2000 Wa manual heat charge control with room and/or outdoor tempera-
ture feedback
NO NO
Maximum con-
nuous heat output Pmax,c 1000 1200 1500 2000 Wa electronic heat charge control with room and/or outdoor
temperature feedback
NO NO
Auxiliary electricity
consumpon
fan assisted heat output NO NO
At nominal heat
output elmax 1000 1200 1500 2000 Wa Type of heat output/room temperature control (select
one)
At minimum heat
output elmin 2.0 2.0 2.0 2.0 Wa single stage heat output and no room temperature control NO NO
In standby mode elSB <0,5 <0,5 <0,5 <0,5 Wa Two or more manual stages, no room temperature control NO NO
with mechanic thermostat room temperature control NO NO
with electronic room temperature control NO NO
electronic room temperature control plus day mer NO NO
electronic room temperature control plus week mer YES YES
Other control opons (mulple selecons possible)
room temperature control, with presence detecon NO NO
room temperature control, with open window detecon NO YES
with distance control opon YES YES
with adapve start control NO YES
with working me limitaon NO NO
with black bulb sensor NO NO

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
Type: VPS
Item Symbol Value Value Item Value
Heat output Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output Pnom 1000 1200 1500 2000 Wa manual heat charge control, with integrated thermostat NO
Minimum heat
output (indicave) Pmin 1000 1200 1500 2000 Wa manual heat charge control with room and/or outdoor tempera-
ture feedback
NO
Maximum con-
nuous heat output Pmax,c 1000 1200 1500 2000 Wa electronic heat charge control with room and/or outdoor
temperature feedback
NO
Auxiliary electricity
consumpon
fan assisted heat output NO
At nominal heat
output elmax 1000 1200 1500 2000 Wa Type of heat output/room temperature control (select
one)
At minimum heat
output elmin <0,5 <0,5 <0,5 <0,5 Wa single stage heat output and no room temperature control NO
In standby mode elSB <0,5 <0,5 <0,5 <0,5 Wa Two or more manual stages, no room temperature control NO
with mechanic thermostat room temperature control NO
with electronic room temperature control YES
electronic room temperature control plus day mer NO
electronic room temperature control plus week mer NO
Other control opons (mulple selecons possible)
room temperature control, with presence detecon NO
room temperature control, with open window detecon NO
with distance control opon NO
with adapve start control NO
with working me limitaon NO
with black bulb sensor NO
Type: VPS DSM (addional DSM interface oponally necessary)
Item Symbol Value Value Item Value
Heat output Type of heat input, for electric storage local space heaters only (select one)
Nominal heat
output Pnom 1000 1200 1500 2000 Wa manual heat charge control, with integrated thermostat NO
Minimum heat
output (indicave) Pmin 1000 1200 1500 2000 Wa manual heat charge control with room and/or outdoor tempera-
ture feedback
NO
Maximum con-
nuous heat output Pmax,c 1000 1200 1500 2000 Wa electronic heat charge control with room and/or outdoor
temperature feedback
NO
Auxiliary electricity
consumpon
fan assisted heat output NO
At nominal heat
output elmax 1000 1200 1500 2000 Wa Type of heat output/room temperature control (select
one)
At minimum heat
output elmin 0,8 0,8 0,8 0,8 Wa single stage heat output and no room temperature control NO
In standby mode elSB 0,8 0,8 0,8 0,8 Wa Two or more manual stages, no room temperature control NO
with mechanic thermostat room temperature control NO
with electronic room temperature control NO
electronic room temperature control plus day mer NO
electronic room temperature control plus week mer YES
Other control opons (mulple selecons possible)
room temperature control, with presence detecon NO
room temperature control, with open window detecon YES
with distance control opon YES
with adapve start control YES
with working me limitaon NO
with black bulb sensor NO

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB

Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB

Feel good through warmth from electricity - www.technotherm.de
Installaon and Operang Instrucons
VPS devices
Feel good through warmth from electricity - www.technotherm.de
GB
Technotherm is a label from Lucht LHZ GmbH & Co. KG
Reinhard Schmidt-Str. 1 | 09217 Burgstädt, Germany
Phone: [phone]
Telefax: [phone]
[e-mail] | www.technotherm.de
Technical alternaons, errors, omissions and errata reserved. Dimensionsare stated without warranty!
Updated: august 18
TECHNOTHERM Aer-sales service:
Ph. [phone]
